Rohnson Orleans R-930 User manual

Drip Coffee Maker “Orléans” R-930
INSTRUCTION MANUAL
Read this manual thoroughly before using and save it for future reference.

IMPORTANT SAFEGUARDS
When using electrical appliance. Basic safety precautions should always be followed including the
following:
1. Read all instructions.
2. Make sure that your outlet voltage corresponds to the voltage stated on the rating label of the coffee
maker.
3. To protect against fire, electric shock and injury to persons do not immerse cord, plug in water or
other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking
off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or
has been damaged in any manner. Return appliance to an authorized service facility for examination,
repair or adjustment.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
8. The use of accessory not recommended by the appliance manufacturer may result in fire, electric
shock or injury to persons.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter or touch hot surface.
11. Do not place on or near a hot gas or electric burner, or in a heated oven.
12. Do not use appliance for other than intended use.
13. Do not clean container with cleansers, steel wool pads, or other abrasive material.
14. To disconnect, turn any control to “Off”, remove plug from wall outlet.Always hold the plug. But
never pull the cord.
15. Scalding may occur if the cover is removed during the brewing cycles. Be careful not to get
burned by the steam.
16. Some parts of appliance are hot when operated, so do not touch with hand. Use handles or knobs
only.
17. Do not set a hot container on a hot or cold surface.
18. Never leave the empty carafe on the warming plate otherwise the carafe is liable to crack.
19. Never use the appliance if the carafe shows any signs of cracks or carafe having a loose or
weakened handle. Only use the carafe with this appliance. Use carefully as the carafe is very fragile.

20. Do not let the coffee maker operate without water.
21. To reduce the risk of fire or electrical shock, do not remove the cover. No user serviceable parts
inside. Repair should be done by authorized service personnel only.
22. The container is designed for use with this appliance. It must never be used on a range top.
23. The appliance must not be immersed.
24. Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and they understand the hazards involved.
25. This appliance can be used by children aged from 8 years and above if they have been given
supervision or instruction concerning use of the appliance in safe way and if they understand the
hazards involved. Cleaning and user maintenance shall not be made by children unless they are older
than 8 and supervised. Keep the appliance and its cord out of reach of children aged less than 8 years.
26. Children shall not play with the appliance.
27. This appliance is intended to be used in household and similar applications such as:
–staff kitchen areas in shops, offices and other working environments;
–farm houses;
–by clients in hotels, motels and other residential type environments;
–bed and breakfast type environments.
28. Save these instructions.

KNOWYOUR COFFEE MAKER
CONTROL PANEL
BEFORE THE FIRST USE
Check that all accessories are complete, and the unit is not damaged. Fill water into water tank to
the MAX level and brew water for several times without coffee powder, then discard the water.
Clean and dry all detachable parts thoroughly according to the section “CLEANING AND
MAINTENANCE”.

USING YOUR COFFEE MAKER
1. Open the water tank lid and fill the water tank with drinking water. The water level should not
exceed MAX level as indicated on the water gauge.
2. Place the funnel into the funnel support, make sure it is assembled correctly, otherwise the
water tank lid can not be closed. Place a paper filter in the funnel.
3. Add coffee powder into the paper filter. Usually, a cup of coffee needs a level spoon of coffee
powder, but you may adjust according to personal taste. Close the water tank lid completely.
4. Insert the glass carafe onto the warming plate horizontally.
5. Plug the power cord into the outlet. If you want to adjust the coffee strength, you can press
“Strength” button once, and then the LED indicator 2 will illuminate in orange and the appliance
will brew thick coffee. If you do not want to adjust the coffee strength, just follow the following
operation to brew normal coffee.
NOTE: Press the “Strength”button again if you want to cancel the function of brewing thick
coffee.
6. Press “On/Off”button, the LED indicator 1 illuminates in red, the display indicates “12:00”
then the appliance begins to work.
NOTE:During brewing process, the buttons of “Prog”, “Hour”and “Min”are invalid.
7. The brewing process can be interrupted by pressing the “On/Off”button at any time. And the
appliance will continue brewing once the “On/Off”button is pressed again.
NOTE: You can take out the carafe, pour and serve at any time. The appliance will stop dripping
automatically. But the time cannot exceed 30 seconds.
8. Remove out carafe to serve when finish brewing (about one minute later after the coffee stops
dripping out.)
NOTE: The coffee you get will be less than the water you have added, as some water is absorbed
by coffee ground.
9. When the process is finished, if you do not want to serve immediately, keep the coffee maker
be energized, and the coffee can be kept warm on the warming plate. And the appliance will shut
off automatically after 40 minutes from the ON/OFF button being activated if it has not been
manually disconnected at the completion of brewing. For an optimum coffee taste, serve it just
after brewing.
8. Always turn the appliance off and disconnect the power supply when not use.
NOTE: Pay attention to pour the coffee out, otherwise you may be hurt as the temperature of
coffee just finished is high.

DELAY FUNCTION
If you do not want the coffee maker to start operation immediately, for example now it is 8:10,
you hope that the coffee maker will automatically start working at 13:00, first follow steps 1 to 5
of above section, and then you can set the auto-start function as follows:
1. Set the current time by pressing “Hour”and “Min”button repetitively, that is 8:10.
NOTE: The time cycle is 24 hours.
2. Press “Prog”button once the LED indicator 1 blinks in white.
3. Set the auto-start time by pressing “Hour”and “Min”button repetitively that is 13:00. (Please
set it within 5 seconds).
4. Press the “Prog”button again, the LED indicator 1 illuminates in white solidly. After a while,
the display will indicate the current clock.
NOTE: You may cancel the auto-start function by pressing “Prog”button again. If you want to
change the auto-start time, only following the above 2-4 steps again.
5. When the time is due, the LED indicator 1 will illuminate in red and the appliance starts
brewing.
6. When the process is finished, if you do not want to serve immediately, keep the coffee maker
be energized, and the coffee can be kept warm on the warming plate. And the appliance will shut
off automatically after 40 minutes from the ON/OFF button being activated if it has not been
manually disconnected at the completion of brewing. For an optimum coffee taste, serve it just
after brewing.
NOTE: During brewing process, the buttons of “Prog”, “Hour”and “Min”are invalid.
CLEANINGAND MAINTENANCE
CAUTION: Be sure to unplug this appliance before cleaning. To protect against electrical shock,
do not immerse cord, plug or unit in water or liquid. After each use, always make sure plug is first
removed from wall outlet.
1. Clean all detachable parts after each use in hot sudsy water.
2. Wipe the exterior surface of unit with a soft, damp cloth to remove stains.
3. Water droplets may buildup in the funnel and drip onto the product base during brewing. To
control the dripping, wipe off the area with a clean, dry cloth after each use.
4. Use a damp cloth to gently wipe the warming plate. Never use abrasive cleaner to clean it.
5. Replace all parts and keep for next use.

REMOVING MINERAL DEPOSITS
To keep your coffee maker operating efficiently, periodically you should clean away the mineral
deposits left by the water according to the water quality in your area and the use frequency, we
recommend removing mineral deposits as follows:
1. Fill the tank with water and descaler to the max level as indicated on water gauge (the scale of
water and descaler is 4:1, the detail refers to the instruction of descaler. Please use “household
descaler”, you may also use the citric acid instead of the descaler (one hundred parts of water
and three parts of citric acid).
2. Insert the glass carafe onto the warming plate horizontally.
3. Make ensure funnel is assembled in place.
4. Switch on the appliance and allow it to “brew”de-scaling solution.
5. After “brew”one-cup solution, switch off the appliance.
6. Leave the solution stay for 15 minutes and repeat step 4-6.
7. Switch on the appliance and run off the solution until the water tank is completely empty.
8. Rinse by operating the appliance with water at least 3 times.
HINTS FOR GREAT-TASTING COFFEE
1. A clean coffee maker is essential for making great-tasting coffee. Regularly clean the coffee
maker as specified in the “CLEANING AND MAINTENANCE”section. Always use fresh,
cold water in the coffee maker.
2. Store unused coffee powder in a cool, dry place. After opening a package of coffee powder,
reseal it tightly and store it in a refrigerator to maintain its freshness.
3. For an optimum coffee taste, buy whole coffee beans and finely grind them just before
brewing.
4. Do not reuse coffee powder since this will greatly reduce the coffee’flavor. Reheating coffee is
not recommended as coffee is at its peak flavor immediately after brewing.
5. Clean the coffee maker when over-extraction causes oiliness. Small oil droplets on the surface
of brewed, black coffee are due to the extraction of oil from the coffee powder.
6. Oiliness may occur more frequently if heavily roasted coffees are used.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a dealer
providing this service.
Disposing of a household appliance separately avoids possible negative consequences for the
environment and health, deriving form inappropriate disposal and enables the constituent
materials to be recovered to obtain significant savings in energy and resources. As a reminder of
the need to dispose of household appliances separately, the product is marked with a crossed-out
wheeled dustbin.
