Ronix 2221 User manual

INSTRUCTION MANUAL
IMPACT DRILL 13mm
2221

USER MANUAL
SPECIFICATION
PARTS LIST
1
Voltage 220V
Frequency 50Hz
Power input 1050W
No load speed 0~1200/0~3200 rpm
Max Drilling capacity in Wood 40mm
Max Drilling capacity in Steel 13mm
Max Drilling capacity in Concete 16mm
Net. Weight 3 Kg
Accessories chuck key 1pc / depth guide 1pc /
side handle 1pc

IMPACT DRILL 13mm
NOTE:
In order to achieve the best performance of your product, please
read this instruction manual carefully before using, and keep it
for future reference.
CAUTION:
To reduce the risk of electric shock do not open this device,
there are not serviceable parts for customers. Please refer any
maintenance or repair to qualied personnel.
This sign means the existence of dangerous voltage at the
inside of the unit, which states a risk of electric shock.
This sign means that there are important instructions of operation
and handling in the manual that comes with this device.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING!
- Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, re
and or serious injury.
- Save all warnings and instructions for future reference.
- The term “power tool” in the warnings refers to your mains-operated
(corded) power tools or battery operated (cordless) power tool.
.WORK AREA SAFETY
- Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
- Don’t operate power tools in explosive atmospheres, such as
in the presence of ammable liquids, gases or dust. Power tools
2

USER MANUAL
create sparks which may ignite the dust or fumes.
- Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.
.ELECTRIC SAFETY
- Power tool plugs must match the outlet. Never modify the plug
in any way. Don’t use any adaptor plugs with earthed (grounded)
power tools. Unmodied plugs and matching outlets will reduce
risk of electric shock.
- Avoid body contact with earthed or grounded surfaces such as
pipe, radiators, ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded.
- Don’t expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
- Don’t abuse the cord. Never use the cord for carrying, pulling
or unplugging the power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or entangled cords
increased the risk of electric shock.
- When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Using a cord suitable for outdoor use
will reduce the risk of electric shock.
- If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use of
an RCD reduces the risk of electric shock.
- Use of power supply via a RCD with a rated residual current of
30mA or less is always recommended.
3

IMPACT DRILL 13mm
.PERSONAL SAFETY
- Stay alert, watch what you are doing and use common sense
when operating a power tool. Don’t use a power tool while you
are tired or under the inuence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result
in serious personal injury.
- Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes,
hard hat, or hearing protection used for appropriate conditions
will reduce personal injuries.
- Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or battery
pack, picking up or carrying the tool. Carrying power tools with
your nger on the switch or energizing power tools that have the
switch on invites accidents.
- Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
- Don’t overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected
situations.
- Dress properly. Don’t wear loose clothing or jewelry. Keep
your hair, clothing, and gloves away from moving parts. Loose
cloths, jewelry or long hair can be caught in moving parts.
- If devices are provided for connection of dust extraction and
collection facilities, ensure these are connected and properly
used. Use of dust collection can reduce dust-related hazards.
4

USER MANUAL
.POWER TOOL USE AND CARE
- Don’t force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and
safer at the rate for which it was designed.
- Don’t use the power tool if the switch doesn’t turn it on and
off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
- Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
- Store idle power tools out of the reach of children and don’t
allow persons unfamiliar with power tool or these instructions to
operate the power tool. Power tools are dangerous in the hand
s of untrained users.
- Maintain power tools. Check for misalignment or binding of
moving parts, breakage o parts and any other condition that
may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
- Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are
easier to control.
- Use the power tool, accessories and tool bits etc. in accordance
with the instruction, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
5

IMPACT DRILL 13mm
.SERVICE
- Have your power tool serviced by qualied repair person using
only identical replacement parts. This will ensure that the safety
of power tool is maintained.
- Follow instruction for lubricating and changing accessories.
- Keep handles dry, clean and free from oil and grease.
.HAMMER DRILL SAFETY WARNINGS
- Wear ear protectors when impact drilling. Exposure to noise
can cause hearing loss.
- Use auxiliary handle(s), if supplied with tool. Loss of control
can cause personal injury.
- Hold power tool by insulated gripping surface, when performing
an operation where the cutting accessory may contact hidden
wiring or its own cord. Cutting accessory contacting a “live” wire
may make exposed metal parts of the power tool “live” and
could give the operator and electric shock.
- Always be sure you have a rm footing. Be sure no one is below
when using the tool in high locations.
- Hold the tool rmly with both hands.
- Keep hands away from rotating parts.
- Don’t leave the tool running. Operate the tool only when hand-held.
- Don’t touch the bit or the work piece immediately after operation;
they may be extremely hot and cold burn your skin.
- Some material contains chemical which may be toxic. Take
caution to prevent dust inhalation and skin contact. Follow material
supplier safety data.
6

USER MANUAL
INSTRUCTIONS FOR USE
.THIS DRILL HAS THE FOLLOWING FUNCTION
The operating switch is used for all work carried out with the
drilling machine. With the speed selection via the regulator
wheel you have optimum control of the machine.
The machine can be set to continuous operation with the
locking button.
The second handle gives you an additional way of holding the
machine rmly.
Depending on the position of the hammer drilling/drilling switch,
you can use your drilling machine as a hammer drill or rotating drill.
The direction switch controls the direction of motion when the
machine is used as a screwdriver or if you would like to remove
a drilling bit that has become jammed.
Using the adjustable bit stop you can x the depth of blind holes
accurately during drilling.
7

IMPACT DRILL 13mm
The mechanical gear box of the machine can be set on two
different positions:
1) Low speed: for drilling bigger holes which needs more force.
2) High speed: for drilling holes with lower diameters.
.PREPARING THE DRILLING MACHINE
WARNING!
When performing the following work, always ensure that the
machine is not connected to the mains power supply.
.INSERTING THE SECOND HANDLE
In order to assemble the second handle, release it by rotating
the lower part anti-clockwise so that you can easily pull the handle
over the drill chuck on to the ange located behind it. Then turn
the handle to a working position that is comfortable for you and
x it in place by tightening it (rotating the lower part clockwise).
8

USER MANUAL
.ADJUSTING THE BIT STOP
The second handle has a retainer for the bit stop. Insert a drill.
Now release the handle. Push the bit stop forwards until its end
is in line with the end of the drill. Now push the bit stop back until
the distance between the end of the bit stop and the end of the
drill corresponds to the depth to which you would like to drill.
.INSERTING THE DRILL
First remove the mains supply from the socket. Turn the ring of
the drill chuck until the clamping jaws are open wide enough.
Insert the drill into the clamping jaws of the drill chuck.
9

IMPACT DRILL 13mm
WORKING WITH THE DRILLING MACHINE
Ensure that the mains power supply voltage is the same as the
operating voltage of your machine. For details, please see the
type plate. Insert the correct drill for the type of job to be performed.
If necessary, adjust the bit stop. Adjust the speed of the machine
using the regulating wheel on the operating switch. The more
the operating switch is pressed in, the faster the drill rotates. Set
the direction switch to the desired direction of motion. Never alter
the position of the hammer drilling switch or the direction switch
when the machine is switched on. The machine is switched on
by pressing the operating switch. When the operating switch is
released, the machine stops. If you would like to use continuous
operation press the locking button while the operating switch is
pressed. In order to switch off the machine during continuous
operation, press the operating switch again and then let it go.
Do not touch the drill chuck while the machine is switched on.
.DRILLING TIPS
- Always insert the correct size and type of drill or screwdriver.
- Set the machine to the correct speed.
- Always hold the machine tightly by the handle and second han-
dle.
- When drilling wood and metal, set the hammer-drilling switch
to drilling.
- When drilling masonry, set the hammer-drilling switch to
hammer drilling.
- When using the machine as a screwdriver, set the hammer-
drilling switch to drilling.
- Set the direction switch to the correct direction.
10

USER MANUAL
- Never change the direction of motion when the machine is
switched on.
CARE OF THE TOOLS
.OVERLOAD
Never use excessive force when drilling. Too much pressure
reduces the speed of the machine, and the required power is
greatly reduced. This may result in overload, which can damage
the motor of the drilling machine. When the drilling machine
becomes too hot, allow it to run for two minutes without a load
and then interrupt working for a short time. Clean the drilling machine
with a clean cloth and a brush. Ensure that the ventilation slits are
not blocked.
WARNING!
Always use the additional grips which come with the appliance.
Losing control of the appliance may result in injuries.
11
