Rhydolabz eCee NXP LPC 2148 User manual

www.rhydolabz.com
We bring the world to you..
Document : Datasheet Model # : DEV - 1127
Date : 11-Dec-07
eCee NXP LPC 2148
ARM Development Board
Quick Start Guide
Rhydo Technologies (P) Ltd.
(An ISO 9001:2008 Certified R&D Company)
Golden Plaza, Chitoor Road,
Cochin – 682018, Kerala State, India
Phone : [phone]
Cell : 0091- 99466 70444
Fax : 0091 - 484-2370579
E-mail : [e-mail], [e-mail]
WebSite : http://www.rhydolabz.com

www.rhydolabz.com
We bring the world to you..
CONTENTS
CHAPTER-1: OVERVIEW
Features
1. Base Board Features
2. Header Board Features
eCee NXP LPC 2148 Package Contents
NXP LPC 2148 Specification
CHAPTER-2: HARDWARE INTRODUCTION
eCee NXP LPC 2148 Function Module
Interface Overview
Power
Clock source
CHAPTER-3 : INTERFACING eCee LPC 2148
Connecting the eCee NXP LPC 2148 Development Board
Programming Steps
Automatic mode
Manual mode

www.rhydolabz.com
We bring the world to you..
CHAPTER-1: OVERVIEW

www.rhydolabz.com
We bring the world to you..
FEATURES
BASE BOARD
FEATURES
The eCee LPC 2148 Development and Evaluation Board from RhydoLabz can be used to
evaluate and demonstrate the capabilities of NXP LPC 2148 microcontrollers. The board (with a base
board and header board) is designed for general purpose applications and includes a variety of
hardware to exercise microcontroller peripherals. The LPC 2148 Board contains all hardware
components that are required in a single-chip LPC 2148 system plus 2 COM ports for serial RS232
output and interfaces like Lcd, Buzzer, Keyboard, Temperature Sensor, Potentiometer, Led’s,
EEPROM etc .
Compact and Ready to use design
Professional EMI/RFI Complaint PCB Layout Design for Noise Reduction
Supports LPC2129/32/38 Header Boards
Includes LPC2148 (with In-built USB Peripheral) Header Board
No separate programmer required (On-Chip Boot loader)
No Separate power adapter required (USB power source)
Two RS-232 Interfaces (For direct connection to PC’s Serial port)
On Board Two Line LCD Display (2x16) (with jumper select option)
On Board 8 LED Interface to test Port pin (with jumper select option)
On Board Pot interface to ADC
On Board Temperature Sensor Interface (Optional)
On Board Buzzer Interface
On Board 4x4 (16 Keys) Matrix Keyboard
On Board I2C EEPROM
On Board External Interrupt Button
On Board Connector for PWM Output
PWM controlled LCD backlight

www.rhydolabz.com
We bring the world to you..
HEADER BOARD
FEATURES
On Board Connector for Analog Output
On Board Speaker Output
LF Amplifier LM 386
Adaptor (any standard 9-12V power supply) option
On Board Power LED Indicator
On Board Reset button
All Port Pins available at Berge Strip
On Board JTAG Connector for Debugging/Programming
Power Supply Reverse Polarity Protection
Three On Board DB9 Connectors (Two for UART and One for CAN)
On Board USB Connector
On Board 1 Amp Voltage Regulator
On Board Connector for regulated 3V3 output
On Board Connector for regulated 5V output
Controller Area Network (CAN) transceiver (optional)
Can be used as main board for developing applications
Easy to use DIP Package
Includes NXP LPC 2148 Microcontroller with In-built USB Peripheral
On Board Power LED Indicator
On Board JTAG Jumper
On Board 10 MHz Crystal Oscillator
On Board 32.768 KHz Crystal for RTC
On Board 3.3V Regulator
On Board Power Supply de-Coupling Capacitors
All Port Pins available at Berge Strip
Header Module can be removed for developing your circuit

www.rhydolabz.com
We bring the world to you..
eCee LPC 2148 PACKAGE INCLUDES
Fully Assembled and Tested eCee LPC2148 Development board
Software CDROM with
Schematic
Programming Software
Sample Hex Code
Example Codes
Led Blinking LCD Display
Matrix Keyboard USB Communication
I2C Protocol RTC Interfacing
Led Control with Timer UART Communication
PWM Generation Buzzer Interfacing
ADC Interfacing DAC Interfacing

www.rhydolabz.com
We bring the world to you..
LPC 2148 SPECIFICATION
High Performance 32-bit ARM7TDMI-S™ CPU
512 KB Programmable Flash Memory provides minimum of 10,000 erase/write cycles and
10 years of data-retention.
32 KB + 8 KB Data Memory (SRAM)
Provides 8KB of on-chip RAM accessible to USB by DMA
USB 2.0 Full-speed compliant device controller with 2 KB of endpoint RAM.
In-System Programming/In-Application Programming (ISP/IAP) via on-chip boot loader
software.
Single Flash sector or full chip erase in 400 ms and programming of 256 bytes in 1 ms.
EmbeddedICE RT and Embedded Trace interfaces offer real-time debugging with the on-chip
RealMonitor software and high-speed tracing of instruction execution.
Two 10-bit ADCs provide a total of 14 analog inputs, with conversion times as low as 2.44 us
per channel.
Single 10-bit DAC provides variable analog output.
Two 32-bit Timers/External event counters.
Four Capture and four Compare channels.
PWM unit with six output pins.
Low power Real-time clock with independent power and dedicated 32 kHz clock input.
Multiple serial interfaces including two UARTs, two Fast I2C (400 kbit/s), SPI™ and SSP
with buffering and variable data length capabilities.
Vectored interrupt controller with configurable priorities and vector addresses.
Up to 45 of 5 V tolerant general purpose I/O pins.
Up to nine edge or level sensitive external interrupt pins.
60 MHz maximum CPU clock available from programmable on-chip Phase-Locked
Loop (PLL) with settling time of 100us.
On-chip integrated oscillator operates with external crystal in range of 1 MHz to 25 MHz
Power saving modes include Idle and Power-down.
Individual enable/disable of peripheral functions.
Processor wake-up from Power-down mode via external interrupt.
Single power supply chip with Power-On Reset (POR) and Brown-Out Detection (BOD:
CPU Operating Voltage range of 3.0 V to 3.6 V

www.rhydolabz.com
We bring the world to you..
CHAPTER-2: HARDWARE INTRODUCTION

www.rhydolabz.com
We bring the world to you..
FUNCTION MODULE

www.rhydolabz.com
We bring the world to you..
INTERFACE OVERVIEW
RESET SWITCH
EXTERNAL
INTERRUPT
BUZZER
TEMPERATURE
SENSOR
-
LM35
ADC VARIABLE POT
4 x
4
MATRIX
KEYBOARD
LED ARRAY
LCD DISPLAY
CAN PORT
(For
LCD CONTRAST
SERIAL PORT
INTERFACE (
COM0
)
HEADER BOARD
WITH
LPC 2148
& CIRCUITRY
SERIAL PORT
INTERFACE (
COM1
)
JTAG
CONNECTOR
USB POWER
INTERFACE
5V REGULATOR IC
EXTERNAL EEPROM
MAX3232
DC ADAPTER
PLUG IN

www.rhydolabz.com
We bring the world to you..
POWER SUPPLY
CLOCK SOURCE
Vin
1
GND
2
Vout 3
U5
LM7805
+C12
47uf/16v C16
0.1uF
Vin
3
GND
1
Vout 2
U6
LD1117S33
C13
0.1uF
V3.3
R30
470R
D10
LED
D9
1N4007
J10
PHONEJACK
C14
47uf/10v C17 10uf/10v
1
2
J11
CON2
C15
10uf/10v
1
2
J12
CON2
V5.0
PWR_DC
EXTERNAL POWER SUPPLY
eCee NXP LPC 2148 Board has two power supplies; you can choose one of the following ways to
supply power
(1) Through an Adaptor (any standard 9-12V power supply)
(2) Through the motherboard USB port
The external Power Supply circuit is given below:
eCee NXP LPC 2148 evaluation board has two clock sources:
32.768 KHz as the RTC clock source
10 MHz as the MCU clock source

www.rhydolabz.com
We bring the world to you..
CHAPTER-3 : INTERFACING eCee LPC 2148

www.rhydolabz.com
We bring the world to you..
CONNECTING THE DEVELOPMENT BOARD
The eCee LPC 2148 requires a 9V-12V adapter or USB connection
for power and either a serial connection for In-system programming,
or the JTAG connector.
Use LPC2000 Flash Utility Software at the PC side for
programming through Serial port. Connect eCee LPC 2148
Development board to your PC using USB cable (for powering it)
and serial cable (for In-serial programming) as shown in the figure.
Note: Serial cable should be connected to COM0 Port of the
development board for downloading. Corresponding jumpers has to
be inserted (see circuit diagram) for the functioning of each
peripheral.

www.rhydolabz.com
We bring the world to you..
P
ROGRAMMING STEPS
I. AUTOMATIC MODE
eCee NXP LPC 2148 development board supports two modes of programming
1. Configure LPC Flash Utility software at the PC side
a. Browse your hex file here.
b. Select Crystal frequency here.
c. Enable DTR/RTS for Reset and boot loader selection.
d. Select your COM port and Set baud rate (4800) here.
2. Connect system serial port to COM port of eCee LPC 2148 .
3. Put jumper on RST(J21) , ISP(J17) and Reset the board
4. Click “Read Device ID” and wait till Device Id is shown
5. Click “Upload to Flash” button in the flash utility software and wait till the programming is
over.
6. Remove jumper on ISP and RST
7. Now Reset the development board

www.rhydolabz.com
We bring the world to you..
II. MANUAL MODE
1. Configure LPC Flash Utility software at the PC side
a. Browse your hex file here.
b. Select your COM port and Set baud rate (4800) here.
c. Disable DTR/RTS for Reset and boot loader selection.
2. Connect system serial port to COM port of eCee LPC 2148 .
3. Put jumper on ISP(J17),*ISP(J20)
4. Click “Read Device ID”
5. The software prompts you to reset the development board.
6. Press Reset button (S18) and press OK
7. Wait till Device Id is shown
5. Click “Upload to Flash” button in the flash utility software and wait till the programming is
over.
6. Remove jumper on ISP (J17),*ISP (J20)
7. Now Reset the development board

www.rhydolabz.com
We bring the world to you..
TECHNICAL SUPPORT
If you are experiencing a problem that is not described in this manual, please contact us. Our
phone lines are open from 9:00 AM – 5.00 PM (Indian Standard Time) Monday through Saturday
excluding holidays. Email can be sent to [e-mail]
LIMITATIONS AND WARRANTEES
This product is intended for personal or lab experimental purpose and in no case should be used where
it harmfully effect human and nature. No liability will be accepted by the publisher for any
consequence of its use. Use of the product software and or hardware is with the understanding that any
outcome whatsoever is at the users own risk. All products are tested for their best performance before
shipping, still rhydoLABZ is offering One year Free service warranty (Components cost + Shipping
cost will be charged from Customer).
