Richards Cold Shrink R-800 User manual

RP-II-R800G [F]
13
Sheet 1 of 12
www.richards-mfg.com
Product Family
R800
517 Lyons Ave, Irvington, NJ 07111
Phone: [phone]
Fax: [phone]
www.richards-mfg.com Installation Instructions
R800 | Deadbreak Elbow with Fully Integral 200A Loadbreak Tap Plug
Applicable Fastener Type For Use With the Following Cable Types
Jacketed Concentric Neutral (JCN)
Longitudinally Corrugated Neutral (LC)
Tape Shield Neutral
G Style
Applicable Catalog Prefix
15kV Class 25kV Class
618
718
918
628
728
928
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:1 SHEET 1 OF 1
A0
As Noted
WEIGHT:
P215LBLC-01A
15 kV R-800 (F
Style, Test Point)

RP-II-R800G [F]
13
Sheet 2 of 12
www.richards-mfg.com
Product Family
R800
WARNING
• System must be de-energized during installation or future operation of this product or its components.
• Do not touch or move energized connectors or components by hand.
• Excess distortion of the assembled connector may result in its failure.
• Failure to follow these instructions will result in damage to the connector and serious or fatal injury.
• This product should only be installed and/or operated by trained personnel in accordance with normal and safe work procedures.
• Variations in equipment or configuration or work procedures may not be covered in these instructions.
• Please contact Richards Manufacturing for any additional questions.
KIT CONTENTS
Standard kits may include the following. Custom kits may vary.
Check package contents to be sure they are complete, undamaged,and properly sized for the application.
!
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:1 SHEET 1 OF 1
A0
As Noted
WEIGHT:
P215LBLC-01A
15 kV R-800 (F
Style, Test Point)
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:2 SHEET 1 OF 1
A0
As Noted
N/A
WEIGHT: 1.14
21LBIC-01A
15kV 200A
Loadbreak
Insulating Cap
with Green
Insulated Ground
Wire;
Cable
Cable
WARNING
KIT CONTENTS
Applicable Catalog Prefix
Product Family
LCN/LCT
Installation Instructions
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:5:1 SHEET 1 OF 1
A0
Polyethylene (Black)
N/A
WEIGHT: 0.03
CS-CAW
Cable Adapter
Wedge Size LM
Insulation Range:
1.280" - 1.480"
Cable Adapter &
Assembly Aid
P625CA-W
WARNING
KIT CONTENTS
Applicable Catalog Prefix
Product Family
CSHN/CSHT
Installation Instructions
WARNING
KIT CONTENTS
Applicable Catalog Prefix
Product Family
CSHN/CSHT
Installation Instructions
15/16” Hole Shear Bolt Lug
P6ALR-X-15/16
15/16” Hole Compression Lug
P6AL-X-15/16
P7ALCU-X-15/16
P9CU-X-15/16
OR
Insulating Cap
21LBICG (for 15kV Class)
22LBICG (for 25kV Class)
R800 Body
Silicone Lubricant
P6SL1
Stud
P625HIP-STUD
P925HIP-STUD

RP-II-R800G [F]
13
Sheet 3 of 12
www.richards-mfg.com
Product Family
R800
TIP: Use To-Scale Cable Cutback Template as aid to prepare cable.
NOTE: Certain items used, such as PVC tape, may not be included.
1Positioning Cable
A. Straighten and train cable end. Cable should be free to move
approximately 2" in either direction.
B. Cut cable to dimensions shown.
C. Clean cable jacket approximately 24" from end of cable.
TIP: Use to-scale cable cutback template on last page as aid to prepare cable.
NOTE: Certain items used such as mastic, PVC tape, shrink tube, etc. may not be included.
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
1
3
/
4
”
Bushing or
Mating Part
2Exposing Cable Shielding
A. Remove cable jacket to dimensions shown.
B. Abrade area as shown.
Abraded areaCable Jacket
12 3/4”
2 1/2” REF
TIP: Use to-scale cable cutback template on last page as aid to prepare cable.
NOTE: Certain items used such as mastic, PVC tape, shrink tube, etc. may not be included.
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
NOTE: Cable Shielding may be wires, straps, metallic
tape, or LC tape. (Wires shown as example)
3Applying Jacket Mastic
A. Apply jacket mastic at position shown by stretching and wrapping with
light tension fully around outer jacket.
Jacket Mastic
Cable Jacket
1”
TIP: Use to-scale cable cutback template on last page as aid to prepare cable.
NOTE: Certain items used such as mastic, PVC tape, shrink tube, etc. may not be included.
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
4Exposing Cable Semi-Conductive Shield
For Strap/Wire Shielded Cable
A. Fold back strap/wire shields and press firmly into jacket mastic.
B. Secure strap/wire shields to cable with PVC tape as shown.
For Metallic Tape/LC Shielded Cable
A. Wrap PVC tape at dimension shown to secure metallic shield.
B. Remove metallic shield up to PVC tape.
TIP: Use to-scale cable cutback template on last page as aid to prepare cable.
NOTE: Certain items used such as mastic, PVC tape, shrink tube, etc. may not be included.
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
Jacket Mastic under strap/wire shield
Semi-Conductive Shield
PVC Tape
Semi-Conductive
Shield
PVC Tape
Metallic Shield
Jacket
Mastic
10 3/4”
2”
TIP: Use to-scale cable cutback template on last page as aid to prepare cable.
NOTE: Certain items used such as mastic, PVC tape, shrink tube, etc. may not be included.
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com

RP-II-R800G [F]
13
Sheet 4 of 12
www.richards-mfg.com
Product Family
R800
5Exposing Cable Insulation
For Strap/Wire Shielded Cable
A. Remove semi-conductive shield to dimensions shown.
B. Place PVC tape marker at dimension shown.
For Metallic Tape/LC Shielded Cable
A. Remove semi-conductive shield to dimensions shown.
B. Check that tape from previous step is 1” from the edge of the semi-
conductive shield as it will serve as a marker.
!WARNING: Do not nick or cut the cable insulation. !WARNING: Do not nick or cut the cable insulation.
TIP: Use to-scale cable cutback template on last page as aid to prepare cable.
NOTE: Certain items used such as mastic, PVC tape, shrink tube, etc. may not be included.
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
9 3/4”
1”
Cable InsulationPVC Tape (marker)Semi-Conductive
Shield
TIP: Use to-scale cable cutback template on last page as aid to prepare cable.
NOTE: Certain items used such as mastic, PVC tape, shrink tube, etc. may not be included.
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
9 3/4”
1”
Cable InsulationSemi-Conductive
Shield
PVC Tape
(marker)
6Preparing Metallic Shield
For Strap/
Wire
Shielded
Cable
Proceed to
next step
For Metallic Tape/LC Shielded
A. Position copper braid so that solder block rests on
the jacket mastic.
B. Wrap copper braid around metallic shield as shown.
C. Wrap constant force spring over wrapped portion of
copper braid.
D. Wrap 2 layers of PVC tape over constant force spring.
E. Press solder block into jacket mastic.
F. Secure braid to cable with PVC Tape.
CHECK: Confirm that solder block is aligned with jacket
mastic.
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
Metallic Shield
Solder Block
Cable
Jacket
Copper Braid around Tape Shield
Jacket Mastic
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
Securing PVC TapePVC Tape
Tape Marker
Constant
Force Spring
7Exposing Conductor
A. Remove cable insulation. Refer to instructions provided with lug for
insulation cutback dimension. Cutback dimension should not exceed 4 3/8".
Cable Conductor
Cable Insulation
Insulation Cutback
!WARNING: Do not nick or cut the conductor strands.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template before proceeding.

RP-II-R800G [F]
13
Sheet 5 of 12
www.richards-mfg.com
Product Family
R800
8Parking Jacket Seal Tube
A. Slide jacket seal tube onto cable as shown. If using a cold shrink tube, orient pull tab facing away from cable end.
For Strap/Wire Shielded Cable
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
RP-II-93JSCS-AMEREN
2/9/2017
Shim Tube
SCALE 1:2
Jacket Seal Tube
Pull Tab
For Metallic Tape/LC Shielded Cable
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
CHECK: Confirm that solder block is aligned with sealing mastic.
4 3
8
"
Wipe Direction
Cable Insulation
Cable Conductor
Wrap constant force spring over wrapped portion of copper braid. C.
Wrap 2 layers of PVC tape over constant force spring. D.
Press solder block into sealing mastic. E.
Secure braid to cable with PVC Tape. F.
For Metallic Tape Shield/LC Shielded
Position copper braid so that solder block rests on the sealing mastic. A.
Wrap copper braid around metallic tape shield as shown. B.
STEP 6-Preparing Metallic Shield
STEP 7- Exposing the Conductor
Remove cable insulation to dimension shown. A.
Clean isulation with approved cleaning wipes by wiping from cable B.
end to shielding.
NOTE: Confirm all dimensions with To-Scale Cable Cutback Template on last
page before proceeding.
WARNING: Do not nick or cut conductor strands.
For Strap/Wire Shielded Cable
Go to Step 7
STEP 8- Parking Shrink Tube
Slide heat or cold shrink tube onto cable as shown. A.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
Product Family
LCN/LCT
Installation Instructions
www.richards-mfg.com
RP-II-62LCN [E]
Rev. E
Sheet 9 of 9
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
RP-II-93JSCS-AMEREN
2/9/2017
Shim Tube
SCALE 1:2
Jacket Seal Tube
Pull Tab
9Installing Cable Adapter
A. Slide cable adapter assembly aid up to insulation.
B. Clean insulation with approved cleaning wipes by wiping in direction of semi-conductive shield.
C. Apply silicone lubricant to cable insulation, cable adapter assembly aid, and inside of cable adapter as shown.
D. Slide cable adapter onto cable until the cable adapter sits flush with the leading edge of the tape marker as shown.
A A
D D
N N
R R
DRAWN
Cable Adapter
Push
Lubricate
(Internal Cavity)
Slide up to here
Push
Cable Adapter Assembly AidTape Marker
(From Step 5)
Lubricate
E. Remove cable adapter assembly aid.
F. Confirm cable adapter is positioned as shown below. Insulation may extend beyond adapter as long as both checks below are confirmed.
A A
D D
N N
R R
DRAWN
4 7/16” to 5 1/8”
Remove
Tape Marker
(From Step 5)
Cable Adapter
Cable adapter edge
CHECK: Confirm that edge of tape marker is flush with end of cable adapter as shown.
CHECK: Confirm that dimension from end of conductor to cable adapter edge satisfies criteria shown above.

RP-II-R800G [F]
13
Sheet 6 of 12
www.richards-mfg.com
Product Family
R800
10 Installing Lug
!WARNING: Lug MUST have a 15/16” hole. Confirm lug and hole dimension before installing lug.
A. Clean conductor of any debris. For aluminum conductor, wire brush and
immediately insert lug onto conductor. Slide lug until the conductor is fully
seated within the lug barrel.
B. Rotate lug so that spade is parallel to the contact face of the bus as shown.
C. For Shear Bolt Connectors: Install lug using separate instructions provided
with lug.
For Crimp Connectors: Select correct tool and die using crimp chart supplied
with lug. Crimp lug (min. number indicated in crimp chart) starting just below
knurl line adjacent to pad. Carefully wipe any excess inhibitor from lug and
cable insulation.
A A
D D
N N
R R
DRAWN
Lug
Bushing
Ensure surfaces are parallel
before installing lug
!Confirm that the distance from the end of the lug to the cable
adapter after installing is as shown. Otherwise redo assembly.
A A
D D
N N
R R
DRAWN
7 1/4” MAX
Lug
Cable Adapter
Locate first
crimp here
Knurl Line

RP-II-R800G [F]
13
Sheet 7 of 12
www.richards-mfg.com
Product Family
R800
11 Installing R800 Housing
A. Clean and lubricate (using supplied or approved silicone grease) entire surface
of cable adapter and cable entrance of R800.
B. Without moving cable adapter, push R800 onto cable adapter and slide until
lug is fully seated inside R800. Confirm cable adapter has not shifted by
observing tape marker. Cable adapter and tape marker should be aligned as
they were in the "Installing Cable Adapter" step.
1
4
"
STEP 12-Applying Shrink Tube
Slide seal tube into position as shown. A.
Shrink down seal tube starting from cable adapter side. B.
Heat or Cold Shrinkable Tube
Shield Wires
Strap/Wire Shielded
1
4
"
Copper Braid
Heat or Cold Shrinkable Tube
Metallic Tape Shielded/LC Shielded
Product Family
R800
Installation Instructions
www.richards-mfg.com
RP-II-R800G
Rev. B
Sheet 5 of 8
517 Lyons Ave.
Irvington, NJ 07111
Phone [phone]
Fax [phone]
www.richards-mfg.com
R800
Interface
Lug Hole
!WARNING: Confirm cable adapter does not shift from proper
positioning during installation of R800 housing.
!WARNING: Confirm the lug has fully seated into housing as
shown.
A A
D D
N N
R R
DRAWN
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:5 SHEET 1 OF 1
A0
N/A
WEIGHT:
CS-R800-Instruction
R800 Housing
Lug
Ensure adapter does not shift during
installation of R800 Housing
Clean and
Lubricate
Clean and Lubricate
(Internal Cavity)

RP-II-R800G [F]
13
Sheet 8 of 12
www.richards-mfg.com
Product Family
R800
12 Inserting Hex Tool
A. Insert Hex tool (P620AT or equivalent 5/
16
" hex tool) through loadbreak interface and engage fastener.
B. Slide fastener into forward position through lug hole (as shown in detail view).
!Fastener is factory-installed in a retracted position. The Fastener must be stroked into forward position. The female threaded end of
Fastener will then extend into the 15/16" Threaded hole of the Lug.
!Confirm that fastener goes through lug hole.
Fastener in the retracted position
Fastener
Lug
Hex Tool Push
Fastener stroked into forward position
through Lug Hole
Fastener through
Lug Hole
Clean
and
or
Deadbreak Interface may be one of the following:
Deadbreak Interface
Optional
STEP 15-Mating Deadbreak Interface
STEP 14- Inserting Hex Tool
Clean
and
Product Family
R800
Installation Instructions
Torque Limited 5/16" Hex Tool
(Richards P620AT or equivalent)
Loadbreak
Interface

RP-II-R800G [F]
13
Sheet 9 of 12
www.richards-mfg.com
Product Family
R800
13 Mounting R800
A. Hand-tighten stud into the appropriate mating part or bushing.
B. Clean and lubricate (using supplied or approved silicone grease) deadbreak interface of R800 and interface of mating part or bushing.
C. Push R800 onto mating part, lining up the hole in the lug with the stud on the mating part.
D. Rotate Fastener with hex tool to engage threads and tighten the assembly. Torque fastener to 20ft-lb (P620AT Tool has built in 20ft-lb torque limiter).
STEP 15-Mating Deadbreak Interface
STEP 14- Inserting Hex Tool
Product Family
R800
Installation Instructions
Optional Test
Point
Deadbreak
Interface
Clean and
Lubricate
Mating Part or
Bushing
Clean and Lubricate
(Internal Cavity)
Stud
!WARNING: A standard threaded stud is included in the kit. If the use of an asymmetrical threaded stud is approved, it MUST be installed
with longer threaded side facing AWAY from equipment as shown below.
Correct

Incorrect
✘

RP-II-R800G [F]
13
Sheet 10 of 12
www.richards-mfg.com
Product Family
R800
14 Installing Mating Component
A. Clean and lubricate (using supplied or approved silicone grease) loadbreak interface of R800 and interface of insulating cap or mating part.
B. Install mating component per manufacturer instructions. Loadbreak Cap shown as reference.
Loadbreak
Interface R800
Clean and
Lubricate
Insulating Cap or
Mating Component

RP-II-R800G [F]
13
Sheet 11 of 12
www.richards-mfg.com
Product Family
R800
15 Applying Sealing Mastic
For Strap/Wire Shielded Cable
A. Apply sealing mastic over previously applied mastic and on top of
folded back neutral wires by stretching and wrapping with light tension.
B. Apply sealing mastic by stretching and wrapping with light tension fully
around nose of cable adapter for a width of 1” as shown below.
For Metallic Tape/LC Shielded Cable
A. Apply sealing mastic over previously applied mastic and on top of solder
block by stretching and wrapping with light tension.
B. Apply sealing mastic by stretching and wrapping with light tension fully
around nose of cable adapter for a width of 1” as shown below.
STEP 12-Applying Shrink Tube.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
STEP 13-Installing Elbow Housing
Product Family
LCN/LCT
Installation Instructions
Sealing Mastic (Step A)
Sealing Mastic (Step B)
1”
Shield Wires
STEP 12-Applying Shrink Tube.
Strap/Wire Shielded
STEP 13-Installing Elbow Housing
Product Family
LCN/LCT
Installation Instructions
Copper Braid
Sealing Mastic (Step A)
Sealing Mastic (Step B)
1”
16 Applying Jacket Seal Tube
A. Beginning with the side closer to the cable adapter, deploy the jacket seal in area shown below ensuring both mastics are completely covered.
For Strap/Wire Shielded Cable
STEP 12-Applying Shrink Tube.
Strap/Wire Shielded
Metallic Tape Shielded/LC Shielded
STEP 13-Installing Elbow Housing
Product Family
LCN/LCT
Installation Instructions
STEP 17-Connecting Deadbreak Elbow to Ground
Product Family
LCN/LCT
Installation Instructions
Jacket Seal Tube
Mastic Mastic
For Metallic Tape/LC Shielded Cable
STEP 12-Applying Shrink Tube.
Strap/Wire Shielded
STEP 13-Installing Elbow Housing
Product Family
LCN/LCT
Installation Instructions
STEP 17-Connecting Deadbreak Elbow to Ground
Product Family
LCN/LCT
Installation Instructions
Jacket Seal Tube
Mastic Mastic

RP-II-R800G [F]
13
Sheet 12 of 12
www.richards-mfg.com
Product Family
R800
17 Connecting Drain Wires to R800
For Strap/Wire Shielded Cable
A. Secure neutrals with binding wire or zip tie 1" from jacket seal tube.
B. Insert one end of a piece of wire (#14 AWG copper or larger) through one of the available grounding eyes and twist to make a small loop. Be sure not to
damage grounding eye.
C. Connect other end of wire to shield wires.
D. Ground the cable shield according to appropriate/approved practice.
Ground Eye Drain Wire
To Ground
1”
Binding Wire or Zip Tie
For Metallic Tape/LC Shielded
A. Secure copper braid with binding wire or zip tie 1" from jacket seal tube.
B. Insert one end of a piece of wire (#14 AWG copper or larger) through one of the available grounding eyes and twist to make a small loop. Be sure not to
damage grounding eye.
C. Connect other end of wire to copper braid.
D. Ground the cable shield according to appropriate/approved practice.
Ground Eye Drain Wire
To Ground
1”
Binding Wire or Zip Tie
Installation Complete
