Rheem RR40-36FV1 User manual

FURY GAS WATER HEATERS

6-year limited tank warranty*

1-year limited parts warranty*
Guardian System™
•
One-of-a-kind air/fuel shut-off device
offers double protection
•
Maintenance free – no filter to clean
•
Standard replacement parts
Easy to Light
•
No matches required
Energy Efficient
•
More hot water at low operating cost
High Altitude Compliant
•
All models are certified for applications
up to 4,500 feet above sea level
Longer Life
•
Magnesium anode rod protects
the tank from rust
Plus…
•
Temperature and pressure
relief valve is included
•
Low profile drain valve
•
Meets or exceeds NRCan
requirements
* See residential warranty information brochure for
complete warranty information.
* May 1, 2004 – 5 year limited warranty in the
Province of Newfoundland.
®
E
G
BA
C
F
H
HOT
WATER
CONNECTION
H
COLD
WATER
CONNECTION
D
1/2"
3/4" N.P.T.
RELIEF
VALVE
OPENING
FLUE ANODE ROD
These units are designed to meet
or exceed ANSI (American
National Standards Institute)
requirements and have been test-
ed according to C.S.A. test proce-
dures and meet or exceed the
energy efficiency requirements of
NRCan, ASHRAE standard 90,
and all government energy effi-
ciency performance criteria for
energy consuming appliances.
Before purchasing this appliance,
read important energy cost and
efficiency information available
from your supplier.
Rheem Guardian System Features…
Flame Arrestor
Plate
A specially-designed
flame arrestor pre-
vents ignition of
vapours outside the
combustion chamber.
Maintenance
Free
Superior air filtration
prevents the flame
arrestor from becom-
ing clogged by lint,
dust and oil.
Exclusive
Combustion
Shut-off System
Should a spill
incident occur, the
Guardian System
shuts off the gas
supply and the air
supply preventing a
sustained vapour
burn in the combus-
tion chamber.
DESCRIPTION FEATURES ROUGHING IN DIMENSIONS (SHOWN IN INCHES) ENERGY INFO.
HT. TO WATER HT. TO
GAS INPUT IN RECOVERY IN FIRST HOUR HT. TO TANK GAS VENT CONN. SIDE WATER SHIP. ENERGY
THOUS. BTU/HR. G.P.H. 100° RISE DEL. G.P.H. VENT HT. DIAM. CONN. SIZE CNTR. T&P CONN. WT. FACTOR
MODEL NUMBER NAT. LP NAT. LP NAT. A B C D E F G H (LBS) NAT.
RR30-30FV 30 27 25.5 22.9 49 49-3/4 46-1/4 19-3/4 14-1/2 3 8 40-1/4 3/4 98 .61
RR40-36FV1 36 34 30.5 28.8 72 53-1/8 49-3/8 20-1/4 14-1/2 3-4* 8 42-3/4 3/4 130 .59
RR50-40FV1 40 36 34 30.5 84 54-1/4 50-1/2 22-1/4 14-1/2 3-4* 8 44 3/4 160 .58
Rheem Manufacturing Company • Water Heater Division
Rheem Canada Ltd./Ltée,128 Barton Street West, Hamilton, Ontario L8N 3P3
06/06 WP FORM NO. 101-6CAN Rev. 2
In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.
SPECIFY LP GAS WHEN ORDERING. Add “P”suffix to the model number and change BTU input. Example: RR30-27PFV.
* RR40-36FV1 and RR50-40FV1 feature a 3-4" combo vent.
NOW WITH
SMALLER
DIAMETERS!
