Ronix 221 Series User manual

IMPACT DRILL
2211-2212

USER MANUAL 3
TECHNICAL SPECIFICATIONS
SAFETY INSTRUCTIONS
Basic safety regulations, the code for the product to avoid an
accident, please read carefully.
.WORK PLACE
1) Keep work place clean and bright, Chaos and dark eld can
cause accidents
2) Don’t in explosive environment, if there are ammable liquids,
gases or dust environment operating the machine.
Machine sparks can ignite the dust and gas.
3) Let children and bystanders left machine operation. Distractions
can make you loose control.
.ELECTRICAL SAFETY
1) The machine plug must be matched with the socket. Must not
be modied in any way plug. Grounding machine
Model No. 2211 2212
Rated power input 600W 800W
Rated voltage 110V~60Hz 110V~60Hz
No-load speed 0-3000/min-1 0-3000/min-1
Chuck capacity 13-30mm 13-30mm
Max. drilling in steel 13mm 13mm
Max. drilling in wood 20mm 20mm

IMPACT DRILL
4
Can not use any conversion plug. Without modication of plugs
and matching socket will reduce the shock hazard.
2) Avoid human contact surface of the ground. Such as pipe,
heat sink, and refrigerators, if you body grounding will increase
the risk of electric shock.
3) The machine must not be exposed in the rain or damp envi-
ronment, water into the machine will increase the risk of electric
shock.
4) Shall not abuse the wire. Wires must not be carrying, pull
the machine or pull out the plug. Let the machine away from
Heat oil , edges or moving parts. Damaged or coil of wire will
increase the risk of electric shock.
5) When the machine outdoor use, se external wire suitable for
outdoor line. Suitable for outdoor use lines will reduce the shock
hazard.
.PERSONAL SAFETY
1) Stay alert, when operating the machine in operation and atten-
tion is in stay awake. Do not in tired, drugs, alcohol or treatment re-
sponse under operating the machine. During the machine operation
energy dispersion can cause serious personal injury.
2) Use safety equipment. Always wear goggles, Safety devices,
such as the appropriate conditions of dust masks antiskid safety
shoes, helmet, hearing protection devices can reduce personal
injury.
3) Avoid sudden starts. Ensure switch when insert the plug is
in the position. Finger on the switch has been switched on or
switch is switched on when inserted into the plug may cause
danger.
4) Before the machine on, remove all keys or wrench, Wrench

USER MANUAL 5
or key on the legacy in rotating machine parts can cause human
hody damage
5) Don’t stretch hand too long, always watch your step and balance.
This accident cases can be a very good control machine.
6) Dress properly, don’t wear loose clothes or wear jewelry,
make your hair, clothes and sleeve away from moving parts.
Loose clothing, accessories or long hair may be involved in the
moving parts.
7) If you provide the chip removal device dust collection equipment
connection device, make sure they connected in good condition
and used properly. Using this device can reduce the risk of debris
caused.
ELECTRIC TOOLS USE AND THE ATTENTION
1) Don’t abuse power tools, according to the application using the
appropriate power tools. Choose the appropriate design rating
electric tools will make your work more effective, safer.
2) If switch tools cannot connect on or off the power and will
not be using the tool. Can’t use the switch to control the electric
tools is a dangerous and must be repaired.
3) On any adjustment, before changing accessories or storage
electric tools, must pull the plug from the power supply or battery
box off power supply. The protective measures to reduce the risk
of electric tools suddenly start.
4) Will spare electric tools storage in children and scope, and
don’t let not familiar with electric tools or do not understand
these instructions to operate power tools, Power tools in the
hands of untrained user is dangerous.
5) Maintenance of electric tools. Check the installation of the
moving part deviation or gets stuck, parts damage and other

IMPACT DRILL
6
conditions affecting the operation of electric tools. If there are
any damage, electric tools must be repaired before use. Many
accidents caused by poor maintenance of electric tools.
6) Keep the cutting tools sharp and clean. Maintain good cutting
tool with a sharp cutting edge not easily jammed and easy to
control.
7) According to the instruction for us, and intends to use the
way of special type electric tools requirements, considering the
operation conditions and operation to use power tools, acces-
sories and tools of cutting head, cc. electric tools will be used for
those who do not tally with the requirements of operation may
cause dangerous situation.
MAINTENANCE
Send your power tools to the professional maintenance personnel,
must use the same spare parts for replacement This will ensure
that the maintenance of the safety of electric tools.
PERFORMANCE AND FUNCTION
Electromagnetic rotary motor or electromagnetic reciprocating
small capacity of motor rotor magnetic eld cutting power op-
eration, through the drive mechanism drive operation device,
driving gear increase the power of the drill bit, so that the drill
bit scraping surface can better into the object, Electric drill gen-
erally applied in the construction industry, industrial, medical,
geological prospecting, etc. The main structure.

USER MANUAL 7
.MOTOR
For single-phase series motor ventilation protection on its own.
Insulation for class E. The stator and the armature wire with
high strength polyester lacquer copper wire and through with
trapezoidal copper platoon to thermosetting plastic and mica
sheet, as insulating medium. Lectrode axis between the core
and pressure into thermosetting plastics, 6,10,13 mm drill hos-
ing cover plastic engineering plastics, 19,23mm drill in the alu-
minum shell is equipped with double insulation structure plastic
bushing.
.SWITCH
Adopt the stirrup quickly cut off and has the self-locking device
of the electric drill switch.
.CAPACITOR
Anti-interference electric drill with a capacitor inside the handle,
which can inhibit tools interference with innite power and tele-
vision.
.REDUCER
Box shell and middle cover adopt the original compound aluminum
alloy die casting and become, strong and durable, gear for xed
gear and the high frequency heat treatment is not easy to wear.

IMPACT DRILL
8
.THE POWER CORD AND PLUG
Three core cord adopts three pin plug, power cord en outside
into the casing is equipped with insulation sheath to protect the
soft line, the other end connection plug frame and then pressed
into plastic (rubber), made from sealed, power plug , sale and
reliable.
.DRILL CHUCK
6,10,13 un using three claw type drill chuck, using three claw
type drill chuck .drill chuck ,please rst remove hole and drilling
shaft on the surface of the forbidden material. Including the anti-
rust wax, and then put the drill chuck loading shaft can be used.
MAINTENANCE INSTRUCTIONS
Electric voltage should comply with the provisions of the electric
drill nameplate
1) Electric drill before use should be no load running a minute,
wait for rotational normal before use.
2) In the process of operation shall not be too hard and all speed
anomalies or workpiece stuck, should reduce or stop hard. prevent
damage to the motor overload.
3) Keep the commutator surface clean, such as found black
mark on the surface of commutator dirt is more, should remove
dirt, brush serious wear and tear, it should be replaced timely
in pairs.
4) Ventilation must be kept clean and smoothness of a drill,
prevent damage of scrap iron or other material into the electric

USER MANUAL 9
drill internal components.
5) electric hand drill moves should hold the drill handle, can’t
use cable electric led or hand cable cable from the socket.
6) Transmission of rolling bearing and gear grease always keep
clean and plentiful.
7) Long-term used electric drill, application before use 500V
megohmmeter measureing insulation, resistance
between metal shell and winding, the resistance value should
be greater than 2 MQ, otherwise must be inspection on winding
and dry processing.
8) Torque control methods: screw torque adjustment ring up, is
the larger the scale value, the greater the torque. On the other
hand, the torsion n-tuning loop downward spiral, the scale value
is smaller, the smaller force.
9) Note: With a electric drill screw must want to press switch
system, its correct position is with your index nger pressure
switch system and unavailable means more pressure.
10) To avoid dust and iron lings from ventilation holes into the
drill the rotor part, don’t pull the power cord, so as not to break,
Do not use electric drill when use hammer percussion, not to
impose the impact of the radial drill shaft part.
11) Electric drill due to ventilation, cooling the long-term use
of internal dust, dust will make gear and bearing lubricating oil
mixed with metamorphic blot aggravate wear, particularly, alter-
native use. In order to guarantee the selection of the electric drill
precision, reduce because of the bearing wear and produce too
much clearance, so need to clean the fatliquoring and internal
lubrication.
