Ritron JMX-111D User manual

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
JOBCOM
®
JMX DISPLAY-SERIES
OWNER'S MANUAL
¤
DISPLAY-SERIES HANDHELDS
COMPACT, ULTRA-SMALL
PROFESSIONAL TWO-WAY RADIOS

1 to 10 Channel Capability

Easier, Enhanced Field Programming

1, 2, 3, or 4 Watt Models

Channel can

Easy-to-hear, High Audio Output

Built-in Quiet Call® Interference Eliminator

NOAA Weather Channel Feature (VHF only)

Emergency Weather Alert Feature (VHF only)
EXPANDED TABLE
FREQUENCY LIST
77 UHF & 26 VHF codes
NEW!
EXTRA FEATURES for
JMX 144D/446D/444D

ACCESSORIES
ii
OPTIONAL ACCESSORIES:
TO ORDER, CALL 800-USA-1-USA.
BPJS-6N .......... Spare/ Replacement JMX Battery
BPS-6N-SC ...... Spare/ Replacement SST Battery
BPS-6N-MH ..... Replacement High Capacity Battery
AFS- 50 ........... VHF Molded Flex Antenna
AFS-450 ........... UHF Molded Flex Antenna
RHD- X ............ Single Ear Headset
RHD-4X ............ Dual Ear Headset
RHD-5X ............ Lightweight Over-the-ear Earset /w In-line PTT
RHD-6X ............ Lightweight Behind-the-head Earset w/ In-line PTT
RHD-8X ............ Lightweight Earbud w/ mic and In-line PTT
RSM-3X ........... Remote Speaker Microphone
REP-2 ............... Low Profile Earphone
CCL-B ............. Cigarette Lighter Charger
MHC-A ............ Cordura Holster w/beltclip & neck strap
BCJS-4AD ...... 4-Well Drop-in Charger: JMX
BCPS-4AD ...... 4-Well Drop-in Charger: SST
BCPS-AD ......... Single-Well Drop-in Charger: SST (Overnight)
BCC-PS ........... Drop-in High-rate Charger/
Conditioner; for SST Models only
Call RITRON for complete listings.
RHD-1X
Single Ear Headset
RHD-4X
Dual Ear Headset
RSM-3X
Remote Speaker Mic
RHD-5X
Over the ear Earset
RHD-6X
Behind the ear Earset
BCJS-4AD
4 Well Drop in Charger
BCJS-AD
Single Well Drop in Charger
MHC-A
Cordura Holster
BPS-6N-SC
Spare Battery
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
RHD-8X
Single Earbud

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
iii
DESCRIPTION ..................................................................... PAGE
BATTERIES
FIG-7: Battery Access and Installation ................................................................ 11
Optional Charging Accessories ............................................................................. 11
Charging ................................................................................................................. 12
Battery Maintenance and Conditioning .............................................................. 1 2
!! CAUTIONS  ALL RADIOS !!
Obser e Caution in the Following En ironments to Maximize the Life of
Your Radio Equipment .......................................................................................... 13
Exposure to Radio Frequency Energy ................................................................. 13
SPECIAL APPLICATION
How To Field Program 2-Tone Encode Codes
for GateGuard Applications, go to www.ritron.com/gg_04.pdf .......................... 14
TABLE 5: Programmable 2-Tone Encode Codes ............................................... 1 4
TROUBLESHOOTING
Notes ........................................................................................................................ 15
Chart ........................................................................................................................ 15
FCC LICENSE REQUIRED
FCC Regulations .................................................................................................... 16
Ser ice .................................................................................................................... 1 6
How to Obtain an FCC Radio License ................................................................. 16
LIMITED WARRANTY ......................................................................... BACK COVER
TABLES:
1. Programmable Frequency Codes ....................................................................... 9
2. Programmable QC Tone Codes ....................................................................... 10
3. Expanded Programmable DQC Codes ............................................................ 1 0
4. Radio Option Codes .......................................................................................... 1 0
5. Programmable 2-Tone Codes .......................................................................... 14
FIGURES:
1. Radio Controls and Connectors .......................................................................... 2
2. Transmit / Busy Lamp .......................................................................................... 4
4. To Select Your Local NOAA Weather Frequency ............................................. 6
5. NOAA Frequencies ............................................................................................... 6
6. How to Place the Radio in Program / Readout Mode ..................................... 7
7. Battery Access and Installation ......................................................................... 11
DESCRIPTION ..................................................................... PAGE
ACCESSORIES
Optional Accessories ................................................................................................. i i
INTRODUCTION
JMX "D-Series" Model Numbers .............................................................................. 1
Features ..................................................................................................................... 1
Inspection .................................................................................................................. 1
CONTROL & OPERATION ......................................................................................... 2
FIG-1: Radio Controls and Connectors .................................................................. 2
OPERATION
On-off/ Volume Adjust .............................................................................................. 3
Channel Selection .................................................................................................... 3
Recei e ...................................................................................................................... 3
Quiet Call Tone Codes ............................................................................................. 4
Transmit ..................................................................................................................... 4
Radio Alert Tones ..................................................................................................... 4
Optional Alert Tones ................................................................................................. 4
FIG-2: Transmit / Busy Lamp .................................................................................. 4
Scan Channel Operation ......................................................................................... 5
Additional Features .................................................................................................. 5
NOAA WEATHER RADIO
Selecting Your Local NOAA Weather Frequency .................................................. 6
FIG-4: To Select Your Local NOAA Weather Frequency ..................................... 6
FIG-5: NOAA Frequencies ....................................................................................... 6
NOAA Weather Channel ........................................................................................... 6
Weather Alert ............................................................................................................. 6
RADIO PROGRAMMING
FIG-6: How To Place the Radio in Program / Readout Mode ............................. 7
How to Readout Field Programmed Frequency & Tone Codes ........................... 7
How to Field Program Frequency and Tone Codes ............................................... 8
TABLE 1: Programmable Frequency Codes .......................................................... 9
TABLE 2: Programmable QC Tone Codes ........................................................... 10
TABLE 3: Programmable DQC Codes .................................................................. 1 0
TABLE 4: Radio Option Codes .............................................................................. 10
How to Delete a Channel ....................................................................................... 10
How to Field Program Radio Options ................................................................... 10
TABLE OF CONTENTS
Call RITRON at 800-USA-1-USA (800-872-1872) or a complete Accessory listing or visit our website at www.ritron.com
NOTE: Refer to pages ii and 11 for Accessory information.

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
INTRODUCTION
page 1
THANK YOU FOR CHOOSING RITRON
Congratulations on your purchase of the JMX "D-Series"
radio. Your new radio is the result of Ritron's 5+ years
of designing, manufacturing, and supplying reliable,
professional wireless communication products. Ritron
wireless products will improve the operation, safety, and
profitability of any organization by providing instant voice
communications between employees throughout the
workplace.
JMX "D-SERIES" MODEL NUMBERS
VHF MODELS
JMX 111D ......... (Jobcom) ..... (1-Watt, 1 Channel)
JMX 141D ......... (Jobcom) ..... (1.5-Watt, 10 Channel)
JMX 146D ......... (Jobcom) ..... ( -Watt, 10 Channel)
JMX 144D ......... (Jobcom) ..... (4-Watt, 10 Channel)
UHF MODELS
JMX 441D ......... (Jobcom) ..... (1-Watt, 10 Channel)
JMX 446D ......... (Jobcom) ..... ( -Watt, 10 Channel)
JMX 444D ......... (Jobcom) ..... (3-Watt, 10 Channel)
The model number located on the back of the radio case
indicates its operating band. A color "dot" label on the
bottom of JMX radio cases also indicates the frequency.
Refer to the Frequency Table on page 9.
VHF band radios are designed to operate between
150 and 16 MHz.
UHF band radios are designed to operate between
450 and 470 MHz.
FEATURES
This manual covers the JMX "D-Series" radios.
Each radio (except JMX-111D) is capable of 10 channels.
The radios are programmed from the factory with
channels. All models (except JMX-111D) can add a scan
channel. All VHF models can be programmed to receive
NOAA weather broadcasts. Each radio is equipped with
the following features:
Push-button operating ontrols. The Push-To-
Talk (PTT) and Channel buttons are on one side of the
radio, and the On/ Volume Up, Volume Down/ Off and
monitor controls on the top.
Channel display. The LED display will show the
current operating channel, and contains a transmit
/ busy lamp.
Qui k- hange battery pa k and drop-in
harger apabilities. See Optional Charging
Accessories on page 11.
10- hannel apability (except JMX-111D). Up to
10 channels can be programmed to contain a
unique channel table frequency and interference
eliminator code.
QC (Quiet Call) intereferen e eliminator
odes. Each channel can be programmed from a
list of 50 QC sub-audible codes.
Field programming. The JMX "D-Series" radio
allows you to quickly select and program each
channel individually while in the field without the
need for a PC programmer. Each channel can be
programmed to one of 6 VHF or 77 UHF channel
table frequencies and one of 50 QC or 104 DQC
(selected models, refer to page 7) interference elimi-
nator codes, or you can delete a channel altogether.
Channel s anning (except JMX-111D). The Scan
channel allows scanning of all channels programmed
into the radio. The Scan channel can be turned On
and Off through Field programming, .
Low battery alert. The radio will sound a low bat-
tery alert tone when your battery is running down to
allow you time to recharge or change your battery.
Weather Channel. VHF models can be programmed
to receive your local NOAA weather radio broadcast.
The Weather channel can be turned On and Off
through Field programming.
Weather Alert. VHF models can be programmed to
alert you when the National Weather Service detects
threatening weather conditions. The Weather Alert
feature can be turned On and Off through Field
programming.
INSPECTION
Make sure the package includes:
 JMX "D-Series" radio
 Antenna
 Rechargeable battery pack (installed in radio)
 Belt clip
 BC-A charger cube
 Owner's Manual
Examine the equipment immediately after delivery
and report any damage to your shipping company.

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
CONTROL & OPERATION
IMPORTANT: CHARGE THE BATTERY PACK before using the radio for the first ti e. Refer to Batteries, pages 11 and 12.
page 2
1ANTENNA
The flexible antenna radiates and receives radio signals.
Screw the antenna base all the way into the threaded
bushing on top of the radio.
NOTE: Use only the type of antenna furnished with the
radio. VHF and UHF antennas are not
interchangeable.
2 ON/ VOLUME UP
To switch the unit On, press the On/ Volume Up button; the
speaker will emit a turn on beep. If the radio turns on to the
Scan Channel it will emit the Scan eep. Once the radio is
On, press this button to increase volume.
3VOLUME DOWN/ OFF
Press the Volume Down/ Off button to decrease volume.
To switch Off the unit, press and hold this button until the
speaker emits a double beep.
4PUSH-TO-TALK SWITCH (PTT)
Press and hold the PTT when transmitting; release it to
receive.
5CHANNEL SELECTOR
Press the button and the radio will emit the channel beep,
advance the channel, and the channel display will show
the new operating channel. When the Scan Channel is
selected the radio will emit the Scan eep and the radio will
begin scanning.
6BATTERY ACCESS DOOR
(CASE BOTTOM)
The battery access door may be removed to access the
battery pack. Refer to "FIG-7: attery Access & Installation"
on page 11.
7JACK COVER
This rubber cover seals out dust and moisture, etc. Snap
the cover into the audio accessory jack and charge jack
openings when the jacks are not in use.
8AUDIO ACCESSORY JACK
The audio accessory jack is used to plug in earphone
options, and, in conjunction with the charge jack, to connect
an optional remote speaker/ microphone or a single-or dual-
ear headset. This jack is also used for PC programming.
9CHARGE JACK
The battery pack may be charged through this jack using
the RITRON charger cube. Refer to Accessories, page ii,
for additional charging options.
10 CHANNEL DISPLAY
The channel display will indicate the current operating
channel. When the Scan Channel is selected the display
will rapidly flash the channels being scanned, and will stop
when a channel is received.
11 SPEAKER
The speaker, located behind the front grille, allows you to
hear calls on your channel.
12 MICROPHONE
The microphone allows your voice to be heard in
transmissions to other radios. Speak in a normal tone;
shouting does not improve your listener's reception.
13 DROP-IN CHARGING CAPABILITY
Two contacts, in the bottom of the radio, permit charging
the battery pack with an optional drop-in charger. Refer to
"Optional Charging Accessories" on page 11.
CH
ON OFF/HOLD
VOLUME
FIG-1: RADIO CONTROLS & CONNECTORS
1
3
4
5
6
7
8
9
11
12
13
10
2

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
OPERATION
page 3
ON-OFF / VOLUME ADJUST
To turn on the radio - press the On/Volume Up button.
The radio will emit a beep and the channel display will
light. If the radio turns on to the Scan Channel it will emit
the Scan eep. The radio will always turn on to the
channel that was selected when it was last turned off.
To adjust the volume - press the volume up or volume
down button until you reach the desired level. The vol-
ume level is displayed as a number between 0 through 9.
To turn OFF "beeps" - speaker beeps can be disabled
through field programming to provide a silent mode of
operation (ideal for security applications), only your
incoming calls will be heard on the speaker. Refer to
page 10 for How to Field Program Radio Options.
When speaker beeps are disabled only the low battery
indication and 2-Tone decode ring tone, if enabled, are
retained.
To turn off the radio - press and hold the Off/Volume
Down button until a two tone "turn-off beep" is heard.
For instant turn-off, press the PTT button while holding
the Off/Volume Down button.
CHANNEL SELECTION
To change channels - press and release the Channel
Selector button. The radio will emit a short Channel beep,
increment the channel, and the Channel Display will
show the new operating channel. If the highest channel
number is selected and you press the Channel Selector
button, the radio resets to channel 1 and the Channel
beep is heard on the speaker.
If the Scan Channel is selected - the radio will emit the
Scan eep and the Channel Display will rapidly flash the
channel numbers as they are scanned. If a signal is
received the channel display will indicate the channel
number, and when the received signal is removed the
radio will wait briefly, sound the Scan eep, then
scanning will resume as normal.
If the Weather Channel is selected - on a VHF radio the
Channel beep will be heard and the display will light a
single segment that indicates which of the seven NOAA
frequencies is monitored. See the "NOAA Weather
Radio" section on page 6 for details.
RECEIVE
To hear calls from other users - adjust the volume as
desired. The radio can only receive broadcasts while the
Push-To-Talk button is not being pressed.
Whether or not you hear these broadcasts depends
upon the squelch settings.
There are two standard squelch modes that can be used
in the JMX "D-Series" portable.
Carrier Squelch lets you hear all broadcasts on
your channel strong enough for the radio to detect,
and silences noise.
Tone Squelch uses the QC or DQC "tone squelch
format available on the JMX. This allows you to
screen out on-channel broadcasts that do not carry
the correct code programmed for the radio.
When Carrier or Tone Squelch is selected by the
user, all channels will operate in that mode. The JMX
"D-Series" radio will operate in tone squelch mode
when it is first turned on.
To activate Tone Squelch or Carrier Squelch and to
Monitor the channel - simultaneously press both the
volume buttons and hold briefly before releasing.
 If the radio emits a SINGLE beep, then Tone Squelch
is turned ON and you will only hear radio transmissions
on that channel with the same QC or DQC tone codes
as your radio.
 If the radio emits a DOUBLE beep, then you are in
Carrier Squelch and you can Monitor all
broadcasts on the channel. To exit Carrier
Squelch press and hold both volume buttons until
you hear the SINGLE beep.
Note: It is possible that the beginning of a call
might be missed while the radio is in
battery saver mode. If this happens, ask
the caller to repeat the message.
If you are unable to activate Carrier Squelch - the radio
has been optionally programmed for Monitor Lockout.
See your Ritron dealer or contact Ritron directly to
disable this option.

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
page 4
QC TONE CODES
(Interference Eliminator Codes)
Tone codes help filter out the "chatter" of others
that share your radio channel. hen you operate
on a frequency with a tone code, you screen out
most interference. This allows you to hear only
those users in your radio group.
IMPORTANT! All radios in the talk group must
operate on the same frequency and
tone code.
TRANSMIT
Normally, you should not transmit until the channel is
quiet. This can be determined by monitoring the channel
prior to transmitting.
To transmit - hold down the Push-To-Talk button and with
the radio four inches away talk into the microphone.
Speak in a normal tone, since talking louder will not
improve the listener s reception.
Keep talk times as short and infrequent as possible to
conserve battery, minimize radio frequency exposure,
and allow others to use the channel.
RADIO ALERT TONES
The handheld responds to certain instructions by sound-
ing a beep or series of tones. These tones can tell you
that the radio is working as you expect.
Power On/Sel Check OK
When it is first turned on, the radio runs a quick self
test to confirm basic functions. When complete the radio
will emit the channel beep and the Channel Display will
show the operating channel. The radio is then ready to
use.
OPERATION
Error Tones
However, if the self test detects a diagnostic er-
ror, an error tone sounds. The error tone
indicates the radio frequency synthesizer is
malfunctioning. Turn off the radio and try again. The
error tone will also sound if a channel has been
programmed for an invalid frequency. A long,
low-pitched tone means the battery voltage is too
low to operate the radio. In this case, recharge the
battery. If you cannot correct a problem, consult an
authorized Ritron service facility or Ritron.
Channel Select
When the Channel button is pressed, the radio will emit
a short Channel beep, increment the channel, and the
channel display will show the new operating channel.
Scan Channel (except JMX-111D)
When the Scan channel is selected by pressing the
Channel button, the radio will emit the Scan beep and
begin scanning.
Tone Squelch
When you press and hold both Volume buttons at the
same time, a single beep will sound to indicate that
tone squelch is on. A double beep means that carrier
squelch is on.
Recharge Battery Alert
As the battery voltage approaches the minimum
required operating voltage the radio will emit a series
of short beeps to alert the user that the battery will
soon need recharging. Once the battery charge drops
below the required operating voltage, the radio emits
a long, low tone and turns itself off. If you turn the
radio back on, it will beep again and shut itself off.
Recharge the battery.
Transmitter Time Out
A low tone followed by a higher-pitched tone sounds
and the transmitter automatically shuts off if you hold
down the PTT button longer than 60 seconds. The
radio automatically switches to receive mode.
OPTIONAL ALERT TONES
JMX "D-Series" models JMX-144D/446D/444D can be
programmed using the RITRON PC Programmer for
optional alert tones. See your Ritron dealer or contact
Ritron directly for programming of these options.
Receive Squelch Tone
A short tone sounds at the end of each received
transmission to indicate that the channel is clear and
you may transmit.
Busy Channel TX Inhibit
If a user is transmitting on your radio frequency
without your tone, you will not be allowed to transmit.
The radio will beep a series of long, low tones while
the PTT is held down (like a busy signal).
Transmit Clear To Talk Beep
A short tone sounds after the PTT has been pressed
to indicate that the radio is ready for you to begin
talking.
FIG-2: TRANSMIT / BUSY LAMP
A Transmit / Busy
Lamp in the upper
left corner of the
Channel Display
is lit whenever
the transmitter is
activated and
blinks when the
channel is busy.

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
OPERATION
SCAN CHANNEL OPERATION
Channel scanning allows you to listen to broadcasts
on your radio channels. The JMX "D-Series" (except
JMX-111D) will scan all channels programmed into the
radio with the exception of the NOAA Weather Chan-
nel, refer to page 6.
How Scanning Works
Using the Channel Selector button, select the Scan
Channel. The radio sounds the Scan Beep, and then
repeatedly checks each channel in the scan list. The
channel display will show the channel numbers as
they are scanned.
When receiving a call on a channel being scanned, the
radio will stop scanning to let you hear communica-
tions on that channel. After the transmission has
ended the radio will pause before it resumes scanning
to allow you time to respond.
When transmitting from the Scan Channel, the
handheld will go to the last channel on which a signal
was received, then transmit. After you release the
PTT the radio will pause to allow time for a response,
and then resume scanning.
Busy Channel Blocking
If one of the channels in the scan list is so busy that
you want to temporarily block it out, press the
Channel Selector button while the radio is stopped on
the channel to be blocked and hold it until scanning
resumes. The blocked channel will now be skipped in
the scan list. The blocked channel will be returned to
the scan list if the radio is turned off, or when the
radio channel is changed using the Channel Selector
button. Channel 1 cannot be blocked.
Last Channel Scanned Alert Tone
When changing channels with the Channel Selector
button, an alert tone will sound to indicate the last
channel that received a message when the radio was
scanning. This will identify the channel on which the
last message was received, and allow uninterrupted
transmission on that channel without the constraints
of scanning. You can then press the Channel Selector
button to return to the Scan Channel.
Priority Scanning (Optional)
The JMX-144D/446D/444D radios can be option-
ally programmed for priority scanning. Priority
can allows you to periodically monitor a Priority
Channel, even if the radio has stopped on another
channel. This will prevent missed calls on the pri-
mary operating channel when in scan mode.
With Priority can enabled:
 The first channel in the scan list is the Priority
Channel.
 The radio checks the Priority Channel every two
seconds to check for activity. This time is
programmable and can be set for 1 - 8 seconds.
 The radio can be programmed to transmit only
on the Priority Channel when scanning, if
desired.
 The radio can be programmed to sound a
Priority Channel Beep whenever the radio
receives on the Priority Channel when scanning.
ee your Ritron dealer or contact Ritron directly for
PC programming of this option.
page 5
ADDITIONAL FEATURES
The JMX "D-Series" handheld radios have other features
available through PC programming. See your itron dealer
or contact itron directly for PC programming of these
option.
Receive and Transmit Frequencies not contained
in Frequency Code Table 1, page 9.
Wide or narrow band transmit operation can be
set per channel.
Additional PC programmable features available to models
JMX-144D/446D/444D ONLY include:
Scan Channel Options include scan resume delay
time, busy channel blocking, last active channel beeps,
and priority scanning options.
Squelch Tightener eceiver carrier squelch can be
adjusted UP or DOWN.
Transmit Power (J X-144D and J X-444D Only)
Transmit Time Out can be changed or disabled.
onitor Lock Out can be set to prevent monitoring
of the channel, only broadcasts with the correct QC or
DQC code can be heard.
Transmit Inhibit on Busy Channel can be set to
prevent transmitting when a broadcast is present on
the receiver that does not carry the correct code.
Receive Squelch Tone sounds at the end of each
received transmission.
Transmit Clear To Talk Beep sounds after the PTT
has been pressed.
Power Saver time can be set or disabled.
Field Programming can be disabled.
4-Hour Inactivity Turn-Off The radio can be set to
turn off automatically if not used for over 4 hours.
2-Tone Encode and Decode The radio can be
programmed to send and receive 2-tone paging.

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
SELECTING YOUR LOCAL NOAA WEATHER
FREQUENCY
VHF models of the JMX "D-Series" radio can hear
weather forecasts from the National Weather Service
which are broadcast on one of the seven NOAA
weather frequencies.
The radio is shipped from the factory without a NOAA
frequency selected. Before using any of the NOAA
weather features on your VHF radio you must first
select the local NOAA frequency.
1. Follow the steps in FIG-4 at right to place the radio
into the Weather Frequency Select mode.
2. The radio will scan to the 1st NOAA frequency
where a broadcast is present. The display will light
a single segment to indicate the NOAA frequency
per FIG-5.
3. Monitor the channel for a few minutes to be sure
it is the broadcast for your local area.
4. Press the Channel button to scan for the presence
of any other NOAA broadcasts, monitoring each
broadcast and noting the frequency as indicated
by the display.
5. Using the Channel button, select the local NOAA
frequency you would like your radio to operate on.
6. Turn the radio off by pressing the Volume Down/
Off button.
7. When the radio is turned back on all weather
features will operate on the selected NOAA
frequency.
NOAA WEATHER RADIO
FIG-4: TO SELECT YOUR LOCAL NOAA
WEATHER FREQUENCY
CH
ON OFF/HOLD
VOLUME
1. PRESS & HOLD UNTIL
THE "RADIO OFF"
TONES ARE HEARD,
THEN RELEASE.
3. PRESS & RELEASE -
THE RADIO WILL
START BEEPING.
2. PRESS & HOLD
THE CHANNEL
BUTTON.
4. CONTINUE HOLDING THE
CHANNEL BUTTON UNTIL THE
BEEPING STOPS, THEN RELEASE
IT & LISTEN.
5. TO FIND THE NEXT ACTIVE
WEATHER CHANNEL, PRESS &
RELEASE THE CHANNEL
BUTTON.
page 6
FIG-5: NOAA FREQUENCIES
162.400 MHz
(center)
162.450 MHz
162.425 MHz
162.550 MHz
162.525 MHz
162.500 MHz
162.475 MHz
NOAA WEATHER CHANNEL
Once a NOAA weather frequency has been se ected on
your VHF mode radio, a channe is created for istening
to Nationa Weather Service broadcasts.
Press the Channe button to step through your radio
channe s. The NOAA Weather Channe wi be after your
ast channe , and the disp ay wi ight the segment
representing the se ected NOAA frequency.
If you wish to exc ude the NOAA Weather Channe
feature, it can be turned off through Fie d Programming.
WEATHER ALERT
Once a NOAA weather frequency has been se ected on
your VHF mode radio it wi isten for emergency
broadcasts from the Nationa Weather Service,
regard ess of which channe you are on.
An a ert tone wi sound in the speaker,
the disp ay wi show an "A" (as shown),
and the Nationa Weather Service emer-
gency broadcast wi be heard - advising
you of threatening weather conditions.
NOTE: NOAA sends a test a ert tone
once each week. Your radio wi respond to
this a ert.
Pressing the Channe button wi return you to your norma
operating channe .
If you do not desire Weather A ert, it can be turned off
through Fie d Programming, refer to page 10.
Have questions? Ca 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
RADIO PROGRAMMING
IMPORTANT
To talk to other users in your group, all
radios must be set to the same frequency
and Interference liminator codes.
FIG-6: HOW TO PLACE THE RADIO IN
PROGRAM/READOUT MODE
CH
ON OFF/HOLD
VOLUME
3. PRESS & RELEASE -
THE RADIO WILL
START BEEPING
RAPIDLY.
2. PRESS & HOLD
THE PUSH-TO-
TALK BUTTON.
4. CONTINUE HOLDING THE PUSH-
TO-TALK BUTTON UNTIL THE
BEEPING STOPS, THEN RELEASE
IT.
5. THE RADIO WILL EMIT A TRIPLE
TONE: IT IS NOW IN PROGRAM/
READOUT MODE.
. PRESS & HOLD UNTIL
THE "RADIO OFF"
TONES ARE HEARD,
THEN RELEASE.
HOW TO READOUT FIELD PROGRAMMED FREQUENCY & TONE CODES
In our example channel 3 of a JMX-446D radio is programmed to operate on the "Brown Dot" fre uency of
464.500 MHz (Fre uency code "04") with 100.0 Hz tone (Tone code "12").
page 7
CHANNEL RADIO IDENTIFICATION
FREQUENCY &
TONE CODES
If more than 5 digits
are displayed, refer
to page 14.
!
1. Place the radio into Program/ Readout Mode by following the instructions in FIG-
6 at left. "P" will appear on the LED display as you enter program mode.
2. Release the Push-to-talk button after the beeping has stopped. The radio will
display a series of six characters for Radio Identification, with each character
separated by a hyphen. The 1st two characters indicate the model number, the
3rd and 4th characters indicate the radio type, and the 5th and 6th characters
indicate the firmware revision.
In this example: Model: 25
Radio Type: 15
Firmware Revision: 01
NOTE: Radio models with firmware revisions prior to 15.01 do not display the
Radio Identification sequence.
3. fter the Radio Identification has been displayed the digit 1 will appear,
followed by a hyphen, and the radio will emit a triple beep indicating that the
radio is in program mode and channel 1 is selected.
4. Press the Channel button to select the channel to be read out. The channel
number will appear briefly on the display as you step through the channels.
When you have settled on a channel a hyphen will appear across the center
of the display to indicate that it is ready for readout.
5. Press and release the On/Volume Up button. The radio will begin to display a
series of four digits; with each digit separated by a hyphen.
The 1st and 2nd digits indicate the frequency code; see Table 1 on page 9.
The 3rd and 4th digits indicate the tone code; see Table 2 on page 10.
JMX-144D/446D/444D Models Only
If a 5th digit is displayed, the channel has been programmed for DQC and the
last three digits indicate the DQC code; see Table 3 on page 10.
6. If the channel is PC-programmed for any frequency not listed in Table 1 on
page 9, an error tone will sound and an "E" will appear on the display.
7. To readout another channel, repeat steps 4 through 6.
8. Turn the radio OFF and then ON againthe radio is now ready to use.
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
RADIO PROGRAMMING
page 8
FREQUENCY CODETONE CODE
SELECT CHANNEL RADIO IDENTIFICATION
HOW TO FIELD PROGRAM FREQUENCY & TONE CODES
04
12
To match other radios, the owner can select Frequency and Tone Codes from Tables
1, 2 and 3 on pages 9 and 10.
In our example we will program channel 3 of a JMX 446D to operate on the "Brown Dot"
frequency of 464.500 MHz (Frequency code "04") with 100.0 Hz tone (Tone code "12").
7. Enter the 1st digit of the frequency code by clicking the PTT button
until the channel display shows the desired number. Pause the
radio will sound a low tone and show a hyphen across the center of
the display to indicated that it is ready to accept the next digit.
8. Enter the 2nd digit of the frequency code by clicking the PTT button
until the channel display shows the desired number. Pause the
radio will sound a low tone and show a hyphen across the center of
the display to indicated that it is ready to accept the next digit.
9. Enter the 1st digit of the tone code (or 1st digit of the DQC code) by
clicking the PTT button until the channel display shows the desired
number. Pause the radio will sound a low tone and show a hyphen
on the display to indicated that it is ready to accept the next digit.
10. Enter the 2nd digit of the tone code (or 2nd digit of the DQC code) by
clicking the PTT button until the channel display shows the desired
number. Pause the radio will sound a low tone and show a hyphen
on the display to indicated that it is ready to accept the next digit.
11. JMX-144D/446D/444D Models Only
FOR DQC CODES ONLY Enter the 3rd digit of the DQC code by
clicking the PTT button until the channel display shows the desired
number. Pause the radio will sound a low tone and show a hyphen
on the display to indicated that it is ready to accept the next digit.
12. Press and release the On/ Volume Up to SA E your programming
entry. The LED display will briefly show the channel number you
have just programmed and the radio will sound a triple beep to
indicate that programming was successful.
NOTE: An error tone will sound if you attempt to save an incorrect
code and an "E" will appear on the display. Turn the radio OFF, check
the digits you are attempting to enter, then start over.
13. To program another channel, repeat steps 6 through 12.
14. Turn the radio OFF and then ON againthe radio is now ready to
use.
1. Refer to Table 1 on page 9 to determine the two digit
frequency code and write it down.
2. Refer to Table 2 on page 10 to determine the two digit
tone code for 100.0 Hz and write it down.
3. Place the radio into Program/ Readout Mode by
following the instructions in FIG 6 on page 7. A "P" will
appear on the LED display as you enter program mode.
4. Release the Push to talk button after the beeping has
stopped. The radio will display a series of six
characters for Radio Identification, with each character
separated by a hyphen. The 1st two characters
indicate the model number, the 3rd and 4th characters
indicate the radio type, and the 5th and 6th characters
indicate the firmware revision.
In this example: Model: 25
Radio Type: 15
Firmware Revision: 01
NOTE: Radio models with firmware revisions prior to
15.01 do not display the Radio Identification sequence.
5. After the Radio Identification has been displayed the
digit 1 will appear, followed by a hyphen, and the radio
will emit a triple beep indicating that the radio is in
program mode and channel 1 is selected.
6. Press the Channel Selector button to select the channel
to be programmed. The channel number will show
briefly on the channel display as you step through the
channels. When you have settled on a channel the
display will show a hyphen to indicate that it is ready
for programming, except the JMX 111D which is a 1
channel radio.
NOTES:
a. YOU MUST enter "No Tone" interference eliminator code "44" to match radios not
having tone codes. Refer to Table 2 on page 10.
b. If the radio does not sound a confirming triple tone when ou attempt to enter
Program/ Readout Mode, the radio was factor or dealer customized to disable
programming. Consult the radio owner or our dealer.
Refer to page
14 for 2-Tone
programming.
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
!

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
RADIO PROGRAMMING
page 9
TABLE 1: PROGRAMMABLE FREQUENCY CODES
*2-digit Frequency placeholder code (Refer to "How to Delete a Channel"
on page 10).
** MURS frequencies - The 5 MURS frequencies do not require an FCC license.
All other frequencies require an FCC license. See page 6 for license information.
Per FCC rules and regulations, a given
radio must not be programmed to
contain a mix of both V F Business
Band and V F MURS frequencies.
VHF MURS **
Code MHz Color Band
No Dot Width
01 154.6000 Green Dot 25
02 154.5700 Blue Dot 25
19 151.8200 MURS 12.5
20 151.8800 MURS 12.5
21 151.9400 MURS 12.5
22 154.6000 MURS/ Green 12.5
23 154.5700 MURS/ Blue 12.5
00 DELETE Code *
VHF Business Band
Code MHz Color Band
No Dot Width
03 151.6250 Red Dot 25
04 151.9550 Purple Dot 25
05 151.9250 25
06 154.5400 25
07 154.5150 25
08 154.6550 25
09 151.6850 25
10 151.7150 25
11 151.7750 25
12 151.8050 25
13 151.8350 25
14 151.8950 25
15 154.4900 25
16 151.6550 25
17 151.7450 25
18 151.8650 25
24 151.7000 12.5
25 151.7600 12.5
26 152.7000 25
00 DELETE Code *
UHF Business Band
Code MHz Color Band
No Dot Width
01 467.7625 J 25
02 467.8125 K 25
03 464.5500 Yellow Dot 25
04 464.5000 Brown Dot 25
05 467.8500 Silver Star 25
06 467.8750 Gold Star 25
07 467.9000 Red Star 25
08 467.9250 Blue Star 25
09 469.2625 25
10 462.5750 White Dot 25
11 462.6250 Black Dot 25
12 462.6750 Orange Dot 25
13 464.3250 25
14 464.8250 25
15 469.5000 25
16 469.5500 25
17 463.2625 25
18 464.9125 25
19 464.6000 25
20 464.7000 25
21 462.7250 25
22 464.5000 Brown Dot 12.5
23 464.5500 Yellow Dot 12.5
24 467.7625 J 12.5
25 467.8125 K 12.5
26 467.8500 Silver Star 12.5
UHF Business Band
Code MHz Color Band
No Dot Width
53 464.5375 12.5
54 464.5625 12.5
55 466.0375 12.5
56 466.0625 12.5
57 466.0875 12.5
58 466.1125 12.5
59 466.1375 12.5
60 466.1625 12.5
61 466.1875 12.5
62 466.2125 12.5
63 466.2375 12.5
64 466.2625 12.5
65 466.2875 12.5
66 466.3125 12.5
67 466.3375 12.5
68 466.3625 12.5
69 467.7875 12.5
70 467.8375 12.5
71 467.8625 12.5
72 467.8875 12.5
73 467.9125 12.5
74 469.4875 12.5
75 469.5125 12.5
76 469.5375 12.5
77 469.5625 12.5
00 DELETE Code *
UHF Business Band
Code MHz Color Band
No Dot Width
27 467.8750 Gold Star 12.5
28 467.9000 Red Star 12.5
29 467.9250 Blue Star 12.5
30 461.0375 12.5
31 461.0625 12.5
32 461.0875 12.5
33 461.1125 12.5
34 461.1375 12.5
35 461.1625 12.5
36 461.1875 12.5
37 461.2125 12.5
38 461.2375 12.5
39 461.2625 12.5
40 461.2875 12.5
41 461.3125 12.5
42 461.3375 12.5
43 461.3625 12.5
44 462.7625 12.5
45 462.7875 12.5
46 462.8125 12.5
47 462.8375 12.5
48 462.8625 12.5
49 462.8875 12.5
50 462.9125 12.5
51 464.4875 12.5
52 464.5125 12.5

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
01 67.0 18 123.0 35 225.7
02 71.9 19 127.3 36 233.6
03 74.4 20 131.8 37 241.8
04 77.0 21 136.5 38 250.3
05 79.7 22 141.3 39 69.4
06 82.5 23 146.2 40 159.8
07 85.4 24 151.4 41 165.5
08 88.5 25 156.7 42 171.3
09 91.5 26 162.2 43 177.3
10 94.8 27 167.9 44 No Tone
11 97.4 28 173.8 45 183.5
12 100.0 29 179.9 46 189.9
13 103.5 30 186.2 47 196.6
14 107.2 31 192.8 48 199.5
15 110.9 32 203.5 49 206.5
16 114.8 33 210.7 50 229.1
17 118.8 34 218.1 51 254.1
00 Delete
HOW TO DELETE A CHANNEL
1. Follow the instructions in FIG-6 on page 7 to place
the radio in the Program/ Readout Mode.
2. Using the Channel button and the LED display on
the front of the radio, select the channel to be
deleted.
3. Enter 4-digit code "0000" as described in the " ow
to Field Program Frequency & Tone Codes" section
on page 8.
4. When all four digits are programmed, press and
release the On/ Volume Up to SAVE your program-
ming entry. The LED display will briefly show the
channel number you have just deleted and the radio
will sound a triple beep to indicate that channel dele-
tion was successful.
5. To delete another channel, repeat steps 2 through 4.
6. Turn the radio OFF and then ON againthe radio is
now ready to use.
7. The remaining channels are in the same sequence
and will retain their same channel number. The
Channel Selector will skip over the deleted channel
numbers.
NOTE: If all channels are deleted the radio will
not operate, instead it will turn on in Field
Program mode to allow entry of a valid
frequency and tone code.
RADIO PROGRAMMING
page 10
TABLE 2: INTERFERENCE ELIMINATOR
PROGRAMMABLE QC TONE
CODES
TABLE 3: DIGITAL INTERFERENCE ELIMINATOR
PROGRAMMABLE DQC CODES
Code Numbers
Code No. Hz Code No. Hz Code No. Hz
356
36
365
371
11
12
13
23
31
32
5
6
52
5
55
023
025
026
031
032
036
0 3
0 7
051
053
05
065
071
072
073
07
11
115
116
122
125
131
132
13
1 3
1 5
152
155
156
162
165
172
17
205
212
223
225
226
2 3
2
2 5
2 6
251
252
255
261
263
265
266
271
27
306
311
315
325
331
332
3 3
3 6
351
62
6
65
66
503
506
516
523
532
5 6
565
606
612
62
627
631
632
6 5
65
662
66
703
712
723
731
732
73
7 3
75
HOW TO FIELD PROGRAM RADIO OPTIONS
1. Follow the instructions in FIG-6 on page 7 to place
the radio in the Program/ Readout Mode.
2. sing the PTT (push-to-talk) button and the LED
display, enter the single digit code from Table 4
below for the option to be programmed.
3. Pausethe display will change and show a hyphen,
you will also hear a short low tone.
4. Press and release the On/Volume p to SAVE your
programming entry. The radio will sound a triple beep
to indicate that programming was successful.
5. Turn the radio OFF and then ON againthe radio is
now ready to use.
Turn Channel Scan ON 1
Turn Channel Scan OFF 2
Turn Weather Channel ON 3
Turn Weather Channel OFF 4
Turn Weather Alert ON 5
Turn Weather Alert OFF 6
Turn Speaker Beep ON 7
Turn Speaker Beep OFF 8
TABLE 4: RADIO OPTION CODES
OPTION CODE NO.

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
BATTERIES
JOBCOM JMX Accessories:
BPJS-6N ....................... 700 mAH Spare Battery Pack
BPJS-AD ....................... Drop-in Charger Adapter
Quad Charger .............. 4-Unit Gang Charger
See Accessories on page ii.
1 . Hold the radio a hown above (A).
2 . U e your thumbnail to open the
Door Latch, a hown below (B).
3 . Lift and rotate the Battery Acce
Door to relea e it (C).
FIG7: BATTERY ACCESS & INSTALLATION:
(A)
(D)
(B)
BOTTOM VIEW OF THE RADIO
OPTIONAL CHARGING ACCESSORIES:
Spare/ Replacement
Battery Pack
Drop-in Battery Charger
with spacer
Battery
Access
Door
Drop-in Charger
Contacts
LATCH
CLOS D
LATCH
OP N
4 . Use the Pull-tab to pull the battery
pack out of the case (D).
5 . Insert the replacement battery
pack, being certain to POSI ION I
RELA IVE O HE CASE AS
SHOWN IN (D). Push the Battery
Pack in as far as as possible.
6 . Replace the Battery Access Door.
Secure it by closing the Door Latch
as shown in (B).
7 . Be certain to firmly lock the Door
Latch, as shown in (B).
BATTERY ACCESS
DOOR
DOOR LATCH
PULL
- TAB
(C)
page 11

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
BATTERY MAINTENANCE & CONDITIONING
Due to the extended run time of the JMX "D-Series" radios, some users
may never fully discharge the battery pack during normal use Achieve
maximum battery life by fully discharging the battery periodically to
condition it
After exposing the battery pack to many cycles of not fully discharging it
before recharging, the radio may exhibit reduced battery capacity This
reduced capacity is evident when, after several hours of use, battery
voltage drops while the radio is transmitting, causing the radio to emit a
low battery warning tone
Condition battery packs by the following procedure as either a
preventive measure, or if you suspect reduced capacity:
TO CONDITION THE BATTERY PACK:
1. Use your radio throughout a normal work day without charging
2.  Press and hold the On/ Volume Up and Volume Down/ Off buttons
simultaneously for 8 seconds to place the radio in "no squelch"
mode
 Release both buttons when you hear the radio beep rapidly; it will
then emit a loud "rushing" noise Press On/ Volume Up to maximize
this noise
3. Put the radio away in a secure place (possibly a desk drawer),
where nothing can press against the buttons to accidentally turn it
off or cause it to transmit Allow the radio to run until it shuts off
when the battery is completely discharged A typical battery pack
may require up to 8 hours to completely discharge
4. When the radio has shut off, charge it overnight for 12-14 hours
The battery will be ready for use with renewed capacity
NOT : A new battery must be charged and discharged several times
before it can reach its maximum charge capacity
CAUTION: Use only RITRON-supplied cha ge s; using othe cha ge s may cause fi e
o explosion, o othe wise damage the adio.
CHARGING
The JMX "D-Series" radio is powered by a rechargeable battery pack Because the battery pack
loses its charge during storage and shipment, fully charge it before first use To ensure peak
radio performance for the next day, charge the battery overnight after each day of use It
completely charges in about ten hours
TO CHARGE THE BATTERY WITH A RITRON CUBE CHARGER
Plug the charger cord into the charge jack (marked "CHG") on top of the radio Then plug the
cube into an 110 VAC outlet The green lamp lights while the battery is charging, and should
go out only when the cube or cord is unplugged
TO CHARGE THE BATTERY WITH A RITRON DROP-IN CHARGER
Two charger contacts, visible through the radio case bottom, permit charging the battery with
an optional Ritron drop-in charger The battery pack may be either removed from the radio case
for charging, or charged inside the radio case
Each drop-in charger comes with a spacer to permit charging a "spare" battery while the radio
is being used
To use the drop-in charger, plug it into a 110 VAC outlet Set either the radio with the battery
installed, or only the battery with the battery spacer, into the charger Refer to the illustration
in Optional Accessories, opposite Each battery contact must rest on a charger contact pin
NOT :
Batte y pack life ave ages one yea . Follow these guidelines to maximize se vice life:
 CONDITION battery packs once a month as directed in Battery Maintenance & Conditioning, at
right
 CONDITION batteries that are run down
 CHARGE batteries for 16 hours before storage, and for 16 hours once a month thereafter
 DO NOT overcharge batteries Unplug the cube charger after 16 hours to avoid overcharging
 DO NOT charge batteries in temperatures colder than about 45°F Charging batteries in
temperatures above 95°C does not harm them, but can reduce charge capacity
BATTERIES
page 12

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
!! CAUTIONS  ALL RADIOS !!
OBSERVE CAUTION IN THE FOLLOWING
ENVIRONMENTS TO MAXIMIZE THE LIFE OF
YOUR RADIO EQUIPMENT:
MOISTURE: JMX "D-Series" radios are not
waterproof. DO NOT directly expose them to rain or
excessive moist re.
CHEMICALS: Detergents, alcohol, aerosol sprays or
petrole m prod cts can damage the radio case. DO
NOT se petrole m solvents of any kind; se a soft
cloth moistened with water to clean the case.
EXTREME HEAT: High temperat res can damage the
battery and other components. DO NOT expose the
nits to extreme heat or leave them in direct s nlight.
LOW TEMPERATURES: The capacity of the battery
is greatly red ced in extreme cold. When sing the
nit in very cold environments, periodically warm the
radio nder yo r coat.
EXCESSIVE TRANSMISSIONS: Maxim m drain on
battery power occ rs when yo are transmitting. DO
NOT hold the P sh-To-Talk switch down longer than
necessary d ring transmission intervals. DO NOT
red ce battery service life by attempting to power a
radio with a depleted battery; always charge
batteries overnight after each day of se.
VIBRATION/ SHOCK: Altho gh yo r JMX "D-Series"
radio is designed to be r gged, it will not s rvive
excessive ab se. Avoid dropping the radio.
NOTE: The optional MH-A holster provides added
protection from weather and shock.
The JMX/SST Series handheld radios generate RF
electromagnetic energy d ring transmit mode. The
transmit mode is active when the PTT switch is
depressed. This radio is designed for, and classified
as, Occ pational Use Only, meaning that it m st be
sed only d ring the co rse of employment by
individ als who are aware of the hazards and the
ways to minimize s ch hazards. This series of radios
is NOT intended for se by the General Pop lation in
an ncontrolled environment.
When sed as directed, this series of radios is
designed to comply with the FCCs RF expos re limits
for Occ pational Use Only. In addition, they are
designed to comply with the following Standards and
G idelines:
 FCC OET B lletin 65, Edition 97-01, S pplement C,
Eval ating Compliance with FCC G idelines for
H man Expos re to Radio Freq ency Electromag-
netic Fields.
 American National Standards Instit te (C95.1-
1992), IEEE Standard for Safety Levels with
Respect to H man Expos re to Radio Freq ency
Electromagnetic Fields, 3 kHz to 300 GHz.
 American National Standards Instit te (C95.3-
1992), IEEE Recommended Practice for the
Meas rement of Potentially Hazardo s Electromag-
netic Fields-RF and Microwave.
EXPOSURE TO RADIO FREQUENCY ENERGY
page 13
To ens re that expos re to RF electromagnetic energy
is within the FCC allowable limits for occ pational se,
always adhere to the following g idelines:
 Use only the antenna(s) available from RITRON for
these models. DO NOT attempt to s bstit te any
other antenna. DO NOT operate the radio witho t
an antenna.
 Keep talk times as short and infreq ent as possible.
DO NOT depress the PTT b tton when not act ally
wishing to transmit. These radios are eq ipped
with an internal timer to limit contin o s transmit
times. DO NOT exceed a 50% transmit d ty cycle.
 When transmitting, hold the radio in front of the
mo th at a distance of at least 4 inches. DO NOT
hold the radio in s ch a manner that the antenna is
next to, or to ching, exposed parts of the body,
especially the face or eyes while transmitting.
 In belt mo nted applications, when transmitting,
remove the radio from the belt and hold away from
the body at least 4 inches.
 When sing external headset accessories, hold the
nit away from the body at least 4 inches while
transmitting.
DO NOT allow children to operate the radio.

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
page 14
2-TONE ENCODE OPERATION
To send a 2-Tone Code, select a channel that has been programmed for 2-Tone
encode. Push and hold the channel b tton ntil yo hear the 2-Tone Code being
sent, then release the channel b tton.
SPECIAL APPLICATION
6. After yo have entered both digits, press and release the On/Vol me
Up b tton to SAVE the entry. The LED display will briefly show the
channel n mber yo have j st programmed and then a hyphen, the
radio will so nd a triple beep to indicate that programming was s ccessf l.
An ERROR tone will so nd if yo attempt to save an incorrect code,
an E will appear on the LED display. Check the digits yo are attempting
to program and start over.
7. Yo may program each channel with the same or a different 2-Tone Code
by repeating steps 3-6.
8. T rn the radio OFF and then ON again for normal operation. See 2-Tone
ENCODE Operation for how to send the 2-Tone Code on yo r radio.
Have q estions? Call 800-USA-1-USA (800-872-1872) or visit o r website at www.ritron.com
TABLE 5: PROGRAMMABLE 2-TONE ENCODE CODES
Code No Code No Code No
91 94 97
92 95 98
93 96 99
HOW TO FIELD PROGRAM TWO-TONE ENCODE CODES
THIS FEATURE AVAILABLE ON JMX-144D/446D/444D MODELS ONLY
For special applications, it is possible to se yo r Ritron portable radio or base station
for remote control applications; s ch as opening or closing a gate remotely (see Rit on
GateGua d at www.ritron.com/gg_04.pdf). This application req ires yo to program
yo r radio for 2-Tone encode operation.
The ser can field program each channel with one of the 9 p e-set 2-Tone Codes
specified in Table 5. These codes correspond to field programmable 2-Tone Codes
available in the RITRON 6-Series OUTPOST Callbox. In o r example we will program a UHF
radio to operate with 2-Tone Code #94.
Important Note:
You can ADD a 2-Tone Code to a channel if the Frequency Code and Tone Code
are not changed. Changing the Frequency Code or Tone Code of a channel will
ERASE any 2-Tone Code programmed on that channel. You must FIRST re-pro-
gram the channel to the desired Frequency Code and Tone Code and then SAVE
the entry by pressing the On/ olume Up button, then you may enter your 2-Tone
Code, remember you must also SAVE this entry by pressing the On/ olume Up
button.
1. Refer to Table 5 to determine the 2 digit, 2-Tone Code(s) yo wish
to program into each specific channel.
2. Follow the instr ctions in Fig 6, page 7 to place the radio in the
Program/Reado t Mode.
3. Using the channel b tton and the LED display on the radio, select
the channel n mber yo want to program a 2-Tone Code into.
4. Enter the 1st digit of the 2-Tone code by clicking the PTT b tton
ntil the program display shows the desired n mber. Pa sethe
radio will so nd a low tone and show a hyphen across the
display to indicate that it is ready to accept the next digit.
5. Enter the 2nd digit of the 2-Tone code by clicking the PTT b tton
ntil the program display shows the desired n mber. Pa sethe
radio so nds a low tone and will show a hyphen across the
display.
2-TONE CODE
If more than 5 digits are displayed during readout, the radio has been
programmed for 2-Tone Encode. The frequency and tone codes will be
displayed, followed by a  , then the radio will display the 2-Tone
code; see Table 5. In this example a UHF radio was programmed to
operate on the Brown Dot Frequency ode 04 (464.500 MHz) with
Tone ode 12 (100.0 Hz) and 2-Tone encode Code 94.
Readout
Sequence
!
Frequency Code Tone Code 2-Tone Code

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
If you have trouble operating the handheld, review the ontrols & Operation, pages 2 through 5.
If you think the radio is malfunctioning, check the list below.
Problem Possible Solutions
GENERAL
The radio does not work at all.  Make sure that the battery is installed correctly, as shown in FIG-7. page 11.
 echarge or replace the battery. (See pages 11 & 12.)
Operating features do not work  The radio has been dealer programmed for customized operation.
exactly as expected. (Consult dealer.)
eception is poor.  Move to a different location. (See Note 2.)
 Confirm the proper antenna is connected to the radio. (See page 2, Antenna)
You cannot hear calls from  Turn off Quiet Call (coded) squelch. (See Note 3.)
other radios.  Ensure radio receives on the same frequency as the caller transmits. (See Note 4.)
 echarge the battery. (See Note 1.)
Your calls cannot be heard in  Make sure that your radio transmits on the receive frequency of the radio(s) you
other radios. want to call. (See Note 4.)
 echarge the battery.
BATTERY
Battery loses charge sooner  eview battery charging instructions, page 12.
than expected.  Conserve the battery. (See Note 5.)
 If the radio is used in extreme cold, warm the radio under your coat. (See Note 6.)
 eplace the battery; see FIG-7, page 11. (See Note 1.)
ERROR TONES
An error tone sounds when the  See "Error Tones" on page 4.
radio is first switched on.
An error tone occurs while  efer to "Transmitter Time-Out," page 4.
transmitting.  efer to " echarge Battery Alert," page 4.
QUIET CALL
You cannot screen out calls  Make sure that the channel is programmed with Quiet Call.
from users outside of your Quiet  Activate coded squelch. (See Note 7.)
Call group.
You cannot hear Quiet Call  Confirm that the channel is programmed to detect the same code as the calling
messages while in Quiet Call radio(s) transmits. (See Note 7.)
(coded) squelch.
Others in your Quiet Call group  Verify that you transmit the same code as the radio(s) you call are programmed
cannot hear your Quiet Call to detect. (See Note 7.)
messages.
TROUBLESHOOTING
1.  Try a battery pack from a working radio. If the radio in question works
with that pack, the original battery is suspect.
 Charge the suspect battery as recommended in this manual. If this
original battery cannot power the radio, try charging it again with
another charger. If the battery still doesn't hold a charge, the pack
should probably be replaced.
 If the battery appears to be "good" after using the second charger,
the first charger may be faulty. Contact a dealer or itron about an
accessory that is not operating properly.
2.  eception can often be improved if you relocate by a short
distance. This effect is more noticeable inside buildings.
 The range for SST radios is about two miles, line-of-sight.
. If your radio does not detect calls from other radios on the channel,
turn off Quiet Call by pressing and holding both volume buttons at
the same timea double beep indicates Quiet Call is off.
4.  Without use of a repeater: To hear a call, select a channel
programmed to receive the caller's transmit frequency. To call
another unit, select a channel programmed to transmit the other
radio's receive frequency.
 Using a repeater: A radio channel can hold two separate operating
frequencies, one for receive and one for transmit. Your channel
must work with the repeater's transmit and receive frequencies.
5.  Maximum power drain occurs when the radio transmits, so don't
hold down the PTT more than needed to transmit.
 Battery power is used while the handheld is left on to receive calls. If
practical, switch off the unit.
6.  Battery capacity is greatly reduced in extreme cold.
 To use the radio in very cold weather, periodically warm it under
your coat if possible.
 An optional remote speaker/ microphone allows keeping the radio
under your coat while transmitting and receiving.
7.  To "talk" with each other, radios must be programmed identically for
Quiet Call code, as well as frequency. Each code is unique; radios
respond only to the code programmed.
 Press and hold both volume buttons at the same time.
A single beep indicates Quiet Call squelch is on.
A double beep indicates Quiet Call squelch is off.
page 15
CHART
NOTES

Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
FCC REGULATIONS
LICENSING 
The FCC requires the owners of the radios to obtain a station license before using them.
The station licensee is responsible for ensuring that transmitter power, frequency and deviation are within
the limits specified by the station license. The station licensee is also responsible for proper operation and
maintenance of the radio equipment. This includes checking the transmitter frequency and deviation
periodically, using appropriate methods.
To get a FCC license for VHF or HF frequencies, submit FCC application Form 600 as indicated in the
block at right. Your Ritron dealer can help you with this process.
SAFETY STANDARDS 
The FCC (with its action in General Docket 79-144, March 13, 1985) has adopted a safety standard for
human exposure to radio frequency electromagnetic energy emitted by FCC regulated equipment. Ritron
observes these guidelines and recommends that you do also:
 DO NOT hold the radio so that the antenna is very close to or touching exposed parts of the body,
especially the face or eyes, while transmitting. Keep the radio vertical, four inches away while
talking into the front panel.
 DO NOT press the Push-To-Talk except when you intend to transmit.
 DO NOT operate radio equipment near electrical blasting caps or in an explosive atmosphere.
 DO NOT allow children to play with any radio equipment that contains a transmitting device.
 Repair of Ritron products should be performed only by Ritron authorized personnel.
SERVICE
Federal law prohibits you from making any internal adjustments to the transmitter, and/ or from changing
transmit frequencies unless you are specifically designated by the licensee.
If your radio equipment fails to operate properly, or you wish to have the radio programmed, contact your
authorized dealer or Ritron.
RITRON, INC. Phone: [phone]
Repair Department AX: 317-846-4978
505 West Carmel Drive
Carmel, IN 46032 USA
FCC LICENSE REQUIRED
HOW TO OBTAIN AN FCC RADIO LICENSE
Federal Communications Commission (FCC)
Licensing Information
Because your Ritron radio operates on Private Land Mobile
frequencies, it is subject to the Rules and Regulations of the
FCC, which requires all operators of these frequencies to
obtain a station license before operating their equip ent.
Make application for your FCC license on FCC For s 600 and
159.
To have forms and instructions faxed to you by
the FCC, call the FCC Fax-On-Demand system at
202-418-0177 from your fax machine;
request Document 000600 & Form 1 9.
To have Document 000600 & Form 1 9 mailed to you,
call the FCC Forms Hotline at
800-418-FOR (800-418-3676).
For help with questions concerning the
license application, contact the FCC at
888-CALL-FCC (888-225-5322).
You must decide which radio frequency(ies) you
can operate on before filling out your application;
refer to Table 1 on page 7 of this manual.
For help determining your frequencies, call Ritron at
800-USA-1-USA (800-872-1872).
page 16

page 3 RITRON, INC. 1-800-USA-1-USA (1-800-872-1872)
Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com
505 West Carmel Drive  Carmel, IN 46032
P. O. Box 1998  Carmel, IN 46032
P : 317-846-1201  Fax: [phone]  Email: [email protected]
Website: www.ritron.com
Pub. 14500046 REV. A 09-04
COPYRIGHT© 2003-2004 RITRON, INC.  ALL RIGHTS RESERVED
RITRON, JOBCOM, QUIC ASSIST, and QUIET CALL ARE REGISTERED TRADEMAR S OF RITRON, INC.
WHAT THIS WARRANTY COVERS
RITRON, INC. ("RITRON") provides the following warranty against defects in materials and or workman-
ship in RITRON Radios, Rechargeable Batteries and Accessories under normal use and service during
the applicable warranty period (as stated below). "Accessories" means antennas, holsters, chargers,
earphones, speaker microphones and items contained in the programming and programming service kits.
Rechargeable batteries will be replaced during the applicable warranty period only if leakage occurs or the
batteries drop below 75% of rated capacity.
WHAT IS COVERED FOR HOW LONG WHAT RITRON WILL DO
Portable JMX Display 1 year * During the first year after date of purchase,
Series Radios RITRON will repair or replace the defective
product, at RITRON's option, parts and
labor included at no charge.
RITRON Rechargeable 1 year
* RITRON will replace the defective battery
Batteries
Accessories 90 days
** After date of purchase
WHAT THIS WARRANTY OES NOT COVER:
 Any technical information provided with the covered product or any other RITRON products;
 Installation, maintenance or service of the product, unless this is covered by a separate written
agreement with RITRON;
 Any products not furnished by RITRON which are attached or used with the covered product, or
defects or damage from the use of the covered product with equipment that is not covered (such as
defects or damage from the charging or use of batteries other than with covered product);
 Defects or damage, including broken antennas, resulting from:
- misuse, abuse, improper maintenance, alteration, modification, neglect, accident or act of God,
- the use of covered products other than in normal and customary manner or,
- improper testing or installation;
 Defects or damages from unauthorized disassembly, repair or modification, or where unauthorized
disassembly, repair or modification prevents inspection and testing necessary to validate warranty
claims;
 Defects or damages in which the serial number has been removed, altered or defaced.
 Batteries if any of the seals are not intact.
IMPORTANT: This warranty sets forth the full extent of RITRONs express responsibilities regarding the covered
products, and is given in lieu of all other express warranties. What RITRON has agreed to do above is your sole
and exclusive remedy. No person is authorized to make any other warranty to you on behalf of RITRON.
Warranties implied by state law, such as implied warranties of merchantability and fitness for a particular purpose,
are limited to the duration of this limited warranty as it applies to the covered product. Incidental and
consequential damages are not recoverable under this warranty (this includes loss of use or time, inconvenience,
business interruption, commercial loss, lost profits or savings). Some states do not allow the exclusion or
limitation of incidental or consequential damages, or limitation on how long an implied warranty lasts, so
the above limitations or exclusions may not apply to you. Because each covered product system is unique,
RITRON disclaims liability for range, coverage, or operation of the system as a whole under this warranty.
WHO IS COVERE BY THIS WARRANTY
This warranty is given only to the purchaser or lessee of covered products when acquired for use, not resale. This
warranty is not assignable or transferable.
HOW TO GET WARRANTY SERVICE
To receive warranty service, you MUST deliver or send the defective product, delivery costs and insurance prepaid,
within the applicable warranty period, to RITRON, INC., 505 West Carmel Drive, Carmel, Indiana 46032, Attention:
Warranty Department.
Please point out the nature of the defect in as much detail as you can. You MUST retain your sales or lease receipt
(or other written evidence of the date of purchase) and deliver it along with the product. If RITRON chooses to
repair or replace a defective product, RITRON may replace the product or any part or component with reconditioned
product, parts or components. Replacements are covered for the balance of the original applicable warranty period.
All replaced covered products, parts or components become RITRONs property.
RIGHTS TO SOFTWARE RETAINE
Title and all rights or licenses to patents, copyrights, trademarks and trade secrets in any RITRON software contained
in covered products are and shall remain in RITRON. RITRON nevertheless grants you a limited non-exclusive,
transferable right to use the RITRON software only in conjunction with covered products. No other license or right
to the RITRON software is granted or permitted.
YOUR RIGHTS UN ER STATE LAW
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
WHERE THIS WARRANTY IS VALI
This warranty is valid only within the United States, the District of Columbia and Puerto Rico.
RITRON, INC. LIMITED WARRANTY
