RGB Spectrum HDR 205HD User manual

RGB Spectrum
950 Marina Village Pkwy.
Alameda, CA 94501
P/N 350-7043
August 7, 2001
HDR 205HD
Ruggedized High Definition
Video Cassette Recorder
User Manual

August 7, 2001 HDR 205HD User Manual i
. . . . .
Table of Contents
Chapter 1 Introduction 1
General
Shock Mounts
Rack Mounts
Recording Media
Mechanicals
Chapter 2 Supplied Components 3
Supplied Components
Optional Components
Chapter 3 Technical Specifications 5
Chapter 4 Remote Control 7
RS-232 Control
Connecting the Optional RS-232 Port
Serial Command Set
Chapter 5 JVC SR-W7U Manual 11

ii HDR 205HD User Manual August 7, 2001

August 7, 2001 HDR 205HD User Manual 1
1
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I NTRODUCTION
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL
The HDR 205HD is a ruggedized version of the model SR-W7U W-VHS tape
recorder from JVC Professional Products. The HDR 205HD works in
conjunction with the Videolink HD, a bi-directional RGB to HDTV scan
converter.
The ruggedized model offers the following features and upgrades:
•All metal chassis
•BNC locking connectors on all inputs and outputs
•RS-422 port (standard)
•RS-232 port (optional)
•Shock mounting
•220 volt AC option
•Internal stiffening
•Rackmounts
For a complete understanding of this recording system, this manual should be
considered in conjunction with the User Manual for the Videolink HD.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SHOCK MOUNTS
Two types of shock mounting are offered:
•for shipboard and airborne applications
•for land-based applications
The difference between these two shock mounting options is that for land-based
applications they are stiffer. There is no visual difference between the two.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RACK MOUNTS
The standard rack mount components supplied with the HDR 205HD includes
slides suitable for a 22" deep rack. The front screw holes of the slide and front
panel of the HDR 205HD are designed to work with a compound style mount.

INTRODUCTION
Recording Media
2 HDR 205HD User Manual August 7, 2001
1
That is, a rack equipped with double vertical mount bars, providing two sets of
front screw holes.
Extenders and mounting adapters can be ordered to custom fit the rackmount to
a particular rack size and style.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RECORDING MEDIA
The recorder can use either W-VHS or Digital S-video cassette tapes. Both
types are offered in recording lengths varying from 1 - 3.5 hours.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MECHANICALS
The back panel of the HDR 205HD is shown below. For specific connection
instructions, please refer to the User Manual for the Videolink HD.
FIGURE 1. Back Panel of HDR 205HD
For a diagram of the front panel, please refer to the JVC Manual included in
Chapter 5 of this manual.

August 7, 2001 HDR 205HD User Manual 3
2
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S UPPLIED C OMPONENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SUPPLIED COMPONENTS
The HDR 205HD is shipped with the following components in the carton:
•HDR 205HD
•Power cord
•User manual
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPTIONAL COMPONENTS
•BNC to BNC cable bundles
•W-VHS and Digital S video cassette tapes

SUPPLIED COMPONENTS
Optional Components
4 HDR 205HD User Manual August 7, 2001
2

August 7, 2001 HDR 205HD User Manual 5
3
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T ECHNICAL S PECIFICATIONS
Connectors
Power Requirements
Physical
Environmental
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Note: See the included JVC Manual in Chapter 5 for additional
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
technical specifications.
HD Video In 3 BNCs (female)
HD Video Out 3 BNCs (female)
S-Video In 4-pin mini-DIN (female)
S-Video Out 4-pin mini-DIN (female)
Audio In L/R RCAs (female)
Audio Out L/R RCAs (female)
Time Code In RCA (female)
Time Code Out RCA (female)
RS-422 9-pin D-Sub (female) - standard
RS-232 9-pin D-Sub (female) - optional
RGB (Display) 15-pin HD D-Sub (female)
Voltage 120 V, 60 Hz or 220 V, 50 Hz (must be specified when ordered)
Power 40 Watts
MTBF 27,000 hours
Dimensions 19.0" (W) x 18.7" (H) x 18" (D); 5U rackmount
Weight 35 lbs
Tempera t ure Operating 5 to 40 C
Non-operating -20 to 60 C
Humidity 35% to 80% non-condensing

TECHNICAL SPECIFICATIONS
6 HDR 205HD User Manual August 7, 2001
3

August 7, 2001 HDR 205HD User Manual 7
4
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R EMOTE C ONTROL
The HDR 205HD is the ruggedized version of the SR-W7U W-VHS recorder
from JVC Professional Products. The HDR 205HD comes standard with an
RS-422 port, suitable for machine control. You can read more about this remote
control method in the JVC Instructions booklet included as part of this manual.
(See Chapter 5.)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RS-232 CONTROL
The HDR 205HD offers an optional RS-232 serial communications port for
remote control of its functions. This enables the device to receive data and
instructions from host applications, and to be explicitly controlled with
commands sent via the serial port from a computer (or ASCII terminal). This
port is configured according to the Electronic Industries Association Standard
RS-232-C published in August 1969.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CONNECTING THE OPTIONAL RS-232 PORT
The ruggedized HDR 205HD can be explicitly controlled with ASCII
Command Set instructions sent via the RS-232 serial port from either a
computer or an ASCII terminal. See "Serial Command Set" below for details
on the Command Set. The serial port is a female DB9 connector.
Serial port connection to the host requires a serial cable to connect to the host.
This cable is typically a standard “straight-through” cable, though if the HDR
205HD is connected to a computer configured as a Data Communications
Equipment (D.C.E.), you’ll need to use a null modem cable (described later in
this document). Make the cable connection during the hardware installation
sequence.
The serial port’s DB9 connector is configured as D.C.E. and is described below.

REMOTE CONTROL
Connecting the Optional RS-232 Port
8 HDR 205HD User Manual August 7, 2001
4
TABLE 1. RS-232 Serial Port Pinout
RS-232
.
.
.
.
.
.
.
.
.
.
.
.
.
.
PARAMETERS
Ensure that your device is set up with these default serial port parameters.
TABLE 2. RS-232 Serial Port Parameters
.
.
.
.
.
.
.
.
.
.
.
.
.
.
NULL MODEM You may need to connect the HDR 205HD’s serial port adapter to a host
computer configured as Data Communications Equipment. This is done using a
null modem. The net effect of a null modem is to reverse the Transmitted Data
and Received Data connections. Also, the Request to Send and Clear to Send
connections are reversed. This is done by using a special “null modem” cable,
or by inserting a small “null modem” box or cable in series with a regular
“straight through” cable.
9-pin D-Sub Description
1 (not connected)
2 Received Data
3 Transmitted Data
4 Data Terminal Ready
5Ground
6 Data Set Ready
7 Request to Send
8CleartoSend
9 (not connected)
Duplex Full
Baud rate 9600 (or as required)
Data bits 8
Start bit 1
Stop bit 1
Parity no parity
Physical 9-pin D-Sub connector (female)
Configuration D.C.E.
Handshake X-On / X-Off

REMOTE CONTROL
Serial Command Set
August 7, 2001 HDR 205HD User Manual 9
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SERIAL COMMAND SET
The HDR 205HD has a limited command set. The commands are simple, four-
character "words." There are no arguments.
BUFFERED COMMANDS
Serial commands must be buffered and issued to the recording device all at
once. That is, you cannot send the commands character by character and
execute with a carriage return. If the complete command is not issued with less
than a 300 millisecond delay between characters, the instruction is ignored.
Buffered commands can be sent by pre-programming the four-character
command string in a communications program which offers this feature. Many
communications programs provide for programming buffered text strings.
Dedicated serial controllers and terminal devices can also be pre-programmed
with the commands and used for RS-232 control of the HDR 205HD.
SERIAL COMMAND SET
The table below details the command set for the HDR 205HD. Commands are
case sensitive and must be entered in uppercase as shown.
TABLE 3. RS-232 Serial Command Set
SEEKING TO MULTIPLE VISS MARKS
It is possible to instruct the VCR to seek forward and backward multiple VISS
marks. Repeated seek commands, either W02B (next) or W00B (previous),
increase the VISS mark search counter as seen on the front panel LCD display.
The counter appears as a red numeral with a “-” for seeking to previous marks.
Command Description Comments
W20F Operate (ON/OFF)
W209 Record
W211 Stop
W219 Play
W229 Pause
W239 Fast Forward
W201 Rewind
W01B Write VISS mark Unit must be in "Play" or "Record" to write
a VISS mark
W003 Erase next VISS mark
W02B Seek to next VISS mark See "Seeking to Multiple VISS Marks"
W00B Seek to previous VISS mark See "Seeking to Multiple VISS Marks"

REMOTE CONTROL
Serial Command Set
10 HDR 205HD User Manual August 7, 2001
4

August 7, 2001 HDR 205HD User Manual 11
5
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JVC SR-W7U M ANUAL
NOTE: This section contains the user manual for the JVC SR-W7U recorder as
published by JVC Professional Products. This insert is only included in the
printed (hard copy) version of the manual and is not available in this PDF file.
The printed version is available from RGB Spectrum.
