Riton X5 Primal User manual
10X42
BINOCULARS
X5 PRIMAL
2
Table of Contents
Bino Specics
3 Overview
4 Bino Technical Specications
5 Basic Operation
5 Eyecup Adjustments
5 Adjust the Interpupillary Distance
5 Binocular Focus
6 Accessories
6 Lens Care
7 Warranty
THANKYOUFOR
CHOOSINGRITON
OPTICS.
We know that you have many
options and we are thankful for
selecting Riton as your optics
provider.
As a company founded by Law Enforcement and Military Veterans,
we take our commitment to service seriously. We have an
unwavering passion for offering high quality optics at the industry’s
most competitive prices and matched by incredible service. You
will see the difference in everything we do because we are different,
and we developed this company to be exactly that so that you, the
consumer, get everything you deserve. If you are ever in need of
additional information or assistance, please contact us. We are here
to continual serve you as a valued partner.
3
X510X42BINOS
Bino SpecicsThe X5 Primal 10×42 HD Binoculars utilize a lightweight
magnesium alloy frame that can handle the most rugged applications while adding minimal
weight to your kit. Featuring Riton HD/ED glass, the X5 Primal 10x42 HD binos have the
clarity to be utilized all day without eye fatigue and robust enough to trust for generations
to come.
Non-Illuminated
DETAILED PRODUCT FEATURES:
• Magnesium Alloy with Rugged
Design Ready for the Toughest
Environments
• 100% Waterproof and Fog proof
• Assembled in EP-Level Clean Room
• Tripod adaptable
• Comes with one neoprene case
and neck strap
4
Magnication: 10x
Objective Lens Diameter: 42mm
Lens Coating: Fully Multi-Coated, Full Wide Band, Waterproof
Coated, Low Light Enhancement
Prism Glass: BAK 4
Focus System: Center Focus
Field of View at 1000 yds: 315ft
Material: Magnesium Alloy
Weight: 23oz/652g
Length: 5.6in/141mm
Eye Relief: 15mm
Exit Pupil: 4.17mm
Technical
Specications
5
BASIC OPERATION
• The eyecups on a Riton 10x42 binocular twist up and down
so any viewer can see the full eld and enjoy comfortable
viewing with or without eyeglasses. When not using
eyeglasses or sunglasses, keep the eyecups fully extended.
For the best viewing when viewing through eyeglasses, twist
eyecups down.
• Properly focus the binocular
• BINOCULAR FOCUS
• For the best possible views, follow this two-step process to properly adjust the center focus and diopter.
• Choose an object that is about 20 yards away from you and stay in the same spot until you have
• adjusted the binocular for your eyes.
• 1. Adjust the center focus—rst start by closing your right eye or covering the right objective lens with
• your hand. Focus your left eye on the object and adjust the center focus wheel until the image is in
• focus. Leave the center focus in this position as you adjust the diopter.
• 2. Adjust the diopter—start by closing your left eye or covering the left objective lens with your hand.
• Look through your right eye and adjust the diopter ring (found on the right eyepiece) until the object
• is in focus. Make note of this diopter setting in case you need to set it again. From this point on, you
• will only need to use the center focus wheel.
Adjust the Interpupillary Distance
• The interpupillary distance (IPD) is the distance between the
• centers of the left and right eye pupils. Match the IPD of your
• eyes to that of the binocular so that you see a single image
• that is free of shading
6
ACCESSORIES
The Riton X5 10x42 Binos come with a rainguard for the ocular
lenses
and tethered objective lens covers. Use these covers to protect the
lenses whenever you are not viewing.
Lens Covers
The Riton protective case provides safe storage between
viewing sessions.
Carry Case
ACCESSORIES
Attach the padded neckstrap to the Riton Binos in three simple
steps. Begin with the right barrel of the binocular and repeat the
process for the left barrel.
Neckstrap
1. Push a few
inches of the strap
through the strap
attachment on the
binocular.
3. Adjust the
overall length,
then pull the tight
until strap secured
within the buckle.
2. Hold the buckle
and thread the end of
the strap through the
buckle.
Note: If using another type of strap, never attach metal o-rings
directly
onto the strap attachment.
• LENS CARE
• Maintain the optical brilliance of the Diamondback binocular
by keeping lens surfaces free of dirt, oils, and dust.
• Protect lenses while out in the eld Make use of the provided
eyepiece and objective lens covers to protect the lenses when
not viewing. Then, store the Riton Binos in the carry case
between viewing sessions.
• Keep lenses clean
• In order to enjoy the best views through your Riton
• binocular, take time to regularly clean the exterior lenses:
• 1. Remove any dust or grit from lenses before wiping. Use
a can of pressurized air, soft camel hair brush, or an acrylic
optical brush.
• 2. Clear lenses of smudges, ngerprints, or eyelash oil. Fog
the lenses with your own breath, then use a non-abrasive lens
cloth to clean the lenses.
• Note: Use lens cleaning uid and optical paper to clean
lenses. Never use facial tissue, heavy cotton, or annel
clothing on lenses—these materials can scratch the surface
of a lens
7
Riton Warranty
As a part of the Riton Promise we believe in providing you with the best possible service, including the industry’s best warranty. The quality of
our products makes this the best warranty you’ll likely never have to use; however, as hunters and outdoorsmen and women, we know that bad
things sometimes happen to even the most cautious.
OUR WARRANTY IS SIMPLE:
• No proof of purchase or registration required for your Riton products.
• Lifetime warranty regardless of original purchaser.
• All warranty replacements will receive a brand-new product off the shelf. We will not ever replace the product with a repaired or
refurbished product.
• Replacement product will be shipped within 48 hours of receiving and approving your return.
• Loss, theft and/or deliberately worn and damaged products are not covered. Warranty is VOID if damage results from unauthorized repair
or alteration.
1-855-39-RITON
8
Riton Warranty
As a part of the Riton Promise we believe in providing you with the best possible service, including the industry’s best warranty. The quality of
our products makes this the best warranty you’ll likely never have to use; however, as hunters and outdoorsmen and women, we know that bad
things sometimes happen to even the most cautious.
OUR WARRANTY IS SIMPLE:
• No proof of purchase or registration required for your Riton products.
• Lifetime warranty regardless of original purchaser.
• All warranty replacements will receive a brand-new product off the shelf. We will not ever replace the product with a repaired or
refurbished product.
• Replacement product will be shipped within 48 hours of receiving and approving your return.
• Loss, theft and/or deliberately worn and damaged products are not covered. Warranty is VOID if damage results from unauthorized repair
or alteration.
1-855-39-RITON
