Bulletin 855H Recordable Horn (Frame E / Flare)
855H-R30E, 855H-R45E, 855H-RC30Ex, 855H-RC45Ex
IP66 - Frame E
IP66/67 - Flare
Wiring practices must meet applicable electrical codes.
Les procédures de câblage doivent répondre aux codes électriques en vigueur.
Bei der Verdrahtung sind die geltenden elektrotechnischen Sicherheitsvorschriften zu befolgen.
Le procedure adottate per i cavi devono rispettare le codifiche elettriche applicabill.
A instalação da fiação deve atender aos códigos elétricos aplicáveis.
Las prácticas de instalación eléctrica deben seguir los códigos eléctricos.
FEATURES:
•
•
•
•
•
•
4 stages - Each stage can record up to 30 seconds of CD quality audio
Record via on-board microphone or from external source using audio input jack
Message can be played back preceded by one of forty five alarm tones, or without any alarm tone if desired
Master / Slave functionality allows multiple horns to be set up exactly the same way
Optional high-output LED beacon available
Horn / LED combination units allow user to select steady or flashing LED function (2 Hz flash rate)
OPERATING AND MARKING:
All units have the following operating requirements and limitations.
855H Horn only units:
Catalog No. Voltage Range Current
855H-R30E 14-30V DC 779mA@14V
855H-R30F 1.51A@24V
1.85A max@30V
855H-R45E 90-260V AC 542mA@120V
855H-R45F (50/60Hz) 517mA@230V
668mA max@260V
855H Combined horn/LED units:
Catalog No. Voltage Range Current
855H-RC30Ex 14-30V DC 936mA@14V
1.67A@24V
1.92A max@30V
855H-RC45Ex 90-260V AC 602mA@120V
(50/60Hz) 552mA@230V
701mA max@90V
Prior to use, the unit will need to be configured to suit the end user.
If recording either via the onboard microphone or the line-in jack, the unit will need to be supplied with power.
HORN SET-UP AND RECORDING
AC and DC units should be powered normally to complete recording and set-up.
Risk of Electrical Shock. Disconnect from power source to prevent electrical
shock before servicing.
WARNING
1
Sound Output @ 1 meter:
111 dB (A) Voice 112 dB (A) Music 126 dB (A) Tone
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
855H-R30F, 855H-R45F
Hearing protection required.

10000229312 00
G. FILLUS 12-22-11
2 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
INSTALLATION & WIRING REQUIREMENTS:
The power terminals on the control unit are clearly marked and will accept up to AWG 16 (1.5mm²) wire size.
2
FRAME E UNITS:
Remove 4 screws on face of unit for access to
power connections, programming
functions, and stage selection connections.
Re-torque as indicated after set-up to
maintain ingress rating.
FLARE UNITS:
ACCESS TO PCB’S FOR PROGRAMMING AND POWER CONNECTIONS
FRAME E FLARE
TONE SELECTION
The 855H Recordable Horn has 45 different tones (See page 12) that can be selected for the first stage alarm. The
unit can then be switched to sound second, third and fourth stage alarm tones. The tones are selected by
operation of DIP switch S4 on the main PCB.
The tone selection table (page 12) shows the switch positions for the 45 tones and which tones are available for the
second, third and fourth stages.
Example
S4 Dip Switch -
Shown Set for Tone 1
(All switches OFF)
See Quick Start Guide (beginning on page 6) for set-up instructions and functions.
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
See PCB layouts on sheet 5 for details.
M4
20 lb-in
(2.2 N•m)
(4 places)
Remove 4 screws on rear of unit for access to
power connections, programming functions, and
stage selection connections.
Re-torque as indicated after set-up to maintain
ingress rating.
Remove
Remove
Optional
LED Beacon
4.5 lb-in
(0.5 N•m)
(4 places)

10000229312 00
G. FILLUS 12-22-11
3 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
STAGE WIRING
DC Units Second, Third and Fourth Stage Selection
The 855H Recordable Horn uses negative switching to change
the tone to the second, third and fourth stages.
To activate the second, third or fourth stage tone, connect the
‘-’ supply line to the relevant stage terminal while maintaining
the DC supply to ‘+’ and ‘-’.
•
•
•
For Stage 2 connect ‘-’ to the S2 terminal
For Stage 3 connect ‘-’ to the S3 terminal
For Stage 4 connect ‘-’ to the S4 terminal
The negative supply must remain
connected to the
‘-’ terminal and a
connection made from this to the
appropriate stage terminal, otherwise
the unit will be damaged.
WARNING
DC CIRCUIT
WIRING
DIAGRAM
CUSTOMER
SUPPLIED
SWITCHES
BEACON
PRE-WIRED
INTERNALLY
TERMINALS ON
PCB
Beacon
Sounder
S4 S3 S2
S4 S3 S2
+-
+
-
3
AC Units Second, Third and Fourth Stage Selection
The 855H Recordable Horn uses Line switching to change the
tone to the second, third and fourth stages.
To activate the second, third or fourth stage tone, connect the
‘L’ supply line to the relevent stage terminal while maintaining
the AC supply to ‘L’ and ‘N’.
•
•
•
For Stage 2 connect ‘L’ to the S2 terminal
For Stage 3 connect ‘L’ to the S3 terminal
For Stage 4 connect ‘L’ to the S4 terminal
AC CIRCUIT
WIRING
DIAGRAM
CUSTOMER
SUPPLIED
SWITCHES
BEACON
PRE-WIRED
INTERNALLY
TERMINALS ON
PCB
Sounder
S4 S3 S2
N
L
N
L
Beacon
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
S4 S3 S2

10000229312 00
G. FILLUS 12-22-11
4 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
The 855H Combo units will have the beacon already pre-wired to the unit so no extra wiring is required. Beacon
will activate when any stage is energized.
BEACON SET-UP
The LED beacon is factory set to the 2Hz flash mode, but it can easily be set to steady mode if desired. To alter the
settings, change the position of the header pin as shown,
•Remove header for steady mode.
•Keep header in standard position for 2Hz flashing mode.
4
MOUNTING DIMENSIONS
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
209.8
190.0
190.0
191.5
183.8
Ø9.0
855H-R30E
855H-R45E
191.5
183.8
86.4
86.5
BEACON
855H-RC30Ex
855H-RC45Ex
209.8
190.0
190.0
Ø9.0
166.0
160.0
219.6
25.0
20.0
142.1 181.0
855H-R30F
855H-R45F
30.0mm
30.0mm
Ø 7.0mm
(3 places)
3 x 6mm (¼”)
Mounting screws
not provided
18°
M20
thread

10000229312 00
G. FILLUS 12-22-11
5 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
PCB LAYOUT
5
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
TONE
VOLUME
VOICE
VOLUME
S2
S3
S4
- -
- -
+ +
+ +
MIC
LINE IN
6
ON
12 3 45
7
23 4 56
ON
1
R/E
RAONTA
MA SY ME
OFF
ON
ACTION RESET
Alarm Tone &
(Voice) Recorded Content Volume Controls
On board
microphone
Audio Line-in
PEAK
Peak Level LED
DC Power & Alarm
Stage Terminal
Master / Slave
Connector
Jumpers
Function LEDs
S2 - Set-up
S4 - Tones
TONE
VOLUME
VOICE
VOLUME
MIC
LINE IN
6
ON
12 3 45
7
23 4 56
ON
1
R/E
RAONTA
MA SY ME
OFF
ON
ACTION RESET
Alarm Tone &
(Voice) Recorded Content Volume Controls
On board
microphone
Audio Line-in
PEAK
Peak Level LED
Alarm Stage Terminal
Master / Slave
Connector
Jumpers
Function LEDs
S2 - Set-up
S4 - Tones
S2 S3 S4
NL
AC Power
Terminal
AC Units
DC Units

10000229312 00
G. FILLUS 12-22-11
6 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
This guide is designed to get the user quickly interfacing with the 855H Recordable Horn.
•
•
•
•
•
Switch
No.
1
2
3
4
5
6
7
855H RECORDABLE HORN QUICK START GUIDE
The unit can be set-up to either play an alarm tone followed by a recorded message, or
just play the recorded message.
The user can:
oRecord on each of the 4 stages using either the Line-in or Microphone inputs
oSelect the required alarm tone for each stage
oDelete unwanted messages.
To re-record a message on a particular stage, the previous message on that stage must
be deleted first.
The “Mass Erase” function will erase all the recorded stages and also reset the unit.
Once the user has configured the unit, it must be put into its Playback Mode and S2
switches set to stage 1, as shown in Quick Ref - Playback Mode (Stage 1 illustrated)
guide below.
OFF Position Function
Record Mode
Stage selection switch
Stage selection switch
Audio Line-In selected
Program (Record &
Erase Mode ON)
Message & Tone
Playback
Single Message or Mass
Erase Mode OFF
SWITCH S2 (SET-UP) FUNCTION SETTINGS
(NOTE: “Black” color indicates “ON” position)
ON Position Function
Playback Mode
Switch 2 On & Switch 3 On = Alarm Stage 1
Switch 2 Off & Switch 3 On = Alarm Stage 2
Switch 2 On & Switch 3 Off = Alarm Stage 3
Switch 2 Off & Switch 3 Off = Alarm Stage 4
On board Microphone selected
Playback (Record & Erase Mode OFF)
Message only Playback
Single Message or Mass Erase Mode ON
6
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E

10000229312 00
G. FILLUS 12-22-11
7 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
1
Set dip switch S2 positions 2,3
& 4 to ‘ON’, all others to ‘OFF’
2
3a
3b
4
•
•
•
•
TO RECORD A MESSAGE ON STAGE 1 USING THE ON-BOARD MICROPHONE
For Stage 1:
For Stage 2:
For Stage 3:
For Stage 4:
RECORD MODE
(NOTE: “Black” color indicates “ON” position)
Set Switch ‘S2’ positions 3 & 4
to ‘ON’; all others to ‘OFF’
Set Switch ‘S2’ positions 2 & 4
to ‘ON’; all others to ‘OFF’
Set Switch ‘S2’ positions 4 to
‘ON’; all others to ‘OFF’
Switch on power or
Press reset button
Press and release action button:
Start recording
Speak into the on-board
microphone (MIC)
It is suggested that a 2” (5cm)
gap be maintained to the
microphone.
The peak detector LED should
flash regularly to maintain a
good recording level.
However, if it stays on for most
of the time, the recording may
be distorted.
Press action button:
Stop recording
TO RECORD FROM AUDIO LINE-IN JACK INSTEAD OF THE ON BOARD MICROPHONE:
Ensure that the audio cable is connected from the message source to audio line-in jack
before recording.
Follow above step 1 but set Switch ‘S2’ position 4 to ‘OFF’ for each stage.
At step 3b, play recording from message source. You will be able to listen as it is
recorded.
IMPORTANT NOTE
After the unit is configured, it must be put into its Playback Mode to operate.
Set switch S2 to stage 1, as shown in Playback Mode chart (next page).
7
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E
PEAK
TA ON RA R/E

10000229312 00
G. FILLUS 12-22-11
8 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
(TO PLAY BACK A MESSAGE)
PLAYBACK MODE
(NOTE: “Black” color indicates “ON” position)
1
For Stage 1:
Set Switch ‘S2’ positions
1,2,3 & 5 to 'ON'
Alternatively for :
For Stage 2:
Set Switch ‘S2’ positions
1,3 & 5 to 'ON’
For Stage 3:
Set Switch ‘S2’ positions
1,2 & 5 to 'ON'
For Stage 4:
Set Switch ‘S2’ positions
1 & 5 to 'ON'
2Switch on power or
Press reset button
3a
8
Unit will sound alarm tone
(if selected) and then
recorded content repeatedly
(If no alarm tone selected,
then recorded content only).
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E

10000229312 00
G. FILLUS 12-22-11
9 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
(TO ERASE ONE STAGE AT A TIME)
ERASE MODE - SINGLE STAGE
(NOTE: “Black” color indicates “ON” position)
1
For Stage 1:
Set Switch ‘S2’ positions
2,3 & 7 to 'ON'
Alternatively:
For Stage 2:
Set Switch ‘S2’ positions
3 & 7 to 'ON'
For Stage 3:
Set Switch ‘S2’ positions
2 & 7 to 'ON'
For Stage 4:
Set Switch ‘S2’ position 7
to 'ON'
2Switch on power or
Press reset button
3a Press action button:
Erase will begin
3b - - - - erase complete
9
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E

10000229312 00
G. FILLUS 12-22-11
10 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
(ERASES ALL STAGES AT ONCE)
MASS ERASE MODE
(NOTE: “Black” color indicates “ON” position)
1Set Switch ‘S2’ position
7 to 'ON'
2
Set jumper J4
‘ME’ to ON position
(centre and right pin
connected)
3Switch on power or
Press reset button
4a Press action button:
Erase will begin
4b - - - - erase complete
5Reset Jumper J4
‘ME’ to OFF position
NOTE:
The Mass Erase mode will also reset the unit to factory settings.
10
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E

10000229312 00
G. FILLUS 12-22-11
11 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
THIS FUNCTION WILL ALLOW MULTIPLE UNITS TO BE SET UP EXACTLY THE SAME AS A
PREDETERMINED “MASTER” UNIT
SYNCHRONIZING TWO SOUNDERS (ALL STAGES)
1
Connect Synch cable to
Master and Slave PCB
2
On both units: Set jumper J6
(SYNC) to ON
Set jumper J5 (S/M) on Master
unit to master position (ON)
Set jumper J5 (S/M) on Slave
unit to slave position (OFF)
NOTE: Position of S2 and S4
dip switches and jumper J4
(ME) does not affect synch
operation.
3
Apply power to the Master
unit first
Then apply power to the Slave
unit
Master Unit
Slave Unit
4a
Press action button on the
Master Unit: Synchronisation
will begin
Master Unit
Slave Unit
4b
- - - - Synchronisation
complete
Switch off Power to units
Master Unit
Slave Unit
5
On both units: Reset on
jumper J6 (SYNC) to OFF
Set jumper J5 (S/M) on
both units to Master
position (ON)
Designate one unit as Master
and one unit as Slave
11
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E
TA ON RA R/E

10000229312 00
G. FILLUS 12-22-11
12 12
B
210mm W x 297mm H
8 - 1/2" W x 11" H
CUT SIZE
TONE S
E
E
LECTIO
O
NTABL
E
E
Printed in UK
DIR: 10000229312 (Version 00)
O
Tone 2 Tone 5 Tone 29
Tone 17 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 6 Tone 5 Tone 29
Tone 3 Tone 20 Tone 29
Tone 7 Tone 5 Tone 29
Tone 10 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 15 Tone 2 Tone 29
Tone 7 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 4 Tone 5 Tone 29
Tone 15 Tone 5 Tone 29
Tone 4 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 18 Tone 5 Tone 29
Tone 2 Tone 27 Tone 29
Tone 2 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 6 Tone 5 Tone 29
Tone 29 Tone 5 Tone 29
Tone 29 Tone 5 Tone 29
Tone 2 Tone 15 Tone 29
Tone 26 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 7 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 26 Tone 5 Tone 29
Tone 26 Tone 15 Tone 29
Tone 2 Tone 5 Tone 29
Tone 38 Tone 45 Tone 29
Tone 36 Tone 5 Tone 29
Tone 35 Tone 5 Tone 29
Tone 9 Tone 45 Tone 29
Tone 34 Tone 45 Tone 29
Tone 23 Tone 17 Tone 29
Tone 31 Tone 27 Tone 29
Tone 2 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 2 Tone 5 Tone 29
Tone 38 Tone 34 Tone 29
Tone 1 340 Hz Continuous
Tone 2 800/1000 Hz @ 0.25 sec Alternating
Tone 3 500/1200 Hz @ 0.3 Hz 0.5 sec Slow Whoop
Tone 4 800/1000 Hz @ 1 Hz Sweeping
Tone 5 2400 Hz Continuous
Tone 6 2400/2900 Hz @ 7 Hz Sweeping
Tone 7 2400/2900 Hz @ 1 Hz Sweeping
Tone 8 500/1200/500 Hz @ 0.3 Hz Sweeping
Tone 9 1200/500 Hz @ 1 Hz - DIN / PFEER P.T.A.P.
Tone 10 2400/2900 Hz @ 2 Hz Alternating
Tone 11 1000 Hz @ 1 Hz Intermittent
Tone 12 800/1000 Hz @ 0.875 Hz Alternating
Tone 13 2400 Hz @ 1 Hz Intermittent
Tone 14 800 Hz 0.25 sec on. 1 sec off Intermittent
Tone 15 800 Hz Continuous
Tone 16 660 Hz 150mS on. 150 mS off Intermittent
Tone 17 544 Hz (100mS) / 440 Hz (400mS) - NF S 32-001
Tone 18 660 Hz 1.8sec on. 1.8sec off Intermittent
Tone 19
1.4KHz-1.6KHz 1s. 1.6KHz-1.4KHz 0.5s - NFC48-265
Tone 20 660 Hz Continuous
Tone 21 554 Hz / 440 Hz @ 1 Hz Alternating
Tone 22 544 Hz @ 0.875 sec Intermittent
Tone 23 800 Hz @ 2 Hz Intermittent
Tone 24 800/1000 Hz @ 50 Hz Sweeping
Tone 25 2400/2900 Hz @ 50 Hz Sweeping
Tone 26 Bell
Tone 27 554 Hz Continuous
Tone 28 440 Hz Continuous
Tone 29 800/1000 Hz @ 7 Hz Sweeping
Tone 30 300 Hz Continuous
Tone 31 660/1200 Hz @ 1 Hz Sweeping
Tone 32 Two tone chime.
Tone 33 745 Hz @ 1 Hz Intermittent
Tone 34 1000 & 2000 Hz @ 0.5 sec Alternating - Singapore
Tone 35 420 Hz @ 0.625 sec Australian Alert
Tone 36 500-1200 Hz 3.75sec / 0.25sec Australian Evac.
Tone 37 1000 Hz Continuous - PFEER Toxic Gas
Tone 38 2000 Hz Continuous
Tone 39 800 Hz 0.25 sec on. 1 sec off Intermittent
Tone 40 544 Hz (100mS) / 440 Hz (400mS) - NF S 32-001
Tone 41 Motor Siren - slow rise to 1200 Hz
Tone 42 Motor Siren - slow rise to 800 Hz
Tone 43 1200 Hz Continuous
Tone 44 Motor Siren - slow rise to 2400 Hz
Tone 45 1KHz 1s on. 1s off Intermittent - PFEER Gen. Alarm
Stage 2
Stage 1 Frequency Description
Stage 3 Stage 4
Switch
(S2) (S3) (S4)
123456
12
INSTRUCTION SHEET
FOR BUL. 855H
RECORDABLE HORN FRAME E
