OWNER’S MANUAL
R720L/R700
FOG MACHINE

Thank you for purchasing this Rockville Fog Machine.
We are very proud to bring you what we consider to be the absolute best value in fog
machines. We have spared no expense in manufacturing these fog machines to meet the
highest quality standards. With proper care and installation this unit will provide you with
the highest levels of satisfaction. We hope that this unit will bring you years of perfor-
mance and reliability.
Please read this installation guide carefully for proper use of your R Series Fog Machine.
Should you need technical assistance please call our technical help line at 1-646-758-
0144, Monday through Friday, 9am to 5pm EST.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT SAFETY INSTRUCTIONS
•To reduce risk of electric shock, never open the unit. There are no user serviceable
parts, refer service to an authorized Rockville service center.
• Do not expose this unit to any kind of moisture.
• Please ensure that the unit is situated in a properly ventilated area.
• Make sure the unit is placed on a level and stable surface.
Features and Specifications
R720L/R700
Includes

IMPORTANT SAFETY INSTRUCTIONS
•To reduce risk of electric shock, never open the unit. There are no user serviceable
parts, refer service to an authorized Rockville service center.
• Do not expose this unit to any kind of moisture.
• Please ensure that the unit is situated in a properly ventilated area.
• Make sure the unit is placed on a level and stable surface.
Features and Specifications
R720L/R700
Includes
• (R720L ONLY) Built in RGB LED lights
• (R720L ONLY) Each LED is 3 Watts
• (R720L ONLY) Top of the line Tianxin brand LED’s are reliable, bright, and have amazing
performance
• Output: capacity 3,000cfm (cubic feet per minute)
• Fog uid included (0.6L)
• 3.5 minute start time (fastest on the market for a similar priced unit)
• Manual fog button
• Wired remote included
• Wireless timer remote included. Hit one button and 30 seconds of fog will come out
• Water-based fogger compatible with standard fog uid made by Rockville, Chauvet,
American DJ, Visual Effects, and other famous brands
• 10 Fluid ounce tank capacity
• Fluid consumption: 10 Fluid Ounces per hour
• Our fog machine will output literally twice as much as other machines being sold by other
famous brands
• Compact and powerful. This machine is portable yet more powerful and reliable than
machines triple the price.
• Strong enough for indoor or outdoor use
• This machine produces a thick fog capable of staying in the air for a long time
• Perfect for DJ use, bars, karaoke parties, etc.
• Power and current: 110V, 60Hz: 440W, 5A operating /AC power: 110V Only
• Unit Weight: 3.3lbs
• Unit Dimensions (Inches): 9.1˝ x 5.1˝ x 4.3˝
• 1 x Wired Remote
• 1 x Wireless Timer Remote
• 1 x Warranty Card
• 1 x User Manual
• 1 x Fluid (0.6L)

Before connecting this unit to a power supply for the rst time you must rst ll the uid
tank with fog uid and check that the nozzle is clean and unobstructed.
Place the machine on a level surface and loosen the cap of the uid tank to ll with qual-
ity water based fog uid. Although other fog uid brands may be used, we recommend
use of Rockville fog uid as it is the best quality and the best price. Plug the remote con-
trol into the socket at the rear of the unit. Switch the fog machine on and allow to preheat
for 4 minutes. Once the machine has reached operating temperature the green light on
the remote control will illuminate. Push the button on the remote control when lit and hold
to produce a 30 to 40 second burst of fog. Always be sure that the fog is not pointed
directly at anyone’s face. LEDs on the R720L operate automatically when the machine
begins to produce fog.
Always monitor fog uid level as running the machine with no uid could cause perma-
nent damage. Please do not touch or place anything in close proximity to the nozzle
during operation or preheating as you could suffer serious burns.
It is normal for your fog machine to have a reheating period after long bursts. The unit
will shut itself down for a short period in order to reach operating temperature (572° F).
Please note that during this time no fog can be produced. The green light on the remote
will illuminate when the unit is ready.
Due to the high operating temperature of fog machines it is advised that the effect be
used in well ventilated areas taking care not to obstruct the air vents. After use, allow
time the unit time to cool down before moving or touching. Not doing so could result in
serious burns.
This fog machine has been designed to function on a power supply of 110V-60HZ and
has been tted with a suitable power plug. Please be sure to use the same type fuse as
the one provided.
The fog machine must be used in a horizontal position on a level surface or it may be
mounted using the bracket provided. Whatever method of installation you choose, the
fog machine must not have more than a 15 degree angle of inclination. We always sug-
gest that for safety purpose use of a suitable hanging clamp and safety cable is essential.
Do not allow fog uid to become contaminated. Always replace cap after use.
There are no user serviceable parts in this unit. Any work on internal parts should be
carried out by a qualied technician. Removal of any covers is considered a breach of
warranty.
If you experience low output, pump noise or no output at all, unplug immediately. Check
uid level, check the hose attached to the tank and make sure there are no obstruc-
tions and uid is owing through the hose, check the external fuse, remote connection,
and main power supply. Ensure that tank is lled and all other components are working
properly. If all appear to be OK, plug the unit in again. If the unit still does not operate
properly and you are unable to determine the cause of the problem, contact Rockville for
servicing.
ATTENTION: If the unit is unable to produce fog, do not continue to push the remote
control button as this may cause permanent damage.
Cleaning your fog machine regularly will help reduce costly parts replacement and repair
charges. We recommend you clean your fog machine after every 40 hours of continues
operation or when the machine will be idle for a long time. Run a cleaning solution com-
posed of 80% distilled water and 20% white vinegar through the system to prevent the
accumulation of particles in the heating element.
1. While unit is unplugged and cool, unscrew nozzle at very front of unit (g.1) and clean
out debris with white vinegar and a pipe cleaner, making sure that the hole is unobstructed.
2. Empty all fog uid from the machine and replace with cleaning solution. Plug the unit in
and allow to heat up as usual.
Set-up/Operation
Installation/Mounting
Cleaning

Do not allow fog uid to become contaminated. Always replace cap after use.
There are no user serviceable parts in this unit. Any work on internal parts should be
carried out by a qualied technician. Removal of any covers is considered a breach of
warranty.
If you experience low output, pump noise or no output at all, unplug immediately. Check
uid level, check the hose attached to the tank and make sure there are no obstruc-
tions and uid is owing through the hose, check the external fuse, remote connection,
and main power supply. Ensure that tank is lled and all other components are working
properly. If all appear to be OK, plug the unit in again. If the unit still does not operate
properly and you are unable to determine the cause of the problem, contact Rockville for
servicing.
ATTENTION: If the unit is unable to produce fog, do not continue to push the remote
control button as this may cause permanent damage.
This unit can pose a burn danger if not used properly. Do not obstruct the nozzle.
Fog output is very hot, avoid coming within 24˝ of the nozzle during operation. Output
nozzle becomes very hot during operation (572° F).Keep ammable materials at least
20˝ away from the nozzle. Always allow the fog machine to cool down before cleaning
or servicing.
Never use any other type of liquid other than Rockville water based fog uid or any
other comparable brand. Never drink fog liquid. If its ingested, call a doctor immedi-
ately. If fog uid comes into contact with skin or eyes, rinse thoroughly with water.
Beware of condensation around the nozzle. Consider carefully when mounting. All fog
machines may splutter small amounts of fog occasionally during operation and for a
minute or so after being turned off.
3. Run unit in a well ventilated area until tank is empty.
4. Replace nozzle.
5. Cleaning is now complete. Unplug and wait until it is cool before relling with Rockville
fog uid or any other water based fog uid.
6. To clean the exterior, wipe with a dry cloth.
7. Always store the unit dry (no uid in the tank).
All fog machines are prone to clogging due to the consistency of uids and the high
temperatures at which they vaporize. However, a well maintained machine should provide
years of reliable use.
Maintenance/Servicing
Troubleshooting
Caution

© 2017 ROCKVILLE // Features and specifications are subject to change and or improvement without notice.
