Rheem Raypak Professional Series User manual
INSTALLATION AND OPERATING
INSTRUCTIONS
Professional Series
PS10353ti-E-HC
PS10354ti-E-HC
PS10355ti-E-HC
FOR YOUR SAFETY: Do not store or use gasoline or other ammable vapors and
liquids or other combustible materials in the vicinity of this or any other appliance.
To do so may result in an explosion or re.
Heat Pump
Pool & Spa
Heater
NOTE:
2
Revision 4 reects the following changes:
3
TABLE OF CONTENTS
1. WARNINGS ............................................................ 4
2. WATER CHEMISTRY ............................................. 5
3. INTRODUCTION ..................................................... 5
4. INSTALLATION CONSIDERATIONS ................... 5
5. ELECTRICAL CONNECTIONS ............................ 8
6. WATER CONNECTIONS ....................................... 8
7. PRESSURE DROP ................................................. 8
8. CONTROLS ............................................................ 9
9. OPERATING INSTRUCTIONS .............................. 9
9
9
9
9
10. HEAT/COOL OPERATION .................................... 9
11. SYSTEM START-UP ............................................. 10
12. SEASONAL STARTUP OR ANNUAL CHECK . . 10
13. SUMMER SHUTDOWN ........................................ 10
14. FREEZE PROTECTION ....................................... 10
15. MAINTENANCE .................................................... 10
16. TROUBLESHOOTING ......................................... 11
17. SERVICE CALL VERIFICATION ........................ 12
18. PLUMBING DIAGRAMS ...................................... 13
19. WIRING DIAGRAMS ............................................ 17
20. INSTALLING REMOTE CONTROL DEVICE..... 20
21. ILLUSTRATED PARTS LIST ............................... 21
4
1. WARNINGS
Pay Attention to these Terms
ADANGER
AWARNING
ACAUTION
CAUTION
NOTE
ACAUTION: Improper chemical content in a swimming
pool or spa can damage the heater. DO NOT add pool
chemicals to the skimmer. This will damage the heater
and could void the heater warranty. ALWAYS follow the
product manufacturer’s directions when adding any
chemicals to your pool.
ACAUTION: Elevated water temperature can
be hazardous. The U.S. Consumer Product Safety
Commission has these guidelines:
1. Spa water temperatures should never exceed 104°F
(40°C). A temperature of 100°F (38°C) is considered
safe for a healthy adult. Special caution is suggested
for young children.
2. Drinking of alcoholic beverages before or during spa
or hot tub use can cause drowsiness which could
lead to unconsciousness and subsequently result in
drowning.
3. Pregnant Women Beware! Soaking in water over
102°F (39°C) can cause fetal damage during the first
three months of pregnancy resulting in the birth of a
brain-damaged or deformed child. Pregnant women
should stick to the 100°F (38°C) maximum rule.
4. Before entering the spa or hot tub, users should
check the water temperature with an accurate
thermometer; spa or hot tub thermostats may err
in regulating water temperatures by as much as 4°F
(2.2°C).
5. Persons with a medical history of heart disease,
circulatory problems, diabetes, or blood pressure
problems should obtain a physician’s advice before
using pools or hot tubs.
6. Persons taking medications which induce
drowsiness, such as tranquilizers, antihistamines,
or anticoagulants, should not use spas or hot tubs.
AWARNING: These heat pump pool heaters are
charged with R-410A refrigerant. Ensure that all service
work is done with gauges and equipment suitable for
R-410A.
5
2. WATER CHEMISTRY
(Corrosive water voids all warranties)
Table A
Recommended Level(s) Fiberglass Pools Fiberglass Spas Other Pool & Spa Types
Table A. Water Chemistry
3. INTRODUCTION
AWARNING: This heater is an electromechanical
machine that incorporates a pressurized refrigerant
gas in a sealed system. ONLY trained and qualied
service personnel are authorized to install or service
this equipment. Without proper training and knowledge
of such equipment, any attempt to install or service the
unit could result in serious injury or even death.
4. INSTALLATION
CONSIDERATIONS
AWARNING: Do not install the unit within 3 ft (91
cm) of fossil-fuel-burning heaters. Air intake along the
sides of this heat pump pool heater could disturb the
combustion process of the unit, and could cause damage
or personal injury.
• Mount the unit on a level, sturdy base, preferably a
concrete slab or blocks. The size of the base should
be at least 3 ft by 3 ft (91 cm by 91 cm).
• You must install the 4 black rubber sound isolation
pads (each 2 inches square [5.1² cm]) that ship with
the unit. The pads are shipped in a bag with the
unions, gaskets and the I&O manual. Install pads
under the 4 corners of the unit to reduce vibration
and sound transmission to the base.
ACAUTION: The unit’s supporting base must be high
enough to keep it completely free of standing water at
all times.
6
AWARNING: This unit is designed for outdoor
installation. It is NOT certied for indoor installation.
DO NOT install it in an enclosed area such as a shed or
garage, or under a porch or deck.
Figure 1
GAS
HEATER
AIR
FLOW
IN
AIR
FLOW
IN
AIR FLOW OUT
12" MIN
(30.5 cm)
60" MIN
(152.4 cm)
F10082
3' MIN
(91.4 cm)
Figure 1. Installation Clearances
page 10.
Figure 2
7
PAD SPECIFICATION
GREATER THAN OR EQUAL TO 4" (10 cm) THICK SOLID CONCRETE 3000 P.S.I. OR GREATER LOAD RATING
PAD LENGTH GREATER THAN OR EQUAL TO UNIT LENGTH +6" (+15.2 cm)
PAD WIDTH GREATER THAN OR EQUAL TO UNIT WIDTH +6" (+15.2 cm)
186 MPH (299 kph), 3 SEC. GUST IN ACCORDANCE WITH:
COVERED UNIT
HEIGHT BETWEEN
37-1/2" – 49-3/4"
(92.3 cm – 126.4 cm)
NOT INCLUDING
ISLATOR PADS
2-1/2" MIN.
(6.4 cm)
SPACING TYP.
(2) 1/4" CONCRETE SCREWS
LENGTH TO PENETRATE
2-3/8" (6 cm) MINIMUM
Figure 2. High Wind Installation Requirements
8
5. ELECTRICAL
CONNECTIONS
pages 17
through 19.
NOTE: Refer to the National Electrical Code, Article
680, for general requirements for swimming pools and
equipment, and to Article 440 for special considerations
necessary for circuits supplying hermetic refrigeration
motor/compressors.
page 20
Model
No. VAC - Phase - Hz
Minimum
Circuit
Ampacity (A)
Maximum
Breaker Size
(A)
10353
10354
10355
Table B. Typical System Electrical Power Requirements
6. WATER CONNECTIONS
ACAUTION: The heater inlet and outlet connections
are NOT interchangeable. They must be connected as
instructed below.
page 13.
WATER IN
WATER OUT
Figure 3. Water Connections
7. PRESSURE DROP
Table C
Flow
gpm (lpm)
Pressure Drop (psi)
10353HC 10354HC 10355HC
Table C. Pressure Drop Across Heater
AWARNING: Install a check valve and/or a Hartford
loop AFTER the heater and BEFORE any chlorinating
devices. Install any automatic chemical feeders AFTER
the heater. Improper installation of any type of automatic
chemical feeders can result in serious damage to, or
premature failure of, the heater. Such damage will not be
covered under warranty.
9
8. CONTROLS
Water Pressure Switch
Digital Water Temperature Control
Figure 4. Digital Water Temperature Control
Defrost Sensor
Delay Timer
9. OPERATING
INSTRUCTIONS
Figure 4
Selecting Pool or Spa Mode
P _S
Increasing Water Temperature
(Pool or Spa Mode)
Reducing Water Temperature
(Pool or Spa Mode)
To make the Board a Pool ONLY Board, call 800-260-
2758 for instructions.
Selecting Temperature (°C or °F)
F _C
10. HEAT/COOL OPERATION
NOTE: Once the control has been programmed to
the desired pool water temperature, the programmed
temperature will be displayed for approximately 5
seconds. The digital display will then show the actual
pool water temperature.
NOTE: Remove the pool/spa blanket and turn on any
fountains, sprays or other water features to speed
cooling.
10
NOTE: Heating is more ecient during warmer daylight
hours and cooling is more ecient during cooler night
time hours.
11. SYSTEM START-UP
page 11.
12. SEASONAL START-UP OR
ANNUAL CHECK
NOTE: At the beginning of the heating season, or
whenever the pool water temperature is to be raised
several degrees, the pool pump and heater may need to
operate continuously for several days. During summer
months, only a few hours per day may be necessary, or
none at all.
NOTE: If the pool pump and heater shut OFF before the
water temperature is raised to the desired level, you must
lengthen the running time of both. To do this, reset the
time clock dial for the longer running time, or manually
operate the pump with the timer override switch. Since
the heater capacity and eciency are both greater at
higher ambient air temperatures, run time should be set
to take advantage of all daylight hours, when the air is
generally warmer.
13. SUMMER SHUTDOWN
14. FREEZE PROTECTION
System Drain-Down
Continuous Pump Operation
15. MAINTENANCE
NOTE: The heater MANUFACTURER IS NOT
RESPONSIBLE for maintenance adjustments.
Air Coil Cleaning
11
ACAUTION: To clean the ns, spray gently with a
garden hose. DO NOT pressure wash. Doing so will bend
the ns and such damage will not be covered under
warranty.
Cabinet Care (optional)
AWARNING: Shut OFF electricity to the unit before
cleaning.
Unplug Condensation Drain Holes
16. TROUBLESHOOTING
UNIT IS RUNNING, BUT NOT HEATING
Remember
that the heater only operates while the pool pump is
running.
NOTE: If the pool pump and heater shut OFF before the
water temperature is raised to the desired level, you must
lengthen the running time of both. To do this, reset the
time clock dial for the longer running time, or manually
operate the pump with the timer override switch. Since
the unit capacity and eciency are both greater at higher
ambient air temperatures, run time should be set to take
advantage of all daylight hours, when the air is generally
warmer.
UNIT IS NOT RUNNING
NOTE: The heater will not run when the Remote position
is selected on the Pool/Spa selector switch and there is
no remote control system attached.
CONDENSATION SEEMS EXCESSIVE
12
Fault Code Meaning of Code
Table D. Control Board Fault Codes
17. SERVICE CALL
VERIFICATION
NOTE: The MANUFACTURER IS NOT RESPONSIBLE for
these adjustments.
Power Supply
Water Flow
Time Clock Adjustment
13
WATER IN
(FROM POOL OR
SPA)
FILTER
CHECK
VALVE
CHEMICAL
INTRODUCTION
NO EXTERNAL BYPASS IS REQUIRED
WATER OUT
(TO POOL OR
SPA)
F10123
INLET AND OUTLET ARE 2" UNIONS
PLUMB THE UNIT AFTER THE FILTER, BEFORE ANY CHLORINATORS.
Figure 5. For systems with pumps of less than 2 HP (under 80 gpm)
18. PLUMBING DIAGRAMS
14
WATER IN
(FROM POOL OR
SPA)
FILTER
CHECK
VALVE
CHEMICAL
INTRODUCTION
WATER OUT
(TO POOL OR
SPA)
EXTERNAL BYPASS (REQUIRED).
ADJUST TO DIVERT A MINIMUM OF 40
GPM THROUGH THE HEATER.
F10124
INLET AND OUTLET
ARE 2" UNIONS
PLUMB THE UNIT AFTER THE FILTER,
BEFORE ANY CHLORINATORS.
Figure 6. For systems with pumps of 2 HP or greater (over 80 gpm)
15
4 SYSTEM PIPE DIAMETERS,
OR 12" (30.5 cm) MAX,
WHICHEVER IS LESS
SYSTEM FLOW MUST EXCEED 120% OF FLOW THROUGH
OPERATING HEATERS.
6
6
Figure 7. Pool Piping for Heat Pump Pool Heater and Gas Pool Heater
16
BRANCH MAIN BRANCH MAIN BRANCH MAIN
15 GPM 2" 2" 15 GPM 2" 2" 15 GPM 2" 2"
30 2" 2" 30 2" 2-1/2" 30 2" 3"
45 2" 2" 45 2" 3" 45 2" 4"
60 2" 2-1/2" 60 2" 3" 60 2" 4"
80 2" 3" 80 2" 4" 80 2" 5"
*Sizing based on 10 ft/sec flow rates
MINIMUM PIPE SIZES
2 UNITS
3-4 UNITS
5-6 UNITS
4 SYSTEM PIPE DIAMETERS, OR 12"
(30.5 cm) MAX, WHICHEVER IS LESS
SYSTEM FLOW MUST EXCEED 120% OF FLOW THROUGH
OPERATING HEATERS.
Figure 8. Pool Piping for Multiple Heaters
17
19. WIRING DIAGRAMS
208V/230V 3Ph, 60Hz Models
18
460V 3Ph, 60 Hz Models
19
380V 3Ph, 60 Hz Models
20
20. INSTALLING A REMOTE
CONTROL DEVICE
Wiring
Figure 9. Heater Wiring Block
Heater Settings
This manual suits for next models
3
Table of contents
Other Rheem Swimming Pool Heater manuals
Rheem
Rheem Raypak ELS 0018 User manual
Rheem
Rheem Raypak XTherm 1005A Manual
Rheem
Rheem M5350ti User manual
Rheem
Rheem M6350tiHC Instruction manual
Rheem
Rheem Raypak X94 SR-410 User manual
Rheem
Rheem Raypak CROSSWIND-30-I User manual
Rheem
Rheem M5350ti User manual
Rheem
Rheem M5350ti Instruction manual
Rheem
Rheem P-M206 Use and maintenance manual
Rheem
Rheem M6350tiHC User manual
Popular Swimming Pool Heater manuals by other brands
Bestway
Bestway 58259 owner's manual
MCZ
MCZ heater Installation and use manual
Blue Lagoon
Blue Lagoon ProfiHeater 1kW manual
Lochinvar
Lochinvar SMART SYSTEM 502 - 2072 Installation & operation manual
Raypak
Raypak 259B Installation & operating instructions
emaux
emaux HP3.8B Installation instructions manual
Zodiac
Zodiac Jandy LXi Installation and operation manual
Laars
Laars Pennant PNCP Installation and operation instructions
Hayward
Hayward Above-Ground Heat Pump owner's manual
hurlcon
hurlcon Viron 250 Installation and operating instructions
Nirvana
Nirvana ECO 50 owner's manual
Plastica
Plastica SOLAR POD PLUS owner's manual
