ROCWARE RC91 User manual

4K PTZ Video Conference
Camera
RC91 uses a new generation of Sony 1 / 2.8 inches high-quality UHD CMOS sensor with a
maximum of 8.4 million pixels to output 4K (3840x2160) ultra-high resolution images,
downward compatible with 1080P, 720P and other resolutions.󶀅Suppo HDMI2.0, can directly
output 4KP60 uncompressed digital video. Combined with AI tracking and smooth PTZ
function, it is used for live events, auditorium lectures, spos and game competitions, online
and distance learning courses, multinational conferences, personnel training courses, live
streaming and other application scenarios.
RC91

Main Features
4K Ultra HD
Using a new generation of Sony 1 / 2.8 inches, up to
8.4 megapixel high-quality UHD CMOS sensors to
output 4K (3840x2160) ultra-high resolution images,
downward compatible with 1080P, 720P and other
resolutions.
AI intelligent tracking
Built-in AI processor, using deep learning
technology through human shape features, no
matter where the face is facing, it can achieve
smooth automatic tracking, which is ve suitable
for automatic target tracking in lectures, speeches,
teaching and other scenes.
12x optical zoom
Using high-quality 8 million ultra-high-resolution
4K ultra-telephoto lens, 12x optical zoom to
capture cstal-clear images with a eld of view of
80.8° ~ 7.5° .
255 presets
Rocware’s unique auto patrol feature optimizes
your camera controls to capture content auto-
matically and seamlessly between your preset
areas.With preset area tracking,you only need
a RC91 to peorm seamless switching of all
your preset areas, giving your videos a wide
variety of shooting ranges.
HDMI2.0
Suppo HDMI2.0 inteace to directly output
4KP60 uncompressed digital video. Equipped with
3G-SDI inteace, the eective transmission
distance is up to 150 meters (1080p30).
Low Illumination
New CMOS image sensor with ultra-high SNR can
eectively reduce the image noise under low
illumination. Meanwhile, the application of 2D and
3D noise reduction algorithms dramatically reduces
image noise. The image maintains clean and clear
even under ultra-low light illumination. The SNR of
the image is as high as 55dB or above.
4k

Product Inteace
Remote Control
Remote control
Multiple control modes, RS232, RS485, network
and USB can be used to control the camera.
Intelligent Exposure
Eectively solve the impact of projection, TV and
other equipment on the shooting of people
1. RESTORE
2. HDMI
3. 3G-SDI
4. LINE IN
5. RS485
6. USB
7. RS232 OUT
8. RS232 IN
9. LAN(PoE+)
10. DC 12V
11. ON/OFF
ON
1 3 4 5 6 7 8 92 10 11
RESTORE HDMI 3G-SDI LINE-IN RS485 USB OUT IN LAN(PoE+)
RS232 DC12V OFF
1.(Standby) Key
Press to enter standby mode. Press again to resume
to normal mode.
2.Numeric Key: To set preset or call preset.
3.* Key: Use with other keys.
4.PRESET Key
Set preset: Store a preset position.
[PRESET] + Numeric key (0-9): Set the preset position.
5.HOME Key
Conrm selection or press to turn the lens back to
the middle position.
6.(Return) Key: Press to return to the previous menu.
7.ZOOM Key
9.FOCUS Key
Press [AUTO] to adjust the focus automatically.
Press [MANUAL] to adjust the focus manually.
When in manual focus mode, press [FAR] to focus
on far object or [NEAR] to focus on near object.
8.L/R SET Key
10.CAMERA SELECT Key
Press the button corresponding to the camera
you want to operate with the remote controller.
Use with other buttons.
12.Auto Tracking Key
[F1]: Not enabled
[F2]: Not enabled
[F3]: Sta AI Intelligent Tracking
[F4]: Stop AI Intelligent Tracking
15.MENU Key
Enter or exit OSD MENU.
17.P/T RST (PTZ Reset) Key
16.BACKLIGHT Key
Backlight ON/OFF: Press repeatedly to
enable or disable the backlight compensation.
14.PTZ Control Key
After zooming, press arrow button to peorm
panning and tilting. Press [HOME] button to
face the camera back to front.
11.# Key

Product Specications
Rocware resees right of nal interpretation for this catalogue.
ROCWARE CORPORATION
Web : www.rocware.com
TEL : [phone]
Address : 3F, No.2 Building, Honghui Industrial Park,
Baoan District, Shenzhen, China
Mail : [e-mail]
Camera
Sensor
Video System
Scanning Mode
Lens
Progressive
12x, f = 3.4mm ~ 41.6mm, F1.8 ~ F3.7
Minimal Illumination 0.5Lux @ (F1.8, AGC ON)
Digital Zoom 16x
Shutter
White Balance
Digital Noise Reduction
Signal Noise Ratio
Horizontal Angle
of View
Veical Angle of View
Horizontal Rotation
Range
Veical Rotation
Range
Pan Speed Range
Veical Rotation
Speed Range
H & V Flip
Image Freeze
Number of Preset
Preset Accuracy
Backlight Compensation
1/30s ~ 1/10000s
Auto, Indoor, Outdoor, One Push, Manual
Suppo
3D Digital Noise Reduction
≥55dB
80.8° ~ 7.5°
49.9° ~ 4.3°
±162.5°
-30° ~ +90°
1.8°/s ~ 80.5°/s
1.5°/s ~ 49°/s
Suppo
Suppo
255
0.1°
1/2.8 inch, CMOS, Max Eective Pixel: 8.40M
HDMI: 4KP25, 4KP30, 4KP50,4KP60,
4KP59.94, 4KP29.97, 1080P25, 1080P30,
1080P50, 1080P60, 1080P59.94,
1080P29.97, 1080I50, 1080I60, 1080I59.94,
720P50, 720P59.94, 720P60
3G-SDI: 1080P25, 1080P30, 1080P50,
1080P60, 1080P59.94, 1080P29.97,
1080I50, 1080I60, 1080I59.94, 720P50,
720P59.94, 720P60
Inteace/Indicator
LINE IN Inteace
Communication
Inteace
USB Inteace
LAN(PoE+) Inteace
3G-SDI Inteace
Restore Button
Power Jack
Tally Indicator
Power Indicator
Status Indicator
Display Screen
Power Switch
1 x Tally Indicator
1 x Power Indicator
1 x Status Indicator
1 x Display Screen
1 x Power Switch
1 x RJ45: 10/100/1000M,Adaptive
Ethernet Po. It suppos PoE+
1 x HDMI: Version 2.0
JEITA type（DC IN 12V）
1 x USB 2.0: Type-C
1 x Restore Button
HDMI Inteace
1 x 3G-SDI: BNC type, 800mVp-p, 75Ω.
Along to SMPTE 424M standard
1 x LINE IN: 3.5mm Audio Inteace
1 x RS485: 3pin phoenix po, Max Distance:
1200m, Protocol: VISCA / Pelco-D / Pelco-P
1 x RS232 OUT: 8pin Min DIN, Max Distance:
30m, Protocol: VISCA network use only
1 x RS232 IN: 8pin Min DIN, Max Distance:
30m, Protocol: VISCA / Pelco-D / Pelco-P
Video Format
USB Video
Communication Protocol
UVC PTZ
Suppo
YUY2: max to 1080P@30fps
H.264 AVC/SVC: max to 2160P@30fps
H.265 SVC: max to 2160P@30fps
MJPEG: max to 2160P@30fps
UVC 1.1~1.5
Suppo
USB Features
Video System
Color System /
Compression
USB Audio
Windows 7, Windows 8, Windows 10,
Mac OS X, Linux, Android
YUY2 / MJPEG / H.264 / H.265
Network Features
Video Compression
Video Stream
First Stream Resolution
Sub Stream Resolution
Bit Rate Control
Frame Rate
Audio Compression
Audio Bit Rate
Suppo protocols
First Stream, Second Stream
3840x2160, 1920x1080, 1280x720, etc.
720x480, 720x408, 640x480, 640x360,etc.
CBR, VBR
50Hz: 1fps ~ 50fps, 60Hz: 1fps ~ 60fps
G711A, AAC
96Kbps, 128Kbps
NDI®|HX, TCP/IP, HTTP, RTSP, RTMP(S),
ONVIF, DHCP, SRT, Multicast, etc.
H.264 / H.265 / MJEPG
