Reveal PRO3 User manual

INSTRUCTION MANUAL
REVEALCELLCAM.COM
TACTACAM.COM
DEER MANAGEMENT SYSTEMS, LLC
INSTRUCTION MANUAL
PRO3

2
REVEAL APP DOWNLOAD
V I S I T Y O U R A P P S T ORE T O DOWNL O A D
DOWN L O A D T H E
TACTACAM REVEAL APP
TACTACAM.COM

3
TABLE OF CONTENTS
INTRODUCTION
What is in the Box?
What you will need
QUICK START GUIDE
Setting Up Your Account
Downloading the App
Add Camera to the App
Sending a Test Picture
Leaving Your Camera in the Field
SETTINGS & SPECIFICATIONS
BEST PRACTICES
Proper Camera Placement
Batteries and Cellular Trail Camera Performance
TROUBLESHOOTING
Camera Sends Pictures of Nothing
Night Vision Flash Range Doesn’t Meet Expectations
Camera Stops Taking Images or Won’t Take Images
WARRANTY
3
4
4
4
6
6
6
7
8
9
10
12
12
13
14
14
14
15
16
TABLE OF CONTENTS

4
• (1) Trail Camera
• (1) Instruction Manual
• (1) Mounting Strap
• (1) Antenna
• (1) Verizon & AT&TSIM Card
• Full-size SD Card - Class 10, U3,
• 16GB-32GB
• Recommended Brands: Tactacam,
Lexar, SanDisk
(Other brands of lower end SD cards are
incompatible with the Reveal X-Pro and will
yield unexpected results)
• 12 AA Batteries Required -
Lithium Batteries recommended
in colder temperatures
INTRODUCTION
WHAT IS IN THE BOX? WHAT YOU WILL NEED
RECOMMENDED CAMERA ACCESSORIES (NOT INCLUDED)
SD Card Solar Panel
T-Post MountLockable Security Box
VIEW AND PURCHASE ALL ACCESSORIES AT REVEALCELLCAM.COM
Adjustable Camera Stake
Reveal Pro 3.0 and will
TACTACAM.COM

5
1
5
2
6
10
14
3
7
11
15
4
8
12
9
13
INTRODUCTION
Lens
Antenna
Camera Working Status Indicator
Microphone
SIM Slot (do not mix SIM’s with other cameras)
Display
PIR Motion Sensor
IR LEDs
Navigation Arrows
SD Card Slot
Power/Enter
Battery Eject Button
External Battery In/DC Port
USB-C Port
Tripod/Mount Attachment
9
4 10
7
12
1
2 8
3
5 11
6
13 14
15

6
QUICK START GUIDE
In your Apple orGoogle Play Store, download the
Tactacam Reveal app and sign inusing the same
email and password you created on the website.
https://account.revealcellcam.com
DOWNLOADING THE APP
please visit the Reveal Web Portal at
https://account.revealcellcam.com/activation
to set up your account. You can also access the
Web Portal directly from your app, by clicking
My Reveal on the account page in the app.
If you already have a Reveal account with
ACTIVE cameras, you can simply log in to
your app and add your camera following the
instructions on page 8.
SETTING UP YOUR ACCOUNT
TACTACAM.COM

7
QUICK START GUIDE
ADD CAMERA TO THE APP
1. Navigate to your Reveal app and login
using your Revealaccount credentials.
Click the home icon.
2. Click the camera icon at the top.
3. From the camera page click the (+) in the
bottom right hand corner.
4. Select Reveal X-Pro and continue.
5. Follow the in-app prompts to activate
your Reveal. Ensure the SIM selected
(Verizon or AT&T) mirrors (or is the same
as) the SIM card already inserted in the
camera.
6. The app will prompt you to scan the QR
code located on the display screen.
1
2
3
4
6
Select the Reveal Pro3 and continue.

8
QUICK START GUIDE
From the camera page click the tool icon to make
changes to the cameras settings. Make sure to
select “Apply Settings” when done to save your
changes.
Note: In cameras SETTINGS > Settings Check,
Daily mode will check settings every 24 hours.
Hybrid mode combines the battery saving
will receive settings instantly but will consume
more battery.
X-Pro allows you to fully control your camera settings directly on-screen. Use the
keypad to navigate (left, right, up, down, enter) to adjust camera settings. For best
results, we recommend leaving the camera settings in the factory programmed
SMS CONTROLS/ON-SCREEN SETTINGS
1. Allow the camera to connect to 4G signal.
Your signal strength will be displayed on
the screen.
SENDING A TEST PICTURE
REMOTELY CHANGE THE CAMERA SETTINGS FROM THE APP.
• After your camera is activated, you will see
the signal status indicator searching, and
then connect showing the signal strength.
• After the camera has connected, push the
power/enter button to send a photograph.
Pro 3.0 allows you to fully control your camera settings directly on-screen. Use the
TACTACAM.COM

9
1. Using the display screen on the Reveal, position the camera to your
desired focal point.
2. Ensure the antenna is securely tightened.
3. Wipe down the seal, removing any dirt or debris.
4. Hit the left navigation arrow to enter work mode (work mode means
the camera is on and will function correctly). From there, your camera
will begin sending you photos.
5. As long as your phone picks up a signal, be sure a motion detected
picture is sent to your phone via the app. This may take a few minutes.
LEAVING YOUR CAMERA IN THE FIELD
START USING THE REVEAL X-PRO
SENDING A TEST PICTURE (CONTINUED)
• When your test picture has been sent successfully, a message is
displayed on the screen notifying you.
• If your test picture does not send, a send failure message will display
on the screen.
2. As long as your phone picks up a signal, be sure a motion detected
picture is sent to your phone via the app. This may take a few
minutes.
START USING THE REVEAL PRO3

10
SETTINGS / SPECIFICATIONS
Camera Mode Photo; Photo+Video
Day/Night Mode Daytime: Color, Nighttime: B+W
IR Range 80+ Feet
PIR Angle 45*
Flash No Glow IR Technology effectively eliminates all
Operating Keys (2) 1x Power button; Navigation arrows
Lens F=6mm; F/No=2.0;
FOV=60* Auto IR-Cut-Remove (at night)
SD Card Class 10, U3, 16GB-32GB, minimum 90MB/Sec
Status Indicator 1 LED
Picture Format JPEG
Video Optional
Trigger Speed 0.5 seconds
SD Card Loop Optional
Operation Power 9-12V
Battery X = 12xAA Cartridge
Optional external power source (12V external
battery pack or solar panel)
- Barrel plug reducer size 4x1.7mm
External DC 12V-2A
TACTACAM.COM

11
SETTINGS / SPECIFICATIONS
Transfer Picture via 4G Thumbnail images sent to app
(Additional data charges may apply)
Request HD Photo and Video
via 4G
Only in supported locations
(Additional data charges may apply)
Upload Frequency/Send Type Instantly (Timely) 4 hours / 12 hours / 24 hours
4G Communication LTE wireless
4G Antenna 1 Antenna
Device Serial No. Yes
Interface LTE, USB, and SD Card
Mounting Strap; Tripod (not included)
Operating Temperature -25*C to 60*C
-13F to 140*F
Operation Humidity 5% to 90%
Waterproof rating IP66
Dimensions 3.62”x4.13”x5.47”
Weight About 0.95lb
FCC RoHs

12
BEST PRACTICES
1. Location and placement is critical for best camera performance.
2. Avoid hanging the camera on small trees that are prone to moving with
the wind.
3. Place the camera about waist height on the tree or post.
4. We recommend having the camera pointing down about 7 to 15 degrees,
We recommend using shims to achieve the desired angle.
5. To achieve the best lighting conditions, face your camera north. Always
avoid facing your camera toward the sun.
6. of
view “window” becomes much smaller, so this is only a good idea if you
plan to set your camera to watch a bait station or scrape.
7. On a food plot:
8. On a trail:
PROPER CAMERA PLACEMENT
• camera too high.
• For the best view place your camera at an angle looking up or down the trail
rather than perpendicular to the trail.
TACTACAM.COM

13
BEST PRACTICES
1. Use the recommended batteries for the Reveal:
2. In cold weather, use lithium ion batteries for best camera speed and
performance.
3. Expected picture count with the proper batteries (in greater than
freezing temps) are:
4. If connecting the Tactacam External Solar Panel (sold separately),
the lithium batteries would act as a backup power source.
BATTERIES AND CELLULAR TRAIL CAMERA PERFORMANCE
• Energizer Lithium batteries
• Duracell Max Alkaline batteries
• Rayovac UltraPro Alkaline batteries
• Lithium: 4,000+ pictures
• Alkaline: 2,500+ pictures

14
TROUBLESHOOTING
1. Check to make sure that batteries are fully charged.
2.
based on max range setting; adjust Night Mode to Max Range for better
3. High quality 1.2V NiMH rechargeable AA batteries can also offer
weather, we do recommend lithium batteries to deliver consistent results.
4.
deliver you better night time images. To improve nightimages do not aim
NIGHT VISION FLASH RANGE DOESN’T MEET EXPECTATION
Use a protective security box such as the
one listed at www.revealcellcam.com
TO HELP PREVENT THEFT OR DAMAGE
Motion sensors (PIR sensors) are actually heat and motion sensors. This is
why on a hot and windy day, people get false triggers. People and animals
are not the only objects that will trigger your camera; vegetation and
precipitation can act as a moving target as well.
1. Be sure to clear any low hanging tree branches, brush, and weeds from
2. Motion sensitivity recommendations:
• Set to High to start, and decrease sensitivity if you’re getting too many false
triggers. 9 being the highest and 1 being the lowest.
CAMERA SENDS PICTURES OF NOTHING
TACTACAM.COM

15
1. Make sure that the SD card is not full. If the SD card is full, the camera
will stop taking images. Users can turn on SD Loop to avoid such
problems. This will cause the SD card to overwrite older images.
2. Make sure that alkaline or NiMH-AA batteries have enough power for the
camera to work.
3. Format the SD card with the camera before using or when the camera
stops taking images.
CAMERA STOPS TAKING IMAGES OR WON’T TAKE IMAGES
TROUBLESHOOTING
The Reveal is IP66 rated waterproof. This means the camera is water
resistant against powerful jets. The only way the Reveal can get
condensation in or behind the lens is if the antenna is not screwed in
all the way, or if there is dirt or debris on the seal. Follow these at home
instructions to alleviate this issue if need be:
• Pull the SD card out and let the camera sit for 3-4 days open, in an area where
there is circulating air (fan or vent).
• You can also put in a sealed container with rice for 24 hours to draw out the
moisture.
• Clean the seal well and tighten your antenna.
•
1. Do not open the camera right away.
2. Be sure to dry the outer housing of the camera, preventing water from
entering the inside of the camera and causing internal damage.
INTERNAL CONDENSATION ON LENS
IF THE CAMERA HAS ACCIDENTALLY BEEN SUBMERGED IN WATER

16
LIMITED WARRANTY
1. One year from the date of purchase.
2. Be sure to register your Reveal under warranty at
www.tactacam.com/warranty
1. This limited warranty covers: manufacturer defects in materials and
workmanship including but not limited to:
2.
technician, or replaced.
1. This limited warranty does not cover any damage caused by the owner
2. This limited warranty excludes damage caused by people or animals,
including but not limited to: antenna, strap, Fresnel lens, glass lens, or
camera housing.
HOW LONG DOES THIS COVERAGE LAST?
WHAT IS COVERED?
WHAT IS NOT COVERED?
• Defective buttons
• Cracked/chipped glass lens
• Broken SD card or SIM card spring mechanism
• Broken USB port
TACTACAM.COM

17
FCC REGULATIONS
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the Federal
Communications Commission rules. These limits are designed to
provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
by the party responsible for compliance could void the user’s
authority to operate the equipment. This device complies with
Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may note cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Federal Communications Commission - Part 15
This equipment complies with the FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum
distance 20cm between the radiator and your body.

18
DO NOT RETURN
THIS PRODUCT TO
YOUR RETAILER
For any warranty issues or questions on how to
[e-mail]
OR
EMAIL
218-282-5650
PLEASE CALL
110 N Sunset Blvd, Caledonia, MN 55921
www.revealcellcam.com
TACTACAM.COM

110 N SUNSET BLVD, CALEDONIA, MN 55921
[email protected] | 218-282-5650
WWW.TACTACAM.COM
© 2024 REVEAL CELLULAR CAMERA BY TACTACAM™
PRO3
