RFoG RF-ENCO-IP-HDSDI-35 User manual

Dwustrumieniowy enkoder HD-SDI na IP
z obsługą OnVIF 2.0
RF-ENCO-IP-HDSDI-35
User Manual ver.2.0

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
2/67
Safety Precaution
Make sure to turn off the power before installing video server.
Do not install under the direct sunlight or in dusty areas.
Make sure to use the product within the temperature and humidity specified in the
specification.
Do not operate the product in presence of vibrations or strong magnetic fields.
Do not put electrically conducting materials in the ventilation hole.
Do not open the top cover of the products. It may cause a failure or electric shock on the
components.
To prevent from overheating, make sure to keep the distance at least 10cm from the
ventilation hole.
Make sure proper voltage before connecting the power.
We appreciate your purchasing video server.
Before installing the product, please read the following with care.

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
3/67
Table of Content
1. Introduction...................................................................................................................................4
About this manual.......................................................................................................................4
Features.....................................................................................................................................4
Product and Accessories............................................................................................................5
System Connections ..................................................................................................................8
2. Installation ..................................................................................................................................10
3. System Operation.......................................................................................................................14
Remote Video Monitoring.........................................................................................................14
Initialization of IP address.........................................................................................................14
4. Remote Configuration.................................................................................................................18
Video & Audio...........................................................................................................................19
Image.......................................................................................................................................23
Network....................................................................................................................................24
Event........................................................................................................................................36
Record .....................................................................................................................................40
Device......................................................................................................................................46
PTZ..........................................................................................................................................47
User .........................................................................................................................................51
System.....................................................................................................................................53
5. Appendix.....................................................................................................................................55

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
4/67
1. Introduction
About this manual
This User Manual provides information on installation setup and operation of the video server, as well as
troubleshooting tips. .
Features
Video server is a video and audio transmission system that provides broadcast quality audio and video, based
on IP network through LAN and ADSL/VDSL. video server can operate in an Encoder mode or a Decoder
mode. Encoder system compresses media data and transmits them, while Decoder system receives and
decompresses them.
Video
- Up to 1920x1080 @ 60 fps
- Highly efficient compression algorithm, H.264 & MJPEG support
- Wide range of transmission rates: 32kbps ~ 16mbps
- Various transmission modes: CBR, VBR
- Motion detection
Audio
- Multi-Transmission Mode : Unidirectional Mode (IP-server to Client PC or Decoder / Client PC or Decoder
to IP-server), Bi-directional Mode
Network
- Fixed IP & Dynamic IP (DHCP) support
- 1:1, 1:N support
- Multicasting
- Automatic transmit rate control according to network conditions
- OnVIF, PSIA compliant
Serial Data
- RS-485 support
- Data pass-through mode : Serial data communication between IP camera and Decoder
- Data pass-through mode : Serial data communication between Encoder - Decoder
Sensor and Alarm
- Support direct connections of external sensor and alarm devices
- Event Alarm

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
5/67
USB
- Connection to internal or external USB storage for remote access, recording and playback
User Interface
- Diagnose and upgrade through dedicated program called True Manager
- System configuration using Internet Explorer
High Reliability
- Reliable embedded system
- System recovery by dual watch-dog functions
Product and Accessories
video server
Quick Manual
Power adapter and Cable
S/W and User CD
Screws
Brackets

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
6/67
Part Names and Functions
Front View
No.
Parts
Function
①
LED
Display system status
②
Audio Input
Audio Input
③
Audio Output
Audio Output
④
HDMI Input
HDMI Video & Audio Input
⑤
HDMI Output
HDMI Video & Audio Output
⑥
USB Port
USB 2.0
⑦
Ethernet/802.3af
1000/100/10MB Base-T Ethernet
⑧
Reset Button
Initialization of network setting
⑨
Sensor
Sensor Input
⑩
Alarm
Alarm or Relay Output
⑧
⑨
⑥
⑦
⑩
③
②
⑤
④
①

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
7/67
Rear View
No.
Part
Function
①
Power
DC +12V power input
②
RS-422/485
Serial port for PTZ control and etc
③
RS-232
Serial port for PTZ control and etc
④
Composite In/ Output
Composite Video Input / Output
⑤
3G/HD/SD-SDI In/Output
3G/HD/SD-SDI Video & Audio Input / Output

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
8/67
or
or
or
System Connections
Video server operates as one mode; Encoder. Video server systems can be connected in either 1-to-1 fashion
where one encoder is connected one decoder or 1-to-many fashion where one encoder connected to many
decoders.
Following chart shows data status of video, audio and serial data.
System Mode
Video
Audio
Serial Data
Encoder
Transmit
Transmit
Transmit/Receive
The system mode is defined by the video communication and the system mode is capable of single directional
transmission of audio and bi-directional of serial data.
Topology
Generally, the encoder and a decoder are connected in 1-to-1 mode. To support specific situation, 1-to-
multiple connection is also supported.
1:1 Connection (Unidirectional Transmission).
The most commonly used configuration is 1 to 1 connection. An encoder is installed at a site where video
images can be transmitted and a decoder is installed at a center location to receive and view the video
images on monitors. Audio and serial data are transferred in either direction.
A decoder and encoder can be connected by setting the encoder’s address at the decoder’s remote IP
1:N Connection (Unidirectional Transmission).
Site
Remote Center (Decoder)
Remote Center
Site
Remote Center

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
9/67
In this configuration, a site can be monitored from many remote center locations. Maximum connections would
be limited by the network bandwidth.
Functionally, the VMS (Video Management System) software can replace the decoder.
Multicast Mode
In the network supporting multicast mode, if Multicast is setup as a system protocol, you can use bandwidth
efficiently regardless of the number of decoders. In 1:N connection, a large number of decoders can receive
audio and video data from an encoder by using a single streaming transmission.
Relaying
In this arrangement, video and audio can be retransmitted from a center to another center. The arrangement
is useful when the network bandwidth at the site is limited while there is more than one center wanting to
monitor the site.
VMS(Video Management System)
VMS (Video Management System) is a Windows based remote monitoring program to access multiple
encoders for real-time monitoring or control of the encoders and connected cameras. Please refer to VMS
User Manual for more information on VMS.
Site
Center 1(Decoder)
Center 1(Decoder)
Site
Remote Center
Site
Remote Center (Decoder)
VMS

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
10/67
2. Installation
Connecting Video
- Encoder System
Connect camera video output line to the encoder (video server) video input port.
- Connecting with Megapixel Camera
Connect a camera which supports HDMI or 3G/HD-SDI output to the HDMI or 3G/HD-SDI Input port of
video server accordingly.
- Connecting with D1 resolution Camera
Connect a camera to the Video Input port of video server accordingly.
Connecting Audio
It is possible to set the mode as Tx-only or audio off.
- Connect audio input and output ports to audio devices accordingly.
- The Audio signal required is line level, so audio equipment with an amp, mixer or other amplifier should
be used.
Connecting Serial Ports
For camera control, PTZ controller (keyboard) and receiver can be connected to serial ports. Two
corresponding serial ports in encoder and decoder which are connected in connected in 1-to-1 fashion works
in pass-through mode. This means that commands at a local system’s COM1 port will be transparently passed
to the remote system’s COM1 port. Also, a command at a local system COM2 port will pass to the remote
system’s COM2 port.
Connecting Sensor and Alarm
Connect sensor and alarm devices to corresponding terminals accordingly.
Connecting Power
After confirming the power source, connect power adaptor and connect the 12VDC connector to the system.
Check if it Works
Once the power is supplied to the camera, it will start booting. The system will boot up to an operating mode
after approximately 40-60 seconds. The green LED on the Ethernet port will flash indicating the system is
ready.
Software provided on the disc called True Manager allows you to check the IP address and other network
details of the camera. Please refer to the True Manager manual for instructions on how to find the IP address

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
11/67
of the camera and if required changing it.
- Encoder LED Display
These LEDs show that the camera is connected but a decoder is not connected.
Once the encoder is connected to a decoder, color of “LINK” LED will turn into green color and “ DATA” LED
will blink as video or audio transmissions occur
PWR
STATUS
LINK
DATA
OFF
Red
Green
Blinking
OFF

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
12/67
- Description of LED
System status can be monitored with LED display
LED
State
Description
PWR
Off
Power off
Red
Power on
STATUS
Green
blinking
Normally operating
Red
System failure: Needs diagnostics
LINK
Off
No connection to remote system
Green
Connected to a remote system
Red blinking
Decoder only: trying to connect to an Encoder
Orange
Illegal connection (unsupported combination of system
modes)
DATA
Green
Data transmission in progress
Red
Data loss
Off
No data transmission

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
13/67
3. System Operation
Remote Video Monitoring
There are two ways to monitor video when the center system and IP camera are connected. In order for a
proper operation, an IP address must be set accordingly. Please refer to True Manager Manual
enclosed with product for further details.
Default ID : admin
Default Password :1234
Video Monitoring using Internet Explorer
Open Internet Explorer and enter camera’s IP address. The system will ask for confirmation to install
Active-X control. Once authorized, the Internet Explorer will start to display video images from camera as
shown below.
Defalut IP Address : http://192.168.10.100

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
14/67
Video Select
Select the Video stream to be viewed : Primary, Secondary, tertiary or quartic streaming.
This camera is capable of dual streaming; primary streaming and secondary streaming..
Video will be displayed according to the resolution set on video configuration. If dual streaming (“Use
Dual Encode” Menu in Video page) is not activated, secondary video is not available
View Size
Adjust the size of the screen.
Screen size if initially adjusted according to the compression resolution. Click on 50% icon and the whole
screen size will be reduced to half size.
Digital Zoom
Control the Digital zoom on the screen
The more the camera zooms in, the smaller the square of control panel is. Position of the image can be
changed by moving position of the square. If you press x1, the screen will return to the normal size.
PTZ Control (Optical Zoom & Digital Zoom Built-in the Camera)
Control PTZ and PTZ Control Panel is used for controlling external PTZ devices when the external PTZ
devices are connected through serial port. It is possible to make zooming control by Zoom in/out buttons

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
15/67
of PTZ control Panel (In order to use digital zoom, select Digital zoom ON in the Camera tab)
- Stop
Stop on-going action
- Focus Near, Focus Far, Auto Focus
Adjust the focus of the lens
Select Preset
Set preset position and move to the specific preset position.
- Goto
Move to the selected preset entry if the preset entry is set.
- Set
Set the current position to the selected preset entry.
- Clear
Delete the selected preset entry.
Sensor Input and Alarm Output
Display the status of the sensor in real time.
This camera supports one sensor input. When the sensor of the camera is working, the sensor light turns
red Operate the alarm device by pressing the number icon. This camera supports one alarm output. A
number icon indicates status of the alarm device.
Snapshot
Capture video images and store them as BMP or JPEG files.
Talk
Transfer audio from PC’s mic to the camera.
File Record

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
16/67
Recording to an AVI file on Live View page is available. AVI files are generated in the specified folder or in
a specified file name on the PC where web browser is running.
1. Press “Set” button to select a folder or create a new folder. Enter the file name on a filename field.
2. Press “Start” button to start recording.
3. Press “Stop” button to stop recording.
4. An AVI file named “IP address_hh_mm_ss” or “File name_IP address_hh_mm_ss” will be generated in
the specified folder depending on where the path specified folder
or a prefix of the file name.
Display Buffer
Set the number of video frames to be buffered before being displayed on web browser. Larger value
results in smoother video by sacrificing the latency. A setting of 10 ~ 15 frames can be used generally for
most situations.
Video Monitoring with Decoder System
Once camera’s IP address is set in the remote IP address section of the decoder, the decoder system will
connect to camera and start receiving the video images. Normally, a monitor connected to the decoder
will display video images
Initialize of IP Address
If a system IP address is lost, the system can be reset to the system default IP address using the reset
button in the back side of the system.
1. While the system is in operation, press the reset button for more than 5 seconds.
2. The system will reboot automatically.
3. Once the system reboots, IP address will be set to the system default as below;
IP mode
Fixed IP
IP address
192.168.10.100
Subnet mask
255.255.255.0
Gateway
192.168.10.1
Base port
2222
HTTP port
80

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
17/67
4. Remote Configuration
Using Web Browser
Remote setting is available by using web browser. Enter IP address of camera and then a live view
screen appears as below. Press Setup button located in the upper right area of the monitoring screen to
go to the server setup. For Remote Setting, user should be authorized higher than manager level.
The configurations are grouped into 9 categories: Video & Audio, Image, Network, Event, Record,
Device, PTZ, System, User. Leaving the page without pressing Apply button, any changes in the page
will be discarded.
Enter IP Address
Press Setup button

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
18/67
Video & Audio
Information
The information provides current information regarding the settings for video and Audio

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
19/67
Encode
- Performance Calculation
Shows the performance usage rate according to the value set at ‘Encode’ mode underneath.
- Input Format
Choose the input format from the list.
- Video Input Auto Detect
Choose the Auto Detect mode. If it is Full Auto Mode, it will be displayed automatically.
If it is Semi Auto Mode, user should select Input format.

RF-ENCO-IP-HDSDI-35 User Manual
P.H.U. RFoG Tomasz Paszkowski, ul. Starogrodzka 1/2, 72-300 Gryfice,
NIP:857-115-72-13, REGON 811833063, tel. [phone]
20/67
- Resolution
Select video encoding solution.
Scaling option is used when encoding resolution is different from input resolution. Without Scaling
option, input video will be cut according to encoding resolution. On the other hand, if Scaling is
selected, input video will be adjusted according to encoding resolution.
- Framerate
Determine the maximum number of frames per second for the video stream.
1,2,3,4,5,6,8,10,15,20,25,30 and 60 frame rate can be selected. The actual frame rate of video can
be less than the maximum frame rate set due to the network bandwidth limitation
- Preference
Select encoding mode to control video quality or bitrate: Quality(VBR) or Bit rate(CBR). If ‘Bitrate’
selected, the video encoding will be effected by the ‘Bitrate’ value entered. Therefore, “Bitrate” mode
corresponds to CBR (Constant Bit rate) encoding. If ‘Quality’ selected, the video encoding will be
effected by the quality of image selected. Therefore, “Quality” mode corresponds to VBR (Variable Bit
Rate) encoding.
- Quality
Select Video quality. 7 levels of quality are available.
Quality mode (VBR encoding) tries to encode every frame in a constant quality. Therefore, resulting
bitrate may vary a lot depending on the complexity or activity changes in the input video. It is
preferred when constant video quality is required and network bandwidth is enough for delivering the
stream of highly varying bitrate.
- Bitrate
Determine bitrate value between 32 ~ 16Mbps.
Bitrate mode (CBR encoding) allows you to set a fixed target bitrate that consumes a predictable
amount of bandwidth. In order to keep the bitrate limit, video quality is controlled dynamically
according to the complexity or activity changes in the input video.
- I-Frame Interval
Determine I-frame Interval between 1 and 255.
- H.264 Profile
Select H.264 Profile : High Profile or Baseline Profile
The standard defines various sets of capabilities which are referred to as profiles,
targeting specific classes of application.
