revoltec C205 Guide

Cordless Mini Mouse
C205
Manual
User's Guide

Introduction
Congratulations on your purchase of the most innovative wireless mouse. With an
incredible sensitivity to surface details and high tracking speed than other mice, the mouse
can track reliably even on tricky polished or wood-grain surfaces. It offers even more
advance that will make you more productive and more comfortable.
2 * AAbatteries
-
+
Battery compartment cover
Features
2.4GHz (distance 6~8m), 16 Channels/4096 ID
Using state-of-art technology. High tracking speed and sensitivity.
Rubber side grips and finger grooves.
One year battery life. (*Optional for specific laser long-life models)
Auto-Link, Plug and Play! No need to set the channel ID.
Power on/off switch.
Ergonomic design.
800/1600 dpi switchable button. Internet Forward & Backward button
A wrong battery placement
may cause batteries overheat.
The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click
any button of the mouse" is compulsory to wake it up.
Power on/off:
There is a Power on/off switch designed to save the batteries power while non-usage of a longer period.
User can push DPI button to change the resolution. The LED on scroll wheel will be flashed when dpi has
been sucessfully swithced.
2*AA Alkaline batteries included.
2. Connect the receiver
Mouse
Wheel button/
Dpi switching indicator/
Low power indicator
Dpi button
Receiver
a. Turn on your PC.
b. Connect the receivere to USB port on PC
ID reset button
Power on/off switch
Battery cover
PC USB
port
A. Hardware Installation
1. Insert the batteries
a. Remove the battery compartment cover on the bottom case of the mouse.
b. Fit in the batteries accordingly to the diagram indicated in the battery cabinet.
c. Close the battery compartment cover properly.
d. Make sure the Power on-off swich on the bottom of the mouse is ON.
e. The Low Power LED in the scroll wheel will blink 3 seconds if the mouse power is on.
3. Communication : The mouse & the receiver
The 2.4Ghz RF mouse features a dual-way transmission technology which enables the
mouse and the receiver auto-communication.
A. Auto-link mode
1. Make sure the Power On-Off Switch on the bottom of the mouse is ON.
2. Operate the mouse, and the LED in the receiver will blink fast. Now the mouse and the
receiver is auto-linked successfully.

B. Manual mode
If you find the communication channel does not connect well, you can use following steps
to reset a new channel ID.
5. Always replace all the batteries at the same time. Mixing old and new batteries or mining types (such as alkaline
with zinc carbon) will reduce overall performance and could cause leakage or rupture.
6. Do not mix different types of batteries (e.g. Ni MH, NiCd, alkaline, and etc) in the mouse.
7. Remove batteries from the electrical device if the device is not going to be used for a long time.
8. If the performance of the batteries decreases substantially, it is time to replace the batteries.
1
Execute ID connection software
Note
2 3
Press ID reset button
ID links OK!
.
While the mouse is working, if encountering any interference, the mouse and the receiver will
automatically source out and transfer to another free channel. During the transferring,
the cursor movement may have a second delay.
4. Replace the new batteries
Please replace a pair of new batteries and follow the previous instructions. (2, 3)
Note
The red LED on the scroll wheel is a low batteries power indicator. It indicates
that batteries inside the mouse need to be replaced.
◎ Trouble Shooting
a. Make sure you have connected the receiver correctly to the computer's USB port.
b. For the best performance, we suggest you to locate the receiver with adistancefrom other electrical devices, such as
the computer, the computer monitor or external storage drives.
c. Make sure you have set the communication between the receiver and the mouse. Refer to the Communication
:The mouse and the receiver
d. If you find the communication channel does not connect well. You can use the software connection tool to re-
connect the mouse & receiver to reset a new channel ID. You are able to get the software from the included
diskette of the package or download from your local brand vendor's website.
e. Some system devices might conflict with the mouse. Confirm the IRQ/address settings of these devices for
conflicts, and change the settings as required.
f. Make sure that you are not working the mouse on glossy or reflective surfaces.
◎ Battery use reminders
1. Remove worn-out batteries from equipment immediatelyand dispose of promptly.
2. Keep all batteries (used or new) out of the reach of children.
3. To have the batteries with a regular check and replace new batteries if not used for a long time.
4. Never dispose of batteries in fire, as they could explode.
www.revoltec.com
