ROBINHOOD ST7001 User manual

Page 1 of 6
Description: ROBINHOOD SUPERTUB DOUBLE DRAWER
Model Number: ST7001
Model pictured:ST7001
Issue: 4

Page 2 of 6
Exploded Tub Assembly
1
2
3
6
9
8
10
5
7
4
11
12
13
14
15
16
17

Page 3 of 6
Exploded Tub Assembly Cont
Part number
Item Description ST 7001
1
Waste grill screw
752230
2 Waste grill 752214SS
3
Overflow O ring
752220
4
Overflow screw (1 off) 999074
5 Waste seal 752209
6
Waste body
752205
7
Overflow hose clip 752229
8 Washing machine waste hose 752224
9
Washing machine waste inlet
752201
10
Overflow hose 752215
11
Overflow body
752219
12
Waste elbow
752204
13
U bend complete kit 75220345
14
Waste T piece
752203
15
Washing machine waste hose clip (1 off)
752228
16 Waste inlet blanking cover 752202
17
Screw (1 off)
999054

Page 4 of 6
Exploded Chassis Assembly
Part number
Item Description ST7001
1
Bottom drawer complete (less handle)
751066
2
Top drawer complete (less handle)
751067
3
Bottom drawer side/runner set (left & right hand) (2 x
sides & 2 x runners) Supplied with item 1
4
Top drawer side/runner set (left & right hand) (2 x sides &
2 x runners) Supplied with item 2
5 Handle complete including screws and washers (1 off) 751048
6 Knob hot (red) 750909RD
7
Knob cold (blue)
750909BU
8
Flexible hose
751141
9
Three way ball valve complete (1 off) Hot 752235HT
N/S Three way ball valve complete (1 off) Cold 752235CD
N/S Non return valve Hot Part of item 9
N/S
Handle screws M4 x 25 Pan Pozi
999073
N/S
Handle washer M4 x 11 flat
999010
N/S
Three way ball valve extension rod (single) 751019
N/S = Not shown
1
2
3
3
6
4
4
5
5
7
8
9

Page 5 of 6
Part number
Item Description ST7001
1
Tap complete including hoses and fittings 751140
2
Ceramic disc cartridge
751140C
3 Aerator O ring
Part not available
4
Aerator cartridge
Part not available
5
Aerator screw end
Part not available
6
Tap Washer Seal
751140OR
7
Flexible hose hot (red)
751140HT
8 Flexible hose cold (blue)
751140CD
9
Optional 65mm pole handle
751140XT
Exploded Tap Assembly
6
9
New Zealand
Monaco Corporation Limited
Telephone: [phone]
Facsimile: [phone]
Email: [e-mail]
www.robinhood.co.nz

Page 6 of 6
Installation Kit
Part number
Item
Description
ST7001
1 Installation kit complete (as shown above) 752043
2
Plug
750636
3 Adjustable foot assembly (1 off) 750920
4
Cable tie Available from Hardware Stores
ECN: 07034
4
1
2
3
Australia
Shriro Australia Pty Limited
(ABN 28 002 386 129)
Telephone: [phone]
Facsimile: 1800 628 577
Email: [e-mail]
5
