ROHS EmCORE-i2702 User manual

EmCORE-i2702
3.5” Miniboard
User’s Manual
Version 1.0
2010.10

This page is intentionally left blank.

- i -
Index
Contents
Chapter 1 - Introduction............................................ 1
1.1 Copyright Notice.........................................................2
1.2 About this User’s Manual...........................................2
1.3 Warning .......................................................................2
1.4 Replacing the Lithium Battery...................................3
1.5 Technical Support.......................................................3
1.6 Warranty ......................................................................4
1.7 Packing List.................................................................5
1.8 Ordering Information..................................................5
1.9 Specications .............................................................6
1.10 Board Dimensions....................................................7
1.11 Installing the Memory ...............................................8
Chapter 2 - Installation..............................................9
2.1 Block Diagram...........................................................10
2.2 Jumpers and Connectors ........................................11
Jumpers............................................................................12
CMOS Jumper Settings (JBAT1)...........................12
CF Card Select (J2) ................................................13
LCD Power (JVLCD1).............................................14
COM2 RS-232/422/485 Slect (JRS2) .....................15
Connectors.......................................................................16
External SMB Connector (JSMB1) .......................16
FRONT PANEL (JFRT1) .........................................17
Serial ATA (SATA1/SATA2).....................................18
RS-422/485 Serial Port (JCOM2) ...........................19
RS-232/422/485 Serial Port (COM2) ......................20
SATA Power Connector (J8)..................................21
3DUDOOHO3RUWConnector (LPT).............................22
LED for Ethernet (CN2)..........................................23
LAN Connector (LAN2)..........................................24
Audio Connector (AUDIO1)...................................25
USB Connector (USB2) .........................................26

- ii -
PWR-ATX Connector (PWR1/2).............................27
ATX Feature Connector (PWR3) ...........................28
AT Power Switch (JPWR1) ....................................29
TV Connector (TV1) ...............................................30
INVERTOR Connector (INV1) ................................31
LVDS LCD Connector (LVDS1)..............................32
Digital I/O (DIO1) ....................................................33
FAN Connector (SYSF1) ........................................34
2.3 The Installation Paths of CD Driver.........................35
Chapter 3 - BIOS......................................................36
3.1 BIOS Introduction.....................................................37
3.2 BIOS Setup................................................................38
3.3 Standard CMOS Features ........................................39
3.4 Advance BIOS Features ...........................................42
3.5 Advanced Chipset Features ....................................44
3.6 Integrated Peripherals..............................................46
3.7 Power Management Setup.......................................50
3.8 PNP/PCI Congurations...........................................52
3.9 PC Health Status.......................................................53
3.10 Load Optimized Defaults .......................................54
3.11 Set Password .........................................................55
3.12 Save & Exit Setup ...................................................56
3.13 Exit Without Saving................................................57
3.14 Award BIOS POST Codes ......................................58
Chapter 4 - Appendix......................................... 62
4.1 I/O Port Address Map ...............................................63
4.2 Interrupt Request Lines (IRQ)..................................64
4.3 BIOS memory mapping............................................65
4.4 Watchdog Timer (WDT) Setting...............................65
4.5 Digital I/O Setting......................................................66
Index

- 1 -
Introduction
1Chapter 1
Introduction

- 2 -
Introduction
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
1.2 About this User’s Manual
This User’s Manual is intended for experienced users and integrators with
hardware knowledge of personal computers. If you are not sure about any
description in this User’s Manual, please consult your vendor before further
handling.
1.3 Warning
Single Board Computers and their components contain very delicate
Integrated Circuits (IC). To protect the Single Board Computer and its
components against damage from static electricity, you should always follow
the following precautions when handling it :
Disconnect your Single Board Computer from the power source when you
want to work on the inside.
Hold the board by the edges and try not to touch the IC chips, leads or
circuitry.
Use a grounded wrist strap when handling computer components.
Place components on a grounded antistatic pad or on the bag that came
with the Single Board Computer, whenever components are separated
from the system.
1.
2.
3.
4.
1.1 Copyright Notice

- 3 -
Introduction
1.4 Replacing the Lithium Battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash-can. It must be disposed of in
accordance with local regulations concerning special waste.
1.5 Technical Support
If you have any technical difculties, please do not hesitate to call or e-mail
our customer service.
http://www.arbor.com.tw
E-mail:[e-mail]

- 4 -
Introduction
1.6 Warranty
This product is warranted to be in good working order for a period of two years
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty
does not apply to products damaged by misuse, modications, accident or
disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any
other incidental or consequential damage resulting from the use, misuse of,
or inability to use this product. Vendor will not be liable for any claim made by
any other related party.
Vendors disclaim all other warranties, either expressed or implied, including
but not limited to implied warranties of merchantibility and tness for a
particular purpose, with respect to the hardware, the accompanying product’s
manual(s) and written materials, and any accompanying hardware. This
limited warranty gives you specic legal rights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or
faxing the vendor and requesting a Return Merchandise Authorization (RMA)
number. Returned goods should always be accompanied by a clear problem
description.

- 5 -
Introduction
1.7 Packing List
1.8 Ordering Information
Before you begin installing your single board, please make sure that the following
materials have been shipped:
1 x EmCORE-i2702 3.5” Miniboard with heat sink
1 x Driver CD
1 x Quick Installation Guide
If any of the above items is damaged or missing, contact your vendor immediately.
EmCORE-i2702 Intel Atom™ N270 1.6GHz 3.5” Miniboard
CBK-8-3945-00
Cable Kit
1 x USB Cable
1 x KB & MS Cable
1 x Audio Cable
1 x SATA Cable
1 x COM Cable
1 x Print Cable
1 x LAN Cable
1 x IDE Cable

- 6 -
Introduction
1.9 Specications
Form Factor 3.5” Miniboard
CPU Intel® Atom™ N270 CPU 1.6GHz with 533MHz FSB
Chipset Intel® 945GSE + Intel® ICH7M
System Memory 1 x 200-pin DDR2 533MHz SO-DIMM Socket Up to 1GB
VGA/ LCD
Controller
Integrated Intel Graphics Media Accelerator 950, support
QXGA up to 2048 x 1546, LVDS support 18/36-bit, support
dual dispaly, TV-out
Ethernet 2 x Realtek 8111C PCIe Gigabit Ethernet controllers
I/O Chips ITE 8718F
BIOS Phoenix-Award BIOS version 6.0PG, support 4MB SPI
Flash ROM
Audio Realtek ALC655 AC97 Audio CODEC, MIC-in/ Line-In/ Line-
Out
Serial Port 2 x COM ports
(COM1: RS-232, COM2: RS-232/422/485 selectable)
Digital I/O 4-in / 4-out
Storage
2 x Serial ATA 150MB/s HDD transfer rate
1 x ATA-66, support 2 ATAPI devices
1 x Floppy connector share with LPT port
Parallel Port 1 x LPT Port (SPP/EPP/ECP mode selectable)
KB/MS Support Standard PS/2 Keyboard and Mouse
Universal Serial Bus 4 x USB 2.0 ports
Expansion Interface Mini PCI
Watchdog Timer 1~255 levels (sec or min)
Hardware Monitor
Chip Integrated in ITE8718F
RTC Support Real Time Clock
Power Connector DC +12V
Operation Temp. 0oC ~ 60oC
Dimension (L x W) 146 x 102 mm (5.7 ” x 4.0 ”)
