Rodak CleanStation 5 User manual

Instruction manual
™
Wet & dry vacuum cleaner
Attention: Before assembly and starting operation, read the operating instructions carefully.
Check that the mains voltage corresponds to the details on the type plate.
Only connect to proper 230 volt, 50 Hz.
Minimum fuse protection 10 A.
Pull the mains plug out of the socket when : the unit is not in use, before cleaning and
maintenance.
Never clean the unit with solvents.
Do not use the cable to pull the plug out of the socket.
When unit is ready for use, do not leave it unattended.
Safeguard from children.
Care must be taken that the mains connection lead is not damaged by being driven over,
crushed, stretched etc.
The unit must not be operated if the mains connection lead is not in perfect condition.
On no account vacuum: burning matches, glowing ashes and cigarette ends, inflammable,
corrosive, fire hazard or explosive substances, vapours, liquids and strong foaming
substances.
This unit is not suitable for vacuuming dust which is damaging to health.
Store the unit in a dry place.
Do not operate a defective unit.
Servicing only by an authorized after-sales service point.
Unit should be used in dry place.
Damaged mains connections cable must be replaced by qualified person only.
Use only for operations for which the unit is intended.
Great care must be taken when cleaning stairs.
Use only manufacturer’s attachments and spare parts.
Keep nozzles and tube ends properly covered.
Never use unit without filters.
Parts conducting electricity (supply cord, plug, motor, switch) should never come into
contact with water.
IMPORTANT NOTES
COMPONENTS DESCRIPTION:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Handle
Exhaust opening
Hose connector
Flexible vacuum hose
Wheels
ON / OFF switch
Supply cord
Supply cord holder
Float
Filter basket
Head
Hook fastener
Vacuum tubes ( 2 pieces)
Tank
Combi Brush
10
9
8
7
6
CleanStation 5
1
211
12
3
4
13
14
5
15

WET VACUUMING
DRY VACUUMING
Assembly
Cellular foam filter
Paper bag + cellular foam filter
Open the container’s locks and remove the apparatus head from container. (Fig. 2 & 3)
From the accessories placed in container, take out the revolving wheels.
Place the container with the opening down.
Mount the wheels on the container. (Fig. 5)
Put the container on the wheels.
Fix the floor brush on extension tube.
Pull the foam filter over the basket. (Fig. 6a)
Fix the apparatus head again on the container. (Fig. 3)
Fix the adapter on the suction tube with a screw (Fig. 12)
The adapter is intended for parking the tube on the vacuum cleaner (Fig. 13)
Wind the connection cord around the head and fix it with the holder on the vacuum
cleaner handle.
Put the accessories on the corresponding places of the vacuum cleaner (Fig. 13).
Join the suction tubes, fix the desired accessories onthe tube with adapter.
Fix the suction hose on the vacuum cleaner container.
Fix the suction tubes on the suction hose.

WET VACUUMING
For wet suction only the foam material cartridge (foam filter) is used, which is pulled
over the basket. The paper bag is not used for wet suction (it has to be removed from
the vacuum cleaner). When a specific level is reached by liquid in the container, the float
will shut the air flow and higher vacuum cleaner tone is heard (lauder operation), meaning
that the container is full. Switch off the vacuum cleaner and unplug the cord. Upon
completion of the sucking operation, empty the container, wipe it up with a dry cloth and
dry the foam filter.
DRY VACUUMING
For dry suction the dry foam filter and paper dust bag are used. A new
dust bag is put upon the container’s connection (see the apparatus assembling, fig. 6b).
When the dust bag is put on the connection, push it to the stop. When the dust bag is
full (the vacuum cleaner does not draw well), it should be replaced by new one.
The dust bag has to be replaced as necessary.

Tel. (91) (0832) 322 66 54 / 2 858 555 Mobile : [phone] Fax : [phone]
Mumbai : 09371915010 / Delhi : (0931) 350 66 03 / Pune : (0937) 245 53 44
Bangalore : (0934) 216 22 26 / Kerala : (0944) 666 53 49 / Gujarat : (9325) 855 344
Chattisgarh : (0930) 228 92 22 / Chennai : (0938) 140 77 70
Blowing
Cleaning and maintenance
With attaching hose connector into exhaust opening it is possible to obtain blowing function.
The vacuum cleaner container and casting have to be cleaned periodically. Wash the soiled
container with water. After rinsing or wet suction dry up the container using a dry cloth.
Clean periodically the foam filter, too; wash it with mild detergents in water. The vacuum
cleaner equipped with outlet filters which can be easily replaced. Clean or replace the filters
as necessary. If the appliance doesn’t function in satisfactory manner (decrease of suction
power), check the dust bag is not filled up; if it is, replace it with a new one. The frequent
cause of unsatisfactory vacuum cleaner operation can be obstructed accessories parts and
tubes. In this case these parts of the vacuum cleaner have to be cleaned.
