REWIRE SECURITY 102-NANO User manual

102-NANO USER MANUAL

Contents
1. Summary ..................................................................................................................................................... 3
2. Applications................................................................................................................................................. 3
3. Hardware Description.................................................................................................................................. 4
3.1 Side........................................................................................................................................................ 4
3.2 Bottom................................................................................................................................................... 4
3.3 Front ...................................................................................................................................................... 4
3.4 Interior................................................................................................................................................... 5
4. Specifications............................................................................................................................................... 5
5. Usage ........................................................................................................................................................... 6
5.1 SIM Card Installation ............................................................................................................................. 6
5.2 Battery and Charger .............................................................................................................................. 6
5.3 Startup................................................................................................................................................... 7
5.4 Changing Your Password........................................................................................................................ 8
5.5 Authorization......................................................................................................................................... 8
5.6 Easy SMS Text Message Locating........................................................................................................... 9
5.7 Interval Tracking .................................................................................................................................... 9
5.8 Exact Street Address............................................................................................................................10
5.9 Location-based service (LBS) / Cell-ID locating ................................................................................... 10
5.10 Monitor (Voice Surveillance) .............................................................................................................10
5.11 Data Logging......................................................................................................................................11
5.12 Shock Sensor Alarm...........................................................................................................................12
5.13 Geo-fence ..........................................................................................................................................13
5.14 Movement Alarm ..............................................................................................................................13
5.15 Over Speed Alarm.............................................................................................................................. 14
5.16 SOS Alarm..........................................................................................................................................15
5.17 Low Battery Alarm.............................................................................................................................15
5.18 GPS Blind Spot Alarm ........................................................................................................................16
5.19 Standby Modes..................................................................................................................................16
5.20 Forwarding Incoming SMS Messages ................................................................................................19
5.21 SIM Card Balance Check ....................................................................................................................19
5.22 Status Enquiry....................................................................................................................................20
5.23 IMEI Number Request: ...................................................................................................................... 20
5.24 Time Setting.......................................................................................................................................20
5.25 TCP/UDP Switch................................................................................................................................21
5.26 Reset.................................................................................................................................................. 21
5.27 PC Software Tracking......................................................................................................................... 21
5.28 GPRS (Internet) Tracking....................................................................................................................22
5.28.1 APN Configuration ...................................................................................................................... 22

5.28.2 APN User ID and Password setup...............................................................................................23
5.29 Server IP Address and Port Setup......................................................................................................23
5.30 GPRS Economy Mode ........................................................................................................................23
5.31 Restore to Factory Defaults ............................................................................................................... 24
1. Summary
102-NANO can locate any remote target by using Geographic Locating System
and send instant SMS or Internet reports to the user by using GSM and GPRS
network. 102-Nano can be used and tracked by either SMS or via our GPS
tracking software –GPSLive. GPSLive allows its users to track and locate their
personal, vehicle and assets in real-time. 102-Nano GPS tracker can also be
used as a simple SMS text message tracker, making it even easier to track the
location of 102-Nano when you’re out and about. Simply call the 102-Nano
tracker and it will reply back with an SMS text message with a link to Google
maps showing its current location in real time. The 102-Nano Kit comes ready
to use out of the box and offers an optional hardwire kit for permanent
installation to a vehicle as well as car charger for charging via a lighter socket
and a magnetic case for attaching the tracker to magnetic surfaces.
Visit GPSLive to get more information on our GPS Tracking platform.
User Manual for GPSLive can be found here.
2. Applications
•Fleet management,
•Bike & Motorbike tracking,
•Personal tracking,
•Vehicle tracking,
•Asset Tracking,

3. Hardware Description
Keep track of your family members, employees or anyone you need to monitor,
with the 102-Nano GPS tracker from Rewire Security, one of the smallest GPS
tracking devices available in the market to this date. Even with its small compact
design, the 102-Nano does not lack on function or features, with the ability to
track by turn or distance with updates from as little as every 10 seconds.
3.1 Side
3.2 Bottom
3.3 Front

3.4 Interior
4. Specifications
Content
Specs.
Dimensions
64mm x 46mm x 17mm ( 1.8” x 2.5” x 0.65” )
Weight
50g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS chip
SIRF3 chip
GPS sensitivity
-159dBm
GPS accuracy
5m
Time To First Fix
Cold status 45s
Warm status 35s
Hot status 1s
Car charger
(Optional) 12—24V input
5V output
Wall charger
110－220V input
5V output
Battery
Rechargeable 3.7V 1000mAh Li-ion battery
Standby
16 hours to 30 days depending on usage and standby mode
Storage Temp.
-40°C to +85°C
Operation Temp.
-20°C to +55°C
Humidity
5%--95% non-condensing

5. Usage
5.1 SIM Card Installation
▪Please make sure that your SIM card is activated and PIN code request is
disabled, the tracker won’t be able to enter a PIN code. If you are using a
free contract SIM card and would like to use the 102-NANO via GPSLive
GPS tracking platform, you may need to contact your SIM card network to
check if your internet data access is active.
Steps for installation:
5.1.1 Open the rear cover and remove the battery.
5.1.2 If you intend to use GPS Data logging to an SD CARD, please insert a
Micro SD Card to the slot as seen in the guide picture below. If not, you can
move on to the next step.
5.1.3 Insert the Standard SIM card into the SIM card holder tray. Please note that
Micro and Nano SIM cards are not supported.

5.2 Battery and Charger
The battery should be charged between 8 - 12 hours before first use. Please use
the battery charging cradle provided with the 102-Nano. The battery charging
cradle is located under the soft pads holding the GPS unit in the package. This
tracker uses built-in Li-ion battery technology, and a fully charged battery can
power the 102-NANO from 16 hours up to 10 days depending on usage and
standby mode. After the first use, the battery should be charged for 2-4 hours
every time.
Warning: Do not puncture, heat or modify li-ion batteries. If at any time you
notice a battery starting to get hot or swell up, stop the charging process
immediately. Improper usage of Li-ion batteries and high temperature may
cause the battery to explode.
5.3 Startup
•Please make sure to use your 102-NANO outdoors as GPS technology will
not work accurately indoors. (GPS signals do not penetrate walls)
•Turn on the unit by pressing the “on/off” button until the indicator is on.
•In 10 to 40 seconds the device will begin to work and acquire GPS and GSM
signals. The indicator will keep flashing frequently when it is searching for
GSM signal.
•Once GSM and GPS connection is established, the LED light will start
flashing less frequently.
▪Please note – The default password for 102-NANO is ‘123456’
Note: While reading the set-up commands, you will notice that some words
are separated by + or space. “+” means two words should be written without
a space, as one word. “Space” means there should be a space between two
words.
e.g. reset+123456 means the command you should send to the tracker is
“reset123456”
▪sleep+123456+space+shock means the command you should send to the
tracker is sleep123456 shock (there is a space between 6 and shock)

5.4 Changing Your Password
Command: password+old password+space+new password
Response: password OK
e.g. password123456 888888
If you forget your password, you can restore it to the default password using the
command : adminpassword13142324.
▪Please note that it is not necessary to change the password unless you intend
to disclose the phone number of your tracker to a third party.
5.5 Authorization
If you are planning to use geo-fence, shock, movement or over-speed alarms,
please register yourself to the unit as an authorized number. Up to 5 numbers
can be authorized. If you call the tracker for 10 times continuously and get its
position, it will save your mobile phone number as the authorized number
automatically. Alternatively, you can authorize your phone using the SMS
command below;
Command: admin+password+space+cell phone number
Response: admin ok!
e.g. admin123456 [phone]
Additional authorized numbers have to be set-up by the first authorized number.
Once a user (phone number) is authorized, 102-NANO will not reply to phone
calls from unauthorized numbers with a location report. However, it will still
respond to SMS commands as long as the password is correct. Alarm
notifications can only be sent to the authorized numbers as well.
Deleting the authorized number:
Command: noadmin+password+space+authorized number
e.g. noadmin123456 [phone]

You have to enter your phone number in “+44” international format for 102-
NANO to be able to recognize your phone number. When you enter your phone
number in international format, please make sure to remove the 0 before your
number.
For example: 07771112233 should be entered as follows; [phone]
5.6 Easy SMS Text Message Locating
If there aren’t any authorized numbers set-up, 102-NANO will reply to all calls
with a location report. If there are authorized numbers set-up, 102-NANO will
only send location reports to the authorized numbers. The SMS Text message
report will include coordinates, current speed & time. There will also be a direct
Google Maps link for smartphone users.
5.7 Interval Tracking
102-NANO can send automatic location reports at set intervals. If SMS mode is
active, reports will be sent as SMS text messages. If GPRS tracking mode is active,
updates will be uploaded to the online tracking server.
Command: fix030s***n+password
102-NANO will not respond to this message but it will start updating its location
continuously at 30 seconds intervals.
e.g. fix030s***n123456
Every 30 seconds is an ideal setting for GPRS (internet live tracking). Increasing
this may reduce your mobile internet data usage. Size of each data package sent
in GPRS mode is approximately 150 bytes.
To cancel interval tracking:
Command: nofix+password
e.g. nofix123456

5.8 Exact Street Address
You must set up the APN of your SIM card provider before using this function. If
your network requires a username and password for GPRS login, please refer to
sections 5.31 to configure the APN, username and password for GPRS login.
Command: address+password
Response: No 2, High Street, Bristol, BS1 2A
e.g. address123456
5.9 Location-based service (LBS) / Cell-ID locating
If 102-NANO cannot establish a solid GPS fix, it will calculate its location using
Cell-ID GSM locating. Location reports will include the GPS coordinates of the last
known position as well as a LAC code. Entering the LAC code to the “Manual
Track” menu of web tracking platform will enable you to see the tracker’s current
location.
You can also send command “address+password” to the tracker to request exact
address. 102-NANO will automatically switch to tracking by LBS in GPRS mode.
The accuracy of LBS also known as Cell-ID tracking depends on the distance to
the nearest GSM Network Cell Tower or Base Station. In urban areas, this
accuracy usually varies between 25-100 meters.
5.10 Monitor (Voice Surveillance)
102-NANO is in tracking mode by default. When monitor mode is activated, it
will automatically answer incoming calls, rather than replying with location
information.
To activate monitor mode:
Command: monitor+password
Response: monitor ok!
e.g. monitor123456
Now 102-NANO will answer your calls and you will be able to listen through the
built-in high sensitivity microphone.

To switch back to tracker mode:
Command: tracker+password
Response: tracker ok!
e.g. tracker123456
5.11 Data Logging
Auto logging：If the 102-NANO loses GSM or GPRS signal, it can store the
tracking position and alerts automatically on the flash drive upon the pre-set
conditions. When GSM reception is re-established, all the event alerts will be
auto-sent to the authorized numbers or online tracking server.
Logging at preset intervals:
Command: save030s005n+password
Response: save ok
e.g. save030s005n123456
Once set, 102-NANO will store the latitude, longitude locations every 30 seconds
for 5 times. (S: second, m: minute; h: hour).
Continuous logging:
Command: save030s***n+ password
Response: save ok
e.g. save030s***n123456
Logging Clearance:
Command: clear+ password
Response: clear ok

e.g. clear123456
Logging Volume: The tracking device has a built-in flash 1MB (~16,000 positions)
but this can be increased by adding a Micro SD card to the slot located under the
SIM Card Slot. A 2 GB Micro SD card is sufficient to record location data for up to
10 months. Data Logging function also enables you to use this tracker as a GPS
Logger. You can download the location data to your PC by using the free PC
software provided through USB connection.
5.12 Shock Sensor Alarm
Shock sensor alarm is deactivated by default. To activate:
Command: shock+password
Response: Shock is activated!
e.g. shock123456
Now when 102-NANO detects vibration, it will send SMS “Sensor
alarm+location” to the authorized numbers. To cancel shock sensor alarm:
Command: noshock+password
e.g. noshock123456
Shock sensor sensitivity configuration:
The shock sensor module has three different sensitivity settings;
First Level: Alarm will be triggered after detecting single vibration.
Command: sensitivity+password+space+1
e.g. sensitivity123456 1
Second Level: Alarm will be triggered after detecting 8 vibrations in 2 seconds.
Command: sensitivity+password+space+2

e.g. sensitivity123456 2
Third level: Alarm will be triggered after detecting 25 vibrations in 5 seconds.
Command: sensitivity+password+space+3
e.g. sensitivity123456 3
5.13 Geo-fence
This feature allows you to create safe zones. When the 102-NANO enters or
leaves this zone, the device will send geo-fence alarm warnings to the authorized
numbers. To be able to configure geo-fence 102-NANO has to stay stationary for
5 minutes. After 5 minutes proceed as follows;
Command: stockade+password+space+latitude,longitude; latitude,longitude
In case of a breach, the device will respond with SMS “stockade!+location” to the
authorized phone numbers every 3 minutes.
Note: The first latitude & longitude is coordinate of the top left corner of the
Geo-fence, while the second latitude & longitude is the coordinate of the bottom
right corner.
e.g. stockade123456 51.460959,-2.622643;51.456842,-2.604446
You can obtain coordinates of any location from google maps by right-clicking to
the desired location and selecting “what’s here?”
To cancel:
Command: nostockade+password
e.g. nostockade123456
5.14 Movement Alarm
To activate movement alert 102-NANO has to stay stationary for 5 minutes. After
5 minutes proceed as follows;

Command: move+password+space+0200
Response: move OK
e.g. move123456 0200
This will activate the movement alert with an area radius of 200 meters.
Maximum radius limit is 999 meters. In case of such a movement, it will reply
SMS “Move+ latitude & longitude” to the authorized numbers in 3 minutes
intervals.
Note: Setting the radius less than 100 meters may result in false movement
alerts. The fault alert occurs if GPS position is miscalculated due to bad GPS
reception. Inaccurate GPS reading will cause the 102-NANO to think that it is in
a different location, possibly farther from its current location, thus the processor
will accept this as a movement and trigger the movement alarm.
To cancel movement alarm:
Command: nomove+password
e.g. nomove123456
5.15 Over Speed Alarm
To activate:
Command: speed+password+space+080 (in km/h)
Response: speed ok!
e.g. speed123456 080
When the speed exceeds 80 km/h, it will send the following SMS to the
authorized numbers every 3 minutes: “speed+080!+location”

To cancel:
Command: nospeed+password
e.g. nospeed123456
5.16 SOS Alarm
102-NANO is equipped with an SOS button. In case of emergency, pressing this
button will notify authorized numbers with three text message followed by a
phone call. The SOS alarm is activated by default and the SOS button is enabled.
To disable the SOS button:
Command: sos+password+space+off
e.g. sos123456 off
To enable the SOS button
Command: sos+password+space+on
e.g. sos123456 on
5.17 Low Battery Alarm
Low battery alert helps users to know when the battery of 102-NANO is low. It
sends 3 notifications to authorized numbers; at %10, at %5 and just before it's
completely flat. Low battery alert is activated by default.
To activate;
Command: lowbattery+password+space+on
e.g. lowbattery123456 on

To deactivate:
Command: lowbattery+password+space+off
e.g. lowbattery123456 off
5.18 GPS Blind Spot Alarm
This function is deactivated by default, to activate:
Command: gpssignal+password+space+on
e.g. gpssignal123456 on
Once activated 102-NANO will send SMS notifications to authorized numbers
when it loses GPS reception.
To deactivate:
Command: gpssignal+password+space+off
e.g. gpssignal123456 off
5.19 Standby Modes
Timed standby after 5 minutes:
When activated, after having no activity (call or SMS commands) for 5 minutes,
102-NANO will change to standard standby mode; GPS module and led light will
be OFF, GSM module (phone line) will still be ON. It will wake up and turn the
GPS module ON only if you call it to request position or send an SMS command.
Please note if movement or shock sensor alarm active this standby mode will not
work.
Command: sleep+password+space+time
Response: sleep time ok
e.g. sleep123456 time

Standby with shock/movement sensor:
With this mode 102-NANO will change to shock sensor standby mode after being
stationary for 5 minutes without any vibration or movement, GPS module and
the LED light will shut off, GSM module will still be ON. As the GSM module will
be ON, you will still be able to communicate with 102-NANO. Vibration,
movement, calling the tracker or sending an SMS message can wake it back up.
To activate;
Command: sleep+password+space+shock
Response: sleep shock ok
e.g. sleep123456 shock
Deep standby mode with shock sensor:
When activated, after being stationary for 5 minutes without any vibration or
movement, 102-NANO will change to deep standby mode with shock sensor.
GPS, GSM and led light will be OFF. Only vibration or movement can wake the
tracker back up from Deep Sleep by Shock Sensor mode. Once it’s awake, it will
automatically send a notification message to the authorized numbers. As the GPS
and GSM modules will be OFF, you won’t be able to communicate directly with
the tracker. However, if you send an SMS command, it can receive and process
this command as soon as it wakes up from Deep Sleep mode.
For constant live internet tracking (GPRS), deep standby mode with shock sensor
provides the longest battery life with a single charge as the GSM module (phone
line) will also be OFF. Please note that the auto interval setting used for live
tracking will override this the standby and keep the 102-NANO awake so GPRS
economy mode should also be activated ;
Command: sleep+password+space+deepshock”
Response: sleep deepshock ok
e.g. sleep123456 deepshock
Command: less+space+gprs+123456+space+on
Response: less GRPS on ok

e.g. less gprs123456 on
▪If there are registered authorized numbers, each authorized number will
receive a notification every time it wakes up from standby with a movement
or vibration. Please use the command below if you do not want to receive
SMS notifications whenever your tracker wakes up from deep sleep;
Command: wake+password+space+off
e.g. wake123456 off
Schedule work standby mode:
With scheduled work standby mode, 102-NANO is able to turn itself completely
off and only wake up at pre-set intervals. When it wakes up it will work for 5
minutes, report its location (SMS or internet) and switch OFF. If you are using
102-NANO in live internet tracking mode and would like to use schedule work
mode, do not forget to activate less GPRS mode as otherwise, the auto-update
interval setting will override the standby. To activate send commands below;
Command: schedule+password+space+time interval
Response: schedule ok
▪Please check below for time interval settings; m = minutes, h = hours, d = days.
Maximum schedule setting is 30 days.
▪Please check Schedule work standby mode setting examples below;
Command: schedule123456 30m - This command will set 102-NANO to stay on
standby and report its location for 5 minutes every 30 minutes.
Command: schedule123456 12h - This command will set 102-NANO to stay in
deep sleep and report its location every 12 hours.
Deep sleep / Start work at specific time mode will provide the longest standby
duration as power usage will be minimal due to both GSM and GPS modules
being on standby at all times. 2 location reports per day will provide
approximately 2-4 days battery life.

To cancel the schedule work standby mode:
Command: noschedule+password
e.g. noschedule123456
Switching standby modes OFF:
Select the sleep mode that suits you best before starting to use your 102-NANO.
Real-Time GPS Tracking consumes a significant amount of battery power and
standby duration of your 102-NANO will be reduced to 5-10 hours if there aren’t
any standby modes active. To turn switch all standby modes OFF;
Command: sleep+password+space+off
e.g. sleep123456 off
5.20 Forwarding Incoming SMS Messages
102-NANO can forward incoming messages from a pre-set number. To activate:
Command: forward+password+space+third parties phone number
Response: forward ok
e.g. forward123456 07587136846
▪Only one number can be set-up for SMS forwarding.
To deactivate:
Command: noforward+password
e.g. noforward123456
5.21 SIM Card Balance Check
Using this function tracker you can instruct the 102-NANO to send an SMS
message to a specific phone number. For instance, to send a text message to your
Sim card network provider to check the credit balance and it will forward the

received content to the authorized number.
To check SIM card balance proceed as follows;
Command: balance+password+space+carrier’s phone number+space+code
e.g. balance123456 check 0212
This function assumes that your SIM card provider network has the option where
you can check your SIM card's balance by sending a text message code to a
specific number; which is sending check code to phone number 0212 in this
example.
▪Please note – This function will only work on certain SIM card providers.
5.22 Status Enquiry
Command: check+password
Response: GSM: 100% GPS: OK/NO GPRS: ON/OFF battery: 100%. (example)
e.g. check123456
5.23 IMEI Number Request:
To request the IMEI number of your 102-NANO use the command below;
Command: imei+password
Response: 8647150022365548 (example)
e.g. imei123456
5.24 Time Setting
This setting can be used to change the time zone of your 102-NANO.
Command: time+space+zone+password+space+local time zone
