Rice Lake RL8025 User manual

70998
RL8025
SkirtedTankStructuralSensor
Installation
Guide

Contents
1. Introduction ............................................................................ 1
2. General Installation of the Sensors...................................... 2
3. Sensor Bolt on Instructions .................................................. 4
5. Sensor Wiring......................................................................... 5
4. Insulation ................................................................................ 5
7. Sensor Specifications............................................................. 6
6. Junction Box Connections, Adjustments & Calibration..... 6
8. Limited Warranty ..................................................................... 8
Copyright © 2003 Rice Lake Weighing Systems. All rights reserved.
Printed in the United States of America.
Specifications subject to change without notice.
March 2003

1
1. Introduction
The RL8025 is a bolt-on strain gage load sensor ideal for processing or inventory
control in both indoor and outdoor applications. It is designed to detect changes in
structureandisdesignedspecificallytoworkwithskirtedtankswherelegsareeither
inaccessibleornon-existent.Itisalsocompatiblewithstandardleggedtanksorsilos
andturnsmost anyunit intoa fullweighing apparatusby measuringthe contentsby
either percent or capacity. The RL8025 can create a signal proportional to the load
from the stress detected in the main support members of tanks or silos. That signal
can then be used to interface with standard weighing indicators such as Rice Lake
Weighing Systems’ 920i programmable weight indicator.
Backed with testing results from –40°to 180°F, the RL8025 is used in groups of
six equally spaced units across the body of a skirted tank (as shown in Figure 1 on
page2), or oneach leg ofa structure (asshown in Figure2 on page3). The RL8025
is available in either alloy steel or optional stainless. It should be noted that the
RL8025 sensor can be used on a wide range of capacity vessels, but care needs to
be used when handling them as they are a sensitive device.
The advantages to using the RL8025 include:
•Lowcost. No lifting oftanks or vessels to installload cells under legs,and
less down time while installing the sensors.
•Durable design. Load sensors are off the ground and out of harms way.
Also no risk of damaged sensors caused by falling objects.
•Easybolt-onweighing. Sensorsbolt ontothetank’s legsor skirtedportion
of the silo. You can calibrate to desired units of measurement (level,
percent full or empty).
•Environmentally sealed. Durable design for indoor or outdoor use.
Authorized distributors and their employees can
view or download this manual from the Rice Lake
Weighing Systems distributor site at www.rlws.com.
The installation should be planned by a qualified structural
engineer.Eachinstallationisunique,andthismanualismeant
to serve only as a general guideline for installation.
Caution

2
2. Installation of the Sensors
There are a number of general guidelines that should be taken into consideration
when choosing a sensor mounting location.
•The placement of load sensors on all load bearing support members
ensures that the entire vessel is being weighed.
•Lookforhiddenloadbearingmemberssuchasdischargechutessupported
on the floor and cross connecting structures, such as catwalks, which can
transferloadsfromadjoiningstuctures.Bothcancausesizableerrorsinthe
sensors. Flexible couplings and slip joint couplings can help with these
problems.
•Sixequallyspacedsensorsshouldbeplacedinalocationthatisconvenient
for servicing and on a mounting surface that is flat, free of paint, free of
weldingseams,andawayfromthedangerofforkliftsandtrucks,asshown
in Figure 1.
Figure 1. Sensor Location and a Typical Application Example
•The RL8025 sensors will not work with double walled skirted vessels.

3
Figure 2. Cross Connecting Support Location
•Thesun’s radiantheat hasalarge impacton loadsensorperformance. The
sun heats steel unevenly, producing stresses in the support members. To
minimizetheproblem,mountsensorsonthebacksideoftanklegs/skirtso
they are out of direct sunlight at all times.
•Acorrosiveatomospherearoundthesensorswilleventuallydamagethem.
Consult with your RLWS distributor for possible preventative measures.
•Theloadmustalwaysbeappliedintheprimaryloadaxis.Extraneousloads
or compound stress must be avoided.
•For vertical support members, select a location about halfway up the
support leg or flange when cross connecting supports are present. Mount
the sensors in the middle of the two supports (shown in Figure 2).
H
1/2H 1/2H H
•WhentheRL8025isinterfacedwitha smartindicatorlikethe920i,itisnot
recommended to configure the indicator to show a displayed weight but
instead, to show vessel contents with graphical icons like a bar graph.

4
3. Sensor Bolt-on Instructions
Once you determine where each sensor will be mounted and in which direction the
sensorisoriented,usethefollowingstepstomountthesensortothesidesofthesilo
or vessel as each sensor comes equipped with mounting hardware that will
accomodate a 1/2" thick material.
1. Be sure that the mounting surfaces are clean, dry, and flat to allow maximum
gripping surface area.
2. Using the sensor and the included plastic drill guides as a template, drill two
5/16" holes. (It is normal for the plastic drill guides to spin during the drilling
process.) Remove the drill guides, install bolts and washers as shown below,
and tighten to 25 ft. lbs torque.
Figure 3. Mounting Example
Insert plastic drill
guides into each
hole before drilling
Thermal
compensation
correction. Consult
factory prior to
adjusting
Install one flat and
one star lock washer
on each side of load cell
T
ank leg /
flange

5
5. Sensor Wiring
Each RL8025 comes with a standard 20-foot weather resistant poly cable.
1. Route each sensor cable so they will not be damaged or cut. Cable should
not be routed near heat sources greater than 150°F. Do not shorten any
sensor cable.
2. Attach red (+) and black (–) leads to a power source (either a metered
power supply @ 10 VDC or a 9-volt battery). Attach a digital volt meter
to the green (+) and white (–) leads. If output reads +15 mV or less, the
sensors are ready for use. If output is over +15 mV, loosen the bolts and
retighten,alternatingtheboltstokeeptheoutputbelow+15mV.Continue
until 25 ft. lbs is reached.
3. Connect the sensors to the junction box which should be mounted outside
of the insulation for easy access. Refer to the guide shown on page 6 and
the labels on the the terminal strips of the junction box for correct wiring.
Toverify the wiring scheme, see the certification shipped withthe sensor.
No summing board is necessary.
4. Insulation
All outdoor applications require insulation to obtain the best accuracy level. After
mountingthesensorsoutofdirectsunlight,placeapieceof2'x2'insulationaround
the section of the leg, or attach the 2'x 2' square to the skirt to cover the sensor and
the surrounding area as shown in the following illustration.
Figure 4. Location of Insulation Wrap
2' x 2'
Insulation
patch
Insulation
wrap
2 FT.

6
4. For optimal performance, use positive and negative remote sense lines if
thewiringrunfromthejunctionboxtotheindicatorislongerthan25feet.
6. Adjustments & Calibration
•Refer to the indicator manual for system calibration guidelines.
roloCeriWlleCdaoL noitcnuF
deRCXE+
kcalBCXE-
neerGGIS+
etihWGIS-
eraBroyarGDLEIHS
7. Sensor Specifications
egnaR.pmeT.pmoCF°051-0
egnaR.pmeTefaSF°081-04-
tuptuOno.tceffE.pmeTF/%5100.
oreZnotceffEpmeTF/%3100.
ecnatsiseRlanimreTMHO007
egatloVnoitaticxECDV51
daolrevOefaS%051
F
B
A
DE
G
C
IH
ABCDEFGHI
Inches
7.19 1.00 .89 1.50 4.79 7.79 1.94 1.25 .50
Millimeters
182.6 25.4 22.6 38.1 121.6 197.8 49.2 31.7 12.7

7
