Roaprobe E0397WST4H4PR User manual
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in
test or images and any necessary changes made to technical data.
Things to consider:
1. The other wireless equipment with the same frequency band can
reduce the transmission range.
2. The range of all wireless equipment depends on the type of obstacles
located between the transmitter and the receiver (e.g. a concrete wall will
interfere with the signal much more than a plasterboard wall).
CONTENTS
English----------------------------------------------------------------- 03 ~ 12
Package Contents
English
1 x Digital Weather Station 3 x Remote Sensor
1 x User Manual 1 x DC Adaptor
1
INITIALIZATION
POWER SUPPLY
MAIN UNIT INSTALLATION
1. Remove the battery compartment cover.
2. Insert 3 x AA batteries matching the correct polarity (+and-)
(Not included).
3. Connect the adaptor with power.
SENSOR INSTALLATION
1. Remove the battery compartment cover, according to the number
marked on the surface of the sensor, dial to the corresponding
channel.
2. Insert 2 x AA batteries matching the correct polarity (+ and -)
(Not included), the red led light will flash for once, then assemble
the battery compartment.
3. Put the sensor to the position you desire.
1. Install batteries for main unit first, then install batteries for
Remote sensor immediately with same channel.
2. After power-on, the LCD will display for 3 seconds, and at the
same time it will start to detect the indoor temperature and humidity,
then the air pressure value, and then start to receive RF signals for
3 minutes, and finally enter the RCC reception.
3. If you want to get a better look , please tear off the transparent
protective film of the host.
2
OVERVIEW
MAIN UNIT
3 4 5 11
16
27
12
8910
1. Indoor temperature and humidity
2. Max/min record of indoor temperature and humidity
3. Weather forecast
Weather forecast for next 12-24 hours
4. Barometric pressure
Barometer display in mmHg, inHg or hPa/mb
5.Moon phase
6.Temperature and humidity of channel1/2/3
7.Max/min record of channel 1/2/3
8.Current time
12/24 hour format selectable
9.Calendar display
Weekdays in 7 languages
10.Automatic backlight
11. Barometric trend
12.DC hole
3
FEATURES
OUTDOOR SENSOR
12
4
3
1. Signal light 2. Hanging hole
3. Battery compartment 4. Channel 1-2-3 switch
• Clear color LCD display
• WWVB atomic time
• Weather forecast for next 12-24 hours with barometer
• Measures in/out humidity and temperature (℉/℃)
• Four groups of temperature & humidity data
• Max/min record of temperature & humidity
• Indoor temperature range: 14℉~ 122℉(-10℃~ 50.0℃)
• Outdoor temperature range: -40℉~140℉(-40℃~ 60℃)
• In/outdoor humidity range: 1%-99%
• Calendar, alarm and snooze function
• Time display in 12/24H
• Auto backlight function
4
RF SIGNAL RECEIVING
RCC SIGNAL RECEIVING
BAROMETER CALIBRATION
1. After power on, the pressure reading will be flashing for 10 seconds.
If there is no need for calibration, touch 【SNOOZE/ LIGHT 】button to
exit setting. If calibration is required, you can press 【+】or【-】button
to adjust data; press and hold 【+】or 【-】button will quickly change
the value by 8 steps.
2. If no operation within 10 seconds, it will automatically save and exit
setting.
3. Barometer range: 23.62-32.75inHg (600-832mmHg,850-1050hPa/mb ).
After barometer setting, It will start receiving 3 outdoor sensors’ signal for
3 minutes. If all 3 channels signal received within 3 minutes or receiving
window ends, it will enter into RCC signal receiving window.
1. After RF signal receiving, it will start searching radio signal for 7
minutes with the antenna symbol displaying on screen.
2. Once signal received, the main unit will display the received time/
month/date/weekday.
3. Daily RCC signal receiving: there are regular radio signal receiving at
UTC 7:00, 8:00, 9:00, 10:00, 11:00 each day. It starts receiving signal at
7:00 everyday. For each day, once signal received at any one receiving
time, it will stop receiving signal that day.
5
FUNTIONS SETTING MODE
4. Manual receiving: press and hold 【+】button to enter RCC signal
receiving.
5. During receiving, press and hold 【+】button to exit RCC receiving.
*RCC symbol display:
1. When receiving signal , RCC icon will be flashing .
2. When signal successfully received, LCD will display complete RCC
icon and exit RCC receiving.
3. If no signal is received, the RCC icon will disappear.
1. Press and hold【SET】button to enter the SETTING MODE, once in
SETTING MODE the preference you are currently setting will blink on
the screen.
（During setting, only the setting figure will display, other parts will be
invisible.）
2. Adjust the currently flashing item, press【+】or【-】buttons (press
and hold to fast adjust).
3. Save your adjustments, press and release the【SET】button to adjust
the next preference. (The setting will be automatically save and exitif
there is no operation within 10 seconds.)
4. When the adapter is powered by, Press and hold【SNOOZE/LIGHT】
button to turn on/off the automatic backlight function.
The preference set order is as follows:
LANGUAGE SELECTION
KEY TONE ON/OFF
AUTO DIM TIME SETTING
6
ALARM CLOCK SETTING
RCC ON/OFF
DST
TIME ZONE SELECTION
CALENDAR YEAR
CALENDAR DATE FORMAT (MONTH-DAY or DAY-MONTH)
CALENDAR MONTH
CALENDAR DATE
TIME FORMAT 12/24H
CLOCK HOUR
CLOCK MINUTE
AIR PRESSURE UNIT SELECTION
WEATHER PATTERN
Exit
1. In standard mode, single press【ALARM】key to view the set alarm
time. (It will return to normal time display mode if no operation in 5
seconds. )Then press 【ALARM】button to turn ON/OFF the alarm.
If the alarm is on, The alarm clock icon will be to the right of the minute.
If the alarm is off, the alarm icon will disappear.
2. Press and hold 【ALARM 】button to enter ALARM CLOCK MODE.
Once in ALARM CLOCK MODE the preference you are currentlysetting
will blink on the screen.
3. Adjust the currently flashing item, press【+】or【-】buttons
(press and hold to fast adjust).
4. Save your adjustments, press and release the【ALARM】button to
adjust the next preference. (The setting will be automatically save and
exit if there is no operation within 10 seconds.)
7
ADJUSTABLE BACKLIGHT
SNOOZE SETTING
1. The alarm sound will last for 2 minutes then be canceled automatically.
It will make sound as follow:
0-10 seconds: Beep per second
11-20 seconds: Beep x 2 per second
21-30 seconds: Beep x 4 per second
31-120 seconds: Keep BI sound
2. When the alarm is ringing, press any other button except
【SNOOZE/ LIGHT 】button to stop the alarm. And the alarm will restart
next day.
3. Or when alarm is ringing, press【SNOOZE/ LIGHT 】button to activate
snooze function. The alarm will ring again in 5 minutes snooze interval.
And the “ ” symbol will be flashing on screen to indicate the snooze
mode. Press any other button except 【SNOOZE/ LIGHT 】button to
exit the snooze mode. And the alarm will restart next day.
1. When the base station powered with batteries only,press
【SNOOZE/ LIGHT 】for 1 second，momentarily light up the screen
for 20 seconds.
2. When powered by adapter,press【SNOOZE/LIGHT】to adjust the
brightness BRIGHT-DIM-OFF.
8
MAX AND MIN RECORD
LOW BATTERY INDICATORS
RF- RE-REGISTRATION
Press and hold the【CH】button to clear all sensors data and start
receiving signal again.
1. Press 【MEM】button to check maximum temperature and humidity,
the value will display for 5 seconds.
2. Press 【MEM】button second time to check the minimum temperature
and humidity, the value will display for 5 seconds.
3. Press 【MEM】button third time will return to standard mode.
4. Press and hold 【MEM】button will clear the max and min record
and reactivate the memory.
5. Normally, the Max and Min record will update every 24 hours at 0:00.
1. About Outdoor Sensor: When battery indicator shows next to the
outdoor temperature, replace batteries in your outdoor sensor.
2. About Cell Battery in Main Unit: The cell battery is only for memorizing
the setting during sudden power outage. When battery indicator shows
next to your indoor temperature, replace battery.
9
HUMIDITY
TEMPERATURE
1. After power on, the indoor temperature will display automatically, it will
update reading each 30 seconds and start to receive outdoor signal which
lasts for max 3 minutes.
2. Indoor temperature display range:14℉~ 122℉(-10℃~ 50.0℃); for
temperature lower than 14℉,the reading will be :”LL.L”; for temperature
higher than 122℉,the reading will be :”HH.H”.
3. Outdoor temperature display range :-40℉~140℉(-40℃~ 60℃); for
temperature lower than -40℉,the reading will be :”LL.L”; for temperature
higher than 140℉,the reading will be :”HH.H”.
4. Arrow indication for temperature changes:
will display when the reading increase by 1.8℉(1℃） within one hour
or compared with last reading.
will display when the reading decrease by 1.8℉(1℃） within one hour
or compared with last reading.
5. Accuracy: ±1.8℉. Temperature resolution is 0.1℉(0.1 ℃).
6. Press 【SET】button to switch from Celsius degree to Fahrenheit
degree.
1. After power on ,the indoor humidity will display automatically, it will
update reading every 30 seconds and start to receive outdoor signal
which lasts for up to 3 minutes.
2. Humidity display range: 1%-99%;for humidity lower than
1%,the reading will be “1%”;for humidity higher than 99%, the reading
will be “99%”.
10
WEATHER FORECAST
PLACEMENT INSSTRUCTION
3. Accuracy: when the temperature is between 68℉~ 78.8℉(20℃~26℃)
and the humidity is between 40-80%,the accuracy is ±5%,if out of this
range the accuracy will be ±8%.
4. Arrow indication for humidity changes:
will display when the reading increase by 3% RH within one hour or
compared with last reading.
will display when the reading decrease by 3% RH within one hour or
compared with last reading.
5.Humidity resolution:1% .
The weather forecast icon will show after power on. There are 5 kinds of
weather modes: Sunny, Partly Cloudy, Cloudy, Rainy, Snowy. The weather
icon displays are based on the hourly calculation of indoor/outdoor
temperature & humidity and barometer data. The forecast is for next
12 hours with 70%-75% accuracy.
Main Unit Placement
Place main unit in a dry area free of dirt and dust. To help ensure an
accurate indoor temperature measurement, be sure to place the Main
unit away from heat sources or vents.
11
If you have problems, please try as following:
Outdoor Sensor
For a more accurate reading and weather forecast, please place the
sensor at a proper place:
1.Avoid exposing to direct rain, sunlight or other heat/cold source.
2.Make sure there is enough air flow around the sensor to reflect the
changes of environment (Well-ventilated).
3. Make sure there ain’t a thick wall or strong interference source using
same signal frequency (433.92MHz) between the weather station and
the sensor.
4. Place the sensor vertically at the height about 1.5m-3m / 4.9ft-9.8ft.
5. When the sensor is first used or relocated, let it stand for around one
hour or more before having accurate measuring of temperature and
humidity.
6. You can place the sensor in multi ways: hang from the back hole using
a nail, place on a stable surface, or lift with a rope. In whatever way,make
sure at least one side of the air vent (back or bottom) is notblocked.
1. Turn off any other existing wireless equipment to check whether this is
the cause of the problem.
2. Move any other existing wireless equipment. Shorten the distance
between the sending and receiving devices and reduce the number of
obstacles(walls, furniture,etc.) between them.
3. Try to remove and reassemble batteries, if the batteries are old, try
new ones.
12
Tips
1.The product must not be dismantled or modified in any way.
2.The weather station must not be exposed to rain or moisture.
3. The product is not intended to be used as a reference thermometer and
we will not beheld liable for any damage which may result from inaccurate
readings.
4. The battery should be removed if the product is not to be used for an
extended period, otherwise the battery might lead and damage the
product. Never leave discharged batteries in the battery compartment.
5.Changing the battery on the weather station erases the saved min and
max readings.
6.Do not expose the product to impacts.
Table of contents
