RGBlink mini pro User manual

Quick Start
mini-pro

mini-pro Quick Start
1
Connect mini-pro to power plug by the link
cable.
Install Your Product
Connect PC,laptop,camera or DVD to mini-pro’s
HDMI IN port via HDMI cable.
Connect the microphone to mini-pro’s Audio IN
port and connect the speaker or earphone to
Audio OUT port.
Connect mini-pro’s LAN port to laptop via CAT6
cable, and control mini-pro on software.
Connect the laptop to mini-pro’s USB 3.0 port via
USB cable, and mini-pro will be captured as a
webcam source.
Turn on the Power button on the rear panel,the
device will enter to the boot interface within 10S.
Connect mini-pro’s USB 3.0 port to your laptop
to stream and record.
Connect mini-pro HDMI OUT port to monitor to
HDMI preview the input and output.

mini-pro Quick Start
2
Touch Screen
Switch Source
Switch Effect Setting
Switch Mode Setting
You can select Fast or T-BAR and set the
duration time
Touch【MODE】icon to enter the menu.
Touch screen also has some simple swipe
shortcut functions.
Push corresponding menu icon and the 2-inch
LCD screen will enter corresponding interface.
When four signal sources plug in, the lights on the signal
source buttons will appear in four states:
Steady green: The signal is recognized and no operation is
performed;
Flashing green: The currently selected signal is ready to be
switched;
Steady red: The current signal is in PGM output;
Unlit: No signal source is connected or the resolution of the
signal source connected is not accepted.
Select the effect, the root directory icon will
be replaced with the last selected icon.
Touch【EFFECT】icon to enter the menu.
mini-pro is default 0.5S Fast Fade mode, by
pushing ①②③④signal buttons, 4 input signals
can be switched in fast fade mode.

mini-pro Quick Start
3
Push button【M】to return to main menu and find
【VIDEO OUT】to set parameters for the HDMI and
USB output.
HDMI output defaults multi-screen preview,
USB output defaults PGM.
Touch【M】again to preview 4 inputs.
Tap【Audio】to enter the sound setting interface.
If the sound and the video are not
synchronous, increase or reduce the Delay
value under AFV.(External and HDMI input
audio support delay up to 160ms)
Turn on【MIX】to always add audio to PGM, Turn
on【AFV】, the audio follows the video switch to
perform a soft gradual transition when video is
switched.
The volume can be adjusted by sliding the
bar,and you can touch【HDMI1】 to make
detail setting.
HDMI/USB output can be switched to PVW, PGM,
TP or the 4 input content in field application.
Video Output
Audio Setting

mini-pro Quick Start
4
When the touch screen is in the main interface/
preview interface/Shortcut interface, the PGM
audio volume can be adjusted by the toggle.
Press button【S】to enter Shortcut interface,
adjust the volume by sliding the bar.
Turn on PIP
Touch 【 M 】 button to return the main
menu,select【PIP】icon.
PIP offers 8 layout options,select one you need.
You can adjust Size and Position for
main/sub picture
PIP
Chroma Key
You can choose on or off to enable/disable the
function and select the background color to be
removed and make adjustments.
Tap【Chroma Key】to enter the setting menu.

mini-pro Quick Start
5
You can choose on or off to enable/disable the
function,select the number of camera,and set
the IP address.
Tap【PTZ】icon to enter the menu.
On the PTZ menu interface, when the PTZ
function is enabled, the rotation angle of the
PTZ can be adjusted by the joystick, and the
focal length adjusted by the toggle.
You can adjust the location and zoom in the
menu.
PTZ
You can set the size of layers via sliding the bar.
Adjust the size of the screen through the toggle,
and all the re-adjusted settings will be saved to
the current View in real time.
You can use the joystick to switch the selection of
the main/sub-screen and adjust the size, push the
signal source to switch between different signals.

mini-pro Quick Start
6
Load and Save
Record
The mini-pro supports recording streaming media content to an external SSD or U disk through the USB2.0 interface. The
SSD storage can reach up to 2T, and the U-disk can support up to 64G. The supported formats include exFAT.
You can save the preset to the corresponding
View 1-8.(Yellow icon indicates the view that
being used,green one is saved views.)
After setting the effect, please touch the button
【M】and select the【Save】.
Push button【S】to enter the Shortcut menu
Format the SSD or U-disk and then insert it
into the USB2.0 interface RECORD.
Turn ON/OFF to record audio and set the
quality.
Press【Record】to enter the menu.
Press the button to start/stop record.
Select View1~4 to load the saved presets
directly

mini-pro Quick Start
7
Contact Information
Visit our website which has a host of resources and check out our YouTube channel for How To videos and
much more. Or reach out to the team any time via the website or our socials.
Proudly designed and manufactured in Xiamen China, our beautiful island city home & HQ.
Xiamen RGBlink Science & Technology Co Ltd
6 th Floor, Weiye Building, Torch Park Hi Tech Zone,Xiamen, Fujian 361006
● Web: http://www.rgblink.com
● Tel: [phone]
● Fax: [phone]
● Customer Hotline: [phone]
● E-mail: [e-mail]
Touch【Disk Info】to view the Capacity and
Remaining time.
