Rocstor Y10A249-A1 User manual

Features
USB Type-C Male (Connect to host computer)
• Supports DP1.2 Alt mode
Note: To get max bandwidth, the host computer should support DP1.2 Alt mode.
Type-C (for PD Charging)
• Type-C female port supports both data
(5Gbps) and PD Charging 100W
(20V/5A)
RJ45 x1
• Supports 10/100/1000Mbps bandwidth
for RJ45 port and supports to work with
Nintendo Switch
VGA
• Supports VGA resolution up to
1920x1200@60Hz
Introduction
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• 1 x Main Unit
• User Manual
This is a premium Rocstor USB-C to two(2) USB 3.0, HDMI, RJ34, VGA, Type-C Data and
PD Charging Adapter. The USB 3.0 port allows you to connect USB device or another
hub to the host USB-C computer, the USB-C female port supports both PD Charging
and data; the Gigabit Ethernet port allows the host computer to get access to the
network; the HDMI and VGA ports allow you to enjoy high definition picture or video
on big screen. It can work on a Macbook or the new Google Chromebook Pixel and
other USB-C supported devices.
HDMI
• Supports HDMI resolution up to
4Kx2K@30Hz
Note: Supports HDMI and VGA to display
the same image simultaneously for
1080p/60Hz
Note: Only RJ45 port supports Nintendo
Switch, other ports don't support
Nintendo Switch.
Upstream:
Downstream:
FEATURES
• 15W is dedicated to this product.
• Multiple USB-C interfaces support plug
and play, hot swapable.
• Support Fast Role Swap of PD 3.0, the
connected device will not get
disconnected while plugging in and
out PD Adapter.
Specification
How to Use
System Requirement
Input / Output Connector
Input
Output USB 3.0 Female x2
USB-C Female x1(for data and Charging)
RJ45 X1
HDMI Female x1
VGA Female x1
USB Type-C Male x1
Warranty
Limited Warranty 2 Year
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certifications FCC, CE
Power Supply
USB-C Female Port Up to 100W (20V/5A)
Accessories
User Manual English Version
1 • Connect the USB-C male port of this product to Macbook or Chromebook or other
USB-C host.
2 • Connect the two USB 3.0 outputs of this product to two USB 3.0/2.0 devices.
3 • Connect HDMI output of this product to HDTV with one HDMI cable.
4 • Connect VGA port of this product to a VGA monitor.
5 • Connect Gigabit Ethernet port of this product to Ethernet Router with an Ethernet
cable.
6 • Automatically or manually set the IP address of the computer.
7 • Connect the USB-C charging port, it can charge from the host computer and
support power for this product simultaneously.
Host computer with an available USB-C Port
- USB 3.0/3.1/3.2
Operating systems
- Windows 7 / 8 / 10 / 11
- Android OS
- Chrome OS
- Linux OS
- Mac OS v10.5 or above
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
®
USB Type-C® Multiport Adapter - PD Charging -
HDMI® 4K@30Hz - VGA - USB®3.0 - USB-C® Gen 1 PD
User Manual
Y10A249-A1
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
USB-A X2
• Max 5Gbps data transmission per port
• USB 3.0 (Port1) Supports max 7.5W
(5V/1.5A ) downstream charging port.
• USB 3.0 (Port2) supports max 900mA
downstream charging.
• 2 USB-A share max 2.8A output
• USB 3.0 port supports to charge and
transmit data for the USB device
simultaneously

Technical Support / RMA
Hours: 9:00 am - 5:00 pm PST
Monday to Friday (except holidays)
Tell: [phone] (National and international)
Fax: [phone]
Email: [e-mail]
Support
Warranty Information
Technical support is available to all the registered users of Rocstor products.
Safety Information:
©2021 Rocstroge, Inc. All rights reserved. Rocstor is registered trademark of Rocstorage, Inc.
Apple®, the Apple logo, Mac®, MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®,
iPad Air®, iPhone®, MacOS® are registered trademarks of Apple, Inc. Google® and Chromebook™ are
registered trademarks of Google, LLC. Microsoft® is registered trademarks of Microsoft corporation. Al
other product names and logos mentioned herein may be trademarks of their respective companies.
USB Type-C® and USB-C® are registered trademark of USB Implementers Forum. Feature and
specification are subject to change without notice. All trademarks and registered trademarks are the
property of their respective. All rights reserved.
TIMELINE WORLDWIDE PROJECTIONS
M ANUFACTURING O PTIONS
NORTHAMERICA UNITEDKINGDOM GERMANY CHINACHINA SOUTHKOREA JAPAN
TIMELINE MANUFACTURING CUSTOMERINTERATION GROWTHFORCAST WORLDWIDE DEVELOPMENT
Thisstatistic shows the year-over-year
growthof manufacturing and sales
Worldwide. Projections are from
2010to2060.
Wedelivered$22.0 billion in revenue
and$10.3billionin operating
incomethispast fiscal year.
Wedelivered$26.0 billion in revenue
and$12.5billionin operating
incomethispast fiscal year.
Wedelivered$30.0 billion in revenue
and$16.5billionin operating
incomethispast fiscal year.
Wedelivered$36.0 billion in revenue
and$20.3billion in operating
incomethispast fiscal year.
Wedelivered$42 billion in revenue
and$26.2billion in operating
incomethispast fiscal year.
Wedelivered$48 billion in revenue
and$28.8billion in operating
incomethispast fiscal year.
EXCELLENCEIN SERVICE GLOBALEXCHANGE PARTNERSHIP DIRECTSALES GLOBALCONNECTIONSEXPEDITEDEXECUTION
CUSTOMERSERVICE
Our timeline is a display of a list
of events in chronological order.
It is typically a graphic design
showinga long bar labelled with
dates alongside itself.
Ourmanufacturing is the production
of merchandise for use or sale
using labourand machines, tools,
chemical and biological processing,
orformulation.
Customer Interaction Management
(CIM) Customer interaction
management is the processfollowed
by companies to interact with its
customers.
Worldwide teamed up to conduct
a survey of more than 500
respondents focused on creating
effective leaders and preparing
the next generation.
TIMELINE WORLDWIDE PROJECTIONS
M ANUFACTURING O PTIONS
NORTHAMERICA UNITEDKINGDOM GERMANY CHINACHINA SOUTHKOREA JAPAN
TIMELINE MANUFACTURING CUSTOMERINTERATION GROWTHFORCAST WORLDWIDE DEVELOPMENT
Thisstatistic shows the year-over-year
growthof manufacturing and sales
Worldwide. Projections are from
2010to2060.
Wedelivered$22.0 billion in revenue
and$10.3billionin operating
incomethispast fiscal year.
Wedelivered$26.0 billion in revenue
and$12.5billionin operating
incomethispast fiscal year.
Wedelivered$30.0 billion in revenue
and$16.5billionin operating
incomethispast fiscal year.
Wedelivered$36.0 billion in revenue
and$20.3billion in operating
incomethispast fiscal year.
Wedelivered$42 billion in revenue
and$26.2billion in operating
incomethispast fiscal year.
Wedelivered$48 billion in revenue
and$28.8billion in operating
incomethispast fiscal year.
EXCELLENCEIN SERVICE GLOBALEXCHANGE PARTNERSHIP DIRECTSALES GLOBALCONNECTIONSEXPEDITEDEXECUTION
CUSTOMERSERVICE
Our timeline is a display of a list
of events in chronological order.
It is typically a graphic design
showinga long bar labelled with
dates alongside itself.
Ourmanufacturing is the production
of merchandise for use or sale
using labourand machines, tools,
chemical and biological processing,
orformulation.
Customer Interaction Management
(CIM) Customer interaction
managementis the process followed
by companies to interact with its
customers.
Worldwide teamed up to conduct
a survey of more than 500
respondents focused on creating
effective leaders and preparing
the next generation.
The process of improving some
measure of an enterprise's success.
Business growth can be achieved
either by boosting the top line
or revenue of the business.
100W PD Adapter
Ethernet Router
Monitor or Projector
HDMI max 4K@30Hz
Host Computer with
USB Type-C
Monitor or Projector
VGA max 1920x1200@60Hz
USB-A (Port2) Devices
max 5Gbps
USB-A (Port1) Devices
max 5Gbps 1.5A
WARNING: Please follow these safety instructions. Failure to do so may result damages or injury.
It is normal that the Rocstor Multi-port Hub adapter becomes very warm during use.
Please note that:
continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to
reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around
the Rocstor Multi-port Hub adapter and use care when handling it. Avoid instances where your skin is
in extended contact with the hub when plugged into the host computer. It is not recommended to
sleep with the adapter when plugged into a host computer. Avoid placing the hub adapter under a
pillow, blanket, or your body when connected to a host computer. If you have a medical condition
that affects your ability to detect heat against the body, extra care should be used. Never use the
adapter in locations with water, such as a sink, bathtub, or shower stall. Never connect or disconnect
the adapter with wet hands.
!
Limitation of Liability
In no event shall the liability of Rocstorage, Inc. and Rocstor (or their officers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of
the product exceed the actual price paid for the product. Some states do not allow the exclusion or
limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Warranty Information
This product is backed by a (2)two-year warranty. Rocstor warrants its products against defects in
materials and workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products at our
discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from
defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Connection Diagram
