Roland DB-700UT Operating and maintenance manual

May. 2000 DB-700
1
Copyright  2000 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permisson of
ROLAND CORPORATION.
TABEL OF CONTENTS Page
SPECIFICATIONS.............................................................. ......................................................................................1
LOCATION OF CONTROLS .............................................. ......................................................................................2
EXPLODED VIEW.............................................................. ..................................................................................3~4
BLOCK DIAGRAM.............................................................. ......................................................................................5
PARTS LIST ....................................................................... ..................................................................................6~7
TEST MODE....................................................................... ......................................................................................8
DC OFFSET ADJUSTMENT ............................................. ....................................................................................10
NOTES IN INSTALLING THE DSP BOARD ...................... ....................................................................................10
CIRCUIT DIAGRAM & BOARD .......................................... ..............................................................................11~15
SPECIFICATIONS
Different point between
the DB-700UT and DB-700JT
Please refer to the followings
1. Nameplate
Please confirm the Nameplate (Rear side of DB-
700 unit)
• Rated Power Output
250 W
• Nominal Input Level (1KHz)
INPUT HIGH :
− 30 dBm/1 M ohms
INPUT LOW :
− 20 dBm/300 k ohms
(AMP TYPE: SOLID STATE)
INSERT RETURN : +4 dBm
• Nominal Output Level
BALANCED DI : +4 dBm
INSERT SEND : +4 dBm
LINE OUT (XLR) : +4 dBm
LINE OUT (PHONE) : +4 dBm
∗ 0 dBm=0.775 Vrms
• Speakers
38 cm (15 inches) x 1
Horn Tweeter x 1
• Memory
A, B (2 memories)
• Controls
AMPLIFIER
• TYPE Switch (3 types)
• GAIN Knob
• VOLUME Knob
• COMPRESSION Knob
SHAPE Switch
EQUALIZER
• BASS Knob
• MIDDLE LEVEL Knob
• MIDDLE FREQUENCY Knob
• TREBLE Knob
D-CHORUS
• INTENSITY Knob (with Switch)
MASTER Knob
PROGRAM
• MANUAL Button
• A Button
• B Button
• WRITE Button
POWER Switch
GND LIFT Switch
• Indicators
POWER INJECTION (2 colors)
D-CHORUS
POWER
• Connectors
INPUT Jacks (HIGH, LOW)
PHONES Jack
BALANCED DI Connector
INSERT Jacks (SEND, RETURN)
LINE OUT Jacks
(XLR type balanced, 1/4" TRS Phone type balanced)
FOOT SWITCH Jacks
(TIP: A/B RING:MANUAL, CHORUS)
• Power Supply
AC 117 V, 230 V or 240 V
• Power Consumption
290 W (117 V, 230 V, 240 V)
• Dimensions
578(W) x 407 (D) x 598 (H) mm
22-13/16 (W) x 16-1/16 (D) x 23-9/16 (H) inches
(include casters)
578(W) x 407 (D) x 559 (H) mm
22-13/16 (W) x 16-1/16 (D) x 22-1/16 (H) inches
(not include casters)
• Weights
34.0 kg / 75 lbs
• Accessories
Owner's Manual English(02235123)
Japanese(02235112)
Caster (00677923)
• Options
Foot Switch FS-5L (BOSS)
* In the interest of product improvement,the specifications and/or
appearance of this unit are subject to change without prior notice.
17059024
Printed in Japan (AA00) (HK)
UT/JT

2
May. 2000DB-700
LOCATION OF CONTROLS
KNOB(G2477116)
ROTARY SWITCH
SRBM13N-F15
(13119218)
PUSH BUTTON #521
(2249752100)
SWITCH SPUP128100
(01782623)
KNOB(G2477116)
POT.RK09L1120 10KB C.CLICK
(00787389) KNOB(G2477116)
POT.RK0971111
10KB W/SWITCH
(01782590)
LED(RED/GREEN)
L-3WSRSGW-CC
(F5029111)
CHASSIS(G281714101)
6.5MM JACK
YKB21-5166
(01782656)
6.5MM JACK
(STEREO)
YKB21-5005
(13449263)
KNOB(G2477116)
POT. RK09L1120 10KB
(13289229)
LED (RED)
L-34HDSL
(1502928100)
AC SWITCH BUTTON
BLACK #650
(2247765000)
AC POWER SWITCH
SDDFC-3B-2 TV-8 8A/250V
(02121801)
DS-KEYTOP
SD4H BLK
(00900178)
LED (RED)
L-174XIT
(F5029118)
TACT SWITCH
EVQ21305RU00G
(13169752)
6.5MM JACK
YKB21-5011
(13449149)
6.5MM JACK
YKB21-5011
(13449149)
6.5MM JACK
YKB21-5005
(13449263)
6.5MM JACK(STEREO)
YKB21-5009
(13449148)
6.5MM JACK
YKB21-5011
(13449149)
SLIDE SWITCH
SSSU12584A
(13159178)
XLR SOCKET YKF52-5003(00122123)
(FRONT VIEW)
(REAR VIEW)
ALL JACK NUT
JACK NUT #756
(22150756)

3
May. 2000 DB-700
EXPLODEDVIEW
d
e
2
5
6
7
10 11
13
4
b
b
c
e
c
f
f
8
a
b
3
h
g
1
a
12
i
b
4
9
(DB-700JT ONLY)
[Parts List]
NO. Part Code Part Name Description
17055153 CABINET ASSY DB-700UT only
TE000031 CABINET ASSY DB-700JT only
CABINET ASSY include the following parts.
22310207 HANDLE (H40) 231-207 W/ESCUCHEON (2 HOLES)
17055035 2-LEG METAL CORNER BLACK
17055154 RUBBER FOOT 9104
17055193 CHROME GRILL
17055146 ROLAND SILVER LOGO RL3
17055166 FFP SILVER LOGO
17055194 SPEAKER 15INCH
17055062 SPEAKER HORN TWEETER KHN08L08 (025H27)150W
17055067 TWEETER GASKET
00677923 CASTER 3020-11-SR + SOCKET
17055140 HANDLE W/ROLAND LOGO H1104
17055207 EMI SHEILD PAPER
[Screw]
NO. Part Code Part Name Description
40010601 SCREW M5X35 ORIGINAL TRUSS MACHINE BZC
17055168 SCREW #8X3/4˝ TRUSS HEAD PHLL WOOD DB-700UT only
TE930136 SCREW 3.5X12 TRUSS TAPPING A FEBC DB-700JT only
17055175 SCREW #4X1/2˝ OVAL HEAD PHLL SHEET METAL DB-700UT only
40230789 SCREW M3X10 OVAL MACHINE BZC DB-700JT only
17055021 TINNERMAN FAST NUT #4 DB-700UT only
40011689 SPEED NUT M3 F-TYPE DB-700JT only
17055176 SCREW #10X1/2 ˝ TRUSS HEAD PHLL STAINLESS STEEL SHEET METAL DB-700UT only
40348112 SCREW 5x20 SUS(+) STS A TRUSS 5x20 DB-700JT only
17055068 SCREW #8-32X1˝ TRUSS HEAD BLACK OXIDE DB-700UT only
40010145 SCREW M4X25 TRUSS FE BZC DB-700JT only
17055070 SCREW #10-32X1˝ OVAL HEAD PHLL BLACK OXIDE DB-700UT only
40010478 SCREW M5X25 OVAL MACHINE FE BZC FOR HANDLE DB-700JT only
17055069 SCREW #8X1/2˝ TRUSS HEAD PHLL WOOD DB-700UT only
TE930136 SCREW 3.5X12 TRUSS TAPPING A BC DB-700JT only
40010690 SCREW 4X30 TRUSS TAPPING A BC DB-700JT only
1
2
3
4
5
6
7
8
9
10
11
12
13
a
b
c
d
e
f
g
h
i

4
May. 2000DB-700
EXPLODEDVIEW
[Parts List]
NO. Part Code Part Name Description
G281714101 CHASSIS
G2467413 HEATSINK
G349712301 AC CORD ASSY VCTF 100V
G349712402 AC CORD ASSY SJT 117V
G349712501 AC CORD ASSY SY010 230VD
G349712801 POWER CORD 230VE
G349712601 AC CORD ASSY FC-305 240VA
12369410RT AC CORD HOLDER 1702B
G2457149 TRANSFORMER 100V/117V
G2457150 TRANSFORMER 230/240V
G2207106 CHASSIS HOLDER
00900178 D S-KEYTOP SD4H BLK
2249752100 PUSH BUTTON #650
22150756 JACK NUT 215-756
F2449212 CHOKE TRANS 230V ONLY
G2477116 KNOB
01893423 FERRITE CORE TFCK-23-11-14
2247765000 AC SWITCH BUTTON BLACK #521
G2467110 HEATSINK
H5319105 INSULOK TIE YJ-368
∗∗∗∗∗∗∗∗ Double Sided Tape #9890
∗∗∗∗∗∗∗∗ Double Sided Tape
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02233356 DSP BOARD ASSY (EXG)
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
40016634 INSULATING SHEET BFG-20 E-2
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
02128534 POWER BOARD ASSY 230V/240V
POWER BOARD ASSY include the following parts.
∗∗∗∗∗∗∗∗ PS1 BOARD
∗∗∗∗∗∗∗∗ MEMORY SWITCH BOARD
∗∗∗∗∗∗∗∗ POWER BOARD
∗∗∗∗∗∗∗∗ INPUT JACK BOARD
∗∗∗∗∗∗∗∗ TW BAORD
∗∗∗∗∗∗∗∗ JACK BOARD
∗∗∗∗∗∗∗∗ Q8
∗∗∗∗∗∗∗∗ Q7
∗∗∗∗∗∗∗∗ Q6
∗∗∗∗∗∗∗∗ Q5
∗∗∗∗∗∗∗∗ IC1
∗∗∗∗∗∗∗∗ Q13
∗∗∗∗∗∗∗∗ Q18
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
18
19
20
21
23
24
26
27
28
29
30
31
32
[Screw]
NO. Part Code Part Name Description
a 40010301 SCREW M3X20 BINDING MACHINE BZC
b 40128689 SCREW M5X8 TRUSS BC
c 40011490 SCREW M3X6 PAN MACHINE W/SW BZC
d 40010345 SCREW M4X10 BINDING MACHINE FE BZC
e 40010323 SCREW M4X6 BINDING MACHINE FE BZC
f 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC
g 40011756 FLANGE HEX NUT M3 ZC
h∗∗∗∗∗∗∗∗ AC CORD EARTH END (117V or 230V/240V)
I 40011501 SCREW M3X8 PAN MACHINEW/SW+PW FE BZC
j 22157503 STAND OFF M3 L=40
k 40011767 FRANGE HEX NUT M4 FECM
l 40011889 EXTERNAL TOOTH WASHER M4 FECM
m 40012867 SCREW M3X8 PIN MACHINEW/SW+PW ZC
n 40012534 SCREW 3X6 BINDING TAPTITE S FE BZC
o G2157509 STAND OFF L=60
p 22157513 STAND OFF L=12
q 40128923 HEX NUT M7
r 17048651 VR ACCESSORY WASHER M7
s 17048630 VR ACCESSORY NUT M9
t 17048631 VR ACCESSORY WASHER M9
u 40340812 SCREW M3X10 PAN MACHINE W/SW BZC
v G2157510 STAND OFF L=15
w∗∗∗∗∗∗∗∗ EARTH END

5
May. 2000 DB-700
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
12345678910111213141516171819202122232425262728
BLOCK &WIRING DIAGRAM
IC9
CN1
CN10
VR & SW
GND LIFT
CN2
W16
PS1
BOARD
FOOT SW
CN10
TWEETER
LED & SW
INPUT
HIGH
CN1
W19
POWER BOARD
IC13
CN5
W21
LIMITTER LEVEL
DETECTION
RETURN
FOOT SW
A/D/A
CN11
AF AD CIRCUIT
DRAM
CN9
CN11
CPU
FLASH MEMORY
W15
DSP BOARD
CN3
SEND
CN3
CN4
EEPROM
CN8
TRANSFORMER
LINE OUT
DSP
CIRCUIT
INPUT JACK
BOARD
CHORUS
JACK
BOARD
W20
POWER
AMP.
SRAM
IC11
INPUT
LOW
IC12
IC8
W18
BALANCED DI OUT
CN2
IC4
MANUAL / A / B
WOOFER
IC10
MEMORY SWITCH
BOARD
W17
Q1
IC1B
IC1A
IC2A
IC2B IC3B
IC3A
IC5A
IC5B
MASTER VOL
JK4 JK5 SW1
POWER SUPPLY
A+15V, A-15V, +VCC, -VCC
D+5V,DGND
HPF
JK3 JK6 JK7 JK8 JK9
IC2A
A+15V, A-15V
D+5V DGND
POWER SUPPLY
A+5V
JK1
JK2
CIRCUIT
CIRCUIT
HOT
COLD
COLD
HOT
PHONES
JK10IC2B
VR10
PHONES
DETECTION
AGND AGND
TW BOARD
CN4
CN9
W14
A
A
A

6
May. 2000DB-700
PARTS LIST
CASING Q'ty
# 17055153 CABINET ASSY FOR DB-700UT ONLY 1
# TE000031 CABINET ASSY FOR DB-700JT ONLY
NOTE : 'CABINET ASSY' includes the following parts.
17055035 2-LEG METAL CORNER BLACK 8
17055140 HANDLE W/ROLAND LOGO H1104 2
22310207 HANDLE (H40) 231-207 W/ESCUCHEON (2 HOLES) 1
17055154 RUBBER FOOT 9104 4
# 17055207 EMI SHEILD PAPER 1
SOUND CARPET 1
# 17055193 CHROME GRILL 1
17055166 FFP SILVER LOGO 1
17055146 ROLAND SILVER LOGO RL3 1
CHASSIS Q't
# G281714101 CHASSIS 1
KNOB, BUTTON Q't
2247765000
AC SWITCH BUTTON BLACK #650 1
00900178 D S-KEYTOP SD4H BLK 1
G2477116 KNOB 10
2249752100 PUSH BUTTON BLACK #521 1
SWITCH Q't
13169752 EVQ 213 05R(100G) TACT SWITCH on MSB SW2, SW3, SW4, SW5 4
01782623 SPUP128100 PUSH SWITCH on PB SW7 1
13119218 SRBM13N-F15 ROTARY SWITCH on PB SW8 1
13159178 SSSU12584A SLIDE SWITCH on JB SW1 1
# 02121801 SDDFC-3B-2 TV-8 8A/250V POWER SWITCH on PS1B SW6 1
JACK, SOCKET Q'ty
13449263 YKB21-5005 W/SWICH 6.5MM JACK on JB JK8, PB JK10 2
13449148 YKB21-5009 JACK on JB JK7 1
13449149 YKB21-5011 JACK on JB JK4, JK5, JK9,on IJB JK2 4
01782656 YKB21-5166 JACK 6.5MM on IJB JK1 1
00122123 YKF52-5003 XLR SOCKET on JB JK3, JK6 2
SPEAKER, BUZZER Q'ty
17055062 KHN08L08 (025H27)150W SPEAKER HORN TWEETER 1
# 17055194 SPEAKER 15INCH 8ohm WOOFER 1
17055067 TWEETER GASKET 1
PWB ASSY Q'ty
# 02233356 DSP BOARD ASSY (EXG) 1
# 02128523 POWER BOARD ASSY 100V/117V 1
# 02128534 POWER BOARD ASSY 230V/240V 1
IC Q'ty
01453078 HD6433042B83F V1.00 IC (CPU MASK) on DSB IC10 1
F5179601 HT24C02 SOP IC on DSB IC8 1
15289123 M51953AFP-600C IC (RESET) on DSB IC14 1
15189261 M5218AFP-600E IC (BIPOLAR OP AMP) on DSB IC1, IC2, IC3, IC5 4
15189251 M5218AP IC (BIPOLAR OP AMP) on PB IC2, IC3 2
01900490 MBM29F040C-70 IC (FLASH MEMORY) on DSB IC12 1
15199207 TA7805S IC(V.RGL) on PB IC1,on DSB IC6 2
00892556 TC170C140AF-003 (ESP2) IC (CUSTOM) on DSB IC9 1
15169596 TC74HC4051AP IC (CMOS) on PB IC4 1
01126767 UDA1309H IC (A/D D/A) on DSB IC4 1
F5279510 V53C16256H-50 IC (DRAM 4M) on DSB IC11 1
F5289602 V62C5181024-70 IC (SRAM) on DSB IC13 1
TRANSISTOR Q'ty
15119113 2SA1015-GR TRANSISTOR on MSB Q10, Q12, on Q21, Q30, Q33 5
15119160 2SA1349-GR TRANSISTOR on PB Q19 1
01782612 2SA1494 POWER TRANSISTOR on PB Q7, Q8 2
15119723 2SA1837 TRANSISTOR on PB Q16, Q26 2
15119158 2SA970-GR TRANSISTOR on PB Q14, Q15 2
15129151 2SC1815-GR(TPE2) TRANSISTOR on MSB Q9, Q11, on PB Q22, Q24, Q28, Q35, Q36 7
15129192 2SC2240-GR(TPE2) TRANSISTOR on PB Q31, Q32 2
15129152 2SC2878-A(TPE2) TRANSISTOR on JB Q1, Q2, Q3, Q4, on PB Q23, Q27, Q34 7
15129209 2SC3381-GR TRANSISTOR on PB Q20 1
01782601 2SC3858 POWER TRANSISTOR on PB Q5, Q6 2
15129732 2SC4793 TRANSISTOR on PB Q17, Q25 2
15139103 2SK30ATM-GR FET TRANSISTOR on PB Q29 1
# 02126367 2SB1016AY TRANSISTOR on PB Q18 1
# 02126378 2SD1407AY TRANSISTOR on PB Q13 1
DIODE Q'ty
F5019203 1N4004 DIODE on PB D9 1
15019126 1SS133 T-77 SWITCHING DIODE on PB D7, D11, D12, D13, D15, D17, D18, D19, 14
D20, D21, D22, D23, D24, D25
15339119T0
1SS352(TPH3) SWITCHING DIODE
on DSB D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12
12
# F5019404 MTZJ16B DIODE on PB D10, D14, D16, D26 4
F5029118 L-174XIT DIODE on MSB D1, D2, D3, D4 4
1502928100
L-34HDSL LED on PB D27, D28 2
F5029111 L-3WSRSGW-CC LED (RED/GREEN) on MSB D5 1
F5039112DG
PBPC803 DIODE on PB D6 1
F5039118 W04G DIODE on PB D8 1
RESISTOR Q'ty
F3839181 0.33 OHM 5W CEMENT RESISTOR on PB R56, R62, R66, R78 4
F3839186 100 OHM 5W CEMENT RESISTOR on PB R46, R63, R109, R110 4
F3749113 100 OHM 1/2W CARBON RESISTOR on DSB R1 1
F3819905 27 OHM 1/2W METAL OXIDE RESISTOR on PB R100 1
F3819907 33 OHM 1/4W METAL OXIDE RESISTOR on PB R40 1
F3819908 47 OHM 1/4W METAL OXIDE RESISTOR on PB R108 1
# 02127090 ERQ14AJ221 FUSE RESISTER on PB R48, R86 2
# 02127089 ERQ16NK2R2E FUSE RESISTER on PB R44, R45, R94, R98 4
15399917 MNR34J5ABJ103 RESISTOR ARRAY on DSB RA1, RA2, RA4, RA5, RA6, RA7 6
# F3839604 5.1 OHM 5W CEMENT RESISTOR on PB R30, R31, R32 3
POTENTIOMETER Q'ty
13299265 EVN-D8AA03B14 10KB TRIMMER POTENTIOMETER on PB VR1 1
01782590 RK0971111 10KB W/SW 9M/M ROTARY POTENTIOMETER on PB VR9 1
13289229 RK09L1120 10KB 9M/M ROTARY POTENTIOMETER on PB VR2, VR3, VR4, VR7, VR10 5
00787389 RK09L1120 10KB CC 9M/M ROTARY POTENTIOMETER on PB VR5, VR6, VR8 3
CAPACITOR Q'ty
F3639141 3300UF/16V ELECTOLYTIC CAPACITOR on PB C40 1
13639548 33UF/16 ELECTOLYTIC CAPACITOR on DSB C43 1
F3639553 470UF/16V ELECTOLYTIC CAPACITOR on PB C32 1
# F3659257 4700UF/100V ELECTOLYTIC CAPACITOR on PB C42, C59 2
# F3639241 470UF/100V ELECTOLYTIC CAPACITOR on PB C25, C58 2
# F3639162 470UF/25V ELECTOLYTIC CAPACITOR on PB C45, C46, C49, C50 4
# 02127056 ECQE2224KF POLYEST. CAPACITOR on PB C23 1
F3519502 EC8472MH CERAMIC CAPACITOR on PB C31 1
01563789 ECQE1335KF POLYEST. CAPACITOR on TWB C21, TWB C22 2
F3519501 PY17FY472MLO 472/250V CERAMIC CAPACITOR on PS1B C35 1
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
SAFETY PRECAUTIONS:
The parts marked have safety-related characteristics. Use only listed parts for replacement.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
NOTE:The parts marked # are new (initial parts).
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

7
May. 2000 DB-700
INDUCTOR, COIL, FILTER Q'ty
# F2449212 CHOKE TRANS 230V ONLY 1
# F2449211 COIL 0.18MH on TWB L8 1
12449347 EXC ELDR35V FERRITE-BEAD
on PB L1, L2, L3, L4, L5, L6, L7, L9, L10, L11, on DSB L1,L2
10
01893423 TFCK-23-11-14 FERRITE CORE 1
CRYSTAL, RESONATOR Q'ty
00894034 MA-406 16.000MHZ TE24 CRYSTAL on DSB X2 1
01453167 SG-8002DC 67.7376MHZ PHC OSCILLATOR on DSB X1 1
FUSE, FUSE HOLDER Q'ty
F2559107 5ST T125L/250V FUSE on PB F3, F4 2
F2559109 5ST T800L/250V FUSE on PB F2 1
# F2559110 5TT 8A/125V SB TYPE (100V/117V) FUSE on PS1B F1 1
# F2559111 5ST T4AL/250V (230V/240V) FUSE on PS1B F1 1
12199550RT HTF-015 FUSE HOLDER on PS1B F1, on PB F2, F3, F4 8
CONNECTOR Q'ty
13369565 B11B-PH-K-S JST CONNECTOR on DSB CN9 1
13369564 B12B-PH-K-S JST CONNECTOR on DSB CN4 1
13369567 B4B-PH-K-S JST (4P) CONNECTOR on DSB CN10 1
13369515 B5B-PH-K-S JST CONNECTOR on DSB CN11 1
13369566 B6B-PH-K-S JST(6P) CONNECTOR on DSB CN6 1
13369516 B9B-PH-KS JST CONNECTOR on DSB CN11 1
13369568 B3B-PH-K-S JST CONNECTOR on IJB CN3, on JB CN1, on DSB CN1, CN2 4
WIRING, CABLE Q'ty
# G3467157 WIRING GREEN 230V/240V GND on PS1B T11 to CHASSIS 1
# H4009776 WIRING W1 RED on PB W2 to Q5 W2, PB W8 to Q6 W8, PB W5 to Q7 W5, 4
PB W11 to Q8 W11
G3467137 WIRING W10 BROWN on PB SP4 to TWEETER- 1
# G3467155 WIRING W11 GREEN on PB G4 to CHASSIS, PB G3 to CHASSIS 2
# G3467156 WIRING W12 GREEN on PB G6 to CHASSIS, IJB G2 to CHASSIS, 3
IJB G1 to CHASSIS
# G3467153 WIRING W13 on PB CN3 to IC1 CN6 1
# G3467154 WIRING W14 on PB CN9 to TWB CN4 1
# G3487148 WIRING W15 on DSB CN1 to IJB CN3 1
# G3487149 WIRING W16 on DSB CN2 to JB CN1 1
# G3467151 WIRING W17 on DSB CN10 to PB CN10 1
# G3467152 WIRING W18 on DSB CN11 to PB CN8 1
# G3467149 WIRING W19 on DSB CN3 to PB CN11 1
# H4009755 WIRING W2 BROWN
on PB TW to TWB, PB W1 to Q5 W1, PB W7 to Q6 W7,
5
PB W4 to Q7 W4, PB W10 to Q8 W10
# G3467150 WIRING W20 on DSB CN9 to JB CN2 1
# G3467148 WIRING W21 on DSB CN4 to MSB CN5 1
# H4009797 WIRING W3 ORANGE
on PB TW to TWB, PB W3 to Q5 W3, PB W9 to Q6 W9,
5
PB W6 to Q7 W6, PB W12 to Q8 W12
# H4009777 WIRING W4 RED on PB W14 to Q13 C, PB W17 to Q18 C 2
# H4009756 WIRING W5 BROWN on PB W15 to Q13 E, PB W18 to Q18 E 2
# H4009798 WIRING W6 ORANGE on PB W13 to Q13 B, PB W16 to Q18 B 2
# G3467158 WIRING W7 RED on PB SP1 to WOOFER+ 1
# G3467159 WIRING W8 BLACK on PB SP2 to WOOFER- 1
G3467139 WIRING W9 ORANGE on PB SP3 to TWEETER+ 1
TRANSFORMER Q'ty
# G2457149 TRANSFORMER 100V/117V 1
# G2457150 TRANSFORMER 230V/240V 1
AC CORD ASSY (Installed) Q'ty
G349712801
230VE AC CORD ASSY 1
G349712601
FC-305 240VA AC CORD ASSY 1
G349712402
SJT 117V AC CORD ASSY 1
G349712501 SY010 230VD AC CORD ASSY 1
G349712301
VCTF 100V AC CORD ASSY 1
SCREWS Q'ty
40011889 EXTERNAL TOOTH WASHER M4 FECM 14
40011756 FLANGE HEX NUT M3 ZC 3
40011767 FRANGE HEX NUT M4 FECM 3
40128923 HEX NUT M7 2
17055070 SCREW #10-32X1 OVAL HEAD PHLL BLACK OXIDE for H-40 HANDLE (DB-700UT ONLY) 4
40010478 SCREW M5X25 OVAL MACHINE FE BZC FOR HANDLEfor H-40 HANDLE (DB-700JT ONLY) 4
17055176 SCREW #10X1/2INCH SHT MTL OVAL HD PHIL BRT NKL for PUNCHING GRILL (DB-700UT ONLY) 8
# 40348112 SUS(+) STS A TRUSS 5x20 for PUNCHING GRILL (DB-700JT ONLY) 8
17055175 SCREW #4X1/2 OVAL HEAD PHLL SHEET METAL for BADGE ROLAND, FFP (DB-700UT ONLY) 4
40230789 SCREW M3X10 OVAL MACHINE SCREW BZC for BADGE ROLAND, FFP (DB-700JT ONLY) 4
17055068 SCREW #8-32X1 TRUSS HEAD BLACK OXIDE for WOOFER. TWEETER (DB-700UT ONLY) 12
40010145 SCREW M4X25 TRUSS FE BZC for WOOFER. TWEETER (DB-700JT ONLY) 12
17055069 SCREW #8X1/2 TRUSS HEAD PHLL WOOD for CORNER PROTECTOR (DB-700UT ONLY) 16
TE930136 SCREW 3.5X12 TRUSS TAPPING A FEBC for CORNER PROTECTOR (DB-700JT ONLY) 12
40010690 SCREW 4X30 TRUSS TAPPING A FEBC
for CORNER PROTECTOR to RUBBER FOOT (DB-700JT ONLY)
4
40011312 SCREW 3X8 BINDING TAPTITE P FE BZC for JB 4
40010678 SCREW 4X20 TRUSS TAPPING A1 FE BZC for SIDE HANDLE (H1104) (DB-700JT ONLY) 20
40340812 SCREW M3X10 PAN MACHINE W/SW BZC for HEATSINK DB-700 to Tr. 11
40010301 SCREW M3X20 BINDING MACHINE BZC for AC CORD 2
40012534 SCREW M3X6 BINDING TAPTITE S FE BZC for CHASSIS to CHASSIS HOLDER 4
40011490 SCREW M3X6 PAN MACHINE W/SW BZC for CHOKE TRANS (230V ONLY) 2
40011501 SCREW M3X8
PAN MACHINE W/SW+PW FE BZC for MSB 2
40012867 SCREW M3X8 PIN MACHINE W/SW+PW ZC 16
40010345 SCREW M4X10 BINDING MACHINE FE BZC for HEATSINK DB-700 12
40010323 SCREW M4X6 BINDING MACHINE FE BZC for JB 2
40010601 SCREW M5X35
ORIGINAL TRUSS MACHINE FE BZC
for CHASSIS 8
40128689 SCREW M5X8 TRUSS BC for TRANSFORMER 6
17055021 TINNERMAN FAST NUT #4 for BADGE ROLAND, FFP (DB-700UT) 4
40011689 SPEED NUT M3 F-TYPE for BADGE ROLAND, FFP (DB-700JT) 4
40011801 SPRING WASHER M3 ZC SRA-260/540/800 2
22157513 STAND OFF L=12 for on MSB 2
G2157510 STAND OFF L=15 for on TWB, DSB 10
G2157509 STAND OFF L=60 for on PB 3
22157503 STAND OFF M3 L=40 for on PS1B 4
17048630 VR ACCESSORY NUT M9 8
17048651 VR ACCESSORY WASHER M7 2
17048631 VR ACCESSORY WASHER M9 8
RUBBER FOOT
17055168 SCREW #8X3/4 TRUSS HEAD PHLL WOOD for CASTER DB-700UT ONLY 40
SIDE HANDLE
17055205 SCREW #8X3/4 TRUSS HEAD WOOD BLACK OX/DE DB-700UT ONLY
PACKING Q'ty
# 17055203 PACKING BOX OUTER DB-700UT ONLY 1
# 02238945 PACKING CASE DB-700JT ONLY 1
# 17055204 PACKING INSERT DB-700UT ONLY 1
# 02238956 PAD UPPER DB-700JT ONLY 1
# 02238967 PAD LOWER DB-700JT ONLY 1
# 02341256 CENTER PAD DB-700JT ONLY 1
MISCELLANEOUS Q'ty
12369410RT AC CORD HOLDER 1702B 2
40124690 CAUTION SEAL FUSE 2
40013812 CAUTION SEAL IEC(100V/117 ONLY) #142 1
# G2207106 CHASSIS HOLDER 2
G2467110 HEATSINK for on DSB IC9 1
# G2467413 HEATSINK 2
40016634 INSULATING SHEET BFG-20 E-2 for HEATSINK DB-700 4
H5319105 INSULOK TIE YJ-368 for on DSB 1
22150756 JACK NUT #756 PLASTIC BLACK 8
# 02128701 POLYSWITCH RXE010 on TWB R29 1
H5039705 TERMINAL 1741BS-2 187 on PB T1-T12 12
ACCESSORIES (Standard) Q'ty
00677923 CASTER 3020-11-SR + SOCKET 4
# 02235123 OWNER'S MANUAL ENGLISH 1
# 02235112 OWNER'S MANUAL JAPANESE 1
40232534 JAPAN ONLY
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

8
May. 2000DB-700
TEST MODE
: on
: off
LEDs showing Ver.1
LED
Figure MANUAL A B WRITE
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
LED
MANUAL A B WRITE
♦ Tools required
• Foot switch:FS-5L 3 units (used in Test 3)
• Connection cable for FS-5L:standard (to CHORUS),
2-mono/1-stereo (to TIP & RING) (used in Test 3)
• Standard plug:1 (to PHONES, used in Test 4)
♦ Setting for test
Panel controls
AMPLIFIER TYPE: SOLID STATE
Other control knobs: Full counterclockwise
SHAPE: OFF
Connect foot switches:
to TIP: A/B - set POLARITY switch on the FS-5L to the Jack
side. FS-5L should light its LED when it is off.
to RING: MANUAL - set POLARITY switch on the FS-5L to
the Jack side. FS-5L should light its LED when it is off.
to CHORUS - set POLARITY switch on the FS-5L to the
side opposite to Jack. FS-5L should light its LED when it is
on.
♦ Function of LEDs in the test mode
The following LEDs express numbers.
The POWER INJECTION LED shows the test results:
OK - lights in green (except in test 1.3)
NG - lights in red
♦ Entering the test mode
While holding down the buttons MANUAL, (MEMORY) A
and B, press the POWER button.
Upon entering the test mode, all LEDs blink.
1 LED, program version, bus
1.1 LED
Press the MANUAL button, the LEDs MANUAL, A
(MEMORY), B, WRITE and CHORUS turn on and off
in that order and repeat the cycle.
1.2 Program version
Press the WRITE button. The following LEDs show the
program version number.When Ver.1, for example, the
WRITE LED lights, as shown in the table below.
NG Lighting LEDÅ^LEDì_ìî
SRAM MANUAL
DSP A
EEPROM B
LED
MANUAL A B WRITE
LED
MANUAL A B WRITE
1.3 CPU bus & DSP bus
Press the MANUAL button. The LEDs MANUAL, A, B
and WRITE blink in that order indicating that the CPU
bus and then DSP bus are being tested. When these
LEDs are all blinking, test is completed and the
following LEDs show the test result.
OK: POWER INJECTION LED lights in red and WRITE
LED lights
NG: POWER INJECTION LED lights in red. The defective
device is indicated by the lighting LED as shown in the
table right.
1.4 POWER INJECTION LED
Repeatedly press the WRITE button and verify that the
POWER INJECTION LED changes its color.
Orange →Red →Green
Press the WRITE button to proceed to the next test.
2 Tact switches
The LEDs shown right indicate the test number.
Test No.2
Press the WRITE button when skipping this test. Otherwise,
press the MANUAL button to start the test.
Press the MANUAL, A, B and WRITE buttons in that order
and verify that the LED on the button lights.
Upon pressing the WRITE button, POWER INJECTION
LED should light in green.
Press the WRITE button to proceed to the next test.
3 Foot switches
The LEDs shown right indicate the test number.
Test No.3
Press the WRITE button when skipping this test. Otherwise,
press the MANUAL button to start the test.
MANUAL →A/B →A CHORUS
Depress the foot switches connected to MANUAL, A/B and
CHORUS sockets in that order. Observe the following LEDs
that should light upon depressing the corresponding foot
switch.
Upon depressing the CHORUS, the POWER INJECTION
LED should light in green to show that the all foot switches
operate correctly.
Press the WRITE button to proceed to the next test.
Foot switch LED
MANUAL MANUAL
A/B A
CHORUS B

9
May. 2000 DB-700
LED
MANUAL A B WRITE
4 Controls
The LEDs shown right indicate the test number.
Test No.4
Press the WRITE button when skipping this test. Otherwise,
press the MANUAL button to start the test.
4.1 Rotate the AMPLIFIER TYPE (rotary switch) knob
from SOLID STATE to TUBE and then to TUBE
DRIVE. Observe the following LEDs that should light
to show the switch position.
When all switch positions are read, the POWER
INJECTION LED lights in green.
Press the WRITE button or depress the A/B foot
switch to proceed to the next test step.
4.2 Start with the leftmost control.
Potentiometer: from full-counterclockwise (FCCW)
position to full-clockwise (FCW) position
As the knob travels, the LED corresponding to the
scale will light:
(These values are just as a guide.)
When all travel ranges of the potentiometer has been
sensed, the POWER INJECTION LED lights in green.
The unlit LED is a sign of NG.
Press the WRITE button or depress the A/B foot
switch to proceed to the next control test.
When the next item to be test is a potentiometer,
repeat the step.
SHAPE switch: turn it on and then off. The green
POWER INJECTION LED indicates that the switch's
on and off states are correctly detected.
Turn on CHORUS switch and verify lighting CHORUS
LED. Then, test the potentionmeter.
PHONES socket: insert the standard plug into the
socket and then withdraw.
The POWER INJECTION LED lights in green
indicating that open/close of socket contacts are
correctly detected.
Press the WRITE button to proceed to the next test.
Switch position LED
SOLID STATE MANUAL
TUBE A
TUBE DRIVE B
Scale LED
0-4 MANUAL
4-6 A
6-10 B
LED
MANUAL A B WRITE
5 DSP
The LEDs shown right indicate the test number.
Test No.5
Press the MANUL button.
The bus between the DSP and DRAM is tested.
The POWER INJECTION LED lights in green when the bus
is intact.
The POWER INJECTION LED lights in red to show NG
bus.
Remove the foot switches.
This completes the test. When proceed to "Loading factory
presets" shown below, press the WRITE button. Otherwise,
turn off the POWER switch.
6 Loading factory presets
When this procedure is following the test 5 above, the
LEDs A, B and WRITE are blinking (standby). Press the
WRITE button to start loading.
While loading, the WRITE LED blinks and at the end of
loading the LED A will light.
Turn off the POWER switch.
CAUTION:The following procedure will erase user data.
♦Checking input/output level, noise level and
power limiter
Connect 8Ωload to speaker out WOOFER and TWEETER.
To check power limiter, connect a 680Ωload to the hot and
cold terminal of LINE OUT BALANCED socket, respectively.
1. Entering the checking mode
1.1 Set AMPLIFIER TYPE switch to SOLID STATE.
1.2 Set MASTER knob to 10.
1.3 Set GND LIFT switch to OFF.
1.4 While pressing MANUAL and WRITE buttons, turn on
POWER switch.
1.5 LEDs "A" and "B" light. Press MANUAL button and the
LEDs turn off. Now the unit is in the checking mode.
2. Checking input and output levels
2.1 Set the following controls:
AMPLIFIER TYPE switch: SOLID STATE
MASTER knob: 10
Other controls: Don't care
2.2 Check input and output levels:
Apply 1 kHz, sine wave signal to INPUT. Check level
at various points by referring to the corresponding
level denoted on the circuit diagram.
3. Checking noise level
3.1 Set the following controls:
AMPLIFIER TYPE switch: TUBE
MASTER knob: 10
Other controls: Don't care
3.2 Check noise levels:
Leave INPUT sockets disconnected.
3.2.1 With panel settings as mentioned 3.1 above:
Measuring point: Speaker output WOOFER (8Ω)
Noise level: −32.0 dBm (IHF-A)

10
May. 2000DB-700
ADJUATMENT
NOTES IN INSTALLING THE DSP BOARD
4. Checking power limiter
4.1 Set the following controls:
MASTER knob: 0
AMPLIFIER TYPE switch: TUBE DRIVE
The DSP internal generator outputs 1 kHz, sine test
signal.
Other controls: Don't care
4.2 Check power limiter:
Leave INPUT sockets disconnected.
Connect a 680Ωload to the hot and cold terminal of
LINE OUT BALANCED socket, respectively.
Turning MASTER knob from 0 to 10, check changes in
sound from WOOFER and LINEOUT. (See Fig.1.)
MASTER VOL:0 MASTER VOL:5
Fig.1
MASTER VOL:MAX
LINE OUT
WOOFER
16 Vp-p 3.6 Vp-p
120 Vp-p
8.2 Vp-p
120 Vp-p
♦ DC OFFSET ADJ
Setting
1. Connect the probes of the DC voltmeter to the plus (RED)
and minus (BLACK) sides of the 15˝ WOOFER CORD.
(At no load.)
2. Adjust VR1 (on POWER BOARD) so that the DC offset is
at 0V±50mV.
DB-700 CHASSIS
15˝ WOOFER CORD
TWEETER CORD
ORANGE
BROWN
BLACK
RED
DC VOLTMETER
Be sure to clamp the DSP BOARD with the cable tie
(H5319105).

11
May. 2000 DB-700
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
12345678910111213141516171819202122232425262728
CIRCUIT BOARD
DSP BOARD ASSY (02233356)
View from component side. Vew from foil side.

12
May. 2000DB-700
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
12345678910111213141516171819202122232425262728
POWER BOARD ASSY 230V/240V (02128534)

13
May. 2000 DB-700
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
12345678910111213141516171819202122232425262728
CIRCUIT DIAGRAM
DSP BOARD ASSY (02233356)
DSP BOARD
AGND
SIG
GAIN CONT
SEND
AGND
RETURN
D+5V
DGND
MIDI OUT
MIDI MUTE
MIDI IN
D+5V
DGND
WRITE LED
WRITE SW
MANUALLED
MANUAL SW
A LED
A SW
B LED
B SW
MUTE
DI OUT HOT
DI OUT COLD
LINE OUT HOT
LINE OUT COLD
AGND
CHORUS FT SW
A/B F T SW
MANUAL FT SW
DGND
LIMIT ER +
LIMIT ER -
MASTER
MUTE
A+15V
AGND
A-15V
DGND
D+5V
MODELING SW
MULTIPLEX OUT
CONT A
SHAPE SW
CHORUSLED
CHORUS SW
PWR INJ 1
PHONES DETECT
MIDI CON NECT
FT SW DE TECT
CONT B
CONT C
PWR INJ 2
67.7376MHz
16.000MHz
1
+7.0dBm
1.72V
-4.4dBm
-4.4dBm
470mV
470mV
NO USE
NO USE
DB-700 SETTING
USE TEST MODE
TYPE : SOLID STATE
MASTER VOL : MAX
ED16
EA1
ED17
ED19
EA6
ED20
CS2
EA4
EA5
ED22
EA3
ED20
ED15
INT1
EA7
ED21
EA2
CS2
ED15
ED12
ED17
ED14
ED14
ED18
INT1
D2
EA4
INT0
EA0
EA8
ED21
EA7
EA2
ED13
ED23
EA6
EA8
EA0
ED18
EA3
ED16
EA1
ED13
ED12
INT0
EA5
ED22
ED19
ED23
LRCK0
MCK
BCK
AD0
AD0
MCK
LRCK1
BCK
LRCK1
LRCK0
AD1
CS0
CS0
D3
A9
A11
D4
A10
A12
A15
A10
D1
A14
A16
A11
D4
A10
A10
A13
A13
A15
A15
A9
D3
D1
A11
D2
A12D6
D6
A11
D5
D2
A16
A1
A1
A16
RD
D5
D4
A6
D7
D7
D7
A7
A8
D7
A1
A0
A3
WR
RST
A8
A8
D0
A6D0
A1
A2
A3
D5
D5
A8
A5
A2
A0
A0
A0
A3
A3
A4
A4
WR
A9
A5
A5
A6
A7
CS1
WR
RD
CS1
A6
A7
D1
D2 A12
D1
A13
A14
A9
D6
D6
A13
D3 D4
A14
D3
A4
RD
D0
D0
A12
A2
A2
A7
WR
RD
A5
A4
DA3
DA3
A
+ +
+
+
+
A
A
D
+
+15
-15
A
+5D
D
+5D
A
A
A
D
+15
-15
+15
-15
A
A
D
+5D
D
D
D
D
D
D
+5D
+5D
+5D
+5D
+5D
D
+5D
D
D
+5D
+5D
+5D
+5D
+5D
D
+5D
+5D
D
+5D
D
D
D
D
D
+5D
+5D
D
+5D D
+5D
D
+5D
+5D
-15
+15
A
+15
-15 A
A
A D
A
+5D
D
+15
-15 AA
+5D
D
+5D
D
+5D
D
+5D
D
+5D
D
+5D
A F
A
+15
-15A
A
A
-15 A
+15
+15
A
A
A
A
A
A
A
A
A
AA
A
A
A
DD
D DD
D D D
D
D
D
D
+5D
R27
33k
R34
3.3k
R30
4.7k
R37
4.7k
R71
220
R21
6.8k R22
6.8k
R15
6.8k
R16 6.8k
R10
6.8k R11
6.8k
R5
6.8k
R6
6.8k
R4
1k
R7
1k
R63
1k
R65
1k
R64
1k
R66
1k
R69
1k R70
1k
R72
1k
R49
6.8k
D2
1SS35212
R2
1M
D1
1SS352
1 2
D3
1SS352
1 2
R8
6.8k
R18
47k
R17
47k
R14
150
R19
150
R29
100
R31
33k
D4
1SS352
1 2
D5
1SS352
1 2
X1
SG-8002DC
OE 1
GND
2OUT 3
VDD
4
D7
1SS352
1 2
R62
1.2k
R61
10k
R74
10k
R78
100k
R43
4.7k R44
4.7k
R33
33k
R35
3.3k
R36
6.8k
R41
2.2k
R42
12k
R50 47k
R46
47k
D10
1 2
D6
1SS352
1 2
D9
1 2
D12
1 2
D11
1 2
D8
1SS352
1 2
R52
150
R53
150
R20
22k
R48
33k
R25
100
R23
6.8k
IC8
HT24C02
A0
1A1
2A2
3
VSS 4
SDA
5SCL
6
WP 7
VCC 8
Q1
2SK880GR
3
1 2
CN2
B3B-PH-K-S
11
22
33
CN10
B4B-PH-K-S
1
12
23
34
4
CN8
NIU
11 22 33 44 55 66 77 88 99
10 10
C44
330p
C37
330p
C3
0.0012
C13
0.0012
C46
0.0015
C51
0.0015
C93
10p
C41
0.1 C42
0.1
C14
10p
C92
12p
C53
0.1
C36
0.1
C32
15p
C21
0.1
C40
15p
C47 10p
C24
0.0012
C49 680p
C22
68p
RA7
10k
1 8 2 7 3 6 4 5
RA5
10k
1 8 2 7 3 6 4 5
RA1
10k
1 8 2 7 3 6 4 5
RA2
10k
1 8 2 7 3 6 4 5
C34
0.068
C35
0.0068
J1
NIU
IC14
M51953AFP
RST 6
DLY 5
VCC
7
GND
4
NC 1
NC 2
NC 3
NC 8
+
-
IC3A
M5218AFP
2
31
+
-
IC1B
M5218AFP
6
57
+
-
IC1A
M5218AFP
2
31
+
-
IC2A
M5218AFP
2
31
+
-
IC5A
M5218AFP
2
31
+
-
IC5B
M5218AFP
6
57
+
-
IC2B
M5218AFP
6
57
X2
MA-406
1 4
IC11
V53C16256H-50
A8
26 A7
25 A6
24 A5
23 A4
22 A3
19 A2
18 A1
17 A0
16
NC
11 NC
12 NC
15 NC
30
RAS
14 UCAS
28 LCAS
29 WE
13 OE
27
I/O16 39
I/O15 38
I/O14 37
I/O13 36
I/O12 34
I/O11 33
I/O10 32
I/O9 31
I/O8 10
I/O7 9
I/O6 8
I/O5 7
I/O4 5
I/O3 4
I/O2 3
I/O1 2
VCC 1
VCC 6
VCC 20
VSS 21
VSS 35
VSS 40
C31
3.3/25
C39
33/16
C54
4.7/25
C64
10/16
C62
4.7/25
C43
33/16
C8
1/50
C19
1/50
10/16
C30
3.3/25
C48
10/16
C38 10/16
C1
1/50
CN1
B3B-PH-K-S
11
22
33
CN6
B6B-PH-K-S
11
22
33
44
55
66
IC6
TA7805S
IN
1OUT 3
COM
2
C90
0.1
CN4
B12B-PH-K-S
11
22
33
44
55
66
77
88
99
10 10
11 11
12 12
R1
100 1/2W
C5
220/16
R75
22k
R73
1k
CN11
B5B-PH-K-S
1
12
23
34
45
5
CN5
NIU
11
22
33
44
55
66
R51
1
L1
EXCELDR35V
C106
0.1
R67
0
CN3
B9B-PH-K-S
11
22
33
44
55
66
77
88
991
C26
10/16
+
-
84
R13
22k R38
22k
R39
150k
R26
2.7k
+
-
84
C12
10/16
C10
10/16
C20 0.1
+
-
84
C33
10/16
+
-
IC3B
M5218AFP
6
57
C25
10/16
C15
4.7/25
C6
0.1
+
-
84
C9
0.0012
C4
0.1
C11
3.3/25
IC12
MBM29F040C-70
A11
1
A9
2A8
3
A13
4A14
5
A17
6
WE
7
VCC 8
A18
9
A16
10 A15
11
A12
12
A7
13 A6
14 A5
15 A4
16 A3
17 A2
18 A1
19 A0
20
DQ0 21
DQ1 22
DQ2 23
VSS 24
DQ3 25
DQ4 26
DQ5 27
DQ6 28
DQ7 29
CE
30
A10
31
OE
32
J3
JMP
R76
0
C65
0.1
R45
47k
C57
0.1
C107
0.1
C56
0.1
C55
0.1
R40
330k
R28
33k
C98
0.1
C105
0.33/50
C45
3.3/25
R32
15k
R47
NIU
C18
47/16
C2
15p
CN9
B11B-PH-K-S
1
12
23
34
45
56
67
78
89
910
10 11
11
C108
0.1
RA6
10k
1 8 2 7 3 6 4 5
J4
JMP
C87
0.1
C104
0.1
IC10
HD6433042VF
VCC 1
PB0/TP8/TIOCA3
2PB1/TP9/TIOCB3
3PB2/TP10/TIOCA4
4PB3/TP11/TIOCB4
5PB4/TP12/TOCXA4
6PB5/TP13/TOCXB4
7PB6/TP14/DREQ0
8PB7/TP15/DREQ1*
9
RESO 10
VSS
11
P90/TXD0
12 P91/TXD1
13 P92/RXD0
14 P93/RXD1
15 P94/SCK0/IRQ4
16 P95/SCK1/IRQ5
17
P40/D0 18
P41/D1 19
P42/D2 20
P43/D3 21
VSS
22
P44/D4 23
P45/D5 24
P46/D6 25
P47/D7 26
P30/D8 27
P31/D9 28
P32/D10 29
P33/D11 30
P34/D12 31
P35/D13 32
P36/D14 33
P37/D15 34
VCC 35
P10/A0 36
P11/A1 37
P12/A2 38
P13/A3 39
P14/A4 40
P15/A5 41
P16/A6 42
P17/A7 43
VSS
44
P20/A8 45
P21/A9 46
P22/A10 47
P23/A11 48
P24/A12 49
P25/A13 50
P26/A14 51
P27/A15 52
P50/A16 53
P51/A17 54
P52/A18 55
P53/A19 56
VSS
57
P60/WAIT 58
P61/BREQ 59
P62/BACK 60
PHAI 61
STBY
62
RES
63
NMI 64
VSS
65
EXTAL
66
XTAL
67
VCC 68
P63/AS 69
P64/RD 70
P65/HWR 71
P66/LWR 72
MD0
73 MD1
74 MD2
75
AVCC
76
VREF
77
P70/AN0
78 P71/AN1
79 P72/AN2
80 P73/AN3
81 P74/AN4
82 P75/AN5
83 P76/AN6/DA0
84 P77/AN7/DA1
85
AVSS
86
P80/RFSH/IRQ0 87
P81/CS3/IRQ1 88
P82/CS2/IRQ2 89
P83/CS1/IRQ3 90
P84/CS0 91
VSS
92
PA0/TP0/TEND0/*
93 PA1/TP1/TEND1/*
94 PA2/TP2/TIOCA0*
95 PA3/TP3/TIOCB0*
96 PA4/TP4/TIOCA1*
97 PA5/TP5/TIOCB1*
98 PA6/TP6/TIOCA2*
99 PA7/TP7/TIOCB2*
100
C99
NIU
J2
JMP
IC9
TC170C140AF-003
CA13
74 CA12
75 CA11
76 CA10
77 CA9
78 CA8
79 CA7
81 CA6
82 CA5
83 CA4
84 CA3
85 CA2
86 CA1
87 CA0
88
CD7
92 CD6
93 CD5
94 CD4
95 CD3
96 CD2
97 CD1
98 CD0
99
INT1
66 INT0
67
CS
68 WR
69 RD
70
TRR5 62
TRR4 61
TRR3 60
TRR2 59
TRR1 58
TRR0 57
TRCKIN 56
RST2 51
RST1 52
VPOUT 53
TRS5 101
TRS4 102
TRS3 103
TRS2 104
TRS1 105
TRS0 106
TRCKO 107
DIRECT
64 TYPE
65
SYO 132
SYI 133
PSEA16 136
PSEA15 137
PSEA14 138
PSEA13 139
PSEA12 140
PSEA11 141
PSEA10 142
EA9 27
EA8 26
EA7 25
EA6 24
EA5 23
EA4 22
EA3 21
EA2 20
EA1 17
EA0 16
ED23 49
ED22 48
ED21 47
ED20 46
ED19 45
ED18 44
ED17 43
ED16 42
ED15 39
ED14 38
ED13 37
ED12 36
ED11 35
ED10 34
ED9 33
ED8 32
ED7 10
ED6 9
ED5 8
ED4 7
ED3 6
ED2 5
ED1 4
ED0 3
WE 13
CAS 14
RAS 15
OSC
29
DA7
111 DA6
112 DA5
113 DA4
114 DA3
115 DA2
116 DA1
117 DA0
118
AD3
120 AD2
121 AD1
122 AD0
123
LRCK1
124 LRCK0
125
BCK1
128 BCK0
129
MCK1
130 MCK0
131
VDD 1 VDD 12 VDD 18 VDD 30 VDD 41 VDD 54 VDD 72 VDD 90 VDD 108 VDD 109 VDD 126 VDD 134 VDD 144
VSS
2VSS
11 VSS
19 VSS
28 VSS
31 VSS
40 VSS
50
VSS
55
VSS
63
VSS
71
VSS
73
VSS
80
VSS
89
VSS
91
VSS
100 VSS 110
VSS
119
VSS
127
VSS
135
VSS
143
C7
NIU
C91
0.1
C100
68p
IC13
V62C5181024-70
NC 1
A16
2
A14
3
A12
4
A7
5A6
6A5
7A4
8A3
9A2
10 A1
11 A0
12
I/O0 13
I/O1 14
I/O2 15
GND 16
I/O3 17
I/O4 18
I/O5 19
I/O6 20
I/O7 21
CE1
22
A10
23
OE
24
A11
25
A9
26 A8
27
A13
28
WE
29 CE2
30
A15
31
VCC 32
R59
10k
C102
0.1
C84
0.1
C78
0.1
C103
0.1
R58
10k
C70
0.1
C94
0.1
C88
0.1
C83
0.1
C29
33/16
R60
10k
R57
10k
R56
10k
C101
0.1
C97
33/16
C28
0.1
C89
0.1
C75
0.1
C86
33/16
C96
0.1
C95
0.1
C85
0.1
C73
0.1
RA4
10k
1 8 2 7 3 6 4 5
C17
0.1
IC4
UDA1309H
ADBCK 1
ADWS 2
MODE0 3
ADENB 4
OVLOAD 5
ADPON 6
VSSA|AD
7VDDA|AD 8
VREF(NEG)
9VREF
10 VREF(POS)
11
BAOL
12 BAIL
13
BAIR
14
BAOR
15
ADREF
16
IREF
17 DAREF
18
VDDO 19
VSSO
20
VOL
21
DACL
22
DACR
23 VOR
24
VDDA|DA 25
VSSA|DA
26
VSSD
27 VDDD 28
DAPON 29
DADEM 30
DABCK 31
DAWS 32
VSSD|F
33 VDDD|F 34
DASDA 35
ANLPTR 36
TEST0 37
TEST1 38
VSS|I/O
39
SYSCLK 40
ADSDA 41
MODE1 42
MODE2 43
CLKEDGE 44
C16
0.1
L2
EXCELDR35V
R24
6.8k

14
May. 2000DB-700
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
12345678910111213141516171819202122232425262728
POWER BOARD ASSY 230V/240V (02128534)
+VCC
-VCC
-VCC
TWEETER 8 ohm
WOOFER 8 ohm
+VCC
TREBLE VOLUME
GAIN
CHORUS
INTENSITY
COMPRESSION MID FREQ
MID
LEVEL
BASS
MASTER
PHONES
LIMITTER +
LIMITTER -
MASTER
AGND
MODELING
MULTIPLEX OUT
MULTIPLEX_C
MULTIPLEX_B
MULTIPLEX_A
SHAPE
CHORUS LED
CHORUS SW
PHONES CONT
A+15V
MUTE
A-15V
D+5V
DGND
CHORUSSHAPEPOWER
+16V
-16V
FUSIBLE
METAL OXIDE
METAL OXIDE
CEMENT
CEMENT
CEMENT
METAL OXIDE
CEMENT CEMENT
CEMENT CEMENT
F4
F3
FUSIBLE
CEMENT
CEMENT
FUSIBLE
COMMON
HOT
GND
Include Tw. Network board
CEMENTCEMENT
Include Tw. Network board
F2449211
3.3/100V 3.3/100V
FUSIBLE
FUSIBLE
FUSIBLE
CHOKE TRANS
100V,117V,240V
230VE,230VD
J14:USE
J14:NO USE
CHOKE TRANS:NO USE
CHOKE TRANS:USE
100V/117V
230V/240V
T800mAL250V
T800mAL250V
T125mAL250V
T125mAL250V
T125mAL250V
T125mAL250V
F2 F3 F4
-16V
+16V
-16V
+16V
MODELING
COLD
HOT
F2
F2449212
W4
DB-700 SETTING
USE TEST MODE
TYPE : SOLD STATE
MASTER VOL : MAX
DB-700 POWER BOARD
1/13
-4.6 dbm
455 mV +5.5 dbm
1.45 V
-11.1 dbm
215 mV
@8 ohm LOAD
@8 ohm LOAD
43.8 V
+35.0 dbm
@NO LOAD
7.7 V
+20.0 dbm
5/13
6/13
8/13
7/13
13/13
9/13
13/13
10/13
11/13
W4
W6
W5
W5
W6
W4
W1
W3
W2
W2
W3
W1
W2
W3
W1
W2
W3
W1
W3 W2
W9
W10
W7
W8
D
+15
-15
+5D
A
+
A A
+
-
+5D +5D
+5D +5D
+5D +5D
+5D +5D
D D
D D
D D
D D
D
D
D
DD
+5D
+5D +5D
+5D
+15
-15
A
F
F
-15
-15
+15 +15
A
A
+
AAA
AA
FA
+15
-15
+15
+15 +15
-15
A
A
A
+5D
D
AA
A
A
AA
A
D
-
++
-
D
D
+5D
+5D
D
D
D
D
D
DD
D
D
D
+5
D
D
F F
F
-15
C59
4700/100
C42
4700/100
R110
100 5W
C23
ECQE2224KF
T3
T2
T1 R92
10k 1/2W
C56
0.068
C33
NIU
Q16
2SA1837
C37
10/50 BP
R97
27k 1/2W
R108
47 1/4W
Q17
2SC4793
+
-
IC2A
M5218AP
2
31
C55
NIU
R49
27k 1/2W
R48
220 1/4W
+
-
IC2B
M5218AP
6
57
R136
22 1/2W
VR10A
RK09L1120 10kB
1
2
3
S
Q19
2SA1349
S
Q20
2SC33811
C39
0.068
JK10
YKB21-5005
1
2
3
4
5
7
8
Q25
2SC4793
R135
22 1/2W
VR4A
RK09L1 120 10kB
1
2
3
VR8A
RK09L1120 10kB C.C.
1
2
3
VR6A
RK09L1120 10kB C.C.
1
2
3
VR7A
RK09L1 120 10kB
1
2
3
VR9A
RK0971 111 10kB
11
12
13
VR9B
RK0971111 10kB
21 22
D27
L-34HDSL
SW7A
SPUP128100
12 11
13
+
-
IC3B
M5218AP
6
57
VR3A
RK09L1120 10kB
1
2
3
VR5A
RK09L1120 10kB C.C.
1
2
3
VR2A
RK09L1 120 10kB
1
2
3
IC4
TC74HC4051AP
7
46
25
5
4
13
12 2
15
1
14
0
13
VEE 7
COM 3
C
9
B
10 A
11 INH
6
VCC 16
GND 8
CN8
W18 ( Board in)
11
22
33
44
55
R76
10k 1/2W
Q29
2SK30ATM-GR
Q5
2SC3858
Q7
2SA1494
R63
100 5W
Q18
2SB1016AY
D10
MTZJ16B
D14
MTZJ16B
CN10
W17 ( Board in)
11
22
33
44
CN11
W19 (Boardin)
1
12
2
3
3
4
45
56
6
7
78
89
9
+- ~
~
D6
PBPC803
D16
MTZJ16B
R101
5.6k 1/2W
L11
EXCELDR35V
R131
22k 1/2W
VR1
EVND8A 10kB
1
2
3
D20
1SS133
D21
1SS133
D25
1SS133
D23
1SS133
D15
1SS133
D18 1SS133
D19
1SS133
Q21
2SA1015GR
Q33
2SA1015GR
Q22
2SC1815GR
Q35
2SC1815GR
Q36
2SC1815GR
Q27
2SC2878A
Q34
2SC2878A
Q23
2SC2878A
C52
0.1
C43
NIU
C38
NIU
C44 NIU
C81
10p
C60
0.1
C66
0.1
C36
220p
C79 15p
C47
0.047
C34
NIU
C95
100p
C67
0.1
C68
0.1
C48
NIU
C78 680p
C94
100p
C91
0.1
L9
EXCELDR35V
L10
EXCELDR35V
C46
470/25
C89
3.3/50
C50
470/25
C80
10/16
C57
0.22/50
C54
33/16
C64
10/16
C25
470/100
C58
470/100
R31
5W 5.1
R66
0.33 5W
R62
0.33 5W
R46
100 5W
R109
100 5W
R70
3.3k
R129
100k
R81
330
R51
560
R116
22
R149
NIU
R53
1.8k
R79
2.7k
R87
820
R69
4.7k
R54
2.2k
R72
560
R73
6.8k
R132
15k
R124
22
R115
10k
R113
10k
R89
220 R68
560
R50
560
R120
10k
R125
15k
R52
47k R55 330
R77
15k
R138
100
R141
100
R145
100
R143
100
R148
100
R144
100
R146
1k
R122
100k
R117
100
R142
100
R140
100
R133
100
R112
2.7k
R102
1M
R121
33k
R130
22k
R134
15k
R88
2.7k
R137
1k
R104
1M
R126
33k
R127
15k
R84
33k R85
33k
R93
2.2k
R96
2.2k
R47
1M
R60
33k R59
33k
R44
2.2 1/6W Q6
2SC3858
Q8
2SA1494
R45
2.2 1/6W
R98
2.2 1/6W
R94
2.2 1/6W
R56
0.33 5W
R78
0.33 5W
D12
1SS133
C63
10/35
C62
10/35
R40
33 1/4W
R80
33k
Q2
2SA1837
R100
27 1/2W
R86
220 1/4W
R71
27k
R82
5.6k 1/2W
C61
10/25
D28
L-34HDSL
D13
1SS133
R90
1M
Q28
2SC1815GR
R91
33k
R95
5.6k 1/2W
R29
RXE010
CN4
W13 (Board in)
1
2
C22
ECQE1335KF
C21
ECQE1335KF
R32
5W 5.1
R30
5W 5.1
L8
0.18mH
J92
J14
C99
0.1
R75
22k
C45
470/25
C49
470/25
R57
10k
C88
0.1
R61
390
R58
47k
R128
22k
R65
33k
Q14
2SA970GR
C93
0.1
Q15
2SA970GR
C65
10/16
C96
0.1
R103
390
Q31
2SC2240GR
R106
47k
R107
10k
Q32
2SC2240GR
D11
1SS133
R105
100k
R83
33k
D9
1N4004G
Q30
2SA1015GR
R64
22k Q24
2SC1815GR
D26
MTZJ16B
R111
10k
C41
0.47/100 R67 100k
R74
22k
C77
0.47/50
C51
22/100
R99
1k
R150
100
R114
100
D22
1SS133
1 2
D24
1SS133
SW8B 21
22
2325 24
SW8A
SRBM13N-F15
12
13
14 11
15 +
-
IC3A
M5218AP
2
31
C97
0.1
T4
C90
0.01
C28
0.1
+- ~
~
D8
W04G
T5
R139
10k
C35
0.1
D17
1SS133
CN7
W14 ( Board in)
1 2 3
C75
0.01
C72
0.1
C40
3300/16
R147
10k
C31
EC8472MH
C29
0.1
SW7B
22 21
23
C98
0.1
IC1
TA7805S
IN OUT
COM
R118
100k
C92
0.1
D7
1SS133
C32
470/16
CN6
W14 (B oard in)
1 2 3
C86
0.1
C53
0.068
Q13
2SD1407AY
C82
10/25
CN9
W13 ( Board in)
1
2
6

15
May. 2000 DB-700
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
12345678910111213141516171819202122232425262728
POWER BOARD ASSY 230V/240V (02128534)
HIGH
LOW
GAIN CONT.
SIG
AGND
ABMANUAL WRITE
DGND
D+5V
WRITE LED
WRITE SW
MANUAL LED
MANUAL SW
B SW
B LED
A LED
A SW
REDGREEN
PWR INJ 2
PWR INJ 1
F1
PS1 BOARD
12/12
to TRANSFORMER
PRIMARY
240V
230VD / 230VE117V100V
AC CORD
VCTF 100V AC CORD AC CORDSJT 117V
57226604 230VE
SY010 230VD
FC-305 240VA
SW2
8A125V (SB TYPE)
T4AL250V
100V/117V
230V/240V
F1
W12
(230V/240V GND)
G3467157
DB-700 SETTING
USE TEST MODE
TYPE : SOLD STATE
MASTER VOL : MAX
INPUT JACK BOARD 4/13
MEMORY SWITCH BOARD 2/13
SIN WAVE
INPUT : 1kHz
342 mV
-7.0 dbm
+3.0 dbm
1.1 V
A
A A
+5D +5D +5D +5D
+5D +5D +5D +5D +5D
D D D D D
D D D DD
JK2
YKB21-5011
1
2
4
C19
0.1
L6
EXCELDR35V
L7
EXCELDR35V
L5
EXCELDR35V
L1
EXCELDR35V
JK1
YKB21-5166
1
2
3
4
CN3
B3B-PH-K-S
1
12
23
3
C20
0.1
R19
15k
R16
330k
D1
L-174XIT
D2
L-174XIT
D3
L-174XIT
D4
L-174XIT
SW2
EVQ21305R
SW3
EVQ21305R
SW4
EVQ21305R
SW5
EVQ21305R
D5
L-3WSRSGW-CC
CN5
W21 (Board in)
11
22
33
44
55
66
77
88
99
10 10
11 11
12 12
Q10
2SA1015GR
Q12
2SA1015GR
Q9
2SC1815GR
Q11
2SC1815GR
C24
0.1
C27
33/16
C26
33/16
R4
1k
R23
1k
R27
1k
R28
1k
R42
680
R36
4.7k
R33
4.7k
R38
330
R35
1k R34 1k
R39
10k
R37
10k
R41
330 R43 560
T6
HOT
T7
COLD
C30
PY17FY472ML0
T9
COLD
T11
GND EARTH
T12
GND EARTH
T10
HOT
T8
N.C
1
SDDFC-3B-2 TV-8
T10
HOT
T9
COLD
T9
COLD
T10
HOT
C17
15p
BALANCED DI OUT
LINE OUT
XLR
TRS
GND LIFT
CHORUS
MANL/A/B
MUTE
DI OUT HOT
DI OUT COLD
LINE OUT COLD
LINE OUT HOT
AGND
CHO FT SW
A/B FT SW
MANUAL FT SW
DGND
SEND
RETURN
SEND
AGND
RETURN
F.S.CONT
W12
JACK BOARD 3/13
+3.8 dbm
1.2 V
@NO LOAD
HIGH IN (-7.0 dBm / 342 mV)
-7.5 dbm
330 mV
LOW IN (+3.0 dBm / 1.1 V)
@NO LOAD
+2.0 dbm
1.0 V
@NO LOAD
HOT / COLD
+7.2 dbm
1.78 V
@NO LOAD
HOT / COLD
+7.2 dbm
@NO LOAD
1.78 V
A
A A
F
F F
A
A
A
A A
A
A
A
A
A
A
F
F
F
F F
A
AD
F
F
F
F
F
F
F
JK3
YKF52-5003
2
3
1
10
SW1A
SSSU12584A 11
1312
JK6
YKF52-5003
2
3
1
10
JK7
YKB21-5009
1
2
3
JK9
YKB21-5011
1
2
4
JK4
YKB21-5011
1
2
4
JK5
YKB21-5011
1
2
4
SW1B
SSSU12584A 21
2322
CN2
W20 (Board in)
11
22
33
44
55
66
77
88
99
10 10
11 11
JK8
YKB21-5005
1
2
3
4
5
7
8
L2
EXCELDR35V
L3
EXCELDR35V
L4
EXCELDR35V
Q3
2SC2878A
Q4
2SC2878A
Q1
2SC2878A
Q2
2SC2878A
CN1
B3B-PH-K-S
11
22
33
C12
100p
C15
100p
C11
100p
C6
100p
C4
100p
C9 0.1
C2
100p
C3
0.1
C5
100p
C7
100p
C10
0.1
C18
100/50
C13
100/50
C16
100/50
C14
100/50
R14
150
R1
150
R6
150
R7
150
R8
150
R11
150
R24
2.7k
R25
2.7k
R5
2.7k
R22
2.7k
R13
100
R12
100
R21
100
R9
100
R10
100
R18
47k
R15
47k
R17
47k
R20
47k
R2
22k
R3
NIU
C1
100p
C8
0.1
