180W Random Orbital Sander
150-76-50479
DOUBLE INSULATION
INSTRUCTION MANUAL
Warning: For your personal safety,
READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
Made in China

2
General Power Tool Safety Warnings
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adaptor plugs
with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use commonsense when operating a power tool. Do not use a
power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as dust mask, non-skid safety shoes,
hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Avoid accidental starting. Ensure the switch is in the off-position before plugging in. Carrying power tools
with your finger on the switch or plugging in power tools that have the switch on invite accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can reduce dust related hazards.
h) The appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.

3
i) Children should be supervised to ensure they do not play with the appliance.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any
adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other
condition that may affect the power tools operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions and in the manner
intended for the particular type of power tool, taking into account the working conditions and the work to
be performed. Use of the power tool for operations different from those intended could result in a hazardous
situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.

4
DESCRIPTION
Your orbital sander has been designed for sanding applications.
1 ON/OFF Switch button
2 Lock button
3 Main handle
4 Dust bag
5 Hook and loop sanding plate
6 Front handle
Accessories supplied with the machine - 125mm 80grx1pc
OPERATING INSTRUCTIONS
Switching on and off
To switch on the machine press the on/off switch (1).
To switch off the machine, release the on/off switch (1).
To switch the machine to continuous mode, you keep the on/off switch (1) fully pressed and simultaneously press
the lock button (2). And subsequently release the on/off switch.
To switch off continuous mode, press the on/off switch (1) again.
Fitting sanding sheets
Take sanding paper of the required grain size and place it on the sanding pad. Make sure that the perforations in the
paper correspond with those on the sanding pad. Press the paper firmly on the sanding pad.
The sanding paper must be
fitted firmly on the sanding pad
and should not come loose.
Never use the machine for
sanding magnesium workpieces.

5
Dust extraction
The dust extraction outlet together with the dust bag takes care of the dust extraction of the working surface. Slide the dust
bag (4) onto the connection. Regularly empty the dust bag to ensure optimum dust extraction.
CLEANING AND MAINTENANCE
Attention! Before performing
any work on the equipment,
turn off the power supply &
pull out the plug.
Service
Only qualified specialist personnel and original replacement parts should be used for repairs. This will ensure that
your device remains safe.
Damaged switches must be replaced by a qualified electrician.
If the mains plug is damaged, it must be replaced by a qualified electrician.
Cleaning
Regularly clean the machine housing with a soft cloth, preferably after each use. Keep the ventilation slots free from
dust and dirt. If the dirt does not come off, use a soft cloth moistened with soapy water. Never use solvents such as
petrol, alcohol, ammonia water, etc. These solvents may damage the plastic parts.
TECHNICAL DATA
Mains voltage V 240
Mains frequency Hz 50
Power input W 180
Orbits min-1 11.000
Sanding surface mm ø 125
Weight kg 1.34
Acoustic pressure level
LpA 78dB(A) K =3 dB(A)
Acoustic power level
LwA 89dB(A) K = 3 dB(A)
STORAGE
Thoroughly clean the whole machine and its accessories.
Store it out of the reach of children, in a stable and secure position, in a cool and dry place, avoid too high and too
low temperatures.
Protect it from exposure to direct sunlight. Keep it in the dark, if possible.
Don’t keep it in plastic bags to avoid humidity build-up.

6

7
Warranty Against Defect
Electrical Agencies Pty Ltd (“us”, “we” “wholesaler”or “our”) guarantees this product for a full replacement for:
Home user domestic use;
Electrical & cordless/portable –24 months from date of purchase
Petrol driven products –12 months from date of purchase
Benchtop machinery –12months from date of purchase
Trade and commercial use:
6 months on all ROK products.
This guarantee covers material and workmanship defects only.
In order for the guarantee to be acted on, the consumer must use the products strictly in accordance with their
operating manual and for the purpose for which they are intended to be used. This guarantee does not apply to
defects arising from abuse, alteration, unauthorised or unreasonable use, nor does it cover general deterioration due to
usage.
The product will be replaced if a defect is found in the product during the guarantee period, subject to verification of the
defect and the date, proof of purchase and purchase price. Furthermore, in order for the guarantee to be claimed, the
defective goods must be returned to the point of purchase promptly from the point in time that the consumer becomes
aware of the defect in the goods and in any case within 7 business days.
The procedure for the consumer to claim the guarantee is that the product must be returned to the point of purchase
within 7 business days of the consumer becoming aware of the defect in the product and subject to the point of
purchase being satisfied that it is a genuine claim for material and workmanship defects and within the time limits
prescribed above, then the retailer will contact the wholesaler for review and determination. The wholesaler reserves
the right to reject the guarantee claim if the goods have not been used in accordance with their intended purpose or in
accordance with the manual. Repair facilities are not available. Spare parts may be available for some products.
The benefits of this guarantee are additional to any other rights and remedies you may have under law.
Once we have received the product and you have complied with the guarantee requirements, our costs associated with
the guarantee claim will be borne by us.
No responsibility will be taken for products lost, damaged or mislaid whilst in transit.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensations for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.

8
These terms and conditions supersede and exclude all former and other representations and arrangements relating to
any guarantees on this product. This includes any representations not made by us relating to the performance of the
product or the result that should to be expected from using the product.
Address for the return of products: The Point of Purchase
Importer and organisation providing warranty:
Electrical Agencies Pty Ltd (trading as Electaserv Trading)
PO Box 842, Morningside QLD 4170.
Telephone: [phone]
Email: [e-mail]
