Road Mate L-640 User manual
1
Key Features
®
User’s Manual Model: L-640
©2011 All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Road Mate DVR.
Road Mate DVR makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No
liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
Features and specifications are subject to change without notice.
All other products and brand names are trademarks of their respective holders. No part of this user manual may be reproduced or
transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose other
than the purchaser's personal use. Revised :01-01-2015
2
Table of Contents
1. BEFORE USING YOUR DRIVING RECORDER 3
2. TECHNICAL SPECIFICATIONS AND FUNCTIONS 5
Specifications & Functions 5
3. IMPORTANT SAFETY WARNINGS 6
4. QUICK START GUIDE 9
5. CONFIGURATION 11
Introducing Your Driving Recorder 11
Operations 12
Install the battery 12
Power on 12
Auto Recording 12
Manual Recording 12
Pause Recording 12
Switch Mode & Display the Menu 12
Power off 13
Adjust your view angle 13
Screen Display Status 13
Accessing the setting Menu 14
Accessing Video Mode Settings & Configurations 14
Video Mode Settings 14
Video Size 15
Date Stamp 15
Video Length 15
Motion detection 16
Loop Rec 16
Loop time 16
Continue 16
Video Sound 16
System Settings 17
Sounds 17
Power Frequency 17
Power Save 17
Panel Protect 18
Date & Time 18
Language 18
TV Out 18
Start-up Image 19
Format 19
IR LED 19
Reset All 19
Accessing the Photo Settings 20
Resolution 20
Quality 20
Exposure 20
Timer 20
Date Stamp 21
Playback Settings 21
Lock file(s) 21
Delete file(s) 21
7. ACCESSING RECORDED VIDEOS 22
Connecting Diagram 22
Accessing files via connecting USB port to a computer 23
Accessing files via Inset SDHC card to computer card reader 23
Viewing the video on (Non-HD) TV set 24
8. HOW TO REGISTER MY PRODUCT 25
9. ONE YEAR CONSUMBER LIMITED WARRANTY 27
10. TROUBLESHOOTING AND FAQs 30
3
Thank you for purchasing Road Mate DVR driving recorder. This user manual provides you with
information to get started. Please read carefully and follow the instructions to connect and set up your
new driving recorder. You may review the troubleshooting FAQs on last page.
Package Contents
Please check the following items have been included with your package.
Product Photo
Description
Qty.
Road Mate DVR, L-640 Driving Recorder
1
USB Cable
1
USB Car Charger
1
Windshield Suction Mount
1
1. BEFORE USING YOUR DRIVING RECORDER
4
Memory Cards Supported
This package does not ship with a SDHC memory card; you need to purchase one for this device.
This device is compatible with Class 6 or 10 SDHC memory card. A 32GB SDHC, class 10, 80MB/s
memory card is recommended to use for this driving recorder. If an accident was occurred, please
lock your SDHC memory card immediately, then remove your SDHC memory card and keep it safe
with you for future evidence.
This device supports up to 32GB SDHC Memory Card, Class 6 or Class 10 (See below
sample images for your reference)
Make sure your SDHC memory card’s write protect switch is set upward to enable writing/erasing.
Make sure a SDHC card is inserted before recording video. DO NOT remove your SDHC
memory card during recording video.
Handling Cautions
1. This device is a precision instrument. DO NOT drop it or subject it to physical shock.
2. This device is not waterproof and cannot be used underwater. If this device gets wet, wipe off
any water droplets with a dry cloth, and promptly consult Road Mate DVR customer service
3. DO NOT leave this device in places prone to excessive heat on a sunny day. Excessive heat
can cause this device to malfunction. The working temperature range is 14°F~158°F (-10°C~
70°C).
4. This device contains precision electronic circuitry. Never attempt to disassemble the device.
5. Use only a blower brush to blow away dust or lens cleaner to clean the lens.
5
This cost-effective driving recorder saves your money by preventing false claims to you. It’s a
compact, face-forward digital recording system, records video/audio in case of any accidents or
incidents that may have taken place and preventing false or fraudulent claims. This compact,
lightweight driving recorder is fitted to your vehicle windshield in order to record forward view during
your journey.
This device is designed to record video and audio simultaneously when you drive on the road; it also
can be used as a portable DV, camera, and web cam. The key features are as following:
Specifications
120° wide angle lens.
6 night vision IR LEDs
2.5”TFT full color screen.
270° whirl display angle.
Built-in speaker & microphone.
Fixed focus, 50cm ~ infinity lens.
¼” Full color CMOS WXGA HD sensor
Modes: video/recorder/camera/webcam
Built-in 500 mAh Li-ion rechargeable battery.
Support SD/SDHC memory card up to 32 GB (SDHC card excluded from the package)
Recording resolution: 280 X 720 (Interpolation), 720 X 480 (D1), 640 X 480 @ 30 fps.
File format: FAT32; Video Format: AVI; Still Image Storage Format: JPEG
USB 2.0 connectivity: USB port connect to PC; AV out connect to TV.
Package weight: 434g; Product size (folded): 106 X 62 X 33 mm
Operating temperature range is 14°F ~ 158°F (-10°C ~70°C)
Power supplied by car charger or USB port (Input: DC 12V~24V, Output: DC 5V, 1 Amp)
Functions
Motion detection for anti-theft.
Adjustable recording time slice
Loop recording video and audio.
Real-time date/time stamp on video
11 international languages user interface.
Supports Real Time & Date stamp on video.
Auto power on/off, when car engine ignites and turns off.
2. TECHNICAL SPECIFICATIONS AND FUNCTIONS
6
IMPORTANT SAFETY WARNINGS
This device is an advanced portable vehicle digital video recorder (also known as driving recorder,
car DVR, dash cam, or car cam etc), it is designed to record video and audio when you are driving on
the road. When you are using the Road Mate DVR driving recorder, the safety rules must be followed
to prevent accidents that may result in injury to yourself or others.
1. Please check the applicable regulations in your state regarding device mounting on windshield;
some states prohibit the mounting of any items on your windshield. This driving recorder is not
a life saving device, you may use recorded video/audio files to provide evidence in the event of
an incident or accident. Please consult your legal counselor if you involved in an accident.
2. It is your responsibility to comply with traffic laws and to use or mount the Road Mate DVR in
such a manner that is compliance with applicable laws.
3. When installing this device on your vehicle windshield, make sure it is secure and does not
obstruct the driver’s visibility of the road. It is your responsibility as the vehicle operator to
securely place the device that will not interfere and prevent the operations of the vehicle’s
safety devices (such as air bags) in your vehicle. Do not place or mount this device unsecured
and in a place where the driver or passengers may receive injury during vehicle operation or
collision. For your safety, take care to route all cables away from shifters, pedals, accessory
controls and other control mechanisms.
4. Keep your eyes on the road; the vehicle’s operator should not be distracted by the driving
recorder device or software while driving and always be fully aware of all driving conditions.
Minimize the amount of time spent viewing the device screen while driving. Do not change
settings or access any functions requiring prolonged use of the device controls while driving.
Should there be a distraction with the ability to drive responsibly, please pull over in a safe and
legal manner before attempting such operations.
5. The windshield mount may not stay attached to the windshield in all circumstances. Do not
place the mount where it will become a distraction, if the mount should become detached.
Keep your windshield clean to help ensure that the mount stays on the windshield.
6. Keep the Road Mate DVR driving recorder safe from extreme temperature conditions; for
example, do not leave this device exposed to direct sunlight for an extended period of time.
The operating temperature range of this device is 14°F ~ 158°F (-10°C~70°C). This device is
not designed for outdoor use; do not place this device in wet and dusty environment in order to
avoid the lens and other components to be dusty and affect the camera effects.
7. Do not use harsh chemicals, cleaning solvents or cleaning agents to clean the device. Please
use a slightly damp soft cloth to clean the device.
8. Do not use any batteries, power sources, and accessories not come with the original package.
Do not use any home-made or modified batteries.
9. Do not short-circuit, disassemble, or modify this device or battery pack.
10.Do not leave any cords near a heat source. It can deform the cord or melt the insulation and
cause a fire or electrical shock.
11.A tinted windshield will cause video clarity or color distortion.
3. IMPORTANT SAFETY WARNINGS
7
Operating Temperature
This device operating temperature range is 14°F ~ 158°F (-10°C ~70°C). Temperatures
below or over the operating temperature may cause damage. The limited factory warranty
will be voided, if your device is subjected to temperatures outside the operating
temperature range.
Battery Warnings
If below guidelines are not followed, the internal lithium-ion battery may experience a
shortened life span or may present a risk of damage to this device, fire, chemical burn,
electrolyte leak, and/or injury.
The battery in the Road Mate DVR driving recorder is rechargeable and should not be
removed or replace with other specifications. In the event that it should need to be replaced,
Do not leave this device exposed to a heat source or in a high temperature location, such
as in the sun in an unattended vehicle. To prevent damage, remove the device from the
vehicle or store it out of direct sunlight.
Do not puncture or incinerate the device or battery.
Do not operate this device outside of the following temperature range from 14°F ~ 158°F
(-10°C ~70°C). When storing the device for an extended time, store within the following
temperature range: from 32°F to 77°F (0°C~25°C).
If using an external battery charger, only use the Road Mate DVR accessory approved for
your product.
Only replace the battery with the correct replacement battery. Using another battery
presents a risk of fire or explosion. Do not remove or attempt to remove the non-user-
replaceable battery. To purchase a replacement battery, see your Road Mate DVR dealer
or the Road Mate DVR web site.
Insert SDHC Memory Card
Open memory cap to insert your SDHC memory card.
8
Charging your Road Mate DVR driving recorder
Please use the USB cable or the car charger comes with the package to charge your Road
Mate DVR driving recorder. Use another type of AC adapter or car charger can result in
malfunction and/or possible fire hazard due to battery overheating.
Only use the car charger approved for supplied with your Road Mate DVR driving recorder.
Use of another type of car charger will result in fire or electric shock.
For safety reasons, the battery in your Road Mate DVR driving recorder will stop charging
when the ambient temperature is less than 32 °F (0° C) or more than 158°F (70° C).
To obtain a full battery charge, it is recommended that you charge the battery initially for at
least 2 hours. Estimated usage of the Road Mate DVR driving recorder on battery power is
approximately 90 minutes.
When connecting to and using a household power outlet, use only AC/DC Adapter (rated
input: 100~240V AC, 50/60 Hz, rated output: 5V, 1A DC). Using anything else can cause
fire, overheating, or electrical shock.
9
3 easy steps
Installation of the Road Mate DVR is very easy and simple. Please read the safety guidelines
described above carefully.
Install suction mount
Find a safe location on the interior of vehicle’s windshield to mount the pedestal.
Use windows cleaner or alcohol pad to clean up internal windshield surface that has been
selected for mounting the Road Mate DVR driving recorder. Let the area dry completely before
you mount the pedestal.
Firmly push the suction base against the windshield and flip the base lever down to the locked
position. Adjust the angle of the pedestal arm by tightening the angle adjustment knob to the
desired angle. Be sure it will not interfere with your view of the road.
4. QUICK START GUIDE
10
For your safety, avoid routing the cable from shifters, pedals, accessory controls, and
DO NOT place the suction mount near to airbags deployment zone or where it will obstruct
view of the road.
Route the car charger cable and connecting power.
Plug the car charger into your vehicle power receptacle (cigarette lighter socket), and connect
the USB connector to the driving recorder USB port. Route the car charger power cord along
the windshield edge. Be sure to stay away from the side air bags shifters, pedals, accessory
controls and other control mechanisms.
Note: If the car charger power-on indicator is ON, it means the power is being supplied to the
driving recorder. Otherwise, check the cable connection to the vehicle power receptacle. If the
power-on indicator remains OFF, please turn your vehicle to ignition position.
Starts car engine and get recording.
Start your car engine, the Road Mate DVR driving recorder will automatically turn on by itself.
Note: Some of vehicles apply power to the power receptacle only when the ignition is ON. If your
cigarette lighter socket is always powered on, the Auto power on/off feature will not function.
Safety Precautions
Follow all safety guidelines for operating your device. Failure to practice safe usage of this
device while driving may result in damage, injury, or death. Road Mate DVR is not responsible
for any damages caused to your car, your device, or yourself due to the installation or use of
this pedestal mount.
11
Introducing Your Car DVR
MENU: Indicates a function which can be changed by pressing the button and changing the
settings.
DOWN: Indicates the navigation down button, by pressing the button.
UP: Indicates the navigation up button, by pressing the button.
MODE: Indicates a mode which can be changed by pressing the button and changing the
mode.
POWER: indicates power on, by pressing the button.
OK: indicates start/stop recording and to confirm an action by pressing the button.
5. CONFIGURATION
12
Operations
■Power on
Auto Power on
While ignition your car engine, the car DVR will automatically power on.
Manual Power on
Press power button , if your vehicle cigarette receptacle always powered on.
Note: The auto power on/off feature will not work, if cigarette receptacle always powered on.
■ Auto Recording
Once the car DVR is powered on, it will automatically start recording.
■ Manual Recording
For manual recording, press the button to start/stop recording.
■ Pause Recording
While recording video, you may press button to pause recording.
■ Switch Mode & Display the Menu
■Mode: press button to select mode below.
Video mode
Camera mode
Voice recorder mode
Playback mode
■MENU: Once a mode is selected, press button to settings.
13
■Power off
1. Shut down your car engine will automatically power off the car DVR or press the [POWER]
button to power off.
■ Adjust your screen view angle
The screen can be whirled 270°, you may adjust the screen to have better view angle.
Screen Display Status
14
Accessing the Setting Menu
Press the button to display the Menu.
*. While video is recording, press button to pause, then press button to access Menu.
Accessing Video Mode Settings & Configurations
1. Under video mode ( ), press the button to access setup interface. use the navigation
buttons and to select desired selection then press the button to confirm.
2. Press button to switch “Video Settings” or “Configuration” .
Video Mode Settings
15
■Video Size: Allows you to choose between the different video resolutions including:
[HD] 1280 X 720 (Interpolation)
[D1] 720 X 480
[640] 640 X 480
1. To change video resolution, select Video Size, then press navigation button
or to select, and press to confirm selection
2. Press back to main menu.
■ Date Stamp: Allows you to add a watermark on video file with date and time.
1. Press or button to select Date Stamp then press button.
2. Press or button to select “Off”, “Date”, “D&T
3. Press to confirm. Press back to main menu.
■ Motion Detection: Allows the car DVR automatically recording when it detects movement.
1. To enable or disable motion detection feature, press or button to select
Motion detect, and then press button.
2. Press or button to select “On” or “Off”
3. Press to confirm. Press back to main menu.
■ Loop Rec: Allows you to set the loop recording ON or OFF.
1. To enable or disable video loop recording feature, press or button to select
Loop Rec, and then press button.
2. Press or button to select “On” or “Off.”
3. Press to confirm. Press back to main menu.
16
■ Loop Time: Set the interval of recording video, from 2, 5, 10 to 15 minutes segment.
4. To set the length of video file segment, press or button to select Loop
Time, and then press button.
5. Press or button to select “2 Min.”, “5 Min.”, “10 Min.”,”15 Min”
6. Press to confirm. Press back to main menu.
■ Continue: Allows you to set the delay shutdown time after power is off.
1. Press or button to select Continue, then press .
2. Press or button to select “Off”, “10 Min.”, “20 Min.”
3. Press to confirm. Press back to main menu.
■ Video Sound: Allows the ability to turn on or off the microphone, while recording video.
1. To enable or disable audio while video is recording. Press or button to
select Audio, and then press button.
2. Press or button to select “On” or “Off”.
3. Press to confirm. Press back to main menu.
17
System Settings
■ Sounds: To change the chime of power on and power off.
1. Press button to select Sounds, and then press button.
Press to select Shutter “On”, “Off”.
Press to select Start-up chime “1”,”2”,”3”.or “None”
Press to select Beep “On” or ”Off”
Press to select Volume level “0”, “1”, “2”, or “3”. 0 is salient.
2. Press to confirm. Press back to main menu.
■ Power Frequency: To set the frequency of your player system.
1. Press or button to select Frequency, and then press button.
2. Press or button to select “50Hz” or “60Hz”.
3. Press to confirm. Press back to main menu.
■ Power save: To set the duration of time that this device screen remains idle.
1. To set the system idle time. Press or button to select Power save then
press .
2. Press or button to select “1 Min.”, “3 Min.”, “5 Min.” or “Off”..
3. Press to confirm. Press back to main menu.
■ Panel Protect: Allows you to set the screen shut off after X time is displayed.
1. To set the screen shutoff time. Press or button to select Panel Protect then
press button.
18
2. Press or button to select “30 Sec.”, “1 Min.”, “2 Min.”, or “Off”.
3. Press to confirm. Press back to main menu.
*. While the Screen shut off feature is in effect, press or to
display the screen.
■ Date & Time: Allows you to set the current date and time.
1. Press or button to select Date & Time, and then press .
2. Press 6 times, to MM/DD/YYY then press or to select your Date
format type. Press after you select your Date format.
3. Press or button to set Month, Date, Year, Hour, Minute, and Second.
Press MODE for each section.
4. Press to confirm. Press back to main menu.
■ Language: Allows you to select the desired language.
1. Press or button to select Language, and then press button.
2. Press or button to select your language.
3. Press to confirm. Press back to main menu.
■ TV Out: To select your video system.
1. Press or button to select TV Out, and then press .
2. Press or button to select “NTSC” or “PAL”.
3. Press to confirm. Press back to main menu.
19
■ Start-up Image
1. Press or button to select Start-up Image, and then press .
2. Press or button to select “Off” or “System”.
3. Press to confirm. Press back to main menu.
■ Format: Allows you completely erase all data from your SDHC memory card.
1. To format your SDHC memory card. Press or button to select Format
your SDHC memory card, and then press .
2. Press or button to select “Yes” or “No”.
3. Press to confirm. Press back to main menu.
4.
■ IR LED: Allows you to set infrared LED to night vision.
1. To enable or disable IR LED. Press or button to select IR LED (Infrared
LED) on or off, and then press .
2. Press or button to select “On” or “Off”.
3. Press to confirm, press back to main menu.
■ Reset All: Allows you to restore this device back to original factory settings.
1. To reset settings back to factory default, press or button to select Reset
All, and then press button.
2. Press or button to select “Yes” or “No”.
3. Press to confirm. Press back to main menu.
20
Accessing Photo Mode Settings & Configurations
Photo Mode Settings
■ Resolution: Allows you to choose between the different photo resolutions including:
5M 2592 X 1944
3M 2048 X 1536
2M 1600 X 1200
1M 1024 X 768
1. To change photo resolution, select Resolution on screen.
2. Press to select, press back to main menu.
■ Quality: Allows you to set image recording quality.
Super Fine
Fine
Normal
1. Press or button to select.
2. Press to confirm. Press back to main menu.
■ Exposure
■ Driver Mode (Timer): To set the respective function remains in effect.
Off
Self-timer 2 Sec.
Self-timer 10 Sec.
Burst (Allows you to shoot up to about 3~4 shots per sec.)
Table of contents
Other Road Mate DVR manuals
