Ricon D143 Installation instructions

RICOH Americas Corporation Content ID# rfg051141
Ver.1.0 Page 1 of 72 2/3/2012
Subject to change without notice
Product Support Guide
D143/D144
Introduction
Model Type
Color MFP
Launch Date
2/20/2012
S/N Configuration
W51yfmxxxxx
W54yfmxxxxx
Product Code
D143/D144
Brand/Model Name
Product Code
Lanier
Ricoh
Savin
D143
MP C4502
Aficio MP C4502
MP C4502
D144
MP C5502
Aficio MP C5502
MP C5502
Product Concept
The D143/D144 is the replacement for the
D088/D089 series.
The new D143/D144 will be launched to
enhance our competitiveness with the highly
strengthened GW+ controller specs, expanded
color space, shortened warm up time and
improved ECO spec.
RICOH decided to equip D143/D144 with our
most advanced controller, GW+, in order to
compete against others. D143/D144 will be
using the new “SPR-F” toner, which will
certainly improve the image quality. Moreover,
the warm up/recovery time will be reduced and
the total ECO spec including TEC value is
planned to be #1. Lastly, D143/D144 will be
adopting the new product design concept, I-
Style (Intelligent Style), which will attract
customer with its design and suite to any office
environment.

Product Support Guide
D143/D144
Ver.1.0 Page 2 of 72 2/3/2012
Subject to change without notice
Order Number
Main Frame
Item
Model Name
EDP Code
Notes
Lanier
Ricoh
Savin
Aficio MP C4502
416072
Standard Mainframe
Configuration
Printer Scanner
Lanier
Ricoh
Savin
Aficio MP C5502
416076
Standard Mainframe
Configuration
Printer Scanner
Lanier
Ricoh
Savin
Aficio MP C4502G
416073
Printer Scanner
Government Version
Lanier
Ricoh
Savin
Aficio MP C5502G
416078
Printer Scanner
Government Version
Lanier
Ricoh
Savin
Aficio MP C4502A
416075
Printer Scanner
Single Pass DF Version
Lanier
Ricoh
Savin
Aficio MP C5502A
416077
Printer Scanner
Single Pass DF Version
Note: Items in yellow are scheduled to launch 6/2012
Options
Item
Description
Product
Code
EDP Code
Common / Unique
PostScript3 Unit
Type C5502
PostScript3 Unit Type C5502
D645-11
415998
C
Fax Option Type
C5502
Fax Option Type C5502
D645-19
415991
C
1-Bin Tray
BN3100
1-Bin Tray BN3100
D632
415986
C
Side Tray Type
C5502
Side Tray Type C5502
D635
415989
C
PictBridge
Camera Direct Print Card Type J
D645-15
416006
C
Paper Feed Unit
(550 x 2)
Paper Feed Unit PB3130 (550X2)
D580
415793
C
1000 x 2LCT
LCIT PB3140 Large Capacity
Cassette
D581
415795
C
Side LCT
LCIT RT3020
D631
415984
C

Product Support Guide
D143/D144
Ver.1.0 Page 3 of 72 2/3/2012
Subject to change without notice
Envelope Feeder
Envelope Feeder EF3020
D638
416272
C
Card Reader
Bracket
Card Reader Bracket Type 3352
D593-61
415814
C
IPDS
IPDS Unit Type 5502
D645-07
416003
C
File Format
Converter
File Format Converter Type E
D377-04
414007
C
Internal Shift
Tray
Internal Shift Sort Tray (SH3060)
D633
415987
C
Fax Connection
Unit
Fax Connection Unit Type B
D645-19
416022
C
G3 Unit
G3 Interface Unit Type C5002
D643-11
415996
C
Platen Cover
Platen Cover Type 3352
D593
415809
C
Bridge Unit
Bridge Unit BU3060
D386
415988
C
Punch Kit for US
2/3 hole
Punch Unit Type 3260 NA
B702
412209
C
1,000 Sheet
Finisher
Finisher SR3090
D588
415804
C
2000 Sheets
Booklet Finisher
Finisher SR3110 Booklet Finisher
D637
416007
C
3000 Sheets
Finisher
Finisher SR3120
D636
416008
C
Wireless LAN
IEEE802.11a/g Unit (Wireless
Interface) Type J
D377-01
414008
C
Copy Data
Security Unit
Copy Data Security Unit Type G
D640
416391
C
Gigabit Ethernet
Gigabit Ethernet Board Type B
D377-21
414204
C
IEEE1284
IEEE1284 Interface Board
(Parallel)Type A
B679-17
411699
C
Optional
Counter
Interface Unit
Optional Counter Interface Unit
Type A
B870-11
413012
C
Key Counter
Bracket
Key Counter Bracket Type H
A674-05
412552
C
Hand Set
Handset Type 5502
D645-27
416324
U

Product Support Guide
D143/D144
Ver.1.0 Page 4 of 72 2/3/2012
Subject to change without notice
Fax 32MB SAF
Memory Unit
Type B
Fax 32MB SAF Memory Unit Type
B
G578
001342MIU
C
FAC52 Cabinet
FAC52 Cabinet
5K6123
416337
C
Browser Unit
Browser Unit Type F
D645-17
416002
U
ADF Handle
ADF Handle Type C
D593
416213
C
Bluetooth
Bluetooth (USB)
D566
415818
C
NetWare
Printing
SD Card for NetWare Printing Type
H
D645-23
416001
C
HotSpot MFP
Option Type E
HotSpot MFP Option Type E
TBA
TBA
ARDF
Destination
Name
Product Code
EDP
Serial #
Generic
ARDF DF3070
D630
416021
TBA
Envelope Feeder
Destination
Name
Product Code
EDP
Serial #
Generic
Envelope Feeder EF3020
D638
416272
W78yfmxxxx
2-Tray Paper Feed Unit
Destination
Name
Product Code
EDP
Serial #
Generic
Paper Feed Unit PB3130
D580
415793
W57yfmxxxxx
LCT (2000-Sheet)
Destination
Name
Product Code
EDP
Serial #
North America/
Latin America
LCIT PB3140
D581
415795
W58yfmxxxxx
LCT (1200-Sheet)
Destination
Name
Product Code
EDP
Serial #
North America/
Latin America
LCIT RT3020
D631
415984
W61yfmxxxxx

Product Support Guide
D143/D144
Ver.1.0 Page 5 of 72 2/3/2012
Subject to change without notice
1 Bin Tray Unit
Destination
Name
Product Code
EDP
Serial #
Generic
BN 3100
D632
415986
W62yfmxxxxx
Shift Tray Unit
Destination
Name
Product Code
EDP
Serial #
Generic
SH3060
D633
415987
W89yfmxxxxx
Side Tray
Destination
Name
Product Code
EDP
Serial #
Generic
Side Tray Type C5502
D635
415989
W64yfmxxxxx
1000-Sheet Finisher
Destination
Name
Product Code
EDP
Serial #
North America/
Latin America/
Europe/Asia/
Taiwan/Australia/L
atin America
SR3090
D588
415804
W75yfmxxxxx
2000-Sheet Booklet Finisher
Destination
Name
Product Code
EDP
Serial #
Generic
Booklet Finisher SR3110
D637
416007
TBA
3000-Sheet Finisher
Destination
Name
Product Code
EDP
Serial #
Generic
Finisher SR 3120
D636
416008
TBA
Bridge Unit
Destination
Name
Product Code
EDP
Serial #
Generic
Bridge Unit BU3060
D634
415988
W63yfmxxxxx
Fax Unit
Destination
Name
Product Code
EDP
Serial #
North America/
Latin America/
Fax Option Type C5502
D643-01
415991
W65yfmxxxxx

Product Support Guide
D143/D144
Ver.1.0 Page 6 of 72 2/3/2012
Subject to change without notice
Supplies/Yields
Item
Name
Order Code
Target Yield
Ricoh / Savin / Lanier
Toner Black
Print Cartridge Black Type
MP C4502, MP C5502
841679
31,000prints/bottle *1
Toner Yellow
Print Cartridge Yellow Type
MP C4502, MP C5502
841680
22,500prints/bottle
Toner Magenta
Print Cartridge Magenta Type
MP C4502, MP C5502
841681
22,500prints/bottle
Toner Cyan
Print Cartridge Cyan Type
MP C4502, MP C5502
841682
22,500prints/bottle
Developer
BK
D1449640
300k
C
D1449660
240k
M
D1449670
240k
Y
D1449680
240K
Staple Set
Cartridge for
SR3110/3120/3090
Staple Type K
410801
5,000shots/staple
Staple Refill
Cartridge for
SR3110/3120/3090
Refill Staple Type K
410802
5,000shots/staple
Staple Set
Cartridge for
SR3110 (Saddle
Stitch)
Staple Type L
411240
2,000shots/staple
Staple Refill
Cartridge for
SR3110 (Saddle
Stitch)
Refill Staple Type L
411241
2,000shots/staple
*1: If EFI controller option is attached, the targeted yield is 29,000prints/bottle Supply Yield
Condition:
1) ISO/IEC19752 is used to measure the above toner yield.
2) The condition is standard temperature and humidity.
3) This yield number may change depending on the circumstances and printing conditions.
4) Starter AIO (included in a carton box of main unit): 6K pages / Cartridge.

Product Support Guide
D143/D144
Ver.1.0 Page 7 of 72 2/3/2012
Subject to change without notice
Option Compatibility
Category
Item
Product Name
You Must Install
You Cannot Install
Original
Feeding
Platen Cover
Platen Cover Type 3352
-
ARDF
ARDF
ARDF DF3070
-
Platen Cover, Single
Pass DF model
ADF Handle
ADF Handle Type C
ARDF(only
DF3070)
Single Pass DF
model
Paper
Feeding
2 tray Paper
Bank
Paper Feed Unit PB3130
-
LCT
LCT
LCIT PB3140
-
2 tray Paper Bank
Side LCT
LCIT RT3020
2 tray Paper Bank
or LCT
-
Envelope
Feeder
Envelope Feeder EF3020
-
-
Finishing
1 Bin Tray
1 Bin Tray BN 3100
-
-
Internal Shift
Tray
Internal Shift Tray SH3060
-
2000 Sheets Booklet
Finisher, 3000 Sheets
Finisher, 1000 Sheets
Finisher, Bridge Unit,
Side Tray
Side Tray
Side Tray Type C5502
2000 Sheets Booklet
Finisher, 3000 Sheets
Finisher, 1000 Sheets
Finisher, Bridge Unit,
Shift Tray
1000 Sheets
Finisher
Finisher SR3090
Bridge Unit and
Paper Bank or LCT
2000 Sheets Booklet
Finisher, 3000 Sheets
Finisher, Shift Tray,
Side Tray
3000 Sheets
Finisher
Finisher SR3120
Bridge Unit and
Paper Bank or LCT
2000 Sheets Booklet
Finisher, 1000 Sheets
Finisher, Shift Tray,
Side Tray
2000 Sheets
Booklet
Finisher
Booklet Finisher SR3110
Bridge Unit and
Paper Bank or LCT
1000 Sheets Finisher,
3000 Sheets Finisher,
Shift Tray, Side Tray

Product Support Guide
D143/D144
Ver.1.0 Page 8 of 72 2/3/2012
Subject to change without notice
Punch Unit
Punch Kit PU3030NA/EU/SC
2000 Sheets
Booklet Finisher or
3000 Sheets
Finisher
-
Bridge Unit
Bridge Unit BU3060
2000 Sheets
Booklet Finisher or
1000 Sheets
Finisher or 3000
Sheets Finisher
Shift Tray, Side Tray
Fax
Fax Option
Fax Option Type C5502
-
-
G3 Unit
G3 Interface Unit Type C5502
Fax Option
-
FAX
Connection
Fax Connection Unit Type B
Fax Option (for
Center machine)
-
SAF Memory
Memory Unit Type B
Fax Option
-
Handset(Only
for RAC)
Hand Set Type 3352
Fax Option
-
FAX Stamp
Marker Type 30
Fax Option
-
Printer
Option
PostScript3
Postscript3 Unit Type C5502
-
EFI Controller
PictBridge
Camera Direct Print Card Type
J
-
EFI Controller
IPDS
IPDS Unit Type C5502
-
EFI Controller
Network
Option
Wireless LAN
Interface
IEEE 802.11a/g Interface Unit
Type J
-
Bluetooth, IEEE
1284, EFI Controller
Wireless LAN
Interface
IEEE 802.11g Interface Unit
Type K
-
Bluetooth, IEEE
1284,EFI Controller
IEEE 1284
Interface
IEEE 1284 Interface Board
Type A
-
Wireless LAN, EFI
Controller
Gigabit
Ethernet
Gigabit Ethernet Type B
-
EFI Controller
Bluetooth
Bluetooth Interface Unit Type D
-
Wireless LAN,
Security
Copy Guard
Security
Copy Data Security Unit Type
F
-
-
Others
Browser Unit
Browser Unit Type F
-
-
Netware
SD card for NetWare printing
Type H
EFI Controller
Optional
Counter
Interface
Optional Counter Interface
Unit Type A
-
EFI Controller
Key Counter
Bracket
Key Counter Bracket Type H
-
EFI Controller
File Format
Converter
File Format Converter Type E
-
-

Product Support Guide
D143/D144
Ver.1.0 Page 9 of 72 2/3/2012
Subject to change without notice
Card Reader
Bracket
Card Reader Bracket Type
3352
-
Scanner
Accessibility
Option
Scanner Accessibility Option
Type C5502
-
Single Pass DF
model
Branding Information
Branding is required as the machines are shipped as a generic version.
Ricoh version machines: You must attach the model label (provided) to the front cover.
Savin/Lanier: You must attach the model label (provided) to the front cover and set the Plug and Play name with
SP 5-907.
Configuration
Main Frame Configuration

Product Support Guide
D143/D144
Ver.1.0 Page 10 of 72 2/3/2012
Subject to change without notice
Item
Machine code
Call Out
Remarks
Mainframe
D143/D144
1
Single pass ADF model has
ADF as standard
Platen Cover
D593
2
One from the two for all
models except the Single
Pass ADF model
ARDF
D630
3
2000(Booklet) / 3000 Sheet
Finishers
D637 / D636
4
One from 9 and 10, requires
11 and one from 7 and 8
Punch Unit 3/2/Holes
B702
-
Requires 10
Punch Unit 2/3/Holes
D570
-
Requires 10
1000 Sheet Finisher
D588
9
One from 9 and 10 requires
11 and one from 7 and 8
2000 Sheet LCT
D581
7
One from the two
2 Tray Paper Feed Unit
D580
8
1200 Sheet LCT
D631
6
Requires 7 or 8
Envelope Feeder
D638
5
Requires Tray 2 of the
Mainframe or 8
1 Bin tray
D632
4
-
Bridge Unit
D634
12
One from the Three
Shift Tray
D633
13
Side Tray
D635
11
Scanner Accessibility
Option
D647
-
-
Card Reader Bracket
D593 - 61
-
-
ADF Handle Type C
D593
-
This is for use when a
person who uses a wheel
chair will lift the ADF up or
down
Optional Counter Interface
Unit
B870
-
-
Key Counter Bracket
A674
-
-

Product Support Guide
D143/D144
Ver.1.0 Page 11 of 72 2/3/2012
Subject to change without notice
MFP Options
MFP Option Board Slot / SD Card Assignments
USB Host Interface
Ethernet
I/F Card Slot B
I/F Card Slot A
SD Card Slots
USB (print)
Fax Option
[A] Controller Box

Product Support Guide
D143/D144
Ver.1.0 Page 12 of 72 2/3/2012
Subject to change without notice
Previous To Current Model Feature Comparison
Mode
D088/D089
D143/D144
Printer Features
Sample Print
Yes
Yes
Locked Print
Yes
Yes
Hold Print
Yes
Yes
Scheduled Print
No
Yes
Stored Print
Yes
Yes
Store and Print
Yes
Yes
Black Over Print
Yes
Yes
CLP Simulation
Yes
Yes
PDF Direct Print
Yes
Yes
PictBridge
Yes
Yes
Mail to Print
Yes
Yes
Classification
Code
Yes
Yes
Bonjour
(Rendezvous)
Support
Yes
Yes
Windows Active
Directory Support
Yes
Yes
DDNS Support
Yes
Yes
PCL resident font
adoption
Yes
Yes
Tray-Parameter
Change from
WebImageMonitor
Yes
Yes
1200dpi Support
Yes
Yes
Mobile Driver
Yes
Yes
XPS Support
Yes
Yes
WS Printer
Yes
Yes
Wireless LAN
interface option *1
Yes
Yes
Media Direct Print
(Print from
USB/SD)
Yes
Yes
Auto Job
Promotion
No
Yes
AirPrint*2
No
TBA
*1 Not only
IEEE802.11b, but
also
IEEE802.11a/g
are supported.

Product Support Guide
D143/D144
Ver.1.0 Page 13 of 72 2/3/2012
Subject to change without notice
Mode
D088/D089
D143/D144
*2 To announce that this model
supports AirPrint function on external
sales materials such as brochures,
acquiring a certification from Apple is
required. And also, this function is
disabled until this model is certified by
Apple.
Scanner Features
Scan to USB/SD
Yes
Yes
WS-Scanner
Yes
Yes
Scan to E-mail
Yes
Yes
E-mail message
attached
Yes
Yes
Subject attached
Yes
Yes
SMTP Auth
Yes
Yes
POP before
SMTP
Yes
Yes
Scan to SMB
Yes
Yes
Scan to FTP
Yes
Yes
Scan to URL
Yes
Yes
Scan to NCP
Yes
Yes
Scanned file
naming
Yes
Yes
Reference #
Setting (ex.
SCAN0001)
Yes
Yes
Scan file type
selection
Yes
Yes
Single TIFF
Yes
Yes
Single JPEG
(Gray Scale)
Yes
Yes
Single PDF
Yes
Yes
Single High
Compression
PDF
Yes
Yes
Multi page
TIFF/PDF
Yes
Yes
Multi page High
Compression
PDF
Yes
Yes
LDAP Support
Yes
Yes
E-mail Address
search
Yes
Yes
FAX address
search
Yes
Yes

Product Support Guide
D143/D144
Ver.1.0 Page 14 of 72 2/3/2012
Subject to change without notice
Mode
D088/D089
D143/D144
Preview before
transmission (TX
Preview)
Yes
Yes
PDF Encryption
Yes
Yes
Drop out Color
Send
Yes
Yes
Twain Scan
Yes
Yes
Universal Send
(Simultaneous
FAX & Scan)
Yes
Yes
Document Clipper
*1
No
No
(*1) Data
Processing / OCR
Package
FAX Features
Detection of
misplaced
document
Yes
Yes
Double-check of
destination
address
Yes
Yes
Direct SMTP
Yes
Yes
IP Fax (T.38)
Yes
Yes
Internet Fax
(T.37)
Yes
Yes
Forward to E-mail
Inbound fax
(G3/Internet)
Yes
Yes
G3 Fax
Transmission
result
Yes
Yes
G3 LAN Fax
Transmission
result
Yes
Yes
Internet fax
sending result
(to SMTP)
Yes
Yes
Fax to e-mail
result (to SMTP)
Yes
Yes
IP Fax sending
result
Yes
Yes
Journal
Yes
Yes
Fax from special
sender
Yes
Yes

Product Support Guide
D143/D144
Ver.1.0 Page 15 of 72 2/3/2012
Subject to change without notice
Mode
D088/D089
D143/D144
Fax and forward
designated
receiver (SUB)
Yes
Yes
Fax forward to
folder
Yes
Yes
with E-mail
Notification
Yes
Yes
Paperless fax
(HDD received)
Yes
Yes
with E-mail
Notification
Yes
Yes
Lan-fax with cover
sheet editor
Yes
Yes
LDAP Support
Fax address
search
Yes
Yes
Max G3 lines
3
3
Universal Send
(Simultaneous
FAX & Scan)
Yes
Yes
DS stored data
sending
Yes
Yes
Security Features
HDD Data
Overwrite
Security*1
YES(std)
YES(std)
Option Type A
Option Type B
Option Type C
Option Type D
Option Type F
Option Type H
v
Option Type I
ISO/IEC15408
Certification
T.B.A
T.B.A
Authentication *2
Windows
Authentication
YES
YES
LDAP
Authentication
YES
YES
YES
YES
Basic
Authentication
YES
YES

Product Support Guide
D143/D144
Ver.1.0 Page 16 of 72 2/3/2012
Subject to change without notice
Mode
D088/D089
D143/D144
User Code
Authentication
YES
YES
802.1.x Wired
Authentication
YES
YES
Encryption
Address Book
Encryption
YES
YES
Authentication
Pwd Encryption
YES
YES
SSL
communication
YES
YES
S/MIME
YES
YES
IPsec
communication
YES
YES
HDD Encryption
(*1)
YES
YES
Type A
v
Locked Print
password
Encryption
YES
YES
Others
Network
Protocol On/Off
YES
YES
IP filtering
(Access Control)
YES
YES
Mask Type for
Copying/Data
Security for
Copying *1
NO
YES
Copy Data
Security Unit
Option (*1)
NO
YES
Type A
Type C
Type E
Type F
v
Printout User
Trace *5
NO
NO
Alteration
Detection *5
NO
NO
Revival Copy *5
NO
NO
Upgraded Data
Security for
Copying
NO
NO

Product Support Guide
D143/D144
Ver.1.0 Page 17 of 72 2/3/2012
Subject to change without notice
Mode
D088/D089
D143/D144
Quota
Setting/Account
Limit
YES
YES
Single Sign On
NO
NO
SMTP over SSL
YES
YES
Mandatory Security Information Print
NO
YES
(*1) Option
required for some
models.
(*2) Please refer
to "printer driver
specification" for
details of
compatible PDL.
(*3) Applicable for
Windows
Authentication
and LDAP
Authentication.
(*4) To be
provided as
optional function
package.
(*5) To be
provided as
Marking Package.
UI Features
UI Customization
NO
YES
My Operation
Panel
NO
YES
Remote Operation
Panel
NO
NO
MFP Full Browser
NO
YES
Operation Manual
on Operation
Panel
NO
NO
Workflow
improvement with
one-button
NO
YES
External USB
Keyboard
NO
YES
QWERTZ Layout
Keyboard
NO
YES
AZERTY Layout
YES
YES

Product Support Guide
D143/D144
Ver.1.0 Page 18 of 72 2/3/2012
Subject to change without notice
Mode
D088/D089
D143/D144
Keyboard
(*1) Ad-C4.5 and
Al-C1 have this
feature with
special
customization.
Accessibility Features
Easy Touch Screen
YES
YES
Normal/Reverse Grip & Light drawing
YES
YES
Scanner Separation
YES*1
(Optional)
YES*1
(Optional)
Tilt Operation
Panel
NO
YES
Distinguishable LED
YES
YES
Single Hand Operation
YES
YES
Electronic Manual (CD manual)
YES
YES
*AP-C, A-C or AL-C only
Other Value Added Features
Hierarchy Document Management
(Document Server)
No
No
Import/Export of Preference Settings
NO
YES
Information Screen (Eco-Friendly Indicator)
NO
YES

Product Support Guide
D143/D144
Ver.1.0 Page 19 of 72 2/3/2012
Subject to change without notice
Installation
Installation Requirements
Temperature Range:
10 C to 32 C (50 F to 89.6 F)
Humidity Range:
15% to 80% RH
Ambient Illumination:
Less than 1,500 lux (do not expose to direct sunlight)
Ventilation:
3 times/hr/person
Ambient Dust:
Less than 0.075 mg/m3 (2.0 x 10-6oz/yd3)
Avoid areas exposed to sudden temperature changes:
Areas directly exposed to cool air from an air conditioner.
Areas directly exposed to heat from a heater.
Do not place machine where it will be exposed to corrosive gas or vapor.
Do not install the machine at any location over 2,500m (8,200 ft.) above sea level.
Place the machine on a strong and level base. Inclination on any side should be no more than 5mm (0.2”)
Do not place the machine where it may be subject to strong vibrations.
Machine level
Front to back: within 5mm (0.2”) of level
Right to left: within 5mm (0.2”) of level
Power Requirements
Input voltage level: 110 - 120 V, 60Hz: 12A
Do not place anything on power cord.
The required wall outlet is a NEMA 5-15R (receptacle)
Space
Foot Print
A (Left)
Over 100 mm (3.9")
B (Rear)
Over 100 mm (3.9")
C (Right)
Over 550 mm (21.7")
D (Front)
Over 750 mm (29.5")
Dimensions (W x D x H): 22.8 x 28.98 x 41.9 (with 2-Tray Paper Bank and fall-prevention
material) Measurement Conditions: With bypass feed table closed
The recommended 750 mm (30”) front space is sufficient to
allow the paper tray to be pulled out. Additional the front
space is required to allow operators to stand at the front of
the machine.

Product Support Guide
D143/D144
Ver.1.0 Page 20 of 72 2/3/2012
Subject to change without notice
Power Consumption / Noise Emission
Power Consumption
Power Consumption
Power
Consumption may
differ depending
on the conditions
and environment
of the machine.
Max Power
Full Option Max
Power
1,584 or less
Operating Power
(Guaranteed value)
900
(Nominal value)
Normal
DF(D143:690.9/D144:781.
4）
SPDF(D143:694.1/D144:7
66.2）
Ready Mode
(Guaranteed value)
240 or less
(Nominal value)
Normal DF 101
SPDF 120
Panel Off
(Guaranteed value)
-
(Nominal value)
-
Shift time(Default)
-
Recovery
-
Low Power
Power (Guaranteed value)
150 or less
(Nominal value)
Normal DF 86
SPDF 98
Shift time(Default)
-
Recovery (Guaranteed value)
10
(Guaranteed (Nominal value)
9.7
Sleep Mode
Power (Guaranteed value)
1.2 or less
(Nominal value)
10
Shift time(Default) S
1 min
Recovery (Guaranteed value)
Normal DF(D143:
15/D144:20)
SPDF(D143:15/D144:20)
(Nominal value)
Normal DF(D143:
15/C3d:18)
SPDF(D143:15/D144:18)
TEC (Typical
Electricity
Consumption)
D143 :normal DF
2,151
D143 : SPDF
2,150
D144 : normal DF
2,719
D144: SPDF
2,749
