HYT TC-780 User manual

PREFACE
Thank you for your purchase of the HYT TC-780 professional portable radio. This
easy-to-use radio will deliver you secure, instant and reliable co unications at peak
efficiency. Please read this anual carefully before use. The infor ation presented herein
will help you to derive axi u perfor ance fro your radio.
MODELS COVERED IN THIS MANUAL
TC-780 VHF Two-way Radio
TC-780 UHF Two-way Radio

1
Contents
Safety and General Infor ation ........................................................................................... 3
Product Inspection ............................................................................................................... 4
Radio Overview .................................................................................................................... 6
Battery Infor ation ............................................................................................................... 8
Antenna Infor ation ........................................................................................................... 11
Asse bly and Disasse bly ............................................................................................... 12
Attaching the Battery .................................................................................................. 12
Re oving the Battery ................................................................................................. 12
Attaching the Antenna ................................................................................................. 13
Re oving the Antenna ............................................................................................... 13
Attaching the Belt Clip ................................................................................................ 13
Re oving the Belt Clip ............................................................................................... 14
Re oving the Accessory Cover ................................................................................. 14
Attaching the Earpiece/Microphone ........................................................................... 15
LCD Icons .......................................................................................................................... 16
Menu .................................................................................................................................. 17
General Radio Operations ................................................................................................. 20
Selecting a Channel .................................................................................................... 20
Trans itting a Call ...................................................................................................... 20
Receiving a Call .......................................................................................................... 20
Progra able Auxiliary Functions .................................................................................... 20
Advanced Operations ........................................................................................................ 22
Power Adjust ............................................................................................................... 22
Select Squelch Level .................................................................................................. 22
Backlight ..................................................................................................................... 22
Call 1- Call 5 ............................................................................................................... 23
Channel Menu Shortcut .............................................................................................. 23
Voice Co pandor ....................................................................................................... 23
Scan Add/Delete ......................................................................................................... 23
Channel Down ............................................................................................................ 23
Channel Up ................................................................................................................. 23
Display Channel Alias ................................................................................................. 23
Display Channel Frequency ....................................................................................... 24
Switch Display ............................................................................................................ 24
DTMF Keypad ............................................................................................................. 24
Exit E ergency ........................................................................................................... 24
Enable E ergency ..................................................................................................... 24
Disable E ergency Alar .......................................................................................... 24
Enable E ergency Alar ........................................................................................... 24

2
Voice Encryption ......................................................................................................... 24
GPS Report................................................................................................................. 25
Ho e Channel ............................................................................................................ 25
Keypad Lock ............................................................................................................... 25
Lone Worker ............................................................................................................... 25
Man Down ................................................................................................................... 25
Short Message ............................................................................................................ 25
Monitor ........................................................................................................................ 25
Monitor Mo entary ..................................................................................................... 25
Nuisance Channel Te porary Delete ......................................................................... 26
Radio Call ................................................................................................................... 26
Scan ............................................................................................................................ 26
Scra bler .................................................................................................................... 26
Squelch Off ................................................................................................................. 27
Squelch Off Mo entary .............................................................................................. 27
Carrier Squelch Level ................................................................................................. 27
Status List ................................................................................................................... 27
Talk Around ................................................................................................................. 27
Vibrate ......................................................................................................................... 27
Volu e Down .............................................................................................................. 27
Volu e Up .................................................................................................................. 28
VOX (Voice-Operated Trans it) ................................................................................. 28
Whisper ....................................................................................................................... 28
Zone Down .................................................................................................................. 28
Zone Up ...................................................................................................................... 28
Inverted Display .......................................................................................................... 28
Background Operations ..................................................................................................... 28
Selecting a Zone ......................................................................................................... 28
Selecting a Channel .................................................................................................... 28
Sending a Voice Call................................................................................................... 29
Receiving a Voice Call ................................................................................................ 29
Channel Scan ............................................................................................................. 29
E ergency .................................................................................................................. 31
Ti e-out Ti er (TOT) ................................................................................................. 32
Battery Save ............................................................................................................... 32
Troubleshooting ................................................................................................................. 33
Care and Cleaning ............................................................................................................. 33
Optional Accessories ......................................................................................................... 34

3
Safety and General Information
The following general safety precautions as would nor ally apply, should be observed
during all phases of operation, service and repair of this equip ent.
◇ This equip ent should be serviced by qualified technicians only.
◇ Do not odify the radio for any reason.
◇ Use only HYT original batteries and chargers.
◇ Do not use any portable radio that has a da aged antenna. If a da aged
antenna co es into contact with your skin, a inor burn can result.
◇ Turn off your radio prior to entering any area with a potentially explosive
at osphere.
◇ Do not charge your battery in a potentially explosive at osphere.
◇ To avoid electro agnetic interference and/or co patibility conflicts, turn off your
radio in any facility where posted notices instruct you to do so.
◇ When instructed to do so, turn off your radio when on board an aircraft. Any use of
a radio ust be in accordance with airline regulations or crew instructions.
◇ To avoid possible interference with blasting operations, turn off your radio when
you are near electrical blasting caps, in a blasting area, or in areas posted: “Turn
off two-way radio.” Obey all signs and instructions.
◇ For vehicles with an air bag, do not place a radio in the area over an air bag or in
the air bag deploy ent area.
◇ Do not expose the radio to direct sunlight over a long ti e, nor place it close to
heating source.
◇ When trans itting with a portable radio, hold the radio in a vertical position with
the icrophone 3 to 4 centi eters away fro your lips. Keep antenna at least 2.5
centi eters away fro your body when trans itting.
WARNING: If you wear a radio on your body, ensure the radio and its antenna is
at least 2.5 centi eters away fro your body when trans itting.

4
Product Inspection
Please unpack the package box carefully and check that all ite s shipped were received;
report any issing or da aged ite s to your dealer.
Accessories
Item Qty. PCS)
Antenna 1
Belt Clip 1
Leather Strap 1
Li-Ion Battery 1
MCU Rapid-rate Charger 1
Switching Power 1
Owner’s Manual 1
Antenna Li-Ion Battery
(1700 Ah)
MCU Rapid-rate Charger
Switching Power
(100-240V) (for use
with different power
cords in different
countries and areas)
Belt Clip Leather Strap

5
Note: Frequency band is arked on the label of antenna, if not, identify the frequency band according to the
color circle. Please refer to the label on the radio unit for detailed frequency band infor ation.

6
Radio Overview
○
1 PTT (Push-to-Talk) Key
○
2 SK1 (Side Key 1)
○
3 SK2 (Side Key 2)
○
4 Antenna
○
5 Microphone
○
6 Speaker
○
7 LCD Display
○
8 Function Keypad
○
9 Nu eric Keypad
○
10 TK (Top Key)
○
11 Channel Selector
Knob
○
12 Radio On-Off
/Volu e Control Knob
○
13 LED Indicator
○
14 Accessory Jack
○
15 Battery Latch
○
16 Belt Clip
○
17 Battery
○
18 Screw, Belt Clip
○
19 Charging Piece
﹡
﹡﹡
﹡PTT Push-to-Talk) Key
Press and hold down the PTT key to trans it; release it to receive.
﹡
﹡﹡
﹡SK1 Side Key 1)

7
Progra able function key.
﹡
﹡﹡
﹡SK2 Side Key 2)
Progra able function key.
﹡
﹡﹡
﹡LCD Display
Used to display radio status infor ation.
﹡
﹡﹡
﹡Function Keypad
 Exit key
Use the Exit key to return to the previous enu.
 Up key
 Down key
 Menu/Select key
Used to enter the enu ode. When you are in the enu ode, this key is also used to
ake enu selections.
﹡
﹡﹡
﹡Numeric Keypad
Used to enter infor ation for progra ing the radio’s lists.

8
﹡
﹡﹡
﹡TK Top Key)
Progra able function key.
﹡
﹡﹡
﹡Channel Selector Knob
Rotate the knob to select a desired channel.
﹡
﹡﹡
﹡Radio On-Off/Volume Control Knob
Rotate the knob clockwise to turn the radio on, and rotate the knob fully counter-clockwise
until a click is heard to turn the radio off.
Turn the knob clockwise to increase the volu e, or counter-clockwise to decrease the
volu e.
﹡
﹡﹡
﹡LED Indicator
The following table indicates LED ode and corresponding radio status:
Status LED
Trans it Red
Receive Green
Low battery alert Flash red
After trans itting a call (within auto reset ti e)
Orange
After receiving a call (within auto reset ti e) Flash orange slowly
Missed call alert Flash orange rapidly
Scan Flash green
﹡
﹡﹡
﹡Accessory Jack
The jack is used to connect audio accessories, or other accessories such as progra ing
cable.
Battery Information
Initial Use
New batteries are shipped uncharged fro the factory. Charge a new battery for 5 hours
before initial use. The axi u battery capacity and perfor ance is achieved after three
full charge/discharge cycles. If you notice the battery power runs low, please recharge the

9
battery.
Applicable Battery Packs
To reduce the risk of injury, charge only the battery specified by the anufacturer. Other
batteries ay burst, causing bodily injury and da age.
Caution:
1. To avoid risk of personal injury, do not dispose of batteries in a fire!
2. Dispose of batteries according to local regulations (e.g. recycling). Do not dispose as
household waste.
3. Never atte pt to disasse ble the battery.
Battery Tips
1. When charging your battery, keep it at a te perature a ong 5℃-40℃. Te perature
out of the li it ay cause battery leakage or da age.
2. When charging a battery attached to a radio, turn the radio off to ensure a full charge.
3. Do not return a battery to the charger before the battery power runs low. This action
will significantly reduce battery life. Never take the charger as a stand for your radio.
4. Never charge a battery that is wet. Please dry it with soft cloth prior to charge.
5. The battery will eventually wear out. When the operating ti e (talk-ti e and standby
ti e) is noticeably shorter than nor al, it is ti e to buy a new battery.
To Prolong Battery Life
1. Battery perfor ance will be greatly decreased at a te perature below 0℃. A spare
battery is necessary in cold weather. The cold battery unable to work in this situation
ay work under roo te perature, so keep it for later use.
2. The dust on the battery contact ay cause the battery cannot work or charge. Please
use clean dry cloth to wipe it before attaching the battery to the radio.
Battery Storage
1. Fully charge a battery before you store it for a long ti e, to avoid battery da age due
to over-discharge.
2. Recharge a battery after several onths’ storage (Ni-MH & Ni-Cd batteries: 3 onths;
Li-Ion & Li-poly er batteries: 5 onths), to avoid reducing battery capacity due to

10
over-discharge.
3. When storing your battery, keep it in a cool, dry place under roo te perature.
Charging the Battery
Use only the charger specified by the anufacturer. The charger’s LED indicates the
charging progress.
Status Charger LED
Standby (no-load) Red LED flashes slowly (0.2s
on/3s off )
Battery is charging Red LED solidly glows
Battery is fully charged Green LED solidly glows
Error Red LED flashes rapidly (0.2s
on/0.2s off)
Please follow these steps:
1. Plug the power cord into the adapter.
2. Plug the AC connector of the adapter into the AC outlet socket.
3. Plug the DC connector of the adapter into the DC socket on the back of the charger.
4. Place the radio with the battery attached, or the battery alone, in the charger.
5. Make sure the battery is in well contact with the charging ter inals. The charging

11
process initiates when the red LED lights.
6. The greed LED lights about 3 hours later indicating the battery is fully charged. Then
re ove the radio with the battery attached or the battery alone fro the charger.
Troubleshooting MCU intelligent rapid-rate charger only):
When troubleshooting, always observe the color of the LED:
No LED Indication?
1. Make sure that the power cord is plugged into an appropriate AC outlet.
Red LED flashes rapidly 0.2s on/0.2s off)?
1. Re ove the battery fro the charger, and:
a) Make sure that it is a HYT authorized battery. Other batteries ay not charge.
b) Re ove power fro the battery charger, and clean the gold etal, charging
contacts of the battery and charger, using a clean dry cloth.
2. The battery te perature ay be above 45℃.
3. Defective battery. Please replace it with a new one.
4. Power up the charger and place the battery back into the charger pocket. If the LED
indicator continues to flash red, replace the battery.
Note:
When the battery charger detects the proper battery conditions, rapid charging begins
auto atically (steady red LED).
If the battery te perature is above 45℃, the charger will report the fault by flashing
red LED rapidly (0.2s on/0.2s off), and will not charge until the battery te perature is
below 45℃, with red LED solidly glows (Ni-MH battery only).
Antenna Information
1. Stubby antenna is ideal for co unication within li ited range. Thin and long antenna
opti izes co unication coverage, and its flexible and soft characteristic akes it
ideal for wearing your radio on the belt.
2. Co unication range ay vary with terrain and your operating conditions. Rainy
days or forest locations ay narrow your co unication range, please ake

12
preparation in advance to avoid potential inconvenience.
Assembly and Disassembly
Attaching the Battery
1. When attaching the battery, ake sure the battery is in parallel and good contact with
the alu inu chassis. The battery botto is about 1 to 2 centi eters below the
botto of the radio’s body.
2. Align the battery with the guide rails on the alu inu chassis and slide it upwards
until a “click” is heard.
3. The battery latch at the botto locks the battery. See figure 1.
Figure 1
Removing the Battery
1. Turn off the radio before re oving the battery.
2. Slide the battery latch, at the botto of the radio’s body, in the direction indicated by
the arrow.
3. Slide down the battery for about 1 to 2 centi eters, and then re ove the battery fro
the radio’s body. See figure 2.

13
Figure 2
Attaching the Antenna
1. Align the threaded end of the antenna with the radio’s antenna connector.
2. Turn the antenna clockwise to fasten it. See figure 3
Removing the Antenna
Turn the antenna counter-clockwise until you can re ove it. See figure 3
Figure 3
Attaching the Belt Clip
1. Re ove the screws (belt clip) on the radio’s body.
2. Align the screw holes on the etal holder of belt clip with those on the radio’s body.
3. Tighten the screws. See figure 4.

14
Figure 4
Removing the Belt Clip
1. Re ove the screws (belt clip).
2. Re ove the belt clip. See figure 5.
Figure 5
Removing the Accessory Cover
1. Unscrew the screw on the accessory cover counter-clockwise with a flat head
screwdriver.
2. Re ove the accessory cover. See figure 6.
Figure 6

15
Attaching the Earpiece/Microphone
1. Insert the tab at the botto of the earphone/ icrophone into the slot on the radio.
2. Align the screw at the top of the earphone/ icrophone with the threaded hole on the
radio.
3. Rotate the screw clockwise to fasten. See Figure 7.
Figure 7
Note: The figures above are only for references. Please ake the object as the
standard.

16
LCD Icons
The LCD displays 17 status icons in all and 8 characters at ost si ultaneously, each
with fixed display position. The display priority is fro high to low, as fro the top row to
the botto row in the table. When a high priority status appears, the icon for the low
priority status will not be displayed until the high priority status disappears.
At the
left ost side
of LCD
… … … … … … At the
right ost
side of LCD
High
Priority
…
…
Low
Priority
Icons & Indications
Icon Indication
Signal Strength Indicator
DTMF Keypad Indicator
Short Message Indicator
Scan Indicator
Priority Scan Indicator
Monitor and Squelch Open Indicator
Trans it Power Indicator
Keypad Lock Indicator
E ergency Indicator
Talk Around Indicator
Accessory Jack Indicator
Scra bler Indicator
Vibrate Indicator
Co pandor Indicator

17
Ho e Channel Indicator
Trans it Inhibit Indicator
Battery Strength Indicator
Menu
Menu Navigation Chart:
Key Function
Select
C
Exit
/ Used to switch a ong function options.

18
Keypad Keys
Key Function
Menu/Select key. Press the Menu/Select key to go to the next enu, or ake
selections.
C
Exit key. Use the Exit key to cancel or return to the previous enu.
Left key. Press the Left key under an input interface to delete an entry. This key
can also be progra ed as a progra able function key.
Right key. Press the Right key under an input interface to ove the cursor right.
This key can also be progra ed as a progra able function key.
Up key. Press the Up key to scroll through enus when in Menu Mode.
Down key. Press the Down key to scroll through enus when in Menu Mode.
This key can also be progra ed as a progra able function key.
0-9 Used to enter nu bers or characters.
Used to enter nu bers or characters.
#
Used to enter nu bers or characters. Press
#
and to lock the keypad.
Menu Display
Top Menu
(as the LCD
shows)
Sub-Menu
(as the LCD shows)
Description of Sub-Menu
Radio Call
Call List Type: HDC2400 Select call list type.
Select HDC2400 call list.
Call List Type: HDC1200 Select HDC1200 call list.
Call List Type: DTMF Select DTMF call list.
Call List Type: 2-Tone Select 2-Tone call list.
Message/Status
Short Message Select the Short Message feature.
Status Message Select the Status Message feature.

19
Syste Scan Syste Scan Enable Select whether to enable the Scan feature.
Audio/Tone
Button Beep (On/Off) On/Off
Voice Co pandor (On/Off) On/Off
Alert (On/Off) On/Off
Talk Around
On Enable the Talk Around feature.
Off Disable the Talk Around feature.
Utilities
Squelch Level Available options are: Off/Loose/Tight
Radio Lock Enable/disable password protection.
Radio Infor ation Version and serial nu ber of the radio.
Backlight Enable/disable the backlight.
Vibrate Enable/disable the Vibrate feature.
Trans it Power Select the trans it power level fro High,
Mediu , Low.
Scra bler Enable/disable the Scra bler feature on the
current channel.
Zone Zone (1/n) Select the current zone.
Progra List Call List Edit the alias and alert tone correlative with
a Call List.
Scan List Add, delete or edit priority channel for a
Scan List.
Optional
Function
GPS Device Display GPS Infor ation
Patrol Device Control patrol record
Encryption Device On/Off
