RHINO MDVR-HDV6 User manual

Single Camera Full HD
Mobile Digital Video Recorder
Model: MDVR-HDV6
USER MANUAL

MDVR‐HDV6In‐CarRecorder
OperationManual
Features
1920x1080FULLHDvideorecording
AdvancedH.264videocompression
2.7inchhighresolutionLCDdisplay
120degreewideanglelens
4Xdigitalzoom
HDMIoutputtoviewvideoonexternalTV/monitor
Captureat30or60framespersecondforsmoothvideorecording
G‐sensortokeeprecordsofsensordataandreal‐timedisplayontheplayer
Documentprotectionwhilerecordingtomaintainvideofileintegrityaftersuddenpowerloss
Continuousrecording,oldfilesareautomaticallyoverwrittenwithnewfilesafterfillingstorage
ChargeviaPC(USB),ACadaptororin‐carcigarettelighter
Tostarttheautoautomaticoff;tostartthevideorecordingfunction
Automaticcirculatingvideorecording,beingabletosettherecordtimeforeachfile
TimeandDatestamponvideoandimagefiles
Setspecificvideorecordduration
MicroSDcardstorage–maximumof32GB

ProductDiagram

1）USBport
2）AVport
3）GPSport(Optional)
4）Powerbutton
5）MENUbutton
6）Lens
7）Speaker

8）MicroSDCardslot
9）UPkey
10）DOWNkey
11）RECbutton/OKbutton
12）MODEbutton
13）HDMIport
14）Resetbutton

KeyFunctions
POWERPowerin‐carrecorderonandoff
MENUOpenandcloseoptionsmenu
MODESwitchoperationmodeandcorrespondingmenu
REC/OKStartorpauserecordingandselectoptionsinmenu
UPScrollupthroughmenus/zoom‐in
DOWNScrolldownthroughmenus/zoom‐out

StartUp
StartingtheMDVR‐HDV6:
oPressthePOWERkeytoturnonin‐carrecorder.Poweronisindicatedbyabluelight;
oPressthePOWERkeyagaintopoweroffthein‐carrecorder,thebluelightwillturnoff.
ChargingBatteries:
oChargingisindicatedbyaredlightonthein‐carrecorder.Thiswillturnoffwhenthebatteryisfullycharged.
TheunitcanbechargedusinganACadaptor,viaUSBconnectedtoacomputerorusingacarcharger.
InsertingandRemovingtheMicroSDcard:
oInserttheMicroSDcardintotheslotandpushitinwardsuntilyouhearitclickintoplace.Toremovethe
card,pushitinwardsagainuntilitpopsout,itcanthenberemoved.

BasicOperation
Switchingbetweenvideo,photoandplaybackmodes:
oPresstheMODEkeytocyclethroughvideocapture,photocaptureandvideo/imageplaybackmodes
CaptureVideoorImages:
oSelecttheappropriatemodeandpresstheREC/OKkeytobeginrecordingtoortotakeastillimage;
oVideorecordingwillbeginonstartupiftheMDVR‐HDV6ispluggedintothecarcigarettelighter;
oPresstheREC/OKkeywhilerecordingtostopvideocapture;
oPresstheMODEkeywhilerecordingtochangebetweendayandnightmode;
Modifyingsettingsforcapture/playbackmodes:
oWheninthedesiredmode,presstheMENUkeye.g.toentervideosettings,pressMENUkeyafterselecting
thevideomode.ThemenucanbenavigatedusingtheUPandDOWNkeysandoptionscanbeselected
usingtheREC/OKkey;
Modifyingsystemsettings:
oPressMENUkeytwicetoenterthesystemsettingsmenu.Thefollowingoptionscanbechangedinthis
menu:
FormatMicroSDcard–deleteallunlockeddatastoredonthemicroSDcard;
Language–selectfromEnglish,TraditionalChinese,SimplifiedChinese,Japanese,Russian,German,
French,Spanish,ItalianorPortugueselanguages;
DateSetup–SetDate/Time;
Frequency–50/60Hz;
ResetSystemSettings–returnallsettingstodefaults;
G‐SensorFunction
oG‐sensorsensitivitycanbesettoHigh,Medium,LoworOffinthesystemsettingsmenu
oVideocapturewillbelockedfollowinganeventthattriggerstheG‐sensor

ModeSpecificSettings
VideoMode:
oVideoresolution:
1920x1080
1440x1080
1280x720
oTimedisplay–ON/OFF
oMotiondetection–ON/OFF
oCyclerecording–Off/3min/5min/10min
oAutopower‐off–Off/1min/3min
oPressbuttonvoice:Off/On
PhotoMode:
oShootType–Single,2secclocking,5secclocking,10secclocking
oImageresolution:
VGA–640x480
1.3Megapixel–1280x960
2Megapixel–1920x1080
3Megapixel–2048x1536
5Megapixel–2592x1944
8Megapixel–3264x2448
10Megapixel–3648x2736
12Megapixel–4032x3024


Video/ImagePlaybackMode:
oPressUPorDOWNkeytoselectthedesiredfileforplayback;
oPressREC/OKkeytostartandstopthevideoplayback;
oAdjustvideovolumeusingtheUPorDOWNkeys;
oRewindvideousingtheDOWNkeyduringplayback;
oPressMENUkeytoselectthefollowing:
Delete–Single/All/SelectFile;
Protectfile–selecttolockorunlockspecificfiles;
Slideplay(images)–selectdisplaydelaysof2sec,5sec,8sectoplaytheslideshow;

ConnecttoPC
ConnecttheMDVR‐HDV6viaUSBtoacomputer.Onthedevice,ablueindicatorwillturnonandtheLCDscreenwill
turnon.TheMicroSDstoragewillbeautomaticallydetected.Hereyoucanbrowseormanagevideoandimagefiles
storedonthecard.To remove,turnoffthedeviceandunplugtheUSBcable.

TechnicalSpecifications

LCDDisplay2.7inchLTPSdisplay(4:3)
Lens120°WideAngleLens
LanguageselectionEnglish、Traditional、Chinese、Japanese、Russian、German、French、
Spanish、Italian
Videoresolution1080HFD1920*10801080P1440*1080720P1280*720
VideoformatMOVH.264compressformat
ImageresolutionVGA640*480,1.3M1280*960,12M4032*3024,10M3648*2736,8M
3264*2448,5M2592*1944,3M2048*1536,2M1920*1080
ImageformatJPG
MemorycardMicroSD
Microphone/SpeakerYes
ShootingwaySingle/2secclocking/5secclocking/10secclocking
TVmodePAL/NTSC
Frequency50HZ/60HZ
USBPortUSB2.0
Powerinput5V500MA
BatteryRechargeableLi‐ion
AccessoriesIn‐carchargerandholder,USBcable,HDMIcable
PCViewRequirementsWindows2000/XP/Vista/7orMACOS10.3.6orabove
TroubleshootingIfdevicecrashesduringusage,presstheRESETbuttonandrestart


