Roemheld RA 60 K User manual

Operating Manual
BA_L4202_EN
Issue 11-2016
Römheld GmbH • Postfach 1253 • 35317 Laubach • Germany • Tel.: [phone] / 89-0 • Fax: [phone] / 89-211
www.roemheld-gruppe.de
Subject to change without notice! Translation of the original German document 1 / 7
Linear Actuator RA 60 K
Max. lifting force 300 to 600 N, stroke from 100 to 200 mm,
Version with limit switch or stroke measuring system
Table of contents
1Description of the product 1
2Validity of the documentation 1
3Target group of this document 2
4Symbols and signal words 2
5For your safety 2
6Application 2
7Installation 3
8Start up 4
9Maintenance 5
10 Trouble shooting 5
11 Technical characteristics 6
12 Accessory 6
13 Disposal 6
14 Declaration of incorporation 7
1 Description of the product
Linear actuators RA 60 K consist of a direct current drive (volt-
age see technical characteristics), whose drive energy is trans-
ferred over a planetary gear and a spindle lifting gear to the
pushing rod.
The generated lifting force is available as push and pull force.
Linear actuators without stroke measuring systems are
equipped with internal limit switches. These avoid unintended
overrun and overload of the mechanical stop positions.
The end positions of linear actuators with stroke measuring
system are definable by the signal of the stroke measuring sys-
tem.
The sturdy design with code class IP69K guarantees a trouble-
free function also in rough operating conditions.
Linear actuators are maintenance free and can be operated
with a duty cycle of up to 15%.
Version with limit switches
The version with limit switches has 2 integrated sensors, which
automatically switch off the motor as soon as the upper or
lower stroke end position is obtained. This guarantees that the
linear actuator does not mechanically push against the stop.
Version with stroke measuring system
The version with absolute stroke measuring system is equipped
with a linear potentiometer. A slider at the pushing rod pro-
duces a signal at the potentiometer, that is proportional to the
position of the pushing rod. This signal can easily be evaluated
by a priority control and is permanently available. Referencing
is not required. Due to the direct connection of the absolute
stroke measuring system to the pushing rod, one gets a precise
stroke information with slight backlash. This linear actuator is
equipped with a potentiometer and a subsequent amplifier that
generates a standardised output signal independent of the
stroke length. With the stroke measuring system, control-ori-
ented applications and the compound of several linear actua-
tors in synchronism can be realised.
2 Validity of the documentation
This operating manual is valid for linear actuators of the follow-
ing types:
RA 60 K –12 V DC
Part no.: F2-XX-XX-1-C-AS3A (with stroke end disconnec-
tion)
Part no.: F2-XX-XX-1-C-AS3A (with stroke measuring sys-
tem)

Operating Manual
BA_L4202_EN
2 / 7
3 Target group of this document
•Experts for installation and maintenance with electro-me-
chanical know-how.
Qualification of the personnel
Expert knowledge means that the personnel must
•be in the position to read and completely understand tech-
nical specifications such as circuit diagrams and product-
specific drawing documents,
•have expert knowledge (electric, hydraulic, pneumatic
knowledge, etc.) of function and design of the correspond-
ing components.
An expert is somebody who has due to its professional educa-
tion and experiences sufficient knowledge and is familiar with
the relevant regulations so that he
•can judge the entrusted works,
•can recognize the possible dangers,
•can take the required measures to eliminate dangers,
•knows the acknowledged standards, rules and guidelines of
the technology.
•has the required knowledge for repair and mounting.
4 Symbols and signal words
WARNING
Person damage
Stands for a possibly dangerous situation.
If it is not avoided, death or very severe injuries will result.
CAUTION
Easy injuries / property damage
Stands for a possibly dangerous situation.
If it is not avoided, minor injuries or material damages will re-
sult.
Hazardous to the environment
The symbol stands for important information for the
proper handling with materials that are hazardous to
the environment.
Ignoring these notes can lead to heavy damages to
the environment.
Note
This symbol stands for tips for users or especially useful infor-
mation. This is no signal word for a dangerous or harmful situa-
tion.
5 For your safety
5.1 Basic information
The operating instructions serve for information and avoidance
of dangers when installing the products into the machine as
well as information and references for transport, storage and
maintenance.
Only in strict compliance with these operating instructions, acci-
dents and property damages can be avoided as well as trouble-
free operation of the products can be guaranteed.
Furthermore, the consideration of the operating instructions will:
•avoid injuries
•reduce down times and repair costs,
•increase the service life of the products.
5.2 Safety instructions
Sicherheitshinweis eT eil 1aSdfsd
The product was manufactured in accordance with the gener-
ally accepted rules of the technology.
Observe the safety instructions and the operating instructions
given in this manual, in order to avoid personal damage or ma-
terial damage.
• Read these operating instructions thoroughly and com-
pletely, before you work with the product.
• Keep these operating instructions so that they are accessi-
ble to all users at any time.
• Pay attention to the current safety regulations, regulations
for accident prevention and environmental protection of the
country in which the product will be used.
• Use the ROEMHELD product only in perfect technical con-
dition.
• Observe all notes on the product.
• Use only accessories and spare parts approved by the
manufacturer in order to exclude danger to persons be-
cause of not suited spare parts.
• Respect the intended use.
•You only may start up the product, when it has been found
that the incomplete machine or machine, in which the prod-
uct shall be mounted, corresponds to the country-specific
provisions, safety regulations and standards.
•Perform a risk analysis for the incomplete machine, or the
machine.
Due to the interactions between the product and the ma-
chine/fixture or the environment, risks may arise that only
can be determined and minimized by the user, e.g. :
- generated forces,
- generated movements,
- Influence of hydraulic and electrical control,
- etc.
6 Application
6.1 Intended use
The product was exclusively designed as an actuating element,
that is not relevant for safety, for the application in the mobile
automotive engineering, conveyor and dosing technology, com-
munal technology as well as agricultural and forest technology.
The product is provided for fixation as per figure 1.
Figure
1
: Mounting
1User's fixed construction
2 User's construction, par-
allel to the centre line,
protected against torsion
and axially displaceable
3 User's fixing bolt with
safety element
4 User's fixing bolt with
safety element

Operating Manual
BA_L4202_EN
3 / 7
Furthermore the following belongs to possible uses:
•Use within the performance data indicated in the chapter
"Technical characteristics".
•The product must only be exposed to push or pull loads.
•Use as per operating instructions.
•Mounting as described in figure 1.
NOTE
Durability and environment tests.
The product is designed for the use in outdoor applications and
is correspondingly resistant to corrosion.
•Before using this product the user has to check the usability
of the product for its application by own durability and envi-
ronment tests.
6.2 Misapplication
WARNING
Injuries, material damages or malfunctions!
•The product must never be opened. At the product no
changes must be made, except the ones expressly men-
tioned in the operating instructions!
The use of these products is not admitted:
•For domestic use.
•On pallets or machine tool tables in primary shaping and
metal forming machine tools.
•In areas for which special guidelines apply, especially in-
stallations and machines:
- For the use on fun fairs and in amusement parks.
- In food processing or in areas with special hygiene regu-
lations.
- In mines.
- In explosive and aggressive environments (e.g. ATEX).
•For other operating and environmental conditions.
Special solutions are available on request!
7 Installation
7.1 Design
Figure
2
: Components
1Fork head, at the front
2 Pushing rod
3 Housing
4 Fork head, at the rear
5 Cable
6 Cable wires isolated with
wire bushs
7.2 Circuit diagrams
7.2.1 Version with limit switches
Figure
3
: for RA 60 K with limit switch
awhite
+ (extend)
- (retract)
bbrown
- (extend)
+ (retract)
Remaining cable ends not
connected!
Note
RA 60 K with limit switches cannot be operated in synchronism.
7.2.2 Version with stroke measuring system
Figure
4
: for RA 60 K with stroke measuring system
awhite
+ (extend)
- (retract)
bbrown
- (extend)
+ (retract)
cyellow Poti output
d grey Poti ground
e Poti reference +

Operating Manual
BA_L4202_EN
4 / 7
Note
The version with (absolute) stroke measuring system is
equipped with a linear potentiometer.
This is evaluated according to the potentiometer principle (volt-
age divider).
For this purpose port d is connected to the reference potential
(0 V) and port e to the constant reference voltage.
At port c only a voltage can be tapped that is proportional to the
position of the pushing rod.
Thus, in retracted mode of the pushing rod a voltage can be
measured near the reference potential and in extended mode
near the reference voltage.
Generally the voltage at port c is connected to an analogous in-
put of the priority control, where it is evaluated.
The input resistance of the analogous input must be >1M ohm
to avoid any influences on the linearity of the absolute stroke
measuring system.
7.3 Mounting - installation
WARNING
Injury / burning due to contact with energized parts!
•Before working on electric equipment, the energized parts
must be de-energized and secured.
•Do not open protection covers at electric parts.
•All electrical works must only be realised by electricians.
Injury by crushing!
Components of the product make a movement while they are in
operation.
•This can cause injuries.
•Keep parts of the body and items out of the working area!
CAUTION
Injury by rotating parts!
The product does not have an anti-torsion device. The extend-
ing pushing rod and mounting parts can rotate.
•Operate the product only in installed condition.
Side loads and forced conditions on the product lead to
the premature failure.
•If required, provide external guides.
•Avoid forced conditions (overdetermination) of the product.
•Max. forces and torques see technical characteristics.
Fixing the connecting cable
• The cables must be fixed by the user so that no bending and
tensile stress will act and the cable cannot be damaged in
any way.
Component damage caused by faulty control
Use control of data sheet M 8.200.
If user's control is provided, this control must be equipped with
the following functions:
•switching off in case of over-current as protection against
blockade, collision, etc.
•current limitation as protection against damages,
•switching off in case of short circuits as protection against
overheating and fire, etc. and
•recognition of defect displacement transducer as protection
against damages, etc.
Do not approach the mechanical stops
It has to be guaranteed by the user's control that the element
will not be moved to the internal mechanical end positions.
1.Disconnect user's control from the voltage network.
2.Prepare the user's construction to mount the product. Pay
attention to sufficient freedom of motion.
3.Connect the product with the fork head at the front ant at
the rear by means of the user's fixing bolts to the user's
construction.
4.Secure the fixing bolts with convenient components of the
user.
Figure
5
: Installation of the product
1User's fixed construction
2 User's construction, par-
allel to the centre line,
protected against torsion
and axially displaceable
3 User's fixing bolt with
safety element
4User's fixing bolt with
safety element
5.Place and fix the cable.
6.Connect all cable wires to the terminal strip, as per circuit
diagram of the product and user's terminal connection plan,
of the user's control.
7.Connect user's control to the voltage network.
Note
We recommend to install the cable ends or plug-type connect-
ors protected against the environmental conditions to avoid
penetration of humidity and premature corrosion.
8 Start up
Before putting into operation the product, an installation inspec-
tion has to be made.
WARNING
Injury by crushing!
Components of the product make a movement while they are in
operation.
•This can cause injuries.
•Keep parts of the body and items out of the working area!
CAUTION
Performance of the product!
The admissible performance data of the product, see chapter
"Technical characteristics", may not be exceeded.
The installation control includes the following:
No side loads may act on the product.
No torques may act on the product.
The product must be connected to the user's construction
with both fork heads by means of a secured fixing bolt.

Operating Manual
BA_L4202_EN
5 / 7
The product must be completely connected to the user's
control as per the corresponding circuit diagram and the us-
er's terminal diagram.
If the above requirements are not met, the product must not be
put into operation.
8.1 Operation
WARNING
Injury by crushing!
Components of the product make a movement while they are in
operation.
•This can cause injuries.
•Keep parts of the body and items out of the working area!
CAUTION
Performance of the product!
The admissible performance data of the product, see chapter
"Technical characteristics", may not be exceeded.
Component damage caused by faulty control
Use control of data sheet M 8.200.
If user's control is provided, this control must be equipped with
the following functions:
•switching off in case of over-current as protection against
blockade, collision, etc.
•current limitation as protection against damages,
•switching off in case of short circuits as protection against
overheating and fire, etc. and
•recognition of defect displacement transducer as protection
against damages, etc.
Do not approach the mechanical stops
It has to be guaranteed by the user's control that the element
will not be moved to the internal mechanical end positions.
The product must only be operated with a suitable control.
9 Maintenance
The product is maintenance free within the indicated service
life.
9.1 Cleaning / disinfection
CAUTION
Do not clean the product in operation
In accordance with code class IP69K the product is provided for
the cleaning with high-pressure cleaners.
•This code class is not guaranteed during retracting and ex-
tending.
•Do not clean the product in operating mode.
•A minimum distance of 30 cm between the nozzle of the
high-pressure cleaner and the product is to be kept.
Material damage, damage or functional failure
Aggressive cleaning agents can cause damage, especially to
seals.
The product must not be cleaned with:
•corrosive or caustic substances or
•organic, solvents such as halogenated or aromatic hydro-
carbons and ketones (cellulose thinner, acetone, etc.).
9.2 Service life
The service life is designed for 20,000 cycles (extending/re-
tracting).
10 Trouble shooting
WARNING
Injuries, material damages or malfunctions!
•The product must never be opened. At the product no
changes must be made, except the ones expressly men-
tioned in the operating instructions!
Trouble
Cause
Remedy
Pushing rod does
not extend or re-
tract after control
No supply voltage
Check and restore
supply voltage
User's construc-
tion too stiff
Check and restore
smooth running
Actuating range of
the user's con-
struction is
jammed by an
item or dirt
Remove item, dirt
Cable break
Immediately put
the product out of
operation and
send it to
Römheld GmbH
Motor, gear or
spindle nut defect
Immediately put
the product out of
operation and
send it to
Römheld GmbH
strongly-reduced
speed
User's construc-
tion too stiff
Check and restore
smooth running
Motor, gear or
spindle nut defect
Immediately put
the product out of
operation and
send it to
Römheld GmbH
Supply voltage
too low
Check and in-
crease supply
voltage, if re-
quired
Stroke end dis-
connection does
not function
(only F2-XX-XX-
X-C-ES3A)
Limit switch defect
Immediately put
the product out of
operation and
send it to
Römheld GmbH
Measuring signal
stroke measuring
system incorrect
(only F2-XX-XX-
X-C-AS3A)
Cable damaged
Immediately put
the product out of
operation and
send it to
Römheld GmbH
Potentiometer de-
fect
Immediately put
the product out of
operation and
send it to
Römheld GmbH

Operating Manual
BA_L4202_EN
6 / 7
10.1 Repair
WARNING
Injuries, material damages or malfunctions!
•The product must never be opened. At the product no
changes must be made, except the ones expressly men-
tioned in the operating instructions!
NOTE
Repair of electrical components
•Repair works, as e.g. the change of electric components
may only be effected by the service technicians of the com-
pany Römheld.
11 Technical characteristics
Max. pull / push force
F2-03-XX-1-C-XS3A
F2-06-XX-1-C-XS3A
[N]
300
600
Speed at max. pull / push force
(at 13.8 V and 20°C)
F2-03-XX-1-C-XS3A
F2-06-XX-1-C-XS3A
[mm/s]
20 +- 20%
9+- 20%
Speed at idle running
(at 13.8 V and 20°C)
F2-03-XX-1-C-XS3A
F2-06-XX-1-C-XS3A
[mm/s]
30 +- 20%
16 +- 20%
Stroke
F2-XX-10-1-C-XS3A
F2-XX-15-1-C-XS3A
F2-XX-20-1-C-XS3A
[mm]
100 +3 -2
150 +3 -2
200 +3 -2
Nominal supply voltage
[V]
12
Adm. supply voltage
[V]
10...16,6
Max. residual ripple
[%]
10
Max. current consumption at max.
pull/push force
[A]
3,5
Max. input power
[W]
50
Max. adm. duty cycle
[ ]
15 %, 1.5
min ON
Protection class as per VDE
0100-40
III
Code class
IP 69 K
Admissible mounting position
any
Adm. environment conditions
(storage and operation)
[°C]
-20 ...+70
Adm. cleaning temperature
[°C]
70 for 5 min
Adm. relative humidity
[%]
30…90 not
condensing
Adm. environmental pressure
[hPa]
700…1060
Only for type with stroke measuring system
(F2-XX-XX-1-C-AS3A)
Connecting resistance
[k]
5
Linearity
[%]
+- 1
Load at 40°C
[W]
0.5
Max. supply voltage for WMS at
connection e
[V]
50
NOTE
In the case of a current consumption exceeding 5 A the user's
control must switch off the product after 10 sec. at the latest.
NOTE
Specifications
•For further technical data see installation drawing of the
product.
12 Accessory
WARNING
Injury / burning due to contact with energized parts!
•Before working on electric equipment, the energized parts
must be de-energized and secured.
•Do not open protection covers at electric parts.
•All electrical works must only be realised by electricians.
To connect the cable, the kit of plug-type connectors AMP Su-
perseal 5 Pol (part-no. 3823-088) consisting of plug and socket
with seals can be used.
Figure
6
: Kit of plug-type connectors AMP Superseal 5 Pol
Professional mounting of plugs and sockets should be made
according to the specifications of the manufacturer Typco Elec-
tronics for the plug-type connector kits.
13 Disposal
Hazardous to the environment
Due to possible environmental pollution, the indi-
vidual components must be disposed only by an
authorised expert company.
The individual materials have to be disposed as per the existing
regulations and directives as well as the environmental condi-
tions.
For the disposal of electrical and electronic components (e.g.
stroke measuring systems, proximity switches, etc.) country-
specific legal regulations and specifications have to be kept.

Operating Manual
BA_L4202_EN
7 / 7
14 Declaration of incorporation
Manufacturer
Römheld GmbH Friedrichshütte
Römheldstraße 1-5
35321 Laubach, Germany
Tel.: [phone] / 89-0
Fax: [phone] / 89-211
E-mail: [email protected]
www.roemheld.com
Responsible person for the documentation:
Dipl.-Ing. (FH) Jürgen Niesner, Tel.: [phone].
This declaration of incorporation applies to the following prod-
ucts:
This operating manual is valid for linear actuators of the follow-
ing types:
RA 60 K –12 V DC
Part no.: F2-XX-XX-1-C-AS3A (with stroke end disconnec-
tion)
Part no.: F2-XX-XX-1-C-AS3A (with stroke measuring sys-
tem)
The listed products are designed and manufactured in line with
the relevant versions of the directives 2006/42/CE (EC-MSRL)
and in compliance with the valid technical rules and standards.
In accordance with EC-MSRL, these products are not yet ready
for use and are exclusively designed for the installation in a ma-
chine, a fixture or a plant.
The following additional EU directives were applied:
•2006/42/EC, Machinery directive [www.eur-lex.europa.eu]
2014/30/EU EMC - Electromagnetic compatibility [www.eur-
lex.europa.eu]
•2011/65/EU, RoHS
The following harmonised standards have been applied:
DIN EN ISO 12100, 2011-03, Safety of machinery; Basic con-
cepts, General principles for design (replacement for part 1
and 2)
DIN EN 60204-1; 2007-06, Safety of machinery - Electrical
equipment of machines, Part 1: General requirements
The products may only be put into operation after it was as-
sessed that the machine, in which the product shall be in-
stalled, corresponds to the machinery directives (2006/42/EC).
The manufacturer commits to transmit the special documents of
the products to state authorities on request.
The technical documentation as per appendix VII part B was
prepared for the products.
Ralph Ludwig
Head of Research and Development
Römheld GmbH
Friedrichshütte
Laubach, 19.01.2022
