Reynolds Building Systems Best Barns Millcreek Safety guide

Manufactured by Reynolds Building Systems, Inc.
This manual is copyrighted. Under the copyright laws, this manual
may not be copied, in whole or in part, without consent from Reynolds
Building Systems, Inc. © Copyright 2011
12'x 20'
Assembly Book
Best Barns USA
the Millcreek
205 Arlington Drive Greenville, PA 16125
Revised July 22, 2021

When measurements are given for a board
length or width, it is from the longest side.
measure from here
Tool List
Hammer & Hand Saw
Framing Square & Level
Power Circular Saw
Power Drill/screwdriver
Measuring Tape
2-8' Step Ladders
Always wear safety glasses when cutting ornailing!
IMPORTANT INFORMATION ABOUT YOUR SHED KIT
To identify which edge we want you to use,
we will refer to the edge as either the 'LAP'
Edge or the Tongue Edge.
Tongue Edge
LAP Edge
Download the most current instruction book at www.barnkits.com; use the "manuals"
link on the menu bar and then select your building kit and size.
Thank you for purchasing our shed kit. Read the instructions before starting the assembly
of the building. If you have any questions about assembling the kit, call 800-245-1577.
Business hours (8:00-5:00 ET) Monday thru Friday.After business hours call 724-866- 4357.
or email to [email protected].
The material that is included in our kit is listed on the back page. The optional floor package,
if purchased, will be supplied by a local lumber supplier.
Our kit does not include the shingles, the quantity needed is listed on the back page. The
siding is primed. You will need to apply a finish coat using latex acrylic paint.
Some of the framing lumber was used in the shipping pallet. Unpack the material from the
pallets. Unscrew the OSB panels and the 2x4s from the shipping pallet. The 2x4s will be
used for wall bracing and to support the loft beams. The bit for the screws is packed in the
hardware bag.
Most buildings are installed on a wood floor and the siding was designed to extend over the
wood flooring. If the foundation is a concrete floor cut the siding flush with the bottom of
the wall plate to prevent the concrete from contacting the siding.
Stacking the boards, according to size, will make them easier to find when needed. Do Not
discard any material until your building is complete.
Before you begin construction, be sure to study this assembly manual.Also, obtain a building
permit and check all pertinent building code regulations for your area.
Thank you for your purchase.

1. Stagger the 4x4 timbers as shown below. Cut (2) two 2x4- 8' boards into 2' long blocks
to secure the 4x4s where they butt together.
Assembly Instructions for
Rear Floor Section
4. Install the floor joists cut above between the 8' joist headers. Secure with 16d galv. deck nails.
5. Place floor assembly over the 4x4s. Square floor assembly. Measure the floor diagonally
(corner to corner) and then the opposite corners; these measurements will be the same when
the floor is square. Toenail frame (headers & joists) to the 4x4 runners.
2. Cut (2) two 2x4-8' to a length of 8' -0". They
will be used for the joist headers. Layout, from
left, for 16" on center joist spacing. 'X' marks
where floor joist will be placed.
6. Cut (2) two 2x4-12' to a length of 12' -0". Layout
for 16" joist spacing, See above.
7. Install floor joists between the joist headers. Square
the floor section and install against the section
assembled above. Toenail to the 4x4s runners.
8. Install 4x8 flooring over the 2x4s Use 8d galv.
spiral floor nails spaced 8" apart.
Material Description 12' x 20'
2x4 Treated Blocking 2 pcs. 8'
2x4 PT Joist Headers 2 pcs. 8'
2x4 PT Joist Headers 2 pcs. 12'
2x4 PT Floor Joist 17 pcs. 12'
4x4 Treated Runners 4 pcs. 8'
4x4 Treated Runners 4 pcs. 12'
Flooring 5/8" or 3/4" 8 pcs. 4x8
Galv Spiral Floor Nails 3 lb. 8d
Galvanized Deck Nails 5 lb. 16d
Foundation size is 12'-0" x 20'-0". Check local building codes in your area, the construction may
have to change. For a concrete slab, install sill sealer as a moisture barrier between the concrete and
the wall plates. Foam sill sealer can be purchased at home centers in rolls 3-1/2" or wider.
Constructing Details for Deluxe Floor System
Deluxe floors include 4x4 runners, standard floors do not.
3. Cut (17) seventeen 2x4-12' treated boards to 11' -9". These will be the floor joists. Treated
lumber may be thicker than 1-1/2". Take this into account when cutting the length of floor
joists. Shorten joist measurements if necessary to obtain 12'-0" building width.
XXXX
XXXX
X
X
15-1/4" 16" 16"
4x4-8' Treated
Runner
4x8 Flooring
2x4-8' Joist Header
4x4-12' Treated
Runner
4x4-8' Runner
4x4-12' Runner
4x4-12' Runner
Front Floor Section
::
:::
:
:::::::
.
.
.
.
...
...
.
.
.
......

2. Repeat to assemble a second Gable Plate.
72" Long 2x6 w/ Notch
72" Long 2x6 w/ Notch
72" Long 2x6
without notch
36" Long 2x6 w/ Notch
36" Long 2x6
w/ Notch
GLUE
4. To provide additional strength, install (2) two rows of 2-1/2" wood screws spaced 16" apart
as shown below.
5. Repeat steps to assemble a second Loft Beam.
Step 2 Assemble Gable Plates
1. Butt (2) two 72" long 2x4s together and secure them by nailing a 3-1/2" x 42-3/4" long
plywood gusset across the top where they butt together. The gusset needs to be centered on
the 2x4s (approximately 50-5/8" of the 2x4s will be exposed on each side of the gusset).
Use wood glue and (2) two rows of (10) ten 6d common nails to secure the gusset.
Step 1 Assemble Loft Beams
1. Locate (2) two 36" long 2x6 boards with a notch on one end and a 2x6 board without a
notch. Position these 2x6 boards on a flat surface as shown below.
2. Apply a coat of glue with a brush to the top surface.
3. Locate (2) two 72" long 2x6 boards with a notch on one end. Install these 2x6 boards
over the bottom boards as shown.
72" long 2x4
3/4" Plywood Gusset
2x6 Beam
16" 16" 16"

4. Secure the 2x4s at the peak with a 12" x 32" wood gusset. Apply wood glue with a brush
between the gusset and truss and nail with (25) twenty-five 6d common nails evenly spaced.
5. Turn the truss over and install a gusset to the other side of the truss.
6. Repeat this process to assemble (8) eight more trusses.
32" Top Gusset
1. Position a Gable Plate (from Step 2) on the floor with the narrow edge side down.
2. Position (2) two truss halves (2x4s connected with a metal plate) with the short legs against
the end of the 2x4 Gable Plate Assembly. DO NOT attach the Gable Plate Assembly to the
truss. It is temporarily used to help hold the 2x4 truss parts in place and will be attached in a
later step. See detail below.
3. There are short 2x4s, that may have an angle on one or both ends. Use these as a jig to hold
the truss halves and gable plate together by temporarily screwing or tack-nail blocks to floor.
This will ensure that the trusses and gable ends are identical.
Do Not Fasten Truss Legs to Gable Plate
Step 3 Assemble Trusses
Truss Half
Metal Plate
2x4 Block
Gable Plate
2x4 Block
Gable Plate Assembly
Short Leg

:
DO NOT use trusses or pre-pressed truss halves for roof gables
1. Place (2) two 61" and (2) two 34-3/4" long 2x4 gable rafters in the truss jig and secure together
with 1"x4" drive-on metal plates.
2. Butt (2) two 40-3/4" long 2x4s against the wood gusset. Nail the bottoms of the 2x4s through
the Gable Plate with (2) two 10d sinkers. Secure the tops with a 1"x4" drive-on plate.
3 Locate a 50" long 2x4 with a double angle on one end and cut to fit between gusset on Gable
Plate and peak of gable. Nail through Gable Plate and plywood gusset with (2) two 10d sinkers.
Secure the top with a 9" x 12" wood gusset. Use (10) ten 6d commog nails.
4 Install (2) two 30-3/4" long 2x4s with barbed plates and nails.
5. Nail truss legs to Gable Plate with (2) two 10d sinkers.
30-3/4" Long 2x4
2x4 Cut to Fit
40-3/4" Long 2x4
9" x 12" Wood Gusset
Step 4 Assemble Roof Gables
If you want to install the loft doors and trim as a
decorative plant (not operating) repeat the above steps.
If you want the loft doors to open, repeat steps 1-6
substituting number step 3 with directions below.
3. Cut a 50" long 2x4 board to fit
between the 40-3/4" boards and
install in the opening 32" from top
of plywood gusset. Secure with
1"x4" metal barbed plates.
6. Position 2nd gable plate and repeat steps to assemble the front roof gable. Read note below:
32"
1"x4" Drive-on Plate
Remove temporary 2x4 blocks

.
.
.
.
.
.
.
..
.
..
.
Building Tip: Gather all pre-cut gable siding and position them on
gable frames before nailing.All siding should extend 3/4" below Gable
Plate. If siding extends above frame cut siding flush with frame.
1. Select a siding panel with a 'Tongue' edge and install on right side of gable. Before you install
the center siding panels ,lay them on the frame and trace the top and side of the door opening
on the siding panels. Cut panels from bottom of siding to top of door opening. Save these
pieces to be installed on loft doors below.
Step 5A Apply Siding to Rear Roof Gable
2. Select the siding panel with a 'Tongue' edge
on right side. Install this panel on left side of
gable. Use 6d galv. nails spaced 8" apart.
The rear gable trim can be
installed now or in Step 18B.
Step 5B Apply Siding to Front Roof Gable
Siding Extends
3/4" Below Plate
'Tongue' Edge
'LAP' Edge
2. Install (2) two 61" long 2x3 boards with
blue marking at peak of the gable. Install
2x3 flush with gable frame. Use 10d
sinkers spaced 6" apart.
4. The loft door frames are temporarily held together with
corrugated fasteners. Place the doors on level surface
with fasteners facing up. Re-cut the siding from step 1
to the size of the door frame. Place primed side down
and secure the siding panel to the frame with 1" screws.
Set doors aside. They will be installed in a later step.
61" Long 2x3
Blue ends
3. Install (2) two 42-1/2"
long 2x3s.
Use 10d sinkers.
First End Panel
Tongue Edge
3. Continue to right side with pre-cut
siding panels.
1. Select rear gable and turn frame over.
If you are installing the loft doors and trim as a decorative plant (not operating)
install the siding as done above but starting from right side rather than from
left side. Skip to steps 2 and 3 below.

Cut the siding flush with the
bottom plate if installing the
building on a concrete slab.
AB
X
X
X
XXX
XX
X
X
C
72" Wall Plate
48" Wall Plate
:::::::
.
.
.
Step 6A Assemble 10' Side Walls
4. Square wall frame. Measure diagonally (corner to corner); the measurements will be the same
when the wall is square.
5.
Cut one of the 48" wide siding panels in half lengthways. Select the half, with the 'tongue'
edge, and install this panel with the 'cut' edge flush with the end of the wall and extending 3/4"
below the bottom plate. Use 6d galvanized nails spaced 8" apart. LAP edge panel will be used
in next step.
6. Install (2) two more siding panels.
Siding Extends 3/4" Below Plate
LAP Edge
1. Position (2) two 2x4-48" boards and (2) two 2x4-72" boards together and indicate with 'X'
marks where the wall studs will be located. Mark the ends that will butt together with the letters
'A' and 'B'. Mark right side end with a 'C'. This will be referenced in a latter step.
2. Install (7) seven 80-1/4" long wall studs between the wall plates. Use (2) two 10d sinkers
at each end of stud. Nail the frames together with (4) four 10d sinkers on each side.
3. Repeat to assemble (3) three more 10' long side wall frames. You will need to cut (2) two
64" long 2x4s to a length of 48" to assemble the last 48" wall frame.
7. Select (1) one of the 10' wall frames and repeat steps 4-6 to apply siding.
24"
23-1/4"
72" Wall Plate48" Wall Plate
23-1/4"
Cut Edge
Tongue Edge
C
AB
B
A
C
B
A

4. Repeat to apply siding to the other 10' wall frame.
Step 6B Assemble Side Walls for 20' Building Length
1. Select one of the 10' side walls with siding. Butt a 10' wall frame against this wall with
the 'C' marks together. Do Not nail these frames together so they can be separated later.
10' Wall Panel from Step 5
72" Wall Plate
2. Square the wall frame. Install a full width siding panel using 6d galvanized box nails spaced
8" apart. Do Not nail along the long edge that overlaps the sided wall frame. You can nail
this edge after the wall panels are installed. This will enable you to separate the wall panels
making them easier to handle.
Do Not Nail Along This Edge
LAP Edge
48" Wall Plate
3. Install another full width siding panel and
a 2' wide siding panel with 'LAP' edge.
CC
LAP Edge

3. Square wall frame. Measure diagonally (corner to corner); the measurements will be the same
when the wall is square.
4.
Install the 1st siding panel with the 'LAP' edge extending 3-1/2" past the wall frame. Use 6d
galvanized box nails spaced 8" apart. The bottom will extend 3/4" below the bottom plate, or
trim flush for cement slab.
5. Install (2) two more siding panels. Cut the last panel to extend 3-1/2" beyond the wall frame.
A
AB
B
XX
XX
X
X
X
X
X
X
X
X
Step 7 Assemble Back Wall
1. Position (4) four 68-1/2" 2x4 boards together and indicate with 'X' marks where the wall studs
will be located. Mark the ends that will butt together with the letters 'A' and 'B'.
2. Install (8) eight 80-1/4" long wall studs, between the wall plates, over the 'X' marks and where
the plates meet. Use (2) two 10d coated sinkers at each end of a stud. Nail wall sections together
using (4) four 10d coated sinker nails, on each side of the studs.
Siding to extend 3/4”
below bottom plate
LAP
Edge
A
B
Siding Extends 3-1/2"
Past 2x4 Stud
:
80-1/4” Wall Studs
68-1/2" Wall Plate
:
:
:
:
:
:
:
AB
68-1/2" Wall Plate
23-1/4"
68-1/2" Wall Plate
19-3/4" 24" 24"

If you want the barn doors in the center of the front wall, go to Step 9B.
:
:
:
:
:
:
75" Long 2x6
OSB Filler
3. Go to Step 10A.
3. Go to Step 10B.
XXX
X
19-3/4"
32-1/2"
2x4 - 68-1/2
Boards
2x4 - 6' Board (Door Spacer)
19-3/4"
....
...
Step 8 Assemble Door Header
Assemble door header using (2) two 75" long 2x6 boards and a 75" OSB filler
panel. Apply wood glue with a brush between OSB and boards. Nail header
together with 10d coated sinkers. Use (12) twelve nails on each side.
19-3/4"
24"
Bottom Wall Plate Assembly
Step 9A Assemble Bottom Wall Plate (doors offset)
Step 9B Assemble Bottom Wall Plate (doors centered)
56-1/2" To Door Spacer
Door Spacer
1. Butt (2) two 68-1/2" boards together to make bottom wall plate. Secure bottom plate with
a 2x4-6' board (used as door spacer) installed 56-1/2" from the end of the 2x4 wall plate.
Secure with (4) four 2-1/2" wood screws.
2. Mark with an 'X' mark where wall studs will be located.
1. Butt (2) two 68-1/2" boards together. Center a 2x4-6' board (used as door spacer) on top and
screw the boards together using (4) four 2-1/2" wood screws.
2. Mark with an 'X' mark where wall studs will be located.

2x4-6' Door Spacer
36"
Optional windows can be installed now or later.
Check measurements. They
should be the same or the
door opening will not be square!
Step 10A Assemble Front Wall (doors offset)
To install doors offset to the left, flip wall before applying the siding.
5. Install a 12" siding panel with a 'LAP' edge and a full width siding panel on the left side of
door (right side if installing door on left). The cut edge on the 12" siding should be flush with
the door opening and the full width sding should extend 3-1/2" past the frame. Siding should
extend 3/4" below bottom plate. When both panels are positioned nail to frame.
6. Install (2) two 7-3/4" high pre-cut siding panels over the door opening. The siding should
extend 3/4" below the door header.
LAP
Edge
Butt Square Edges
Together
LAP Edge
3/4" Below Header
12" Siding Panel
Cut Edge
12-3/4"
Siding Panel
Siding Extends
3-1/2" Past 2x4 Frame
2x6 Door Header
68-1/2' Top Wall Plates
1. Gather the material listed below to assemble the door wall.
2. Install (4) four 80-1/4" wall studs over the 'X' marks using 10d sinkers.
Wall Studs with Door
Jacks Attached
3. Install pre-built studs with
the door jacks attached to
either side of the door spacer.
4. Install door header on the
door jacks. Use 10d sinkers.
7. Install a 12-3/4" wide siding panel on the end of the
wall frame. The siding will extend 3-1/2" beyond
the 2x4 wall frame.
!
2 68-1/2" Wall Plates
4 80-1/4' Wall Studs
2 80-1/4' Wall Studs
w/ door jacks attached
1 Door Header from Step 8
1 Bottom Plate from Step 9A
Material List
!
!

2x4-6' Door Spacer
!
!
Check measurements. They
should be the same or the
door opening will not be square!
!
!
Step 10B Assemble Front Wall (doors centered)
2x6 Door Header
Siding 3/4"
Below Header
Cut Edge
Tongue Edge
Cut Edge
Butt Square Edges
Together
5. Locate a 12" siding panel that has a 'LAP' edge. Position the 'cut' edge flush with the left side
of the door opening. Do Not nail the 'LAP' edge until the other siding is applied.
6. Cut a full width siding panel in half lengthways. Select the siding with the 'tongue' edge and
install this at the left end of the wall frame. Siding should extend 3-1/2" past the frame.
7. Install (2) two 7-3/4" pre-cut siding panels over the door opening. Siding should extend 3/4"
below header.
8. Install a 12-34" siding panel with the 'cut' edge flush with the side of the door opening.
9. Install the last siding panel. It should extend 3-1/2" beyond the 2x4 wall frame.
LAP Edge
LAP Edge
12" Siding Panel
12-3/4"
Siding Panel
Siding Extends 3-1/2"
Past 2x4 Frame
Wall Studs with Door
Jacks Attached
68-1/2" Top Plate
2x4 Bottom Plate w/ Door Spacer
2 68-1/2" Wall Plates
4 80-1/4' Wall Studs
2 80-1/4' Wall Studs
w/ door jacks attached
1 Door Header from Step 8
1 Bottom Plate from Step 9B
Material List
1. Gather the material listed below to assemble the door wall.
2. Install (4) four 80-1/4" wall studs over the 'X' marks using 10d sinkers.
!
3. Install pre-built studs with
the door jacks attached to
either side of the door spacer.
4. Install door header on the
door jacks. Use 10d sinkers.

There are (2) two 2x4s that are screwed to each pallet. Unscrew these 2x4s and use (2) two
of the 2x4s as braces to hold the walls straight. The other 2x4s will be used later.
Step 11 Set Walls
Layout both beams for the spacing of the loft floor joists.
The 'X' marks where the floor joist will be placed.
Step 12 Layout Loft Joist Spacing on 2x6 Beams
Nail Along
Siding Edge
Front Wall Frame
2x4 Wall
Brace
23-1/4"
24"
24"
10' Long Rear
Wall Panel
1. Set the back wall panel between (2) two 10' long side walls. Position the 'C' mark toward front
of building. Secure wall panels together at the corners using (4) four 10d sinkers per corner.
2. Install the next (2) two side walls with the 'C' mark towards back of building.Nail with 10d
sinkers. Nail siding edge where panels overlap.
3. Install front wall between the side walls. Nail along the siding edge where the side wall siding
panels overlap.
4. Unscrew and remove the 2x4 door spacer (this will be used later). Cut and remove the
bottom 2x4 in the door opening. Secure walls to floor using 10d sinkers or concrete
anchor bolts (not supplied).

2. Use the beam as a reference to mark
where the floor joist will be placed.
The 2x4 floor joist, when installed,
will be aligned with the wall studs.
1. Install the rear 2x6 beam 84" from the 2x4 joist header boards with the 'X' marks on the beam
facing the back wall. Use a 2x4-7' board as a gauge to properly space the beam. Refer to Step
15 to see how the loft floor joists will be installed. Place the notch under the top plate and
secure with a 2-1/2" wood screws through the top of the wall plate.
2. Remove 2x4s used to brace walls and gather the (2) two 2x4s removed from pallets. Cut (2)
two boards to fit under beam. Toenail to beam with 10d sinkers.
Step 14 Install 2x6 Loft Beams
3. Repeat to Install the other beam with the 'X' marks on the beam facing the front wall. When
the front beam is installed there will be 56" between the beams
Step 13 Install Loft Floor Joist Headers
1. Install (2) two 68-1/2" long 2x4s on the back wall to support the floor joists. Install the 2x4s
flush with the top of the 2x4 wall plate. Secure to wall studs and top plate with 10d sinkers
spaced 4" apart.
68-1/2" Long 2x4
3. Repeat to install joist header support boards on the front wall.
:
:
......
2x6 Beam
2x4 Board Cut to Fit
Back Wall
84" to 2x4 Joist Header
.

2x4 Hanger
Cover 'X' Marks on
2x6 Beams
Step 16 Install Loft Flooring
Install 84" long 2x4s between the front and
rear beams and the 2x4s joist headers. Install
2x4 hangers with 10d sinkers.
1. Install 7/16" OSB loft flooring on back loft floor joists. Loft flooring should be flush with
outside of top wall plates. Use 6d common nails spaced 8” apart. See layout pattern below:
2. Repeat to install loft flooring at the front of the building.
3. Install 3-1/2" x 56” floor fillers on top of side wall plates between the loft flooring.
4’x6’ Flooring
44"’x 6’ Flooring
4’x6’ Flooring
44"x 6’ Flooring
3-1/2" x 56" Filler
Step 15 Install 2x4 Floor Joists

1x4 84-1/2" Corner Trim
Side Wall
1x4 72" Top Trim
Cut to Fit
........
Back and Front Walls
.
.
.
.
.
.
Step 17 Install Wall Trim
1. Install (2) two 84-1/2" long 1x4 corner trim boards on the back wall, flush with the siding on
the side walls and flush with loft flooring. Use 6d galvanized box nails spaced 12" apart.
2. Install (2) two 1x4-72" trim boards between corner trim and flush with the top of the loft
flooring. Cut last board to fit. See diagram below.
3. Repeat for front wall trim.
Step 18A Set Rear and Front Gables
WARNING: The gable ends are heavy
and awkward. You'll need helpers to lift
and set gables in place.
1. Install the rear gable on the rear wall. The
siding on the gable must extend over the 1x4
trim board, not behind it. See detail 'D' on
next page. Nail bottom gable to loft flooring.
Use 10d sinker nails spaced evenly in space
between studs.
1x4 Trim
Loft Floor
flush

DETAIL 'D'
:
::
:
:
:
:
:
:
:
:
1x4 Trim
Step 18B Set Rear and Front Gables (continued)
2. Install (2) two 61" long 1x4 gable trim flush with the top edge of the gable. Install the
ends with blue marks together. Install trim with 6d galvanized nails spaced 12" apart.
3. Install (2) two 42-1/2" long 1x4 gable trim
flush with the side edge of the gable.
4. Install the front gable. DO NOT apply trim.
Trim and overhang are installed in a later
step.
1x4 Trim
Bottom Edge of Gable Siding
Overlaps Top Wall Trim; nail
with 6d galvanized box nails.

.
.
.
.
.
.
.
.
24"
18-3/4"
Rear Gable
Measure from Face
of Gable Plate
:
:
:
:
Step 19 Install 2x4 Truss Plates
3. Layout the truss spacing. Measure from the inside face of the 2x4 gable plate to mark the
location of the first truss. The last truss space will be more than 24".
Important: When marking the opposite wall, place the 'X' mark on the same side of the line
so your trusses are parallel when they are installed.
1. Install a 64" long 2x4 truss plate against the rear gable
and flush with outside edge of wall plate, followed by
a 72" truss plate. Install another 64" long 2x4 truss plate.
Cut a 48" long 2x4 truss plate to size and install. Use
10d coated sinker nails spaced 16".
2. Repeat to install truss plates on the opposite side.
64” Truss Plate
72” Truss Plate
Rear Gable

1. Place trusses over the 'X' marks and secure
trusses to 2x4 truss plate using 2x4 hangers and
10d sinkers.
2. Locate 65-1/4" long soffit boards that have a
beveled edge. Install one of these boards flush
with the top of the siding and butting against
the rear gable trim. Secure soffit boards to the
top wall plate with 3" long screws spaced 8"
apart. Cut to fit and install a 48" soffit board
to fit behind 2x3 boards on the front gable.
Step 20 Install Trusses & Soffit Boards
Step 21A Install Roof Sheathing
1. Install a 42" x 72" OSB roof panel flush with
the face of the rear gable trim. Use a straight
edge to align the top of the sheathing with the
top of the truss. Continue adding sheathing
following the layout on the next page. OSB
will extend past front gable. Use 6d common
nails, spaced 6" apart.
2. Repeat step for opposite side.
Straight Edge
To prevent the nails from protruding
through the bottom of the soffit board,
nail at an angle when nailing roof
sheathing to the soffit boards.
Metal Truss Hanger
Soffit Block Flush With Siding
3. Repeat to install soffit boards on
the opposite side.
