TRUGLO TG7650 User manual

When Brightness CountsTM

This product is not a toy. Read all warnings and instructions prior to
use. Property damage, serious injury or death may result from
improper use. Keep out of the reach of children.
Laser light is extremely bright and can potentially cause permanent
eye damage or interfere with critical operations if improperly used.
TRUGLO, Inc.
525 International Parkway
RICHARDSON, TEXAS 75081
MADE IN CHINA
TG7650G / TG7650R
WARNING
WARNING
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
Green Laser:
POWER OUTPUT<1mw
WAVELENGTH 500-540nm
Red Laser:
POWER OUTPUT<1mw
WAVELENGTH 630-670nm
TRUGLO, Inc.
525 International Parkway
Richardson, Texas 75081
Ph: 972-774-0300
Fx: 972-774-0323
E-mail: [email protected]

NEVER look into or stare at the laser beam or its reflection.
NEVER point the laser beam at a person or animal.
NEVER shine the laser at reflective surfaces.
NEVER point the laser beam at any type of moving vehicle, including aircraft.
Such actions are unlawful and extremely dangerous.
NEVER point the laser beam at a person using binoculars or other magnifying
instruments, such as rifle scopes, cameras or telescopes.
NEVER remove any safety label from the laser.
NEVER attempt to dissemble, repair or modify the laser. Such actions could lead to
hazardous exposure.

Before you begin, always make sure the weapon is unloaded and
safe to handle.
Always practice safe handling techniques with any weapon.
Once mounted, the weapon will be pointed in the direction of
anything illuminated by the laser.
Never point the laser at a target you do not intend to shoot.
Never engage the trigger until you are ready to fire. The laser can be
activated without placing your finger insider the trigger guard.
WARNING
WARNING
WARNING
WARNING
WARNING

On /Off
Constant on: Move the on /off lever to the
down position.
Momentary on: Hold the on /off lever in the
up position.
Laser / Light Modes
Laser only: Move the mode switch to the
up position.
Light only: Move the mode switch to the middle position.
Laser and Light: Move the mode switch to the down position.
LED
On / Off
Lever
Laser / Light
Mode Switch
Laser
Output
Aperture

Battery
• YourlasersightusestwoCR123Alithium3-voltbatteries.
To replace batteries:
CAUTION: CHECK TO MAKE SURE YOUR WEAPON IS UNLOADED.
• UnlocktheQuick-DetachLever.
• RotatetheBackPlateLockandremovetheBackPlate.
• Replacethebatteries(pleasenotethepolarityofeachbatterymarkedon
the outside housing).
• ReinstalltheBackPlateandlockinplace.

BackPlate
(interchangeable)
Polarity
Diagram
Quick-Detach
Lever
BackPlate
Lock
Recoil Lug
(interchangeable)
Batteries

Mounting
CAUTION: CHECK TO MAKE SURE YOUR WEAPON IS UNLOADED.
• YourlasersighthasintegratedmountingrailsthatattachtoastandardWeaver-style
base or Picatinny rail.
• UnlocktheQuick-DetachLeverandsetthelasersightontothemountingbaseof
the weapon.
• TheRecoilLugshouldfitintooneofthegroovesinthetopofthemountingbase.Be
 surethelasersightisfullyseatedbeforelockingtheQuick-DetachLever.
PLEASE NOTE:
• ItmaybenecessarytointerchangetheRecoilLug.
• TwoadditionalRecoilLugsareincluded.Thesecanbeusedtofitamajorityof
firearm/rail configurations.

Left-Handed Back Plate
1. UnlocktheQuick-DetachLever.
2. RotatetheBackPlateLockandremovetheBackPlate.
3. InstalltheLeft-handedBackPlateandlockinplace.
Remote Pressure Switch
1. UnlocktheQuick-DetachLever.
2. RotatetheBackPlateLockandremovetheBackPlate.
3. Install the Remote Pressure Switch and lock in place.
• ToreplacetheRecoilLug,usetheincluded2mmhexwrench.

ZEROING (windage and elevation adjustments)
Please note that the laser has been pre-set at the factory to be aligned with the mounting
baseofthelasersight.Onlyminorwindageandelevationadjustmentsshouldberequired.
Ifsignificantadjustmentsarenecessary,pleasemakesurethelasersightisproperly
mountedoradjustthemountingbase.Themaximumadjustmentisapproximately
10inchesinalldirectionsat30feet.Insufficientadjustmentisnotadefectwiththe
laser sight.
CAUTION: ALWAYS USE EYE AND EAR PROTECTION. SHOOT ONLY AT AN APPROVED
SHOOTING RANGE OR A SUITABLE SAFE AREA.

• Aftercarefullyfiringatthetarget, CHECK TO MAKE SURE
YOUR WEAPON IS UNLOADED.
• MakeanynecessaryadjustmentstotheW/Eadjustment 
screws using the included 1.25mm allen wrench.
• TurningtheWindageAdjustmentScrewclockwisemovesthe
POI to the left.
• TurningtheElevationAdjustmentScrew clockwise moves the
POI down.
• Donotover-adjustthewindageorelevationadjustment 
screws. Stop turning if you feel any resistance.
Windage
Adjustment
Screw
Elevation
Adjustment
Screw

TWO-YEAR LIMITED WARRANTY
TRUGLO, Inc. warrants this product to be free from original defects in materials and workmanship for a period of
TWO(2)YEARSfromthedateoforiginalretailpurchase,subjecttothelimitationssetforthherein.Thiswarranty
appliesonlytotheoriginalretailpurchaserandrequiresthepurchasertosupplyacopyoftheoriginalproofof
purchase(originalsalesreceipt)atthetimewarrantyserviceisrequested.Noadditionalwarranty“registration”
isrequired.
If this product should malfunction or fail, contact us for a Return Merchandise Authorization number. The RMA
number should be clearly marked on the outside of the package. Please include a complete description of the
problem, your name, address, telephone number and a copy of the original proof of purchase. All transportation,
insurance and freight charges associated with warranty service and repairs are the responsibility of the
purchaser. Please include a check or money order in the amount of $12.50 to cover processing and return
postage.Ifanoriginaldefectisfoundbyus,wewill,atouroption,repair,replaceormakeappropriateadjustment.
For contact information go to www.truglo.com or call 972-774-0300.
ThisLimitedWarrantydoesnotapplyto:(a)asserteddefectscausedbynormalwearandtearofanypart
includingknobs,camouflagefinish,etc.;(b)asserteddefectscausedbymodification,unauthorizedservice,ac-
cidents,neglect,misuse,abuse,impropermaintenance,actsofNature;(c)asserteddefectsinvolvingsubjective
personallikesorjudgments;(d)batteries;or(e)productspurchasedoutsidetheUSA.

THISLIMITEDWARRANTYISTHEEXCLUSIVEWARRANTYFORTHISPRODUCT.WEDISCLAIMANYAND
ALLOTHERWARRANTIESOFANYKIND,EXPRESSORIMPLIED,INCLUDINGANYWARRANTIESOF
FITNESSFORAPARTICULARPURPOSEOROFMERCHANTABILITY.WESHALLNOTBELIABLEINTORT,
INCLUDINGNEGLIGENCEORSTRICTLIABILITY,ANDSHALLHAVENOLIABILITYATALLFORINJURY
TOPERSONSORPROPERTY.OURLIABILITYFORFAILURETOFULFILLANYOBLIGATIONUNDERTHIS
LIMITEDWARRANTYORANYOTHERLIABILITYINCONNECTIONWITHTHISPRODUCTSHALLBELIMITED
TOTHEAMOUNTOFTHEPURCHASEPRICERECEIVEDBYUSFORTHEPRODUCT.THEREMEDIESSTATED
INTHISLIMITEDWARRANTYARETHEPURCHASER’SEXCLUSIVEREMEDIESAGAINSTUSREGARDING
THISPRODUCT.UNDERNOCIRCUMSTANCESSHALLWEBELIABLEFORANYINDIRECT,INCIDENTAL,
SPECIALORCONSEQUENTIALDAMAGES,INCLUDINGLOSTPROFITSANDREVENUES,INCONVENIENCE
ORINTERRUPTIONSINOPERATIONS,ORANYOTHERCOMMERCIALORECONOMICLOSSESOFANY
KIND.THESELIMITATIONSANDDISCLAIMERSARENOTMADEBYUSWHEREPROHIBITEDBYLAW.SOME
STATESPROHIBITLIMITATIONSOFWARRANTIESANDTHEPURCHASERMAYHAVEADDITIONALRIGHTS
IN THOSE STATES.
