FAUCET AND DISPENSER INSTALLATION STEPS 7
NOTE: The wall outlet the base
unit plugs into must have a
continuous power supply and be
fused. It should not be controlled by
the same wall switch that operates
your disposal. If it is controlled by
the same wall switch, it’s required
that you purchase an adapter such
as a wireless switch or air switch to
control the disposal, and leave the
wall switch turned on.
NOTE: Always consult a professional before drilling into a surface other than stainless steel.
If you don’t have a sprayer hole or don’t wish to use it, the soap dispenser hole is a viable alternative.
STEP 1
PREPARATION
ENSURE REQUIRED MINIMUM CLEARANCE
• Identify locations for the faucet or dispenser and base unit.
• Check for a grounded electrical outlet under the sink.
• FAUCE T ONLY: Ensure there is at least 2" (50mm) from the center of the
mounting hole to a wall or backsplash.
• Check that the installation hole and counter thickness will work:
• FAUCE T ONLY: Required hole size is 1-1/4" (32mm), and the maximum
counter thickness (depth) is 1.5" (38mm) for all models.
• DISPENSER ONLY: Required hole size is 1" (25mm), and the maximum
counter thickness (depth) is 1.5" (38mm) for all models.
PREPARE THE INSTALL LOCATION
• Turn off water supply.
• Use a wrench to remove the nut connecting the sprayer washer flange
in the sprayer hole.
• DISPENSER ONLY: If using the sink sprayer hole, remove the nut that
connects the sprayer hose at the bottom of the faucet.
• Use a drain pan to catch any excess water in the line.
• Plug the hose opening with a cap (not supplied).
• If drilling a hole into a stainless steel sink or countertop: Cut a mounting
hole with a hole saw or a hole punch.
• If your installation hole is larger than 1" (25mm) you will need
an escutcheon.
