RH Baby&child BARLOW SWING-ARM TASK SCONCE User manual

BARLOW SWING-ARM TASK SCONCE – ASSEMBLY INSTRUCTIONS
Thank you for selecting RH Baby & Child lighting. Our assortment is crafted with the highest quality materials that coordinate
perfectly with our Baby & Child bedding collections, making it easy to create an elegant nursery or child s bedroom. Each
item s surface is sealed, which eliminates the need for polishing and ensures a lasting finish for years to come.
PARTS ENCLOSED:
(B) Mounting Plate (1)
(E) Canopy Screws (3)
(F) Swing Arm (1)
(G) Shade (1)
(H) Canopy (1)
(I) On/Off Switch (1)
(K) Electrical Cord (1)
(L) Wall Anchors (2)
(M) Wall Screws (2)
IMPORTANT SAFETY INSTRUCTIONS:
This sconce can be used as a plug-in or a fixed unit when used with the appropriate
conversion kit. For your safety, this sconce is equipped with a 3-pronged polarized plug.
If the plug does not fit securely into your outlet, do not force it – contact a professional
electrician. Use the plug with an extension cord only if it can be fully inserted into the
cord s socket. Never alter the plug in any way.
This fixture is designed for use with LED beads. To avoid the risk of fire, do not change the
lamp for use with any other LED beads.
WARNINGS:
All wires are connected. When unpacking, be careful not to pull wires, as a bad
connection may result. Do not connect electricity until the fixture is fully assembled. To
reduce the risk of fire, electrical shock, or personal injury, do not try to replace the LED
beads, as they are non-replaceable. Do not touch the LED beads when fixture is turned
on. Keep flammable materials away from lit LED beads.
THIS PRODUCT IS NOT A TOY AND HAS NO PLAY VALUE.
WARNING: STRANGULATION HAZARD
Keep cord at least 3 feet away from cribs, bassinets, and toddler beds.
Keep out of reach of children under 3 years of age.
PLUG-IN ASSEMBLY & INSTALLATION:
1. Carefully remove all parts from the box and remove all plastic coverings.
2. Drill 2 holes into the wall that align with the holes on the mounting plate (B) of the
sconce and insert wall anchors (L).
3. Place mounting plate (B) onto the wall anchors (L), then screw wall screws (M) into
anchors.
4. Attach the canopy (H) to the mounting plate (B) and use canopy screws (E) to secure.
5. Adjust the swing arm (F) and shade (G) to get desired angle and height.
6. Plug into proper electrical outlet and turn the on/off switch (I) to test fixture.
CARE INSTRUCTIONS:
Do not use polishes or cleaners, as they will damage the finish.
Wipe clean with a soft, dry cloth.
BARLOW SWING-ARM TASK
SCONCE
Plug-I I stallatio

BARLOW SWING-ARM TASK SCONCE – ASSEMBLY INSTRUCTIONS
Thank you for selecting RH Baby & Child lighting. Our assortment is crafted with the highest quality materials that coordinate
perfectly with our Baby & Child bedding collections, making it easy to create an elegant nursery or child s bedroom. Each
item s surface is sealed, which eliminates the need for polishing and ensures a lasting finish for years to come.
PARTS ENCLOSED:
(A) Plastic Wire Connectors (3)
(B) Mounting Plate (1)
(C) Mounting Screws (2)
(D) Green Ground Screw (1)
(E) Canopy Screws (3)
(F) Swing Arm (1)
(G) Shade (1)
(H) Canopy (1)
(I) On/Off Switch (1)
(J) Plug Screw (1)
BARLOW SWING-ARM TASK
SCONCE
Direct-Wire i stallatio
IMPORTANT SAFETY INSTRUCTIONS:
This sconce can be used as a plug-in or a fixed unit when used with the appropriate
conversion kit. For your safety, this sconce is equipped with a 3-pronged polarized plug.
If the plug does not fit securely into your outlet, do not force it – contact a professional
electrician. Use the plug with an extension cord only if it can be fully inserted into the
cord s socket. Never alter the plug in any way.
* DIRECT-WIRE FIXTURES: WE STRONGLY RECOMMEND INSTALLATION BY A
LICENSED ELECTRICIAN.
This fixture is designed for use with LED beads. To avoid the risk of fire, do not change the
lamp for use with any other LED beads.
WARNINGS:
All wires are connected. When unpacking, be careful not to pull wires as a bad connection
may result. Do not connect electricity until the fixture is fully assembled. To reduce the
risk of fire, electrical shock, or personal injury, do not try to replace the LED beads, as they
are non-replaceable. Do not touch the LED beads when fixture is turned on. Keep
flammable materials away from lit LED beads.
THIS PRODUCT IS NOT A TOY AND HAS NO PLAY VALUE.
WARNING: STRANGULATION HAZARD
Keep cord at least 3 feet away from cribs, bassinets, and toddler beds.
Keep out of reach of children under 3 years of age.
DIRECT-WIRE ASSEMBLY INSTRUCTIONS:
1. Carefully remove all parts from the box and remove all plastic coverings.
2. Shut off the main electrical supply from the main fuse box/circuit breaker.
3. Cut the plug from the end of the electrical cord (K). From the back side of the fixture,
pull the electrical cord through the exit hole at the bottom of the back plate. Then insert
plug screw (J) into the exit hole at side of the canopy (H) and secure tightly.
4. Cut the cord to the desired length (at least 6 from the back plate) to make a “J BOX”
connection.
5. Guide the wiring from the outlet box through center hole in the mounting plate (B).
6. Attach the mounting plate (B) to the outlet box using the mounting plate screws (C).
7. Attach the ground wire from the fixture to the ground junction box wire
from the outlet box (usually green or bare wire). Or wrap the ground wire around the
green ground screw (D).
8. Connect the hot wire to the hot junction box wire (usually black or smooth) with a
plastic wire connector (A) and wrap the connection with electrical tape. Connect the
neutral wire to the neutral junction box wire (usually white or ribbed) with a plastic wire
connector (A) and wrap the connection with electrical tape.
9. Attach the canopy (H) to the mounting plate (B) and use canopy screws (E) to secure.
10. Adjust the swing arm (F) and shade (G) to get desired angle and height.
11. Restore power to the junction box and turn the on/off switch (I) to test fixture.
12. Installation is complete.
CARE INSTRUCTIONS:
Do not use polishes or cleaners, as they will damage the finish.
Wipe clean with a soft, dry cloth.

BARLOW SWING-ARM TASK SCONCE – ASSEMBLY INSTRUCTIONS
NOTE: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on. The user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
