Richman RM310 User manual

RM310
3+1 burners gas grill
1
Dear customer,
Congratulations on your purchase of the RICHMAN 200 grill. This product has been developed on the
basis of the latest technical knowledge and produced using reliable and high quality components.
Please take a few minutes before starting operation of the gas grill unit and read the following operating
instructions. The instruction shall be marked directions to the installer to leave them with the consumer
and to the consumer to retain them for future reference.
Example only: SERIAL#______MFG. DATE________ PURCHASE DATE:________
Question, problems, missing parts? Before returning to your retailer, call our customer
1. Out door use only
2. This grill in not intended to be installed in or on
recreational vehicles and/or boats.

RM310
3+1 burners gas grill
2
service department at 1-866-898-8187, M-F 9:00am-5:00pm.
TABLE OF CONTENTS
zSafety Information………………………………………………………………………………………………………………………….……
zPackage Contents List…………………………………………………………………………………………………………………….……
zAssembly Instructions………………………………………………………………………………………………………………………….
zRegulator & Hose Instructions, Gas Tank Instructions………………………………………………………….……….…
zOperating instructions…………………………………………………………………………………………………………………………
zCooking Tips………………………………………………………………………………………………………………………………..………
zCare and maintenance………………………………………………………………………………………………………………....……
zTroubleshooting…………………………………………………………………………………………………………………….……………
zWarranty……………………………………………………………………………………………………………………………………..….….
Danger
If you smell gas
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
1. Do not store or use gasoline or
other flammable liquids or vapors
in the vicinity of this or any other
appliance.
2. An LP cylinder not connected for
use shall not be stored in the
vicinity of this or any other
appliance.

RM310
3+1 burners gas grill
3
zSafety Information
Warning
zFailure to comply with these instructions could result in a fire or explosion that could cause serious
bodily injury, death or property damage.
zSpiders and small insects can spin webs and nest in the grill burner tubes during transit and
warehousing which can lead to a gas flow obstruction resulting in a fire in and around the burner
tubes. This type of “FLASHBACK FIRE” can cause serious grill damage and create an unsafe
operating condition for the user.
To reduce the chance of a FLASHBACK FIRE you must clean the burner tubes as follows before
initial use. Also do this at least once a month in summer and fall or whenever spiders are active in your
area, and if your grill has not been used for an extended period of time.
-1. Remove the screw from the rear of each burner using a Phillips head screwdriver.
-2.Carefully lift each burner up and away from the gas valve orifice.
-3.Check and clean the burner tubes for insects and insect nests. A clogged tube can lead to a fire
beneath the grill.
-4.Refer to the figure below and perform one of these 3 cleaning methods:
METHOD 1: Bend a stiff wire or wire coat hanger into a small hook as shown and run
the hook through the burner tube and inside the burner several times to remove debris.
METHOD 2:Use a bottle brush with a flexible handle and run the brush through the burner
tube and inside the burner several times to remove any debris.
METHOD 3: Use an air hose to force air through each burner tube. The forced air should pass
debris or obstruction through the burner and out the ports.
For safe operation ensure the gas valve assembly orifice is inside the burner tube before using your grill.
See figure. If the orifice is not inside the burner tube, lighting the burner may cause an explosion and/or
fire resulting in serious bodily injury and/or property damage.

RM310
3+1 burners gas grill
4
Grill Installation Codes
The installation must conform with local codes or, in the absence of local codes, with either the national
fuel gas code, ANSI Z 223.1/NFPA 54, Natural gas and propane installation code, CSA B149.1, or
propane storage and handling code, B149.2, or the standard for Recreational vehicles, ANSI A 119.2,
and CSA Z240 RV series recreational vehicle code, as applicable.
LP gas grill models are designed for use with a standard 20 lb. Liquid Propane Gas tank, not included
with grill. Never connect your gas grill to an LP gas tank that exceeds this capacity.
Warning
Liquid Propane Gas (LPG) grill models must be used with the liquid propane gas regulator
assembly supplied. Any attempt to convert the grill from one fuel type to another is extremely
hazardous and will void the warranty.
Grill shall be used only outdoors and shall not be used in a building, garage or any other enclosed area.
Never obstruct the flow of ventilation air around your gas grill cabinet.
Never disconnect the gas regulator assembly or any gas fitting while your grill is lit. A lit grill
can ignite leaking gas and cause a fire or explosion which could result in property damage, personal
injury or death.
Keep the gas regulator hose away from any heated surface and dripping grease. Avoid
unnecessary twisting of the hose. Visually inspect the hose prior to each use for cuts,
cracks, excessive wear, or other damage. If the hose appears damaged, do not use the gas
grill. Call 1-866-898-8187 for a Richman replacement gas hose assembly
Warning
zThe gas hose should be inspected after each use-look for any cuts, cracks, excessive wear or other
damage. Let the hose be replaced every two years by a qualified technician or the retailer only.
zOnlyusehoseandregulatorsapprovedforLPGGas.
zAvoid twisting and bending of the gas hose.
zKeep the gas hose or any other electrical cords away from hot surfaces of the grill.
zThe gas hose must comply with national regulations and should not be longer than 1.5 meters.

RM310
3+1 burners gas grill
5
PRE-ASSEMBLY
Read and perform the following pre-assembly instructions:
□Tools Required for Assembly include:
․protective work gloves
․protective eyewear
․Phillips Head Screwdriver (included in hardware pack in Parts Box)
□You will need assistance from another person to handle the grill head and other large, heavy parts.
□Open lid of shipping carton and remove parts box and packing materials. Lay a cardboard sheet on
floor and use as a work surface to protect floor and grill parts from scratches.
□Slice all four corners with a utility knife to lay open the carton. This allows you to remove the grill
head and components packed inside.
□Use the Hardware and Part Diagrams to ensure all items are included and free of damage.
Do not assemble or operate the grill if it appears damaged or missing parts.
1. Out door use only
2. This grill in not intended to be installed in or on recreational vehicles and/or boats.

RM310
3+1 burners gas grill
6
zPackage and Hardware Contents List
NO. DESCRIPTION QTY NO. DESCRIPTION QTY
81
1
1
2
3
4
5
6
71
1
1
3
2
1
91
10 1
12 1
13 3
14 1
15 1
17 1
16 1
11 1
Fri ebox Assembl y
WarmingRack
CookingGrids
Fl ame Tamers
Ri gnt Rent
Ri ght Si de Burner Assembl y
Swivel LockingCaster
Tank Bol t
Ri ght Door
Door Handl e
Case Body Ri ght Panel
Case Body Back Panel
Electronic Igniter Holder
El ect roni c Igni t er
Bott l e Opener
Swi vel Caster

RM310
3+1 burners gas grill
7
NO. DESCRIPTION QTY NO. DESCRIPTION QTY
1
18
19 1
20 1
21 1
1
24
2
26 1
27 1
28 1
29 1
30 1
31 1
33
1
34
2
32
1
22 2
23
1
25
35
2
Motor Base
Left Vent
Left Drawer Assembl y
Gar eas e Box
Ti ssue Hanger Hol der
Car t Bear m Front
Ti ssue Hanger
Door Magnet
Case Body Lef t Panel
St rai ght Cast er
BottomPanel
Door Crosspi ece
Door - hi nge
Codi ment Tray
Manual Igni ter Sti ck
Left Door
Gas Tank Barrier Bar
WarmingRack Holder 2
36

RM310
3+1 burners gas grill
8
F
NO. DESCRIPTION QTY
A
B
C
D
E
H
26
19
13
2
2
10
2
G6
SUS430 1/4"-i n. X10-mmTr uss
He a d Sc r ew wi t h l o c k i ng was he r
Q235 5/32 Nut
SUS430 1/4"-i n. X12-mmTr uss
Hea d Sc r e w wi t h l o c k i ng wa s he r
SUS430 5/32"i n. X10mmTruss Head Screw
Flat SilicomWasher
SUS430 1/4"-i n. X10-mmSt age Scr ew
Q235 5/32"-i n. X10-mmTruss Head Screw
Q235 1/4"-i n. X10-mmTruss Head Screw

RM310
3+1 burners gas grill
9
zParts Diagram
1
2
3
4
5
6
7
9
10
11 12
13
14
15
16
17
19
20
21
24
26
25
18
27
29
28
31
30
34
32
35
8
22
23
33
36

RM310
3+1 burners gas grill
10
zAssembly Instructions
Step 1. Install Casters and Tank Bolt
□Place the Bottom Panel (34) upside down and attach the 4 Casters to the Caster Seats. Use care to
install each Caster into the correct position.
□Insert the Tank Bolt (15) to the front of the Bottom Panel (34) as shown picture.
35
17
34
15
16
A
16(1X)
17(1X)
35(2X)
A(16X)
15(1X)
34(1X)
Step 2. Install Case Body and Gas Tank Barrier Bar
□Attach the Case Body (11, 12 & 26) and the Door Crosspiece (33) to the Bottom Panel (34) as shown
picture.
□Attach the Gas Tank Barrier Bar (36) to the Bottom Panel(34) and the Case Body Back Panel(11)
12
11
26
31
33
B
C
12(1X)
11(1X)
26(1X)
31(1X)
33(1X)
B(9X)
C(6X)

RM310
3+1 burners gas grill
11
Step 3. Install Firebox Assembly to Case Body Assembly and
connection of Electric Igniter
□Place the Firebox Assembly（1）ontheCaseBodyAssemblyandlockitupby6TrussHead
Screws（B）. We recommend using 2 people to lift the Firebox Assembly (1)
□Connect the Electric Igniter to Switch Line and Igniter Wire Line tighten as shown
9
1
B
1 (1X)
9 (1X)
B(6X)
Step 4. Install Door Magnet, Electronic Igniter and Battery
□Attach Door Magnet(25) to the Front Cart Beam（23）as shown picture.
□Attach the Electric Igniter Holder（10）to the Front Cart Beam（23）using Truss Head Screws
□Put the Electric Igniter to the Electric Igniter Holder as shown and unscrew the electronic igniter cap.
Place the “AA” Battery into the igniter with the positive (+) end up. Screw the electronic igniter cap
back into place.
23
25
10
10(1X)
23(1X)
25(2X)
C(2X)

RM310
3+1 burners gas grill
12
Step 5. Install Front Cart Beam and Vents
□Attach the Front Cart Beam(23) to the front of Firebox Assembly(1) using Truss Head Screws(B)
□Using Flat Silicon Washer(E) and Stage Screws(D) lock Left Vent(19) and Right Vent(5) to the
Firebox Assembly(1)
5
E
D
19
B
5 (1X)
19(1X)
D (2X)
E (2X)
B(4X)
Step 6. Install Drawer Handle and Tissue Hanger
□Attach the Drawer Handle(13) to the Front Panel of Drawer using Nuts (G)
□Attach the Tissue Hanger(24) to the bottom of Drawer using two Tissue Hanger Holder(22) and lock
it up by 4 Truss Head Screws(F)
F
13
22
24
G
22 (2X)
24 (1X)
13 (1X)
F (4X)
G (2X)

RM310
3+1 burners gas grill
13
Step 7. Install Left Drawer Assembly to Firebox Assembly.
□Loosely screw 2 Truss Head Screws with Locking Washer (A) into two holes on the left side of the
firebox as shown. Slide the Left Drawer Assembly (20) over the heads of those screws and tighten.
A (2X)
Step 8. Secure Left Drawer Assembly to the Firebox
Assembly and install Warming Rack Holder
□Use 3 Truss Head Screws(A) from inside of the firebox to secure attached Left Drawer Assembly as
shown
□Attach the Warming Rack Holder (36)to both inside panel of firebox using 3 Truss Head Screws(F)
A
F
36
F (3X)
A (3X)
36(1X)

RM310
3+1 burners gas grill
14
Step 9. Install Right Side Burner Assembly to Firebox
Assembly.
□Loosely screw 2 Truss Head screws into the bottom two holes in the right side of the firebox as
shown. Slide the Side Burner Assembly over the heads of those screws and tighten.
A (2X)
Step 10. Secure Right Side Burner Assembly to the Firebox
Assembly and Connection of Side Burner Valve
□Use 3 Truss Head Screws (A) from inside of firebox to secure attached Right Side Burner Assembly.
□Attach Right Side Burner Assembly (7) to the firebox from the bottom of Side Burner Assembly as
shown.
□Connect Side Burner Valve to Connector of Gas Appliance, Switch Line and Ignition Wire Line from
the bottom of the Side Burner Assembly as shown.
□Attach Left Drawer Assembly (7) to the firebox from the bottom of Left Drawer Assembly as shown.
□Attach the Warming Rack Holder (36) to the right side panel of firebox using 3 Truss Head Screws(F)
F (3X)
F
A
A (3X)
36(1X)
36
C (2X)
C
C

RM310
3+1 burners gas grill
15
Step 11. Install Door Handle and Door-hinge
□Attach the Door Handle (13)to the Doors (14 & 27) using 2 Nuts(G) and the Door-hinge(32)
at the bottom of the Door(14 & 27)
32
14
13
27
G
27 (1X)
13 (2X)
14 (1X)
G (4X)
32(2X)
Step 12. Place Condiment Tray and Manual Igniter Stick into
Case Body Assembly
□Put the Condiment Tray (30) into two holes of the Left Door (27)
□Attach the Cover of Manual Igniter Stick (29) and Manual stick (28) to the Door (14) using the Truss
Head Screws(C) and put the Manual stick (28) into the Cover (29)
□Attach the Bottle Opener (8) to the right side of Side Burner Assembly (7) as shown.
C
28
29
30
8
C28 (1X)
29 (1X)
30 (1X)
C (3X)
8 (1X)

RM310
3+1 burners gas grill
16
Step 13. Place Flame Tamers, Cooking Grids, Warming Rack,
Side Burner Cooking Grid and Grease Box into the Firebox
Assembly
□Place the Flame Tamers (4) into the Firebox Assembly (1).
□Place the Cooking Grids (3) into the Firebox Assembly (1).
□Place the Warning Rack (2) into the slots along the top of Firebox Assembly (1) as shown.
□Place the Side Burner Cooking Grid (6) into the Right Side Burner Frame (7).
□SlidetheGreaseBox(21)fromthebackoftheFireboxAssembly.
3 (2X)
2 (1X)
4 (3X)
21 (1X)
6 (1X)
Step 14. Exchange Vents to Motor Base
□Unscrew the Vents (5 & 19) and attach the Motor Base (18) to the Firebox Assembly (1) using 2
Truss Head Screws as shown.
18 (1X)
H (2X)

RM310
3+1 burners gas grill
17
Step 15. Place LP Cylinder into the Cabinet
□Place the LP cylinder down into the tank support hole in the bottom of the cabinet. Use the tank bolt
to secure the tank in a fixed position with tank valve faces to the front.
Do Not Hook Up the LP Cylinder to the Regulator Assembly at this time.
Step 15. Congratulations – Assembly is now Complete
□Remove any additional labels or packing material from the grill except the CSA label. Be sure to clean
all foam packing material out of all areas.
□Please proceed to and read the remaining sections of the Operator’s Manual prior to hooking up your
LP cylinder or operating your grill.

RM310
3+1 burners gas grill
18
zRegulator & Hose Instructions, Gas Tank Instructions
Gas Installation
Correct LP gas tank use
zLP gas grill models are designed for use with a standard 20 lb. (9.1kg) Liquid Propane Gas (LP Gas)
tank, which is not included with the grill. Never connect your gas grill to an LP gas tank that
exceeds this capacity. A tank of approximately 12” (305mm) in diameter by 18-1/2”(472mm) high
is the maximum size LP gas tank to use. You must use an “OPD” gas tank which offers a listed
Overfill Prevention Device. This safety feature prevents tanks from being overfilled which can cause
malfunction of the LP gas tank, regulator and grill.
zThe LP gas tank must be constructed and marked in accordance with the Specifications for LP-Gas
Cylinders of the U.S. Department of Transportation (D.O. T.) or the National Standard of Canada,
CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of Dangerous Goods; and
Commission, as applicable.
zThe LP gas tank must have a shutoff valve terminating in a LP gas supply tank valve outlet that is
compatible with a Type 1 tank connection device. The LP gas tank must also have a safety relief
device that has a direct connection with the vapor space of the tank.
zThe tank supply system must have a means for vapor withdrawal.
zThe LP gas tank used must have a collar to protect the tank valve.
zNever connect an unregulated LP gas tank to your gas grill. The gas regulator assembly supplied
with your gas grill is adjusted to have an outlet pressure of 11”water column (W.C.) for connection
to an LP gas tank. Only use the regulator and hose assembly supplied with your gas grill.
Replacement regulators and hose assemblies must be those specified by Richman.
zHave your LP Gas dealer check the release valve after every filling to ensure it remains free of
defects.
zAlways keep the LP gas tank in an upright position. Do not subject the LP gas tank to excessive
heat.
zNever store an LP gas tank indoors. If you store your gas grill indoors, always disconnect the LP
gas tank first and store it safely outside.
zLP gas tanks must be stored outdoors in a well-ventilated area and out of the reach of children.
zDisconnected LP gas tanks must not be stored in a building, garage, or any other enclosed area.
zThe regulator and hose assembly can be seen after opening the door (if applicable) and must be
inspected before each use of the grill. If there is excessive abrasion or wear or if the hose is cut, it
must be replaced prior to using the grill again.
zNever light your gas grill with the lid closed or before checking to ensure the burner tubes are fully
seated over the gas valve orifices.
zNever allow children to operate your grill. Do not allow children or pets to play near your grill.

RM310
3+1 burners gas grill
19
zUse of alcohol or drugs may impair the ability to assemble and operate the appliance.
zKeep a fire extinguisher readily accessible. In the event of an oil or grease fire, do not attempt to
extinguish with water. Use a type B extinguisher or smother with dirt, sand, or baking soda.
zIn the event of rain, cover the grill and turn off the burner and gas supply.
zUse your grill on a level, stable surface and ensure the locking casters are locked before use.
zDo not leave the grill unattended when in use.
zDo not move the appliance when in use.
zAllow the grill to cool before moving or storing.
zDo not use your grill as a heater.
zThis grill is not intended to be installed in or on recreational vehicles and /or boats.
It is very important to keep your appliance’s clear and away from any combustible materials.
Maintain at least 24 inches of clearance from sides and back and do not use under overhead
combustible construction.
Warning
A. Do not store a spare LP gas tank under or near this appliance.
B. Never fill the tank beyond 80 percent full;
C. If the information in “(a)”and “(b)” is not followed exactly, a fire causing death or serious injury may
occur.

RM310
3+1 burners gas grill
20
NO overhead combustible
construction
Notes about LP Gas Tank Exchange Programs
zMany retailers that sell grills offer you the option of replacing your empty LP gas tank through an
exchange service. Use only those reputable exchange companies that inspect, precision fill, test
and certify their tanks. Exchange your tank only for an OPD safety feature equipped tank as
described in the LP gas tank section of this manual.
zAlways keep new and exchanged LP gas tanks in an upright position during use, transit or storage.
zLeak test new and exchanged LP gas tanks BEFORE connecting one to your grill.
Testing for gas leak
zTest all connections for gas leaks before first use, at the beginning of each new season, or when
gas cylinder was changed.
zMake sure procedure is carried our in well ventilated area and never in a presence of flame, sparks
or heat source. If you smell gas, never attempt to light the grill.
zMake sure that all temperature knobs on the grill are in the OFF position.
zOpen the gas valve of the gas cylinder and/or the pressure regulator.
zTest all connections for leaks. For testing use a half water/half soap solution. Apply the solution to
the connection points with a brush.
