1
Induction Cooker
OPERATION MANUAL
R-2450
◆Please read the operation manual carefully before using and well keep this in a safe place for
future reference.

2
IMPORTANT SAFEGUARDS
When using electrical appliance, basic safety precautions should always be followed
including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plugs, or the whole unit in water or
other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or
taking off parts.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the nearest authorized
service facility for examination, repair, or adjustment.
7. The use of accessory attachments not recommended by the appliance manufacturer may
cause injuries.
8. Do not use outdoors
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or other hot
liquids.
12. Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect, turn
any control to “off”, then remove plug from wall outlet.
13. Do not use appliance for other than intended use.
14.Do Not Cook on Broken Cook-Top –If cook-top should break, cleaning solutions and
spillovers may penetrate the broken cook-top and create a risk of electric shock.
15. Clean Cook-Top with Caution –If a wet sponge or cloth is used to wipe spills on a hot
cooking area, be careful to avoid steam burn, some cleaners can produce noxious fumes if
applied to a hot surface.
16.Do not place metallic objects such as knives, forks, spoons and lids on the Table Stove since
they can get hot.
17.a) A short power-supply cord is to be provided to reduce risks resulting from becoming
entangled in or tripping over a longer cord.
b) Longer extension cords are available and may be used if care is exercised in their use.
c) If a long extension cord is used:
1) The marked electrical rating of the extension cord should be at least as great as the
electrical rating of the appliance;
2) The longer cord should be arranged so that it will not drape over the counter top or table
top where it can be pulled on by children or tripped over unintentionally.
SAVE THESE INSTRUCTIONS
NOTICE:
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of
electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not
fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not
modify the plug in any way.

3
Product Configuration
Control Panel
Power Cord
Exhaust Vent
Control Panel
Ceramic Plate
Power /TEMP/ Timer
Display
On / Off
lock
Functions
Power/TEMP/Timer
adjustment
Timer

4
After inserting the plug into the socket, a “Beep” will emit, the indicator above the [On/Off] key will
start to flash, the display lights are activated shortly so they can be checked for proper
functioning. And the display shows C
Press On/Off, LED display will be on, LED display show ON.
2.1Cooking Mode:
1. Power: Press the [Function] key, display will show [1600] representing that the default power is
1600W. It can be adjusted by pressing the [+] or [–] key to set the desired power. There are 10
power levels in total (200W, 400W, 600W, 800W, 1000W, 1200W, 1400W, 1600W, 1800W,
2000W). To cancel this mode, press [Function] key to switch to temperature setting mode or
[On/Off] key to stop the operation.
2. Temperature Celsius: Press the [Function] key twice, the display will show [240C] representing
that the default power is 240℃. It can be adjusted by pressing the [+] or [–] key to set the desired
Celsius. There are 10 Celsius levels in total (60℃, 80℃, 100℃,120℃,140℃,160℃,180℃, 200℃,
220℃, 240℃). To cancel this mode, press [Function] key to switch to power setting mode or
[On/Off] key to stop the operation.
3. Power and Temperature indication would be switched in turn when the user press the
[Function] key.
2.2 Timer Function:
User can set the cooking time when specific cooking mode is selected. Press the [Timer] key
once to access the timer function, the [TIMER] indicator will light up. Display will show the default
time [10], user can press [+] or [–] key to set for the desired time; [+] or [–] can adjust the minutes
by 1 minute. And if you hold the [+] or [–] key some time, the minutes could be adjusted by 10
minutes. The time can be adjusted from 1 minute to 240 minutes. After setting, user can press
[Timer] key once to confirm or wait until the display stop flashing. After the “Beep” signal, the
appliance will stop the operation and change to standby mode automatically when the end of the
countdown. To cancel this function, user can either press the [On/Off] key to return to standby
mode or hold the [Timer] key to resume the desired power or temperature operation.
2.3 Child Lock Function:
To prevent children from turning the cooktop on accidentally or changing the cooking settings,
press the CHILD LOCK button for a few seconds. the [CHILD LOCK] indicator will light up. and
the cooktop will not respond to power level, temperature or timer changes. You can press the
CHILD LOCK button either when the cooktop is operating, or when it’s turned off.
When the CHILD LOCK is on, the only button that will function is the ON/OFF button. To cancel
the children lockout, press the children safety button for at least 3 seconds, the light will go out
and the function is canceled.
3.Selection of Cookware
3.1 Material required:
Steel, cast iron, enameled iron, stainless steel, flat-bottom pans/pots with bottom diameter
from 12cm to 20cm.

5
So suggest to use the required pot, do not try to use other pot instead (especially pressure
sensors vessels.)
3.2 Please kindly according to the below requirement if necessary to use the vessel is not
equipped.
Pan/pot must be suitable for induction cooker.
Pan/pot should be tried out if it's bought by self to see if there are unusual phenomena.
Pan/pot bought by self should be flat and come with the cover with gas vent
4. Maintenance and Daily Care
1. Remove the power plug prior to clean the unit. Do not clean it until the surface cools down.
2. Glass plate, panel and the shell:
①Soft cloth for slight stain.
②For greasy, dirt, blot by using a clean damp cloth with neutral detergent.
3. While the radiator-fan working, dust and dirt would remain on the gas vent, please clean it by
brush or cotton stick regularly.
4. Remember do not washing the unit by water directly to avoid damaging.
5. To protect induction cooker, be sure to have a good contact between plug and socket before
using.
6. Do not pull out the power cord directly during operation. To extend the appliance's using life,
press the "ON/OFF" button first, then pull out the power cord.
7. In order to make operating time longer, the fan would still working for cooling the plate, it is
better to plug out after the fan stops working.
8. Please pull out the power cord and put it away when not used for a long time.
9. Some models have structural design to against cockroaches, if needed, can put something
like mothball to expel the cockroaches.
Any other servicing should be performed by an authorized service representative.
5. Troubleshooting and Treatment
During operations, if any error occurred, please check the following table before calling for
service. Below are common errors and the checks to perform.
Symptoms
Check points
Remedy
After connecting the
power and pressing the
“power” key, the
appliance has no
response.
Is the electricity in suspension?
Use after resuming the
electricity.
Is the fuse broken down?
Check the root causes
carefully. If the problem cannot
be fixed, please contact
Service Centre for checking
and repairing.
Is the plug connected firmly?
Magnetic stainless
steel pan
Stainless steel pot
Iron blast pan
Magnetic stainless
Iron pan
Stainless Steel pot
Iron board pan

6
Heating being
interrupted in normal
use and a “Beep” will be
heard.
Incompatible cookware or no
cookware is used?
Replace compatible cookware
for the induction cooker.
Is the cookware not considerably
placed form the center of the heating
zone?
Place the cookware at the
center of the defined heating
zone.
Is the cookware being heated but
continually being removed?
Place a cookware inside the
heating zone.
Symptoms
Check points
Remedy
No operation during the
heating being in use.
Is the cookware empty or the
temperature too high?
Please check whether the
appliance is being misused.
Is the air intake/exhaust vent clogged
or dirt has accumulated?
Remove the stuff clogging the
air intake/exhaust vent.
Operate the appliance again
after cooling down.
Is the cooker working over 2 hours
without any external instruction?
Reset cooking modes or use
timer function.
Error codes occur.
E0 Without cookware or Incompatible
cookware used
E1 IGBT sensor open circuit/short
circuit
E2 Internal overheat
E3 Over-voltage
E4 Under-Voltage
E5 Top plate sensor open/short
circuit
E6 Top plate overheat
When showing error signal E0,
E2 and E6, please check
whether the cookware is not
suitable, or switch on the
appliance again after it is
cooled down naturally. When
showing E1, E3-E5, please
contact Service Centre for
checking and repairing.
If the above remedies/controls can not fix the problem, unplug the appliance immediately,
contact Service Centre for inspection and repairing, note the error code and report it to Service
Centre Ltd. To avoid any danger and damage to the appliance, do not disassemble or repair it by
yourself.
6. Product Specifications
Model
R-2450
Rated Voltage
220-240V~50/60Hz
Power
2000W

7
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a dealer
providing this service.
Disposing of a household appliance separately avoids possible negative consequences for the
environment and health, deriving form inappropriate disposal and enables the constituent
materials to be recovered to obtain significant savings in energy and resources.As a reminder of
the need to dispose of household appliances separately, the product is marked with a
crossed-out wheeled dustbin.
