Instruction Manual
COMMERCIAL MICROWAVE OVEN
RM1129
Version 1

2
CONTENTS
Product Features 2
Specifications* 2
Parts Included 2
General Safety Warnings 2
Operation Safety Warnings 3
Cleaning & Maintenance 3
Installation 4
Operation 5
Power save mode 7
Mute 7
Child safety lock 8
Error codes 8
Materials suitable for use 8
Troubleshooting 8
Notes 8
PRODUCT FEATURES
▪Commercial grade Stainless Steel exterior and
interior.
▪29L internal capacity.
▪Power level adjustable in 5 steps.
▪20 individually customisable cooking
programs.
▪Easy Clean interior surfaces.
SPECIFICATIONS*
Model
RM1129
Power Source
230 Volts AC ~
50Hz
Input Power
1600 Watts
Output Power
1100 Watts
Oven Capacity
29 Litres
Oven Cavity (W x D x H)
350 x 357 x 226 mm
External Dimensions
(W x D x H)
542 x 461 x 329
(includes handle and
standoff)
Net Weight
18Kg
*Specifications subject to change
PARTS INCLUDED
▪Microwave Oven (appropriate model)
▪Instruction Manual
GENERAL SAFETY WARNINGS
Read all Instructions and safety warnings prior to
use. Keep user manual for future reference.
Personnel must be trained prior to operating this
appliance.
This product is suitable for commercial use only.
This machine should not be operated by persons
with reduced physical, sensory or mental
capabilities, or lack of experience or knowledge,
unless they have been given supervision or
instruction concerning the safe use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Avoid contact with the exterior of this machine as
surfaces can get hot.
Do not cover or block filter or ventilation
openings.
Keep power cord away from heated surfaces.
The machine should be disconnected from all
power and allowed to cool before cleaning.
Regularly inspect the supply cord/plug and
discontinue use immediately if damage is found.
This machine contains no user-serviceable parts. It
is hazardous for anyone other than a competent
person to carry out any service or repair operation
that involves the removal of a cover which gives
protection against exposure to microwave energy.
Touching internal electrical components may
cause serious injury or death, even with the
microwave unplugged. Do not remove any cover
unless qualified to do so.

3
This appliance must be returned to Roband
Australia, or one of our agents to carry out repairs.
Do not remove any cover panels from the
machine.
Roband will accept no liability if the instructions in
this manual have not been followed
OPERATION SAFETY WARNINGS
If the door or door seals, door hinges or any part
of the machine is damaged, the oven must not be
operated until it has been repaired by an
authorised person.
Do not operate oven without food or load in oven
cavity.
Liquids and other foods must not be heated in
sealed containers since they are liable to explode.
Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must be
taken when handling the contents.
The contents of feeding bottles and baby food
jars shall be stirred or shaken and the temperature
checked before consumption, in order to avoid
burns.
Only use utensils that are suitable for use in
microwave ovens.
Do not put metal in the microwave oven.
When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of
ignition. If smoke is observed, switch off or unplug
the appliance and keep the door closed in order
to stifle any flames.
Eggs in their shell and whole hard-boiled eggs
should not be heated in microwave ovens since
they may explode, even after microwave heating
has ended.
he oven should be cleaned regularly and any
food deposits should be removed. Failure to
maintain the oven in a clean condition could lead
to deterioration of the surface that could
adversely affect the life of the appliance and
possibly result in a hazardous situation.
Ceramic Glass oven cavity base
The special Ceramic Glass oven cavity base used
in the ROBAND®Microwave ovens has a high
impact strength however impact from sharp
objects or heavy blows to the edges can lead to
breakage.
CLEANING & MAINTENANCE
CAUTION: Disconnect from power and allow to
cool before cleaning.
CAUTION: Steel cutting processes used in the
construction of this machine can result in sharp
edges. Avoid contact with sharp edges during
cleaning and maintenance.
CAUTION: Do not wipe plastic and painted
sections of the oven with bleach, thinners or other
cleaning agents, as this may cause these parts to
dissolve or change shape.
Toxic cleaners should be avoided when cleaning
the inside of the Microwave as they may contact
food.
Caustic cleaners should always be avoided, as
they may damage components inside and outside
the unit.
This unit is not suitable for cleaning with the use
of a water jet or immersion.
The door frame, seal and parts nearby must be
cleaned carefully with a damp cloth when they are
dirty.
Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door components
since they can scratch the surface, causing
damage to the door or shielding mesh within.
If the supply cord is damaged it must be replaced
by a cord set supplied by Roband. Internal
maintenance should only be performed by

4
Roband or one of our service agents.
Cleaning the control panel:
Do not use a detergent or an alkaline spray to
clean the control panel as this may cause damage.
Use a dry or a cloth lightly dampened with water
to clean.
Cleaning the Microwave interior:
After use, clean up any spilled liquids, spattered
oil and food as quickly as possible. If the oven is
used while dirty the efficiency drops and the food
may get stuck on the interior. Clean the interior
with a cloth soaked in warm water with mild
detergent dissolved in it, and then rinse any
residue off with a damp cloth.
Regular cleaning will prevent a build-up of oils
and foodstuff and keep the machine looking new.
INSTALLATION
IMPORTANT: DO NOT USE THE MICROWAVE
DOOR HANDLE TO LIFT THE MICROWAVE
OVEN.
Any damage to the machine as a result of freight
must be reported to the Freight Company and to
the agent responsible for the dispatch of machine
within 24 hours of receipt. No claims will be
accepted after this period.
Do not under any circumstances attempt to use
a damaged product.
Remove all packaging materials, tape, and any
protective plastic from the machine. Remove any
glue residue from the protective plastic or tape
using citrus cleaner.
Product should be installed at counter height only
(approximately 800- 1100mm). Installing outside
the recommended mounting height could cause
damage to the door hinges and prevent
operation.
Do not position the microwave on top of or
immediately above another appliance.
Place the product on a firm, level surface in the
desired position.
Allow at least 150mm clearance from top, back
and sides when positioning the microwave.
Do not obstruct filter or ventilation openings.
Install away from TV and radio sets as reception
and radio interference might be affected.
Do not position Microwave near sources of heat,
water, oil or steam.
Do not stack any appliances or materials on the
top of the microwave.
Do not connect to power using an power board
or extension cord.
WARNING: This product must be connected to
an RCD protected circuit, ensure the circuit is
properly earthed.
Before connecting the machine to the power
supply, ensure that all switches are in the OFF
position.

5
OPERATION
1. MICROWAVE –Indicates when the microwave
is in operation.
2. DEFROST –indicates defrost setting.
3. POWER LEVEL –Indicates power other than
100%.
4. CHILD LOCK –Indicates Child lock is active.
5. PROGRAM –Setup cooking programs.
6. DEFROST –For using Defrost mode.
7. NUMERAL PAD 0-9 –To input time or
program.
8. CHECK PROGRAM –To view program
settings.
9. x2 –Double time.
10. POWER LEVEL –Used to set power level.
11. STOP / RESET –To stop Cooking and Reset
timer.
12. START / +30sec –Begin/resume cooking or
quick-start 30s.
NORMAL COOKING - MANUAL OPERATION
1. Place the food to be cooked or heated in a
container suitable for use in a microwave then
place inside the oven and close the door.
2. Set Power level by pressing ‘POWER LEVEL’
until desired power is displayed.
Power will cycle through 100%, 80%, 60%, 40%
and 20% with each press.
Enter cooking time by pressing the numbers on
the ‘NUMERAL’ keypad.
3. Press ‘START’to begin cooking.
4. Cooking can be paused by pressing ‘STOP’
once or by opening the door. To resume
cooking while paused, close the door if open
and or press ‘START Note, Pressing ‘STOP’
again while paused or with the door open will
clear remaining time.
NOTE: The oven can be programmed for a
maximum of 20 minutes at 100% power, and 60
minutes if 80% power or less is selected.
NOTE: Using a Low power may increase cooking
time, but may produce a more uniform result in
foods such as dairy and meats.
The internal cooling fan will run to prevent
microwave components from overheating.
DEFROST
Defrost function cycles power intermittently to
assist food to thaw evenly.
1. Place the food to be defrosted in a container
suitable for use in a microwave then place
inside the oven and close the door.
2. Press the ‘DEFROST’ button
3. Enter desired time using ‘NUMERAL’ keypad
(Max defrost time is 60 minutes)
4. Press ‘START’ to begin defrost
The DEFROST indicator lights on the display show
the oven is in the DEFROST mode. The oven
beeps during the defrosting cycle to signal that

6
the food needs to be turned or rearranged. When
the defrosting time ends, you will hear 3 beeps.
5. Defrosting can be paused by pressing ‘STOP’
once or by opening the door. To resume
defrosting while paused, close the door if open
and or press ‘START Note, Pressing ‘STOP’
again while paused or with the door open will
clear remaining program time.
QUICKSTART
1. Place the food to be cooked or heated in a
container suitable for use in a microwave then
place inside the oven and close the door.
2. Press ‘START’ to begin cooking with a time of
30 seconds.
3. Pressing ‘START’again while running will add
30 seconds to the timer. By pressing multiple
times a maximum cooking time of 5 mins can
be entered.
4. Cooking can be paused by pressing ‘STOP’
once or by opening the door. To resume
cooking while paused, close the door if open
and or press ‘START’Note, Pressing ‘STOP’
again while paused or with the door open will
clear remaining program time.
Note: Quickstart always runs at 100% power
PROGRAMMED MENU
The microwave can store up to 20 Pre-
Programmed Time / Power sequences.
1. Place the food to be cooked or heated in a
container suitable for use in a microwave then
place inside the oven and close the door.
2. Select a pre-programmed sequence using the
‘NUMERAL’ pad to call up the desired
program. To select program 10-20, touch the
‘NUMERAL’ pad twice rapidly, e.g. 1-1 =
program 11, 2-2 = program 12, 3-3 = program
13 etc.
The oven will automatically begin the
programmed cook sequence after a short pause.
Note, if no program has been entered into a
program position “NO DATA” will show on the
display.
3. Cooking can be paused by pressing ‘STOP’
once or by opening the door. To resume
cooking while paused, close the door if open
and or press ‘START’Note, Pressing ‘STOP’
again while paused or with the door open will
clear remaining program time.
Pre-Programmed Cooking Times and Power
Level:
Note: the above programmed times and
power levels can all be changed if desired.
ENTERING A NEW PRE-PROGRAMMED
SEQUENCE
1. Press ‘PROGRAM’button. The display will
read “PROGRAM”
4. Select a program number using the
‘NUMERAL’ pad to call up the desired
program. To select program 10-20, touch the
‘NUMERAL’ pad twice rapidly, e.g. 1-1 =
Number
Cooking Time
Power Level
1
0:10
100%
2
0:20
100%
3
0:30
100%
4
0:45
100%
5
1:00
100%
6
1:30
100%
7
2:00
100%
8
3:00
100%
9
4:00
100%
0
5:00
100%

7
program 11, 2-2 = program 12, 3-3 = program
13 etc.
2. Press ‘POWER LEVEL’ to select the desired
power level.
3. Enter time required using the ‘NUMERAL’
keypad.
The display will show “STAGE 2”
4. Press ‘START’to save program, press ‘STOP’
to exit without saving, after saving press
‘STOP’to exit program function.
PROGRAMMED MENU - STAGED COOKING
Staged cooking sequences can also be saved to
the programmed menu. A staged program will
cook in 2-3 sequential time/Power stages.
1. Press ‘PROGRAM’
2. Enter the program number to be changed. To
select program 10-20, touch ‘NUMERAL’ pad
twice rapidly, e.g. 1-1 = program 11, 2-2 =
program 12, 3-3 = program 13 etc..
1. Press ‘POWER LEVEL’to select the desired
power level.
2. Enter time for Stage 1 using numeral keypad.
The display will show “STAGE 2”
3. Press ‘POWER LEVEL’again until desired
power level for Stage 2 is displayed.
4. Enter time for Stage 2 using ‘NUMERAL’
keypad.
5. Repeat Step 3 and 4 if a 3rd Stage is required.
6. Once Power and time settings have been
entered for required stages press ‘START’to
save or ‘STOP’to cancel programming.
7. When a staged program is run the microwave
will run through each stage automatically
without user input. The display will show total
time for all stages.
CHECK PROGRAM
Time and power settings for the Programmed
menu buttons can be checked using this function.
1. Press ‘CHECK PROGRAM’
2. Enter the number (1-20) of the program you
want to check.
3. Display will show the time and power settings
for each stage stored to the program entered.
4. Press ‘STOP’to end.
DOUBLE QUANTITY
By selecting ‘x2’ you can temporarily double the
cooking time of a previously entered program.
1. Place the food to be cooked or heated in a
container suitable for use in a microwave then
place inside the oven and close the door.
2. Press ‘x2’
3.Enter desired programmed menu number
using the ‘NUMERAL’ pad. The oven will
automatically begin the programmed cooking
sequence after a short pause.
Note: The extended cooking time cannot exceed
maximum cooking time of 60 minutes, or 20
minutes at full power.
POWER SAVE MODE
The display can be turned off when idle to save
power. To activate, press and hold ‘CHECK
PROGRAM’for 5 seconds. When in Powersave
mode open the door or press any button to wake
the microwave. Once awake the microwave will
operate as usual. To deactivate Powersave, press
any ‘NUMERAL’ button then press and hold
‘CHECK PROGRAM’for 5 seconds.
MUTE
Stops beep when buttons are pressed. To activate
press and hold ‘x2’for 5 seconds.

8
To deactivate mute press and hold ‘x2’ for 5
seconds.
CHILD SAFETY LOCK
To activate press and hold ‘STOP’for 5 seconds.
Unit is now locked and cannot be used until it is
unlocked. To unlock press and hold ‘STOP’again
for 5 seconds.
ERROR CODES
E10: Maximum cooking time exceed in staged
cooking. Total maximum cooking time is
20 minutes at 100% power or 60 minutes in
other power levels. Press ‘STOP’to clear.
E20: Program menu data unable to read or write.
MATERIALS SUITABLE FOR USE
Items containing metal should not be used in
the microwave as they may cause sparking.
Even a small amount of metal plating on the
edge of dishes and cups can cause sparking
and should not be used.
Combustible materials such as paper should
be used with caution as they may ignite. Use
only for short cooking times and only while
attended.
Plastic foam should not be used in the
microwave as it may melt and contaminate
food.
Use only products marked as microwave safe
for ceramic, glass and plastic products.
TROUBLESHOOTING
Only after all points below have been checked
should you call for service:
If the Microwave is not working:
✓Check that the machine is plugged into the
power point correctly and the power is
switched on and working.
✓Check that the door is properly closed and not
obstructed by food or any object.
If the Microwave is sparking in the cavity:
✓Check that there are no metal utensils, metal
containers or dishes with metal trim being
used.
NOTES
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________
____________________________________________

9
WARRANTY
The warranty conditions set out below are in addition to any warranties implied or governed by law.
Roband Australia warrants that this appliance shall be delivered free from defects in material and
workmanship. The warranty for this product is offered to the original purchaser, to be free of fault in both
workmanship and materials for a period of 12 months from date of purchase. Roband’s obligations pursuant
to this warranty are limited to the repair or replacement of the defective goods or materials, at its discretion
and subject to the terms contained within this Warranty statement.
The following conditions apply:
The product must be installed, maintained and used under normal operating conditions within the scope of
the operating instructions.
All warranty claims must be submitted to Roband or an authorised Roband dealer, and Roband
authorisation must be granted prior to repairs being carried out. Proof of purchase is required for any repair
authorisation.
Warranty is back to base, meaning delivery to and collection of your product to Roband or an authorized
service agent is the responsibility of the purchaser.
Where a product cannot be returned back to base, on-site warranty can be arranged by prior agreement.
The following exclusions apply:
Claims or faults arising from misuse, neglect, transport damage or other mechanical damage, including but
not limited to; door’s, hinges & interlock switches etc., other than those arising from manufacture or material
defects. Where relevant, glass, Teflon® and lamps are not included in this warranty and RCD tripping due
to moisture absorption by Tubular Heating Elements is not a warranty fault.
Roband or any subsidiary company or Agent shall not be liable for loss of profit or damage to other
equipment and property except where it is in breach of the guarantees provided in accordance with
applicable legislation.
Roband reserves the right to reject a warranty claim if it is not satisfied with the circumstances under which
the fault occurred or where a product has been altered from its original specification.
For on-site repairs outside of capital city metropolitan areas, travel costs, service callout fee and related
labour costs etc. are the responsibility of the claimant.
Any costs incurred for false claims or faults due to incorrect usage etc. are the responsibility of the claimant.
Any attempt to repair the product by non-Roband approved service personnel or the use of non-genuine
parts will void the warranty agreement
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a major failure.
For the name of your nearest Australian authorised service agent, please contact:
Roband Australia Pty Ltd For your nearest International distributor, please visit:
1 Inman Road,
Cromer, NSW, 2099, Australia,
Warranty: 1800 268 848
Tel: [phone]
Email: [e-mail]
Web: www.roband.com.au
https://www.roband.com.au/worldwide/
®
®
