Riton X1 TACTIX RRD User manual

RRD
X1 TACTIX

2
Table of Contents
3 OpticSpecics
5 Explanation of MOA
5 Explanation of Second Focal Plane
6 Reticle Information
6 FastFocusEyepiece
7 Explanation of Parallax
8 IlluminationSystem
8 FactoryZero,WindageandElevation
9 MountingtheRitonOptic
9 EyeReliefandReticleAlignment
10 BoreSighting
10 ZeroingtheRiescope
11 ZeroResettheTurrets
12 Troubleshooting
12 Warranty
THANKYOU
FORMAKINGA
PURCHASEWITH
RITONOPTICS.
We know that you have many
options and we are thankful for
selecting Riton as your optics
provider.
AsacompanyfoundedbyLawEnforcementandMilitaryVeterans,
wetakeourcommitmenttoserviceseriously.Wehavean
unwaveringpassionforofferinghighqualityopticsattheindustry’s
mostcompetitivepricesandmatchedbyincredibleservice.You
willseethedifferenceineverythingwedobecausewearedifferent,
andwedevelopedthiscompanytobeexactlythatsothatyou,the
consumer,geteverythingyoudeserve.Ifyouareeverinneedof
additionalinformationorassistance,pleasecontactus.Wearehere
tocontinualserveyouasavaluedpartner.

3
X1TACTIXRRD
Optic Specics Madefromasinglepieceofaircraft-gradealuminum.Your
RITONX1TactixRRDopticiswaterproof,fogproofandthelensesarefullymulti-coated.
Ithasbeentestedtowithstandupto1200Gforceofimpactaswellasbeingsealedwith
OringsandNitrogenpurgedandsealedforfogandwaterprotection.Ithasunlimitedeye
relief,easytousecappedadjustmentknobsforelevation,windageandsideillumination
controlknob
DETAILED PRODUCT FEATURES:
• Push/PullLockingZeroReset
Turrets
• AircraftGradeAluminumwith
RuggedDesignReadyforthe
ToughestEnvironments
• 100%Waterproof,Fogproofand
Shockproof(testedupto1200G’s)
• 1/4MOAFingertipWindageand
ElevationAdjustment
• Fast-FocusEyepiece
• AssembledinEP-LevelCleanRoom
Objective
RailMount
Illumination
WindageAdjustment
ELEVATIONADJUSTMENT

4
Magnication: 1x
ParallaxSetting: 50yds
ObjectiveLensDiameter: 29mm
LensCoating: FullyMulti-Coated,FullWideBand,Waterproof
Coated,LowLightEnhancement
DotSize: 2MOARedDot
FieldofViewat100yds: 68ft
Material: 6061-T6AircraftGradeAluminum
Weight: 9.5oz/269g
Length: 3.76in/95.5mm
EyeRelief: Unlimited
ExitPupil:28mm
ClickValueat100yds: 1MOA
AdjustmentRange: 120MOA
Technical
Specications

5
Explanation of
Minute of Angle (MOA)
MOAunitofarcmeasurementsarebasedondegreesand
minutes.Thereare360degreesinacircleand60minutesina
degreeforatotalof21,600minutes(MOA)inacircle.Aminuteof
anglewillsubtend1.05inchesatadistanceof100yards.
Pictures of turrets with ticks and 1/2 adjustments.
*Graduations can be calculated at additional distances beyond 500 yds.
1 MOA 1 IN 2 IN 3 IN 4 IN 5 IN
100Yards 200Yards 300Yards 400Yards 500Yards
Second Focal Plane (SFP) Reticle
ThereticleinyourRitonriescopeisaSecondFocalPlane
(SFP).SFPreticlesarelocatedinrearoftheimageerecting
andmagnifyinglenses.TheadvantageofaSFPreticleisthatit
alwaysmaintainsthesameappearance.Shootersusingreticle
hashmarksshouldbeawarethatthelistedsubtensionsused
forestimatingrange,holdover,andwindagecorrectionareatthe
maximummagnication.

6
Reticle Information
TheX1TactixRRDhasa2MinuteofAngle(MOA)dot,isnight
visioncompatibleandcanrunupto1600hoursononesingle
CR2032battery.
Explanation of Parallax
Parallaxdescribesasituationwherethefocalplaneoftheobjectinthescopeisoffset
fromthereticle.Ifyouhaveparallax,youhaveanopticalillusionthatmustbecorrected.
Parallaxshouldnotbeconfusedwithfocus.Parallaxcompensationchangesneitherthe
focusofthereticlenorthefocusoftheimage;itsimplymovestheplanesatwhichthese
twoobjectsareinfocussothattheysharethesameplane.
TO ADJUST THE PARALLAX:
1. Setyourfastfocuseyepieceforyoureye.Lookatablankbackdropandturnyoureye
pieceinandoutuntilyouhaveacrispsharpreticle.
2. Lookthroughscopeandplacecross-hairontarget.Moveyourheadaroundwithout
leavingexitpupil.Doesthecrosshairmoveorbecomeblurry?
3. Ifthecross-hairmovesorisblurry,setthesideparallaxtoestimatedrange,usethisas
startingpointandnetuneasneeded.
YOUR RITON RIFLESCOPE DOES
NOT HAVE A PARALLAX FOCUS
AND IS FACTORY FOCUSED AT A
DISTANCE OF 100 YARDS.

7
Factory Zero
YourRitonriescopeispre-setfromthefactorywiththereticlein
thecenteroftheadjustmentranges.
TO FIND FACTORY ZERO:
1. Dialturretonedirectionuntilitwillnolongerrotate.
NOTE-Donotforcetheturretpastit’sstoppingpoint.
2. DialturretoppositedirectioncountinghowmanyMOAit
turns.
3. DividethattotalnumberofMOAinhalfanddialtothat
numberforyourfactoryzero.
4. Completethisprocedureforbothwindageandelevation
dialstoapproximatelycenterthereticle.
Illumination knob with numbers and battery location
Illumination System
Thevariableintensityreticleilluminationsystemaidsinlowlight
situations.
TO ACTIVATE THE ILLUMINATION:
1. Rotatetheadjustmentknobineitherdirection.
Note - The illumination knob allows for 11 levels of brightness intensity.
TO CHANGE BATTERY:
1. Unscrewtheoutercap.
2. Removethebattery.
3. ReplacewithanewCR2032batterywithpositivesideout.
4. Re-installthebatterycapandbesuretotightenfully.

8
Mounting Your Riton Red Dot
TO MOUNT YOUR RITON RED DOT:
1. LoosenthenutonthebottomoftheREDDOTbase.Then
attachthelowerhalftotherail/baseandmakesurethisis
solidlyseatedinthebasegroove.Topreventrecoilinjury,
positiontheringsothatyouhaveatleastfourinchesofeye
relief.
2. Note.theRitonRRDhasanunlimitedeyerelief.
3. IfyouplantomountamagnierbehindyourRedDotbesure
toleavesucientspaceforthisasyoumountyourRRD
4. Beforetighteningthescoperingscrews,adjustformaximum
eyerelieftoavoidinjuryfromrecoil.
5. Besurethebaseclampishookedaroundtheoutsideofthe
rail/base.Pressdownwardand
Eye Relief and Reticle Alignment
TO SET A PROPER EYE RELIEF AND RETICLE
ALIGNMENT:
1. Settheriescopemagnicationtothehighestsetting.
2. Slidetheriescopeasfarforwardaspossibleintherings.
3. Whilelookingthroughtheriescopeinanormalshooting
position,slidetheriescopebacktowardsyourface,
payingattentiontotheeldofview.Justasthefulleldof
viewisvisible,stopthemovementoftheriescope.
4. Withoutdisturbingthefront-backplacement,rotatethe
riescopeuntiltheverticalcrosshairexactlymatchesthe
verticalaxisoftherie.Useofareticlelevelingtool,a
weighthungonarope,orbubblelevelstohelpwiththis
procedure.
5. Afteraligningthereticle,tightenandtorquethering
screwsdownperthemanufacturer’sinstructions.

9
Bore Sighting
Boresightingisapreliminaryproceduretoachieveproper
alignmentofthescopewiththerie’sbore.Initialboresightingof
theriescopewilldecreasetheamountoftimeandammunition
youneedtouseattherange.
Thiscanbedonebyusingamechanicalorlaserboresighter
accordingtothemanufacturer’sinstructionsorbyremovingthe
boltandsightingthroughthebarrelonsomeries.
TO BORE SIGHT YOUR RIFLESCOPE:
1. Placetheriesolidlyonarestandremovethebolt.
2. Sightthroughtheboreatatargetapproximately100yards
away.
3. Movetherieandtherestuntilthetargetisvisuallycentered
insidethebarrel.
4. Withthetargetcenteredinthebore,makewindageand
elevationadjustmentsuntilthereticlecrosshairisalso
centeredoverthetarget.
Note - If a laser bore sighting or any other similar device inside the bore
was used, it must be removed before ring. An obstructed bore can cause
serious damage to the gun and possible injury to the shooter.
TO ZERO THE SCOPE:
1. Startsight-inprocessfrom25yards,fromsolidrestre3-shotgroup,ensuringthat
youreatsamespoteachtime.Usegridlinesontargettocenterandlevelyour
crosshairs.
2. Aftertherst3-shotgroup,makeadjustmentstobringbulletimpacttocenteroftarget
you’reshootingat.Repeatthisprocessat100yardsandyouwillhaveaccurate100
yardzero.
Note - Scope graduations are 1 MOA. Scope turrets are marked with direction of bullet impact change.
At 100 yards a 1 MOA scope adjustment will move bullet impact 1 inch in direction adjusted. At 25
yards that same 1 MOA adjustment will be 4 times smaller, so 1 MOA adjustment at 25 yards will move
bullet impact 1/4 of an inch.
Section Continued

10
Riton Warranty
AsapartoftheRitonPromisewebelieveinprovidingyouwiththebestpossibleservice,
includingtheindustry’sbestwarranty.Thequalityofourproductsmakesthisthebest
warrantyyou’lllikelyneverhavetouse;however,ashuntersandoutdoorsmenandwomen,
weknowthatbadthingssometimeshappentoeventhemostcautious.
OUR WARRANTY IS SIMPLE:
• NoproofofpurchaseorregistrationrequiredforyourRitonproducts.
• Lifetimewarrantyregardlessoforiginalpurchaser.
• Allwarrantyreplacementswillreceiveabrand-newproductofftheshelf.Wewillnot
everreplacetheproductwitharepairedorrefurbishedproduct.
• Replacementproductwillbeshippedwithin48hoursofreceivingandapprovingyour
return.
• Loss,theftand/ordeliberatelywornanddamagedproductsarenotcovered.Warranty
isVOIDifdamageresultsfromunauthorizedrepairoralteration.
Troubleshooting
Problemsthoughttobeassociatedwiththescopeareoftenactuallymountproblems.Take
timetoensurethemountsaretighttotherieandthatscopeissecuredanddoesn’ttwist
ormoveintherings.Conrmthatcorrectbaseandringsarebeingusedandintheproper
orientation.Besuretotorqueringspermanufacturer’sspecs.
Keepinmindtherearemanyissuesthatcancausepoorbulletgrouping.Alwaysutilizea
solidrestandmaintaingoodshootingtechnique.Haveaqualiedgunsmithlookoveryour
rietobesureallthingsareinworkingorder.Seethattheactionandbarrelareproperly
cleaned.Someriesandammunitiondon’tworkwelltogether,trydifferentammunitionand
seeifaccuracyimproves.
