Roland PM-3 User manual

Thank you, and congratulations on your choice of the Roland Personal Monitor System PM-3.
Features
• The PM-3 personal monitor system is perfect for electronic percussion set-ups such as V-Drums,
SPD-20, etc. And also fills the needs for small keyboard monitoring systems.
• When set up as Roland advises, the woofer unit and two speakers provide a three-dimensional
depth and sound, creating an ambience similar to when playing acoustic drums.
• The woofer unit features an "Active Dual-Drive" system, consisting of two speakers producing a
powerful "low end."
• MIX INPUT, LINE OUTPUT and MAIN INPUT jacks are provided to expand the possibilities
(practice/monitoring/live performance etc.)
Copyright © 2000 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the
written permission of ROLAND CORPORATION.
Owner’s Manual
Before using this unit, carefully read the sections entitled: “IMPORTANT SAFETY
INSTRUCTIONS” (p. 2), “USING THE UNIT SAFELY” (p. 3), and “IMPORTANT NOTES” (p.
4). These sections provide important information concerning the proper operation of the
unit. Additionally, in order to feel assured that you have gained a good grasp of every
feature provided by your new unit, Owner’s manual should be read in its entirety. The
manual should be saved and kept on hand as a convenient reference.

2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION: RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING - When using electric products, basic precautions should always be followed, including the following:
Read all the instructions before using the product.
Do not use this product near water — for example, near a
bathtub, washbowl, kitchen sink, in a wet basement, or near
a swimming pool, or the like.
This product should be used only with a cart or stand that is
recommended by the manufacturer.
This product, either alone or in combination with an amplifier
and headphones or speakers, may be capable of producing
sound levels that could cause permanent hearing loss. Do
not operate for a long period of time at a high volume level
or at a level that is uncomfortable. If you experience any
hearing loss or ringing in the ears, you should consult an
audiologist.
The product should be located so that its location or position
does not interfere with its proper ventilation.
The product should be located away from heat sources such
as radiators, heat registers, or other products that produce
heat.
The product should be connected to a power supply only of
the type described in the operating instructions or as marked
on the product.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
A.
B.
C.
D.
E.
The power-supply cord of the product should be unplugged
from the outlet when left unused for a long period of time.
Care should be taken so that objects do not fall and liquids
are not spilled into the enclosure through openings.
The product should be serviced by qualified service
personnel when:
The power-supply cord or the plug has been damaged; or
Objects have fallen, or liquid has been spilled into the
product; or
The product has been exposed to rain; or
The product does not appear to operate normally or
exhibits a marked change in performance; or
The product has been dropped, or the enclosure
damaged.
Do not attempt to service the product beyond that described
in the user-maintenance instructions. All other servicing
should be referred to qualified service personnel.
GROUNDING INSTRUCTIONS
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock.
This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
DANGER: Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a
qualified electrician or serviceman if you are in doubt as to whether the product is properly grounded.
Do not modify the plug provided with the product — if it will not fit the outlet, have a proper outlet installed by a qualified
electrician.
For the USA
The product which is equipped with a THREE WIRE GROUNDING TYPE LINE PLUG must be grounded.
WARNING:
IMPORTANT:
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the
letter E or by the safety earth symbol or coloured GREEN or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
THIS APPARATUS MUST BE EARTHED
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.
GREEN-AND-YELLOW: EARTH, BLUE: NEUTRAL, BROWN: LIVE
For the U.K.

3
USING THE UNIT SAFELY
• Before using this unit, make sure to read the
instructions below, and the Owner’s Manual.
..........................................................................................................
• Do not open or perform any internal modifica-
tions on the unit.
..........................................................................................................
•Make sure you always have the unit placed so it is
level and sure to remain stable. Never place it on
stands that could wobble, or on inclined surfaces.
..........................................................................................................
• Do not excessively twist or bend the power cord,
nor place heavy objects on it. Doing so can
damage the cord, producing severed elements and
short circuits. Damaged cords are fire and shock
hazards!
..........................................................................................................
• In households with small children, an adult
should provide supervision until the child is
capable of following all the rules essential for the
safe operation of the unit.
..........................................................................................................
• Protect the unit from strong impact.
(Do not drop it!)
..........................................................................................................
• Do not force the unit’s power-supply cord to share an
outlet with an unreasonable number of other devices. Be
especially careful when using extension cords—the total
power used by all devices you have connected to the
extension cord’s outlet must never exceed the power
rating (watts/amperes) for the extension cord. Excessive
loads can cause the insulation on the cord to heat up
and eventually melt through.
..........................................................................................................
• Before using the unit in a foreign country, consult
with your retailer, the nearest Roland Service
Center, or an authorized Roland distributor, as
listed on the "Information" page.
..........................................................................................................
• Always grasp only the plug on the power-supply
cord when plugging into, or unplugging from an
outlet.
..........................................................................................................
• Try to prevent cords and cables from becoming
entangled. Also, all cords and cables should be
placed so they are out of the reach of children.
..........................................................................................................
• If the unit could become a hazard if it moves, all
caster wheels should be removed once the unit has
been placed at the place of installation, or has been
loaded onto a vehicle.
..........................................................................................................
• Never climb on top of, nor place heavy objects on
the unit.
..........................................................................................................
• Never handle the power cord or its plug with wet
hands when plugging into, or unplugging from,
an outlet.
..........................................................................................................
• Before moving the unit, disconnect the power
plug from the outlet, and pull out all cords from
external devices.
..........................................................................................................
• Before cleaning the unit, turn off the power and
unplug the power cord from the outlet (p. 8).
..........................................................................................................
• Whenever you suspect the possibility of lightning
in your area, pull the plug on the power cord out
of the outlet.
..........................................................................................................
• Should you remove the thumbscrews, make sure
to put them in a safe place out of children's reach,
so there is no chance of them being swallowed
accidentally.
..........................................................................................................
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.
Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.
The ●symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the power-
cord plug must be unplugged from the outlet.
The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never
be carried out (are forbidden). The specific thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.

4
IMPORTANT NOTES
In addition to the items listed under “IMPORTANT
SAFETY INSTRUCTIONS” and “USING THE UNIT
SAFELY” on pages 2 and 3, please read and observe the
following:
Power Supply
• Do not use this unit on the same power circuit with any
device that will generate line noise (such as an electric
motor or variable lighting system).
• Before connecting this unit to other devices, turn off the
power to all units. This will help prevent malfunctions
and/or damage to speakers or other devices.
Placement
• Using the unit near power amplifiers (or other equipment
containing large power transformers) may induce hum.
To alleviate the problem, change the orientation of this
unit; or move it farther away from the source of inter-
ference.
• This device may interfere with radio and television
reception. Do not use this device in the vicinity of such
receivers.
• Do not expose the unit to direct sunlight, place it near
devices that radiate heat, leave it inside an enclosed
vehicle, or otherwise subject it to temperature extremes.
Excessive heat can deform or discolor the unit.
•To avoid possible breakdown, do not use the unit in a wet
area, such as an area exposed to rain or other moisture.
• Do not allow rubber, vinyl, or similar materials to remain
on the unit for long periods of time. Such objects can
discolor or otherwise harmfully affect the finish.
• Do not put anything that contains water (e.g., flower
vases) on the unit. Also, avoid the use of insecticides,
perfumes, alcohol, nail polish, spray cans, etc., near the
unit. Swiftly wipe away any liquid that spills on the unit
using a dry, soft cloth.
Maintenance
• For everyday cleaning wipe the unit with a soft, dry cloth
or one that has been slightly dampened with water. To
remove stubborn dirt, use a cloth impregnated with a
mild, non-abrasive detergent. Afterwards, be sure to wipe
the unit thoroughly with a soft, dry cloth.
• Caring for the covering
Clean with a stiff-bristled brush.
• Never use benzine, thinners, alcohol or solvents of any
kind, to avoid the possibility of discoloration and/or
deformation.
Additional Precautions
• Use a reasonable amount of care when using the unit’s
buttons, sliders, or other controls; and when using its jacks
and connectors. Rough handling can lead to malfunctions.
• When connecting / disconnecting all cables, grasp the
connector itself—never pull on the cable. This way you
will avoid causing shorts, or damage to the cable’s
internal elements.
•Asmall amount of heat will radiate from the unit during
normal operation.
• To avoid disturbing your neighbors, try to keep the unit’s
volume at reasonable levels. You may prefer to use
headphones, so you do not need to be concerned about
those around you (especially when it is late at night).
•When you need to transport the unit, package it in the box
(including padding) that it came in, if possible. Otherwise,
you will need to use equivalent packaging materials.
• Use a cable from Roland to make the connection. If using
some other make of connection cable, please note the
following precautions.
• Some connection cables contain resistors. Do not use
cables that incorporate resistors for connecting to this
unit. The use of such cables can cause the sound level
to be extremely low, or impossible to hear. For infor-
mation on cable specifications, contact the manufac-
turer of the cable.

5
Attaching the Mount Bracket
fig.1e
1. Using the provided screws, attach the mount plate to the
bottom of the speaker so it is oriented as shown in the
diagram.
fig.2e
2. Insert the mount base into the slots of the mount plate as
shown in the diagram.
3. Attach the mount base to the mount plate by turning the
thumbscrew.
fig.3e
4. Insert the mount bracket into the mount base as shown in
the diagram.
5. Attach the mount bracket by turning the thumbscrew.
For details on attaching the speakers to the drum stand, refer
to “Sample Setting” (p. 9).
Screw No.10-32 x 3/8" Flat/Phillips Black (included)
Mount Plate
Hole
Mount Base
Thumbscrew
Thumbscrew
Mount Bracket

6
Panel Descriptions
Control Panel
fig.4
1. POWER Switch
This switch turns the power on/off. When the power is on,
the indicator will be lit.
2. PHONES Jack
Connect headphones (optional) to this jack. When you
connect headphones to this jack, no sound will be heard from
the speakers.
3. MIX IN Volume Knob
This adjusts the volume of the device connected to the MIX
INPUT Jacks 8 .
4. HIGH Knob
This adjusts the tone of the treble. Turning this knob
clockwise will increase the treble sound, while turning it
counterclockwise will decrease it.
5. WOOFER Volume Knob
This adjusts the volume of the sound from the woofer unit.
When this knob is turned fully counterclockwise, no sound
will be heard from the woofer unit.
6. MAIN Volume Knob
This adjusts the volume of the device connected to the MAIN
INPUT Jacks 7 .
* The input sensitivity of the PM-3 has been set somewhat high,
to allow use with percussion sound modules having relatively
low output levels. But if you connect a sound module with a
high output level (such as the TD-10), distortion may occur if
you turn the volume level up too much. Be careful.
1
2
3
4
5
6

7
Panel Descriptions
Jacks (Side Panel)
fig.5
7. MAIN INPUT Jacks
Connect the percussion sound module to these jacks. If the
device has only monaural output, use the L (MONO) Jack.
8. MIX INPUT Jacks
Connect a CD/MD player to these jacks. If the device has
only monaural output, use the L (MONO) Jack. The sound
that is input to these jacks will not be output from the LINE
OUTPUT Jacks 9 .
9. LINE OUTPUT Jacks
These jacks output the sound directly that is input to the
MAIN INPUT Jacks 7 .
10. SPEAKERS Jacks
Connect the speakers (included) by using the provided
speaker cables.
* Do not connect any devices except the included speakers.
fig.ADD_logo2
With the Active Dual-Drive system driving one woofer that
is facing outwards, along with the aligned bass-reflex woofer
inside the cabinet, this system, despite its compact size,
delivers rock-bottom bass sounds with impressive attack,
outperforming even bigger, cabinet-sized speakers.
fig.ADD
7
8
9
10

8
Connections/Turning On the Power
* To prevent malfunction and/or damage to speakers or other devices, always turn down the volume, and turn off the power on all devices
before making any connections.
Turning On/Off the Power
* Once the connections have been completed, turn on power to
your various devices in the order specified. By turning on
devices in the wrong order, you risk causing malfunction and/or
damage to speakers and other devices.
1. Make sure that all volume controls on the PM-3 and
connected devices are set to “0.”
2. Turn on the devices connected to the MAIN INPUT Jacks
and MIX INPUT Jacks.
3. Turn on the PM-3’s [POWER] switch.
* Always make sure to have the volume level turned down before
switching on power. Even with the volume all the way down,
you may still hear some sound when the power is switched on,
but this is normal, and does not indicate a malfunction.
4. Turn on the device connected to the LINE OUTPUT Jacks.
5. Adjust the volume levels for the devices.
* Using a connection cable that contains a resistor can cause the
sound level to be low. Use a connection cable that does not
contain a resistor.
Before switching off the power, lower the volume on each of
the devices in your system and then TURN OFF the devices
in the reverse order to which they were switched on.
CD Player
Speaker Cable
(included)
Speaker
(Left)
Speaker
(Right) Mixer
to INPUT
to LINE OUT
Percussion Sound Module
to OUTPUT

9
Sample Setting
fig.7e
Attach the speakers to the drum stand using the mount
brackets (included).
* Do not use any speakers except the included speakers.
* Be sure to place the woofer unit so that the heat sink on the side
panel is not obstructed. Also, make sure the woofer unit does not
touch any curtains or other fabrics.
*The heat sink performs cooling when the woofer unit is placed as
shown above. Do not place the woofer unit on its side or upside
down.
Roland
Roland
Woofer Unit
Speaker
(Left) Speaker
(Right)
Heat Sink

10
Block Diagram
fig.8
POWER AMP
MAIN INPUT
MIX INPUT
LINE OUTPUT
PHONES
SPEAKERS WOOFER
MAIN
MIX IN HIGH
L (MONO)
R
L (MONO)
R
L
R
L
R
WOOFER
POWER AMP POWER AMP

11
This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC.
For EU Countries
Specifications
System Configuration
Speaker (x 2) + Woofer Unit
Rated Power Output
Speaker 50 W/8 ohms x 2
Woofer Unit 100 W/4 ohms
Total 200 W
Nominal Input Level
Main Input -10 dBu
Mix Input -10 dBu
Nominal Output Level
Line Output -10 dBu
Speakers
4” Woofer + 2” Midrange + 1” Tweeter
Woofer Unit
10” Woofer x 2
Controls
Main Volume Knob
Woofer Volume Knob
High Knob
Mix In Volume Knob
Power Switch
Connectors
Main Input Jacks (L/MONO, R)
Mix Input Jacks (L/MONO, R)
Line Output Jacks (L, R)
Speaker Jacks (L, R)
Phones Jack (Stereo)
Enclosure
Speaker Sealed
Woofer Unit Active Dual-Drive
Power Supply
AC 117 V, AC 230 V, AC 240 V
Power Consumption
160 W
Dimensions
Speaker
118 (W) x 115 (D) x 186 (H) mm
4-11/16 (W) x 4-9/16 (D) x 7-3/8 (H) inches
Woofer Unit
555 (W) x 335 (D) x 450 (H) mm
21-7/8 (W) x 13-3/16 (D) x 17-3/4 (H) inches
Weight
Speaker 1.6 kg / 3 lbs 9 oz (for each)
Woofer Unit 30 kg / 66 lbs 3 oz
Accessories
Owner’s Manual
Mount Bracket x 2
Screw (No. 10-32 x 3/8” Flat/Phillips Black) x 8
Speaker Cable x 2
*0dBu = 0.775 V
*In the interest of product improvement, the specifications and/or
appearance of this unit are subject to change without prior
notice.

17055111 3*RAD
