RND 365-00007 User manual

PC AND MULTIMEDIA CABLE TESTER
RND 365-00007
Amplier Probe
FEATURES
• The amplier Probe is designed to identify and trace wires or cables within a
group without damaging the insulation
• Works with any Tone Generator to identify wires.
• Volume control for increased sensitivity and adjustable to suit work
environment.
• Recessed ON/OFF buon prevents baery drain
• Power supply is in any 9V baery with a life of approximately 100 hours
• A plug receptacle is provided for head set or head phone
-1-
3-position
toggle switch
Phone jack
Tone Generator
3-colored LED
Red and black
test leads
4conductor
modular cord
and plug
Tip
Amplier Probe
Volume control
Test buon
Speaker

TONE GENERATOR
INSTRUCTIONS:
1. Connecting the Tone generator.
In terminated working cables:
Connect one test lead to a terminated wire and other test lead to earth or
equipment ground.
In unterminated or non-working cables:
Connect one test lead to a terminated wire and other test lead to earth or
equipment ground.
2. Depress the round on/o spring-loaded buon of the amplier probe. The
volume control switch can be adjusted to suit the environment. Volume can be
increased to overcome noise, or decreased to reduce interference.
3. Touch the tip of the amplier probe to the insulation of each suspect conductor.
4. Reception of tone will be loudest on the subject wire.
5. The plug receptacle is provided for connecting to a head set or hand set.
MAINTENANCE:
The Amplier Probe is maintenance free except for baery replacement.
Remove the screw from the baery compartment, replace the 9V baery
and reassemble.
Warranty limited solely to repair or replacement; no warranty of
merchantability, tness for a particular purpose or consequential damages.
FEATURES:
• Red or black test leads are provided, and has a standard 4 conductor modular
cord and plug.
• A 3-position toggle switch controls the modes of operation plus 3-colored LED
Light Emiing Diode is provided for line polarity, continuity and voltage testing.
• A tone selector switch, located inside the test set is provided for choosing either
a single solid tone or dual alterating tone.
(CAUTION: DO NOT CONNECT TO AN ACTIVE AC CIRCUIT EXCEEDING
24V IN THIS MODE.)
-2-

INSTRUCTIONS:
• IDENTIFYING TIP & RING (SWITCH TO “OFF”):
1. Connect the RED test lead to the side of the one line and the BLACK lead to the
side of the another line.
2. The LED will glow “GREEN” when you connect the RED test lead to the RING
SIDE of the line.
3. The LED will glow “RED” when you connect the RED test lead to the TIP SIDE of
the line.
• IDENTIFYING LINE CONDITION (SWTICH TO “OFF):
1. Connect the RED test lead to the RING SIDE of the line and the BLACK to
the TIP.
2. Watch the LED:
1) A BRIGHT “GREEN” LED indicates a CLEAR line.
2) NO lamp indicates a BUSY line.
3) A BRIGHTLY FLICKERING “YELLOW” lamp indicates a RINGING line.
• VERIFYING LINES ( SWITCH TO “OFF” THEN “CONT” ):
1. Dial the line to be veried.
2. While the line is ringing, connect the RED lead to the RING SIDE of the line and
the BLACK to the TIP.
3. In the “o” position, the indicator lamp will icker “YELLOW” when the test
leads are connected to the subject pair
4. If you switch the test set to “CONT”, it will terminate the call on the subject line.
• SENDING TONE (SWTICH TO “TONE”):
(CAUTION: DO NOT CONNECT TO AN ACTIVE AC CIRCUIT EXCEEDING 24V
IN THIS MODE.)
1. Connect the test leads to the pair, or aach one lead to the ground and one
lead to either side of the line.
2. A dual alternating tone, or single solid tone can be selected from the switch
inside the tone generator.
3. Probe the suspected wires with the amplier probe. Reception of tone will be
strongest on the subject wire. In cases of ready access to bare conductor,
a handset may be used to receive the tone.
• TESTING CONTINUITY (SWITCHING TO “CONT”):
(CAUTION: DO NOT CONNECT TO AN ACTIVE AC CIRCUIT EXCEEDING 24V
IN THIS MODE.)
1. Connect the test leads to the subject pair.
2. Use “CONT” position.
3. A bright “GREEN” light indicates continuity. The LED will not glow if the
line resistance exceeds 10000 Ω
-3-

• TESTING CONTINUITY USING TONE (SWITCH TO “TONE”):
(CAUTION: DO NOT CONNECT TO AN ACTIVE AC CIRCUIT EXCEEDING 24V
IN THIS MODE.)
1. Connect the test leads to the subject pair.
2. Use a handset or headset at the remote end and touch the wire end(s) with the
clip leads(s)
3. Reception of tone is an indication of continuity
• MODULAR TESTING:
1. All above tests are available through the modular plug for line 1 only - red and
green wires.
• COAX TESTING:
1. To test unterminated coax, connect red to outer shield and black to center
conductor or red to outer shield and black to ground.
2. To test terminated coax, connect red to connector housing and black to center
pin or red to connector housing and black to ground.
• MAINTENANCE
BATTERY REPLACEMENT INSTRUCTIONS:
1. Seperate the case, install a fresh 9V baery and reassemble.
DO NOT OVERTIGHTEN.
2. Warranty limited solely to repair or replacement; no warranty of
merchantability, tness for a particular purpose or consequential
damages.
-4-
