Auto Flash
OPERATING MANUAL
Cover_1-4.fm Page 1 Friday, December 20, 2013 4:04 PM

1
Thank you for purchasing the Auto-flash AF540FGZ II/
AF360FGZ II.
In addition to easy daylight sync photography with P-TTL auto,
the AF540FGZ II/AF360FGZ II also allows wireless P-TTL
auto photography and high-speed sync in combination with a
digital single lens reflex camera or lens-interchangeable single
lens digital camera.
Please read this operating manual before using this flash unit.
For Use with the Following Models:
645D, K-5II, K-5IIs, K-5, K-30, K-50, K-500, and K-r
When using the flash unit with the models listed above, the camera’s
firmware needs to be updated to the latest version in order to use the
LED beam as the AF-assist spot beam. (Refer to page 53.)
This update corrects the focus position deviation caused by
the difference in wavelengths between the AF-assist spot beam
of this flash unit and existing flash units.
The LED beam cannot be used as the AF-assist spot beam when
using the flash unit with the digital single lens reflex cameras released
before the K-7 and K-x. Set OFF for AF Spot Beam (Sb) in the function
menu. (Refer to page 52.)
Firmware Download URL:
http://www.ricoh-imaging.co.jp/english/support/download_digital.html
Although we have carefully designed this flash unit for safe
operation, please pay special attention to items marked
with the following symbols when using the flash unit.
WARNING
This symbol indicates that violating this item could cause
serious personal injuries.
CAUTION
This symbol indicates that violating this item could cause minor
or medium personal injuries, or loss of property.
is a symbol indicating items that are prohibited.
is a symbol emphasizing a warning.
Introduction
This operating manual applies to AF540FGZ II and
AF360FGZ II.
The illustrations used in this operating manual are those
of AF540FGZ II.
FOR THE SAFE USE OF YOUR FLASH UNIT
WARNING
The flash contains electronic circuits that operate at
high voltages. Do not attempt to disassemble the flash
unit yourself, as there is danger of an electric shock.
If internal parts of the flash unit become exposed due
to impact, etc., do not touch them as there is danger
of an electric shock.
Do not expose the flash unit to water or moisture as
there is danger of an electric shock.
AF360FZ_540FGZ.book Page 1 Friday, December 20, 2013 6:11 PM

2
CAUTION
Do not use the flash and/or LED beam near a person’s
eyes, as it may hurt them. Be particularly careful when
using the flash around infants.
The following may lead to an explosion or fire.
lShorting the batteries
lExposing the batteries to flames
lDismantling the batteries
lRemove the sticker covering the battery
lAttempting to recharge non-rechargeable batteries
Remove the batteries from the camera immediately if
they become hot or begin to smoke. Be careful not to
burn yourself during removal.
AF360FZ_540FGZ.book Page 2 Friday, December 20, 2013 6:11 PM

3
Precautions for Your Flash Unit
lNever use organic solvents such as paint thinner, alcohol
or benzine to clean the flash unit.
lAvoid leaving the flash unit for extended period in places
where the humidity and temperature are very high such as
in a car.
lBe careful not to subject the flash unit to strong vibrations,
shock or pressure. Use a cushion to protect the flash unit
when carrying it in a motorcycle, car, boat, etc.
lThe flash unit is designed to be water-proof and dust-proof.
However, do not use the flash unit where it may be directly
exposed to rain, water, etc.
lWhen using the flash unit off the camera, do not try to
attach any metallic object to the electric contacts or to
mount incompatible accessories. Otherwise, the P-TTL
auto mechanism may be damaged or rendered inoperable.
lPeriodic checks are recommended every 1 to 2 years in
order to maintain high performance. If the unit has not
been used for an extended period of time, or is being
readied for an important shoot, it is recommended that you
take a test flash with the test button and test shoot with it.
Test flash is also important to maintain optimum
performance.
lAvoid contact with garbage, dirt, sand, dust, water, toxic
gases, salt, etc. When the flash unit is subjected to rain
or moisture, wipe it off with a dry cloth.
lWhen photographing black or white subjects, use
exposure compensation.
lThe flash unit may become hot when discharges many
times in succession, resulting in damage or malfunction.
lDo not attach any accessories such as the hot shoe grip
which have the different number of electrical contacts.
lThe hot shoe of the camera incorporates flash signal
contacts. Dirt, dust, or corrosion on the contacts may
cause a malfunction.
lWe will not be held responsible for any accidents or
damage, etc. caused due to the use of this product with
cameras and accessories made by the other companies.
lThe LED beam of the unit is to assist shooting with a
camera. Do not use the LED beam for other purposes.
AF360FZ_540FGZ.book Page 3 Friday, December 20, 2013 6:11 PM

4
nCautions Regarding Batteries
lThis flash unit uses four AA alkaline, lithium, or nickel metal
hydride batteries. Do not use any other types of batteries.
The flash unit may not be able to operate correctly or
demonstrate sufficient performance, or the flash unit itself
may generate heat, depending on the type of batteries used.
lAA alkaline and lithium batteries themselves are not
rechargeable. Also, do not dismantle the batteries.
Trying to recharge or dismantle the batteries may cause
an explosion or leakage.
lWhen changing batteries, do not mix batteries of different
types or capacities, or from different manufacturers.
lDo not insert the batteries with the positive (+) and
negative (-) terminals the wrong way around. Incorrect
insertion may lead to an explosion or fire.
lBattery performance may temporarily be hindered in low
temperatures. Batteries should be kept warm in
temperatures below freezing for proper performance.
lIf you do not intend to use the flash unit for an extended
period of time, remove the batteries. Leaving them in may
cause damage to the flash unit due to leakage etc.
lDo not short the batteries or dispose of the batteries in fire.
Do not disassemble the batteries. The batteries could
explode or catch fire.
lRemove the batteries from the flash unit immediately if they
become hot or begin to smoke. Be careful not to burn
yourself during removal.
AF360FZ_540FGZ.book Page 4 Friday, December 20, 2013 6:11 PM

5
Introduction......................................................................................... 1
FOR THE SAFE USE OF YOUR FLASH UNIT.................................. 1
Precautions for Your Flash Unit.......................................................... 3
nCautions Regarding Batteries .................................................................... 4
Overview of the Operating Manual ..................................................... 7
Names of Parts ................................................................................... 8
nParts of This Flash Unit.............................................................................. 8
nMajor Bundled Items ................................................................................ 10
nLCD Panel Indicator ................................................................................. 11
1. Getting Ready 13
Inserting the Batteries....................................................................... 13
Mounting to the Camera ................................................................... 15
Turning the Power On and Off.......................................................... 16
Setting Button/Adjustment Dial Functions ........................................ 18
Flash Coverage Angle ...................................................................... 21
2. Taking Pictures 24
Using the Flash Modes ..................................................................... 24
nP-TTL Auto Flash ..................................................................................... 25
nManual Flash............................................................................................ 26
nMulti Flash................................................................................................ 27
nWireless Mode (P-TTL) ............................................................................ 28
nWireless Mode (Manual) .......................................................................... 29
nTaking Pictures/Shooting Movies with LED Beam (LED Beam Mode) .... 30
Contents
Using the Sync Modes ...................................................................... 31
nLeading Curtain Sync Mode...................................................................... 31
nTrailing Curtain Sync Mode....................................................................... 31
nHigh-Speed Sync Mode............................................................................ 32
nContrast Control Sync Mode..................................................................... 34
Using the Function Menu .................................................................. 36
About the Function Menu .................................................................. 37
Setting Items in the Function Menu................................................... 38
Advanced Functions.......................................................................... 40
nWireless Mode .......................................................................................... 40
nSlave Flash ............................................................................................... 48
nSlave Mode Setting................................................................................... 50
nBounce Flash............................................................................................ 51
nAF Spot Beam with LED ........................................................................... 52
nWide-Angle Panel ..................................................................................... 54
nTest Flash ................................................................................................. 54
nConnecting with the Extension Cord......................................................... 55
nPrecautions When Photographing with a Slave Flash.............................. 55
3. Appendix 56
Flash Effective Range ....................................................................... 56
nCalculating the Flash Effective Range...................................................... 56
nGuide Number (GN).................................................................................. 57
Optional Accessories......................................................................... 61
Specifications .................................................................................... 62
Warranty Policy ................................................................................. 64
AF360FZ_540FGZ.book Page 5 Friday, December 20, 2013 6:11 PM

6
AF360FZ_540FGZ.book Page 6 Friday, December 20, 2013 6:11 PM

7
1
3
2
The operating manual includes the following chapters.
Overview of the Operating Manual
1 Getting Ready
This chapter explains about getting ready to take pictures after you purchase
the flash unit.
Be sure to read this chapter before you start taking pictures or operating
the flash unit.
2 Taking Pictures
This chapter explains how to take pictures and how to set the functions
for taking pictures.
3 Appendix
The appendix includes materials, data tables, and specifications.
AF360FZ_540FGZ.book Page 7 Friday, December 20, 2013 6:11 PM

8
nParts of This Flash Unit
1Bounce angle adjustment
2LCD panel
3Flash mode button
4Sync mode button
5LED button/LED Ready lamp
6Test button/Ready lamp
7Zoom button
8LCD panel illumination button/Function button
9Power switch
0Setting button
aAdjustment dial
Names of Parts
AF360FZ_540FGZ.book Page 8 Friday, December 20, 2013 6:11 PM

9
bBounce lock release button
cBattery chamber cover
dLocking lever
eFlash signal contacts
fWide-angle panel
gFlash head
hLED emitter
iWireless slave sensor
jShoe bracket
kShoe lock pin
AF360FZ_540FGZ.book Page 9 Friday, December 20, 2013 6:11 PM

10
nMajor Bundled Items
1Stand
2Case
3Operating manual (this manual)
4Certification
Slide the hot shoe bracket into the opening of the stand.
•You cannot attach the off-camera shoe adapter F to the
bundled stand.
•When attaching the flash unit to the stand, do not tighten the
locking lever too far. Tightening too far may cause the locking
lever to not lock sufficiently when the flash unit is removed
from the stand and attached to the hot shoe of the camera.
Opening of the stand
Stand
AF360FZ_540FGZ.book Page 10 Friday, December 20, 2013 6:11 PM

11
nLCD Panel Indicator
1Wireless mode indicator: MASTERÕCONTROLÕSLAVE
2Flash mode indicator: P-TTLÕMÕMultiÕ (P-TTL)
Õ (Manual)
3Sync mode indicator:
(Leading curtain sync)Õ(Trailing curtain sync)
Õ (Contrast control sync)Õ(High-speed sync)
4Adjustment dial indicator
5Number of flashes
6Effective flash range indicator:
Minimum distance – Maximum distance (in P-TTL mode)
Correct exposure distance (in manual mode)
7Zoom indicator:
auto (Zoom)Õmanual ( Zoom) XXX mm= 13, 16, 19, 24,
34, 48, 58 (K series (APS-C))
25, 30, 35, 43, 62, 87, 106 (645D)
3, 4, 5, 6, 9, 13, 15 (Q series)
AF360FZ_540FGZ.book Page 11 Friday, December 20, 2013 6:11 PM

12
8Catchlight indicator
9LED beam mode
0Flash output compensation indicator: -4.0 to +2.0 levels,
(auto (A), 1/3, 1/2 step)
aFunction menu indicator
bFlash frequency indicator
cBounce flash indicator
dFlash output adjustment indicator: X / XXX
•In poorly lit locations where the LCD panel cannot be seen,
pressing the LCD panel illumination button ( ) will
illuminate the LCD panel for about 10 seconds.
Pressing it again will turn off the illumination.
AF360FZ_540FGZ.book Page 12 Friday, December 20, 2013 6:11 PM

13
1
1Slide the battery chamber cover as shown in the figure
to open.
2Insert four AA batteries, making sure the plus/minus
markings (+, -) match the diagram inside the battery
chamber cover.
Types of Batteries
This flash unit uses four AA batteries of the same type,
as shown below.
- Alkaline battery (LR6)
- Lithium battery (FR6)
- Nickel-Metal Hydride battery (Ni-MH)
(Nickel manganese (Ni-Mn) and nickel cadmium (Ni-Cd)
batteries cannot be used.)
•For information about recycling times and total number
of flashes, refer to “Specifications” on page 62.
•If the indicators on the LCD panel or the Ready lamp does
not light up, the batteries may be exhausted or not inserted
correctly. Verify the orientation of the batteries or, if the
indicators and the Ready lamp still do not light up, replace
them with new batteries.
1. Getting Ready
Inserting the Batteries
21
AF360FZ_540FGZ.book Page 13 Friday, December 20, 2013 6:11 PM

14
1
•If you let the flash unit discharge successively using lithium
batteries, the batteries will overheat, activating a safety circuit
that temporarily disables the flash unit. If this occurs, rest the
flash unit so that the temperature of the batteries returns
to normal.
•The blinking low battery indicator
shown in the illustration appears on
the LCD panel when the batteries are
exhausted. Replace all the four
batteries with new ones.
AF360FZ_540FGZ.book Page 14 Friday, December 20, 2013 6:11 PM

15
1
1Remove the hot shoe cover from the camera.
2Attach the flash unit to the camera.
1Facing the LCD panel, turn the locking lever of the flash
unit to the left.
2Slide the hot shoe bracket of the flash unit into the
camera’s hot shoe from the back of the camera forward.
3Facing the LCD panel, turn the locking lever of the flash
unit to the right to lock it.
•When releasing the flash unit, be sure to face the LCD
panel and turn the locking lever to the left, then loosen
the shoe lock pin. Otherwise, the hot shoe will be
damaged.
•Do not hold the flash unit when attached to the
camera. Otherwise the camera may drop and
be damaged.
Mounting to the Camera
21
AF360FZ_540FGZ.book Page 15 Friday, December 20, 2013 6:11 PM

16
1
1Turn the camera on, then turn on the unit’s power switch
(ON).
•The Ready lamp will light up when the flash is charged.
2Turn off the unit’s power switch (OFF).
•If charging time takes more than 20 seconds, the
batteries have been exhausted and should be replaced
with new batteries. If the flash unit is used with exhausted
batteries, the settings may return to their default
configuration.
Auto Power Off Function
When the flash unit is left unused for about 3 minutes with the
power switch set to the (ON) position, it automatically switches
off to save the power.
1Turn on the power switch (ON).
2Press and hold the function button ( ).
3Rotate the adjustment dial to display PH on the LCD panel.
4Press the setting button (SET) to blink PH1 or PH2.
PH1: Enables the auto power off function. (Default setting)
PH2: Disables the auto power off function.
5Rotate the adjustment dial to select PH1 or PH2.
Turning the Power On and Off
Power switch
Ready lamp
AF360FZ_540FGZ.book Page 16 Friday, December 20, 2013 6:11 PM

17
1
6Press the setting button (SET) to complete the setting.
•To exit the function menu, press and hold the function
button ( ).
•Refer to “Using the Function Menu” (page 36) for details
on the function menu.
•In wireless mode, the power will turn off after about 1 hour
of non-operation (in SLAVE mode only).
Quick Power On Function
If the flash unit is mounted on autofocus cameras, press the
shutter release button half way down to turn on the power.
AF360FZ_540FGZ.book Page 17 Friday, December 20, 2013 6:11 PM

18
1
With the setting button (SET) and adjustment dial, you can
configure the settings of flash modes or LED beam mode, such
as flash output, etc. Refer to page 20 for each setting item, and
also “Using the Function Menu” (page 36) when using the
function menu.
1Turn on the power switch (ON).
2Press the setting button (SET) to blink the number you want
to set.
3Rotate the adjustment dial to set the blinking number.
Setting Button/Adjustment Dial Functions
21
AF360FZ_540FGZ.book Page 18 Friday, December 20, 2013 6:11 PM

19
1
4Press the setting button (SET) again to complete the
setting. Adjust the other setting items using the same
procedure.
•If you want to use multiple flash units set to P-TTL and
adjust the amount of light at the same time, use the
camera’s exposure compensation.
3
