Revox Joy S119 User manual

Introduction network receiver
1
E 1.7

Contents network receiver
1
Welcome.................................................... 3
Setup ............................................................ 4
Scope of delivery ......................................... 4
Safety............................................................ 4
Caution: Lithium batteries (internal)............ 4
Fuse .............................................................. 4
Installation - Safety advice.......................... 5
Safety measures .......................................... 6
Regulations pertaining to the unit............... 7
S119/ S120 Front panel................................ 8
Display colours: Status LED ........................ 9
S119/ S120 Connection panel .................... 10
Explanation of the connections................. 11
S208 Remote control............................... 12
Initial operation.......................................... 12
One S208 controls several receivers 12
Two S208s for one receiver ................12
Lithium battery information.................12
S208 Overview............................................ 13
Explanation of the Remote control............ 14
Charging the battery .................................. 15
Charging control / status display .......15
Battery care ............................................... 16
Keep the number of charging cycles to
a minimum.............................................16
Store in a cool environment ...............16
Total discharge protection .................16
Useful facts: Revox Joy radio system....... 16
S208 Basic settings.................................17
Remote control .............................17
Select device ................................20
Change zone .................................20
Information....................................20
Start Pairing ..................................20
First contact ................................................21
Speakers and outputs ......................... 21
Power cable ......................................... 21
LAN/WLAN network connection ....... 21
Establishing the connection to the network
.....................................................................22
Establishing the connection to the remote
control using pairing...................................23
Establishing the connection to the remote
control .........................................................24
First steps in the Main menu ............25
Radio not available!?..................................26
S119/S120 Basic settings ...........................27
Speaker Setup ..............................28
FM Tuner.......................................30
DAB+ .............................................33
Network ..................................35
Network Status .................................... 35
WLAN status ........................................ 35
IP Settings ............................................ 35
WLAN Settings..................................... 36
Network Restart................................... 36
MAC Address ....................................... 36
Quick start function ............................. 36
Software........................................37
Internet..................................................37
USB........................................................ 37
Remote access .............................38
Clock..............................................38
Auto Standby ................................39
Operation - Start-up process................. 40
The configuration options ..........................41
Operation ....................................................42

network receiver Contents
2
Main menu ...............................................43
Last Music ..................................................43
My Music ....................................................44
Shortening access times ....................45
Change menu language ......................45
Radio ...........................................................46
DAB+ / FM Tuner .......................................50
USB/ iPod..................................................51
USB........................................................51
iPod......................................................51
iPod selection.....................................52
Audio server ...............................................53
Control functions ........................................54
Cover display ........................................54
Local inputs.................................................55
Rename Input .......................................56
Settings and comfort functions..................57
Sound Setting ...............................57
Alarm Clock 1 / 2...........................58
Short Time Alarm..........................60
Sleep-Ttimer .................................61
Change My Music ........................61
Device info....................................63
Basic settings ...............................63
Setting up Internet Radio .......................64
Internet Audio Portal - IAP.....................65
Initial login ..................................................66
IAP Registration page ................................67
Managing the Revox IAP............................68
Adding radio stations to Favorits ...............69
Synchronising Joy devices ........................70
Error messages........................................71
Status messages .....................................74
A. Switching the device on ......... 74
B. Waiting for the network .......... 74
C. Switching the device off ......... 74
Network terminology ........................... 75
General.................................................. 75
DNS ....................................................... 75
LAN........................................................ 75
Gateway................................................ 75
Client ..................................................... 76
DHCP ..................................................... 76
IP Address ............................................ 76
MAC Address ....................................... 76
NAS ....................................................... 76
Power Line – LAN................................ 76
Proxy Server......................................... 76
Router (WLAN Router) ........................ 77
Server.................................................... 77
SSID....................................................... 77
UPnP-AV ............................................... 77
WLAN .................................................... 78
WPA ...................................................... 78
WEP....................................................... 78
Wi-Fi ...................................................... 78
Network: Questions & Answers ............79
Appendix...................................................82
Warranty..................................................... 82
Copyright advice ........................................ 82
Environmental protection .......................... 82
Technical data 1/2..................................... 83
Technical data 2/2..................................... 84

Introduction network receiver
3
Welcome
The S119 and S120 network receivers
from Revox combine the latest streaming
technology with an audiophile stereo
output from the high-end range.
When you see the compact construction, it
is easy to forget that there are full-blown
torodial transformers and heavy duty
power supplies at work in the network
receivers, so that if required, up to 240
watts (S120) are available at the speaker
terminals. Combined with the DSP
professional speakers and space
correction, you, in the company of your
Revox speakers, will reach a musical
zenith, which need fear no comparison
with its peers.
For the benefit of audiophile music
lovers, Revox deliberately avoided the
use of fans. So that nonetheless, the
S119/S120 can keep a cool head, even
when the temperatures outside top the
40°C mark, a heat coupler has been
used. This aluminium heat pipe
dissipates the heat away from the
network processor over a gold-plated
coating on a large area of copper. The
heat can then escape from the inside of
the housing through the convection
openings. In this way, we achieve a
processor temperature that is lower by
up to 30°C, which impacts positively on
the processor stability and ensures a
long working life.
In order to keep the operation on a par
with the sophisticated technology, a lot
of time and effort was invested in the
detail of the optional remote control. You
will feel it and see it.
This product innovation from Revox
stands out as a true system for life,
thanks to its legendary robustness and
longevity, which the brand is known for
throughout the world.

network receiver Introduction
4
Setup
Please check the unit and accessories
after unpacking, to ensure that
everything is there and that there are no
signs of transit damage. Read the User
manual through carefully before starting
to use the unit. Keep the manual for later
reference.
A unit that shows signs of mechanical
damage or which has had liquid in it
should not be connected to the mains
supply.
Only use the mains cable supplied. When
using an alternative power cord, the
ratings must meet 10A/125V. The
alternative power cord requires a
certification (UL / CSA / VDE).
The unit’s power supply and connections
values (mains voltage, frequency) must
be checked before connecting it to the
mains. Fuses used in the device must
comply with the factory definitions in the
“Technical Data” section.
Scope of delivery
Network receiver (1x)
Power cable (1x)
Network cable (1x)
Quick Reference Guide
Network receiver User manual CD *
* Contains the complete S119/S120 German/English
User manual in PDF format. A PDF Reader is required.
Safety
Take note of the label on the back of the
unit.
In order to avoid the risk of an electric
shock, do not open the housing.
Maintenance and repairs should only be
carried out by qualified experts.
Caution: Lithium batteries (internal)
Danger of explosion if battery is
incorrectly replaced. Replace only with
the same or equivalent type – CR2032
3V.
Batteries shall not be exposed to
excessive heat such as sunshine, fire
or the like.
Take note of the disposal hints within
the chapter
Appendix.
Fuse
The S119/S120 is equipped with a
primary fuse located inside the housing.
This internal fuse may not be changed by
the user.
In this case of a fault, please contact
your nearest Revox Service Point.

Introduction network receiver
5
Installation - Safety advice
Please follow the instructions in the
User manual supplied.
Do not position the unit close to strong
heat sources or in direct sunlight.
Please take note of the following, if the
receiver is to be installed in a cabinet
or closed shelves. Allow at least 5 cm
of free space around the device, so
that the air can circulate freely and
that there is no build up of heat. Do not
cover openings on the back wall or in
the base of the unit.
It must be ensured that the correction
functioning of the unit's ventilation
openings is not affected by being
covered, e.g. by curtains, newspapers,
table cloths, or similar.
This unit conforms to protection class
2. This means that with this unit, the
ground cable is not connected to the
housing, in order to effectively
eliminate sound-damaging ground-
loops. With these network receivers
however, Revox uses the ground cable
for the reduction of noise fields. For
this reason, both the supplied cable
and the connection panel are fitted
with a ground cable.
The power plug should be removed
from the socket during longer periods
of non-use, for instance during an
absence.
Unplug the unit from the mains during
storms. Voltage peaks through the
mains power supply caused by
lightning strikes can damage the unit.
There must be easy access to the
power plug so that the unit can be
unplugged at all times.
Lay the power cable such that it
cannot be damaged. The power cable
should not have kinks or be laid over
sharp edges. It should not be walked
on or be exposed to any chemicals.
The last point is valid for the whole
unit. A power cable with damaged
insulation can lead to electric shocks
and represents a fire hazard.
Never pull on the cable when plugging
the unit in or out. Always hold the plug.
Liquids, flammable or other objects
should not be inserted in the unit’s
openings as this can lead to faults, fire
or an electrical shock.
Do not expose the device to splash
water or high levels of humidity. Do not
stand containers filled with liquid, e.g.
flower vases, on the device.
It is only designed for operation in
temperate, non-tropical climates.
Take note of and follow the safety
advice on the following pages.

network receiver Introduction
6
Safety measures
Read and take note of the following
safety advice for your own safety and to
avoid unnecessary damage to your
equipment. Please keep this safety
advice in a safe place for future
reference.
Avoid locating the unit in a position
which:
-is exposed to direct sunlight
-is directly next to a source of heat
-has poor ventilation
-has a dusty atmosphere
-is unstable
-has high humidity
The guarantee covers the intended
usage of the unit.
High build-ups of dust and humidity
cause creepage current in the unit that
can cause a risk of shocks when
touching the unit or lead to a fire.
If you have moved the unit from a cold to
a warm environment, leave it switched
off for about two hours because of a
possible build up of condensation
dampness.
You should always switch your S119/
S120 off before connecting or
disconnecting other devices or
speakers.
Protect your unit from:
-damp, dripping water and steam
-impacts and mechanical loads
-magnetic and electrical fields
-cold, heat, direct rays of the sun and
severe changes of temperature.
-dust
-accesses to the inside of the device
Do not stand any articles with open
flames, e.g. lit candles on the unit.
Please note
In order to exclude the risk of an electric
shock, do not remove the housing. Only
have repair work carried out by a Revox
specialist dealer.
Volume
Loud music can cause hearing damage.
Avoid extremes of volume, particularly
over longer periods of time.
Supervision
Do not allow children to handle the
equipment without supervision. Do not
allow children in close proximity to the
unit. Do not operate the S119/S120
without supervision. Switch the power
switch off or unplug the unit if you are
going to be absent for a longer period of
time.
Cleaning
The unit should be cleaned using just a
damp, soft and clean cloth without any
abrasive cleaning agents.

Introduction network receiver
7
Regulations pertaining to the unit
In EU and EEC countries, Revox offers a
guarantee on units bought in the EU,
over and above the statutory rights of
guarantee claims against the seller. The
guarantee covers material and labour
during the period of the guarantee,
which is defined by the Revox Sales
Partners in the individual countries that
make up the EU.
In all countries, the guarantee services
offered by the Revox Sales Agents are
over and above the statutory regulations.
They are only valid in the country of
purchase. Proof of purchase from an
authorised Revox Partner must be
produced to make a claim on the
guarantee.
The guarantee is made null and void in
the case of incorrect intervention
measures or non-professionally executed
repairs.

network receiver Presentation
8
S119/ S120 Front panel
As well as housing the multi-colour
status LED, the front panel of the
receiver also conceals a radio module
(RF) for the bidirectional data traffic with
the optional S208 remote control. The
unit is controlled through the S208
remote control.
Front view of the S119 network receiver
Advice about the installation location
As the radio module is located directly
behind the glass panel on the front of the
unit, the S119/S120 should be installed so
that it is aligned in the direction of the
remote control. This guarantees the
maximum distance for operating use the
S208. Walls and ceilings, particularly
those made out of brick or concrete
(with reinforcement), significantly
reduce the distance.

Presentation network receiver
9
Display colours: Status LED
Dark-blue 
Quickstart function [off]:
In this standby mode, all functions,
with the exception of the radio
module, are deactivated.
Power consumption: < 0.6 W*
Light-blue 
Quickstart function [on]:
Unit is in standby mode. If the
Quickstart function is activated, the
network processor is switched on
permanently. This significantly reduces
the switch-on phase, as the
connection to the network doesn't
have to be built up again. All other
sub-assemblies, such as the audio
signal processing or the outputs,
including the main transformer are
switched off, as with normal standby
mode. Quickstart mode is also a
requirement, in order to be able to
control the receiver with a network-
based Revox App.
Power consumption: approx. 4.5 W*
The USB input supports the charging of
external devices, e.g. an iPhone in
standby mode.
* without USB feed
.
Green (flashing)
After switching on at the power switch,
the status LED flashes green for about 10
seconds. During this time, the S208 remote
control can be paired/ synchronised with
the receiver, i.e. these two devices can be
connected with each other, functionally.
You will find the necessary steps for this
procedure explained in the
S208 Remote
control
chapter.
Red (flashing)
A non-defined fault has occurred. If
necessary, switch the unit off and on
using the power switch.
Red (permanent)
The timer in the network receiver is
active. This can be the case, for example,
if the timer function is activated, with
which the receiver switches itself on
automatically after a certain time.
White 
The receiver is in operation.

network receiver Presentation
10
S119/ S120 Connection panel
USB information
Revox recommends that you only use the
USB connection for data carriers up to
32 GB as with large data quantities, the
reading time increases greatly or it can
be impossible to record data. With a
large music collection, we recommend
using a network hard disc (NAS) with an
UPnP service e.g. the Revox S37 audio
server with integrated rip function.
DAB+/ FM combiner information
A DAB+/FM combiner is needed for the
parallel reception of DAB and FM signals
through the tuner module's F socket. In
this way, the two inputs, FM (87.5 - 108
MHz) and DAB+ (174 - 230 MHz), are
combined onto a joint HF output. Revox
offers an optimised FM/DAB combiner
under the order number 1.561.091.01.
Please take note of the
connection information on
the following pages.

Presentation network receiver
11
Explanation of the connections
Name
Function
AC Power Power cable connection (class 2 with ground cable) The
voltage definition [V~] on the unit label must be adhered to.
Aux 1 / Aux 2 Analogue audio inputs, max. input voltage: 2.0 V pp
Coax 1 / Coax 2 Digital audio inputs through coaxial cable
Optional
1
Antenna input for an optional FM/DAB module.
Optimised for cable reception.
Factory
2
Reset button for restoring factory defaults. Can be activated
using a paper clip.
Loudspeaker (Right + Left) Speaker connection / Impedance: at least 4Ω
Network RJ45 network connection for wired audio streaming (iRadio,
NAS) and for App control
Power switch
Power switch - no power consumption when in off position
Please note: If the power cable is connected, certain internal
switching areas are live, even if the switch is in the off position.
Optical 1/ Optical 2 Digital audio inputs through fibre optic – TOSLink
(SPDIFF, max. 96 kHz)
Output Analog Controlled analogue audio output, e.g. for external output
Output Digital
3
Digital audio output over coaxial cable (potential-free)
The
Analog Output is muted with the loudspeaker output.
Output Sub (Subwoofer)
Controlled analogue audio output for active subwoofer
Pilot signal for subwoofer wakeup available in the S119/S120
basic settings
Start up Start button for start-up from the standby state. Quick Start
function is activated for permanent control through an App.
USB / iPod / iPhone USB B input for the USB memory stick (< 32 GB ) or iPod/iPhone
connection.
Wi-Fi WLAN antenna connection for wireless audio streaming
(iRadio, NAS) and App control, supplied with the unit
1 not supplied with the S119/S120
2
Switch off the S119/ S120 via Power switch – Press and hold the Factory button. Switch the
device back on with the power switch. Release the Factory button after 5 seconds
3
SPDIFF Sampling rate 48 kHz for the sources: Radio, USB, Audio Server, Aux1/2
Sources Coaxial / Optical: Signal pass-through / Sampling rate In = Out/ max. 96 kHz
The Output Digital is permanently active and is not muted with the output.

network receiver Presentation
12
S208 Remote control
The optional S208 Remote control offers
you the optimum way to control the
S119/S120 network receiver. All
information is displayed clearly on the
TFT colour display, through the bi-
directional wireless connection.
Additionally, the control of third-party
devices with an IR Code can be
integrated through a database. The
remote control is configured using the
free-of-charge
S208 EasyCreator PC
software that can be downloaded from
the Revox homepage.
Initial operation
The remote control battery should be
charged up for at least 3 hours before
you start to use it. Please refer to Page
15 of this User manual for information on
how to do this.
The charger supplied with the remote
control is used to charge the lithium ion
battery in the S208.
The operation of the S119/S120 using the
S208 Remote control is described in the
next chapter. The setting options of the
remote itself, such as the background
colour of the display, are defined in the
S208. On the other hand, the menus and
setting options that affect the network
receiver itself depend on the
corresponding device. As a result, the
description is split between the S208 and
the S119/S120.
One S208 controls several receivers
Up to 24 network receivers can be
controlled with one S208 Remote control.
However, it can only communicate or
have a wireless connection with one
receiver at a time. If a connection to a
second receiver is established (
Select
device
hotkey), the connection to the
first receiver is automatically closed.
Two S208s for one receiver
If you are using several S208 remotes, it
should be noted that one receiver can
only have a wireless connection to one
remote controller at a time. If for
example, there is already a connection
to remote control 1, remote control 2
cannot establish a connection to the
receiver. Remote control 2can only
establish a connection once remote
control 1has ended the connection to
the receiver with the button or has
established a connection to another
receiver.
Lithium battery information
The remote control, with the battery in it,
should not be exposed to sources of
great heat such as the direct rays of the
sun or to fire. Please also read the
information concerning the disposal of
this product in the Appendix at the end
of this User manual.

Presentation network receiver
13
S208 Overview

network receiver Presentation
14
Explanation of the Remote control
Button
Function with S119/S120 network receiver
(not IR operation)
Switch S119/S120 off
hotkey to switch between/switch on network receivers and IR devices.
Menu-dependant option buttons - (number input
:
lower/upper case)
Main menu with source selection (radio, USB, local sources, etc...)
Access to (basic) settings.
Short
press: S119/S120 settings (only if there is
already a connection to the receiver)
Long
press: S208 settings
Displays the information screen about the currently selected source
Adds the track that is currently playing to the My music list
Calls the My music list
Quit menu / Up one level / Back
Change zone. Displays all available zones
Displays the source's Home menu, e.g. radio, music server, ...
Confirm / Accept / Select
Right-Left / Decrease-Increase / Delete-Cursor to the right
Up-Down / Decrease-Increase
Volume control. Volume level can be set from 0 to 40. Comfort start-up volume*
Mute / Un-mute
Decrease-Increase / Down-Up
Stop
Short: Track down-up / Down-Up Long: fast forward/ - backward
Record [currently without function]
Play
Pause
Digits 0-9 / Letters A-Z
Start/end SHUFFLE
Start/end REPEAT (track/all)
* If the volume is set to a level higher than [Vol 20] when it is switched off, a
lower volume level [Vol 10] is used when the device is switched on again.

Presentation network receiver
15
Charging the battery
The S208 remote control has a
rechargeable lithium ion battery that can
be charged using either the supplied
charger or a mini-USB connection.
Use the charger with the supplied USB
cable and the pluggable power supply.
Insert the S208 vertically in the charger
cradle (Step 1) and then let it slope
backwards (step 2). This ensures that
there is good contact between the 4 gold
contact-connections on the charging
cradle and the remote control.
Alternatively, the charger can also be
connected to the network receiver's
USB output if this is not needed for any
other purpose. In this case, the
pluggable power supply is not required.
Charging control / status display
Battery is being charged -
do not interrupt the charging process
Battery is fully charged -
charging process can be ended
Battery full
Battery almost empty
Battery empty - please recharge
The USB pluggable power supply
consumes no power [0.0W] when the
S208 Remote control is not in the
charging cradle.
Connecting charger to the power supply

network receiver Presentation
16
Battery care
Keep the number of charging cycles to a
minimum
The working life of a lithium ion battery is
largely determined by the number of
times it is charged, irrespective of
whether it is charged from 90% to 100%
or from 10% to 100%. For this reason, it
makes sense to charge the remote only
once the charge-level display is showing
[Almost empty] or [Empty]. This will
lengthen the working life of the battery
with the same number of charging
cycles.
Store in a cool environment
If possible, don't place or keep the
remote control in warm or hot locations,
e.g. on a window sill or other places that
get hot. At temperatures above 40°C, the
rate of self-discharge increases and
irreversibly shortens the overall working
life and capacity. Particularly if the
remote control is not going to be used
for several weeks, it should be kept in a
cool location with the battery at 50% to
80% charge.
Total discharge protection
The S208 remote control has a total
discharge protection feature that
switches the battery that provides its
power off, as soon as this is completely
discharged either through usage or
through longterm storage. Once the S208
is in this state, it no longer reacts to
button-presses. In this case, the remote
control has to be completely recharged
using the charger or the USB
connection. This takes at least 3 hours.
Useful facts: Revox Joy radio system
The transmitting power of the S208
remote control and the receiver unit in
the Joy device is in the μW or mW range,
depending on the data traffic. Is the S208
in standby mode, there is even no radio
communications between the devices -
no polling at short intervals.
The S119 / S120 is the off-mode only in a
receiving mode, which means that he
"hears" only, whether data for him are
sent. No active sending.
Conclusion: The Revox Joy receiver
behaves exemplary in electric smog.

Configuration network receiver
17
S208 Basic settings
The Basic settings for the S208 are
called up by pressing and holding the
button for > 2 seconds.
Then, you can select from the following
basic settings:
Remote control
Select device
Change zone
Information
Start pairing
You can make your inputs and selections
in the individual menus using the
navigation buttons, OK and the number
pad.
 Decrease / Delete - Increase
 Up-Down
OK Confirm
0-9 Direct input of numbers/letters
Uppercase-Lowercase
Remote control
Name [Re:control S208]
Time: Hours (0-23) [13]
Time: Hours (0-59) [45]
Stand-by (0-300) [60]
Time in cradle [On]
Weekday
Brightness
Background colour
Hotkeys
Change language
Rename device
Delete device
Add zone
Delete zone
Transport lock
Name [Re:control S208]
Editing options for the remote control's
name, which is displayed in the
Home
menu.
Time: Hours (0-23) [13]
Time: Hours (0-59) [45]
Time setting in hours and minutes, in
case there is no connection to the
network through the receiver. Otherwise,
the time is updated over the network
(Internet).
Stand-by (0-300) [60]
Timeout in seconds until the remote
control, not the receiver, switches to
standby. A longer timeout shortens the
battery life accordingly.

network receiver Configuration
18
Time in cradle [On] / [Off]
The S208 Remote
control can display
the current time
[On], when it is in
the charging cradle
in standby mode.
The timeout until
the time is shown,
depends on the
Stand-by (0 - 300s) setting. The power
consumption while the time is being
displayed and while trickle charging is
happening (battery 100% charged), is
0,8W.
There is no time display if charging (fast /
trickle charging) is done directly through
the USB socket.
.
Weekday
Weekday selection, which appears as an
abbreviation (Mo, Tu, We ...) in the status
bar at the bottom of the display. This is
also important for the receiver's alarm
clock function.
Brightness
The TFT colour display can be operated
at three different brightness settings,
low / medium / high , as well as in
automatic mode In this case, the
integrated brightness sensor (see S208
overview) measures the ambient
brightness and adjusts the background
lighting accordingly.
The brighter the background lighting
selection, the shorter the battery life.
Background colour
Five colours are available as background
colour:
Dark grey / Walnut / Blue / Red /
Moss green.
On the one hand, this gives
you the option of choosing a colour that
matches your personal preference but it
also makes it easier to differentiate
between them, if several remotes are
being used.
Hotkeys
Four hotkeys are available per
Zone/Room that can have network
receivers or IR devices assigned to them
from the list of available devices.
Network receivers are integrated into
this list by being paired with the S208. IR
devices are integrated through the S208
EasyCreator PC program. You can now
assign these devices to the hotkeys in
the corresponding zones through the
hotkey menu. This function is also
available in the
S208 EasyCreator PC
program.
