Manual
Dust Analyser DustMon RD 100
Translation

2
Copyright
© Copyright by
Retsch GmbH
Retsch-Allee 1-5
42781 Haan
Germany

3
Table of Contents
1Notes on the manual............................................................................................................................. 6
1.1 Disclaimer.......................................................................................................................................... 6
1.2 Copyright............................................................................................................................................ 6
1.3 Explanation of signs and symbols ..................................................................................................... 6
1.4 Explanations of the Safety Instructions ............................................................................................. 7
2Safety...................................................................................................................................................... 8
2.1 Intended use of the device................................................................................................................. 8
2.2 Improper use...................................................................................................................................... 8
2.3 Obligations of the operating company............................................................................................... 9
2.3.1 Provisions ...................................................................................................................................... 9
2.3.2 Personnel....................................................................................................................................... 9
2.3.3 Workstation and device ................................................................................................................. 9
2.3.4 Qualification of personnel .............................................................................................................. 9
2.3.5 Personal protective equipment (PPE) ......................................................................................... 10
2.4 Repairs............................................................................................................................................. 10
2.5 Preventing risks during normal operation........................................................................................ 10
2.6 Preventing damage to equipment.................................................................................................... 11
2.7 Confirmation Form for the Managing Operator................................................................................ 11
3The DustMon RD 100........................................................................................................................... 13
3.1 Technical data ................................................................................................................................. 14
3.2 Views of the device.......................................................................................................................... 15
3.3 Signs on the device ......................................................................................................................... 17
3.4 Type Plate Description..................................................................................................................... 17
4Packaging, Transport and Installation .............................................................................................. 19
4.1 Accessories included with delivery.................................................................................................. 19
4.2 Packaging........................................................................................................................................ 19
4.3 Transport.......................................................................................................................................... 20
4.4 Temperature Fluctuations and Condensation ................................................................................. 20
4.5 Conditions for the Installation Site................................................................................................... 21
4.6 Electrical Connection....................................................................................................................... 22
5First Commissioning........................................................................................................................... 23
5.1 Instrument Assembly ....................................................................................................................... 23
5.1.1 Sample Collection Box................................................................................................................. 23
5.1.2 Lab Valve..................................................................................................................................... 24
5.2 Connecting the device to the power supply..................................................................................... 24
6Operating the Device .......................................................................................................................... 25
6.1 Switching the device on/off.............................................................................................................. 25
7DustMon RD 100 –Measurement using the internal control unit .................................................. 26
7.1 Measurement Considerations.......................................................................................................... 26
7.2 DustMon RD 100 display during the measurement......................................................................... 28
8DustMon RD 100 using PC control unit / software installation ...................................................... 30
8.1 Description of the program interface ............................................................................................... 31
8.2 System settings before the first measurement................................................................................ 31
8.3 Starting the measurement using the DustMon RD 100 software .................................................... 34
8.4 Results and information about the sample...................................................................................... 35
8.5 Loading the results .......................................................................................................................... 36
8.6 Superimposing measurement results.............................................................................................. 37
8.7 Changing the graphics display ........................................................................................................ 38
8.8 Calculating results as an average ................................................................................................... 39
8.9 DustMon RD 100 - Transfer of results to Excel (txt file).................................................................. 40
9Troubleshooting .................................................................................................................................. 42

4
9.1 "Error clean" message on the on-board display .............................................................................. 42
9.2 White light source OFF –device is not functional ........................................................................... 42
10 Cleaning and maintenance................................................................................................................. 43
11 Checking the white light source ........................................................................................................ 44
12 Calibration............................................................................................................................................ 46
12.1 Setup Kalibration ............................................................................................................................. 46
12.2 Disable calibration function for Standalone mode........................................................................... 47
12.3 Calibration using reference glass (filter lens) in standalone mode.................................................. 48
12.4 Calibration against Reference Sample(s) using standalone mode ................................................. 48
12.5 User defined calibration value ......................................................................................................... 50
13 Repairs ................................................................................................................................................. 51
13.1 Returning for repair and maintenance............................................................................................. 51
14 Accessories ......................................................................................................................................... 52
15 Disposal................................................................................................................................................ 53
16 Index ..................................................................................................................................................... 55

Notes on the manual
5

Notes on the manual
6
1 Notes on the manual
This manual provides technical guidelines for the safe operation of the device. Read this
manual through carefully before installing, putting into service and operating the device.
Reading and understanding this manual is essential for handling the device safely and as
intended.
This manual does not contain any repair instructions. Please contact your supplier or contact
Retsch GmbH directly if anything is unclear or you have questions about these guidelines or the
device, or in the case of any faults or necessary repairs.
You can find further information about your device at https://www.retsch.com on the pages for
the specific device concerned.
Amendment status:
The document amendment 0001 of the "Dust Analyser DustMon RD 100" manual has been
prepared in accordance with the Machinery Directive 2006/42/EC.
1.1 Disclaimer
This manual has been prepared with great care. We reserve the right to make technical
changes. We assume no liability for personal injuries resulting from the failure to follow the
safety information and warnings in this manual. No liability will be assumed for damage to
property resulting from the failure to follow the information in this manual.
1.2 Copyright
This document or parts of it or its content may not be reproduced, distributed, edited or copied
in any form without prior written permission of Retsch GmbH. Damage claims shall be asserted
in the case of infringements.
1.3 Explanation of signs and symbols
The following signs and symbols are used in this manual:
Signs and symbols
Meaning

Indicates a recommendation and/or important information.
Bold type
Indicates an important term.
•< Point 1>
•< Point 2>
•< Point 3>
List of equivalent points.

Steps for following an instruction.

Notes on the manual
7
1.4 Explanations of the Safety Instructions
DANGER
D1.0000
Risk of fatal injuries
Source of danger
−Possible consequences if the danger is ignored.
•Instructions and information on how to avoid the risk.
Fatal or serious injuries may result if the “Danger” sign is disregarded. There is a very high
risk of a life-threatening accident or lasting personal injury. The signal word DANGER is
additionally used in the running text or in instructions.
WARNING
W1.0000
Risk of life-threatening or serious injuries
Source of danger
−Possible consequences if the danger is ignored.
•Instructions and information on how to avoid the risk.
Life-threatening or serious injuries may result if the “Warning” sign is disregarded. There is
an increased risk of a serious accident or of a possibly fatal personal injury. The signal word
WARNING is additionally used in the running text or in instructions.
CAUTION
C1.0000
Risk of injuries
Source of danger
−Possible consequences if the danger is ignored.
•Instructions and information on how to avoid the risk.
Average to slight injuries may result if the “Caution” sign is disregarded. There is an average
or slight risk of an accident or personal injury. The signal word CAUTION is additionally
used in the running text or in instructions.
NOTICE
N1.0000
Type of damage to property
Source of the damage to property
−Possible consequences if the information is ignored.
•Instructions and information on how to avoid the damage to
property.
Damage to property may result if the information is disregarded. The signal word NOTICE is
additionally used in the running text or in instructions.

Safety
8
2 Safety
CAUTION
C2.0002
Risk of injury
Lack of knowledge of the manual
−The manual contains all safety-related information. Disregarding the
manual can therefore lead to injuries.
•Read the manual carefully before operating the device.
Target group:
The DustMon RD 100 has been designed for preparing samples in a laboratory environment.
laboratory environment. This manual is therefore directed at persons who work with this device
in a comparable environment and who already have experience with similar equipment.
The DustMon RD 100 is a modern, efficient, state-of-the-art product from Retsch GmbH. Its
reliability is ensured when used as intended and with knowledge of this technical
documentation.
2.1 Intended use of the device
As a laboratory device, the DustMon RD 100 may only be used for sample preparation and not
as a production machine.
The device has been designed for stationary operation in a dry and clean working environment.
Operating company and operating staff must have read the Manual and be familiar with the full
range of functions of the device.
2.2 Improper use
The DustMon RD 100 may only be used as intended.
Any uses other than the described intended use are regarded as improper use.
The DustMon RD 100 is not suitable for processing sample materials that can form explosive
air mixtures.
Any form of claims for damage to equipment or personal injury resulting from improper use
and/or the failure to comply with the safety instructions shall be ruled out.

Safety
9
2.3 Obligations of the operating company
2.3.1 Provisions
The user bears responsibility for ensuring that people working with the device and the
corresponding equipment have taken note of and understood all relevant safety regulations.
2.3.2 Personnel
•Ensure that only trained personnel are deployed whose training and experience enable
them to recognise risks and avoid potential hazards.
•Staff should be given regular training on using the device, and in particular regarding
sudden events.
•Only allow trainee staff to work on the device when they are being supervised by
qualified personnel.
•Check the safety awareness of staff regularly.
•Define staff responsibilities according to qualification and job description.
•Provide staff with personal protective equipment (PPE).
•Ensure that the following conditions have been met:
–Staff have read and understood this Manual, and in particular the chapter on
Safety.
–Staff are aware and take note of the relevant accident prevention and safety
regulations.
–Staff wear the designated personal protective equipment (PPE) when working with
the device.
2.3.3 Workstation and device
•Ensure that there is sufficient lighting and ventilation at the workstation.
•Ensure that the exhaust air is properly conducted outside.
•All signs on the device must be kept in a legible condition.
•Ensure that all inspections and servicing work prescribed in this Manual are carried out.
2.3.4 Qualification of personnel
Work/operating phase
Qualification
Transport
Installation
Commissioning
Operation
Controlling
Servicing
Disposal
Qualified employee who has been trained in
the safe use of the device.
Work on the electrical equipment on the
device
Electrician who, on the basis of his/her
training, knowledge and experience is able

Safety
10
to evaluate the work assigned and
recognise potential hazards.
2.3.5 Personal protective equipment (PPE)
Work/operating phase
Personal protective equipment (PPE)
Transport
Installation
Safety footwear
Commissioning
Installation of additional equipment
Servicing
No PPE needed.
Disposal
Safety footwear
Normal operation (operation and control)
No PPE needed.
2.4 Repairs
This manual does not contain any repair instructions. For safety reasons, repairs may only be
carried out by Retsch GmbH or an authorised representative or by qualified service technicians.
In case of repair, please inform…
…the Retsch GmbH representative in your country,
…your supplier, or
…Retsch GmbH directly.
Service address:
2.5 Preventing risks during normal operation
The failure to comply with the following safety instructions constitutes improper use and
presents a risk to personnel and to operational safety.
Transport and installation
•Wear safety footwear for transport and installation.
•Only connect the device to sockets with a PE protective conductor.
•When connecting the device, the values on the type plate must correspond to those for the
power connection.
Operation
•Read the manual before commissioning the device.

Safety
11
•Only operate the device at a workstation of sufficient size that offers adequate stability.
•Check the mains lead for damage before operating the device.
•Never operate the device if damage is visible or suspected.
•Only operate the device according to the technical application limits.
•Before operating the device, take measures that take account of restricted communication
during operation of the device.
•Do not operate the device in potentially explosive atmospheres.
•Take note of the safety data sheets for the samples and follow instructions by taking
appropriate measures in advance.
•Do not use explosive and/or flammable substances.
Servicing and repair
•Before servicing, switch the device off at the main switch.
•Only clean the device with a dry or damp cloth.
•Do not clean the device with compressed air.
•Have all repairs carried out by the device manufacturer or by an authorised agent.
2.6 Preventing damage to equipment
•Protect the device against condensation if large fluctuations in temperature are to be
expected (e.g. during air transport.
•Do not knock, shake or throw the device during transport and installation.
•Comply with conditions at the installation site when installing the device.
•Only clean the device with a dry or damp cloth.
•Do not use any solvent or aggressive detergent for cleaning.
•Only use original spare parts for maintenance work.
2.7 Confirmation Form for the Managing Operator
This manual contains essential instructions for operating and maintaining the device which must
be strictly observed. It is essential that they be read by the user and by the qualified staff
responsible for the device before the device is commissioned. This manual must be available
and accessible at the place of use at all times.
The user of the device herewith confirms to the managing operator (owner) that he has received
sufficient instructions about the operation and maintenance of the system. The user has
received the manual, has read and taken note of its contents and consequently has all the
information required for safe operation and is sufficiently familiar with the device.

Safety
12
The managing operator should for legal protection have the user confirm the instruction about
the operation of the device.
I have read and taken note of the contents of all chapters in this manual as well as all
safety instructions and warnings.
User
Surname, first name (block letters)
Position in the company
Place, date and signature
Managing operator or service technician
Surname, first name (block letters)
Position in the company
Place, date and signature

The DustMon RD 100
13
3 The DustMon RD 100
The DustMon RD 100 from Retsch GmbH is a laboratory device used for dust measurement.
DustMon RD 100 is an independent measuring system to determine the dust content in
powders and granulates. DustMon RD 100 is a newly-designed measuring system based on
the principle of light attenuation. The robust design and simple operation guarantee fast,
reliable results under even the toughest conditions.
The DustMon RD 100 is offered with a white light source (LED).
The DustMon RD 100 can be used as a stand-alone measuring system or without PC and
DustMon software. The measurement can be started using the integrated display, and this
display also shows the results at the end of the measurement. When connected to a PC, the
results can be saved and printed out.
The DustMon RD 100 comprises the following components:
•Sample holder
•Tube
•Sample collection receptacle
•Light source
•Detector
The sample is placed in the sample container, the flap opens immediately (or with a delay
depending on the setting defined by the user), then the measurement begins. The dust present
in the product rises and gets between the light source and detector, thereby causing light
attenuation. The light attenuation is directly related to the dust concentration in the sample to
be measured.
The DustMon software produces a measurement based on a dust index scale, where the dust
index value is determined as follows:
Maximum value measured
Value measured after 30 seconds
Dust index = maximum value measured + value measured after 30 seconds

The DustMon RD 100
14
Fig. 1: The DustMon RD 100
3.1 Technical data
General information
Area of application
Agriculture, biology, chemistry / plastics,
building materials, engineering / electronics,
environment / recycling, food, geology /
metallurgy, glass / ceramics, medicine /
pharmaceuticals / detergents / fertilisers /
powdered foods / grain processing and
storage
Specifications
Mains connection
100 –240 VAC 50/60 Hz (external 12 V (DC)
power supply unit)
Protection rating
IP 20
Electromagnetic compatibility (EMC)
EMC class in acc. with EN 50081-2:1992 or
EN 50082-2:1992
Light source
White 30.6 mW LED
Measurement principle
Light opacity
Measuring system
Photosensor –635 nm light voltage
transformer
Measurement parameters
Dust index, dust surface, maximum and final
value
Feed quantity
10 g –200 g, usually 30 g

The DustMon RD 100
15
Measurement time
30 seconds (adjustable up to 999 seconds)
Ambient temperature
5 –40 °C
W x H x D
320 x 900 x 220 mm
Height of device 340 mm, height of tube 560
mm
Weight, net
5 kg
Conformity
CE
3.2 Views of the device
Fig. 2: Front view of the DustMon RD 100
Components
Function
1
Sample container
For filling the sample
2
Sample flap with tube
Opens and allows the sample to fall into the
collecting box
3
Sample collection receptacle
Collects the sample and the rising dust is
measured
3

The DustMon RD 100
16
The connector panel is on the right-hand side of the DustMon RD 100:
Fig. 3: View of the connector panel
Components
1
On/Off switch
2
Mini-USB (PC connection)
3
Opening for cleaning with compressed air
4
Power supply unit connection (12 V / DC)
Fig. 4: View of detaching the tube
Components
Function
6
Button to detach the tube
Press to remove the tube (e.g. for cleaning)

The DustMon RD 100
17
3.3 Signs on the device
Notice
Meaning
Read the Manual
Safety notice:
The device manual must be
read before commissioning
and operating the device.
Electrical current warning
Caution –electric shock! The
housing may only be opened
by trained personnel. Pull
out the power plug prior to
servicing!
Type plate
Information:
Performance and connection
data for the device.
3.4 Type Plate Description
Fig. 5: Type plate
1 Device name
2 Year of manufacture
3 Article number
4 Serial number
5 Manufacturer’s address
6 CE mark
7 Disposal sign
8 Barcode
9 Voltage version
1
2
3
4
5
6
7
8
9
10
11
12
14
13

The DustMon RD 100
18
10 Supply frequency
11 Power
12 Current
13 Number of fuses
14 Fuse type and fuse rating

Please always specify the device name (1) or the article number (3) as well as the serial
number (4) for the device if you have any questions.

Packaging, Transport and Installation
19
4 Packaging, Transport and Installation
4.1 Accessories included with delivery
Fig. 6: Scope of delivery
Components
1
DustMon RD 100 housing and electronics
2
Sample collection receptacle
3
DustMon RD 100 tube
4
Power supply unit
5
White light inspection glass
6
USB cable to connect DustMon RD 100 to the PC
4.2 Packaging
The packaging has been adapted to the mode of transport. It complies with the generally
applicable packaging guidelines.

Packaging, Transport and Installation
20
NOTICE
N2.0001
Complaint or return
Keeping the packaging
−Inadequate packaging and insufficient securing of the device can
jeopardise the warranty claim in the event of a complaint or return.
•Keep the packaging for the duration of the warranty period.
4.3 Transport
CAUTION
C3.0000
Risk of injury caused by the device falling down
Incorrect transport of the device
−Due to its weight, the device can cause injuries if it falls down.
•Wear safety shoes during transport.
NOTICE
N3.0017
Damage to components
Transport
−Mechanical or electronic components may be damaged during transport.
The device must not be knocked, shaken or thrown during transport.
•Move the device gently during transport.
NOTICE
N4.0014
Complaints
Incomplete delivery or transport damage
−The forwarding agent and Retsch GmbH must be notified immediately in
the event of transport damage. It is otherwise possible that subsequent
complaints will not be recognised.
•Please check the delivery on receipt of the device for its
completeness and intactness.
•Notify your forwarding agent and Retsch GmbH within 24 hours.
4.4 Temperature Fluctuations and Condensation
NOTICE
N5.0016
Damaged components due to condensation
Temperature fluctuations
−The device may be exposed to substantial fluctuations in temperature
during transport. The ensuing condensation can damage electronic
components.
•Wait until the device has acclimatised before putting it into service.
Temporary storage:
Also in case of an interim storage the device must be stored dry and within the specified
ambient temperature range.
