Ronix RNP-AH2NPD2812-IRM User manual

Preliminary
Full-HD, Multi Video format
Vari-focal lens Indoor Dome
Operating Instruction
Before installing and using this product,
please read the instruction fully and keep it handy for use later on.
1080P

Safety Precaution
03
ULTRA CLEAR RESOLUTION CAMERA
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To prevent electric shocks and risk of fire hazards, do NOT use other than
specific power source.
The symbol is intended to alert the user to the presence of important
operating and maintenance(servicing) instructions in the literature
accompanying the unit.
The symbol is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
Warning :
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
Caution :
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority
to operate the equipment.
Mains power quality should be that of a typical commercial environment. If the user
of the model requires continued operation during power mains interruptions, it is
recommended that the model be powered from an uninterruptible power supply
(UPS) or a battery.

ULTRA CLEAR RESOLUTION CAMERA
Safety Precaution
04
NOTICE
The image used in this instruction manual are processed to help comprehension
and may differ from actual video of the camera.
Avoid installing areas where has shock or vibration which results in the problems.
Pay attention to safety when laying the connection cable and observe that the cable
is not subjected to heavy loads, kinks or damage and no moisture can get in.
Never open the device such as boards or lens.
The warranty becomes void if repairs are undertaken by unauthorized persons.
Maintenance and repair have to be carried out only by authorized service centers.
Use only a mild detergent to clean the housing.
The camera should never be operated beyond the technical specifications.
This can lead to destruction.
The camera should never be operated in water.

ULTRA CLEAR RESOLUTION CAMERA
Contents
05
Safety Precaution
p.03~04
Contents
p.05
Features
p.06
Composition
p.07
Dimensions
p.08
Part Names
p.09
Installation Instructions
p.10~12
Operating Instructions
p.13~29
Specifications
p.30~31

ULTRA CLEAR RESOLUTION CAMERA
Features
Key Features
06
• 1/2.8” SONY Exmor CMOS sensor
• 1080p/720p THD, AHD, CHD Video or 960H CVBS Video Selectable
• THD/AHD/CHD Video Transmission Distance over Coax.; 500M
• Automatically removable IR Cut filter by Dual filter switcher
• Built-in f=2.8~12mm F1.4 Mega pixel DC Auto Iris Vari-focal lens
• Sensitivity of 0.002 Lux (BW@IRE 40, Sens-up On/ IR Off)
• D-WDR (Wide Dynamic Range)
• Improved noise reduction 2D+3D-NR(THD/AHD/CHD), 2DNR(960H)
• FOCUS ASSIST for Error free focus adjustment
• 2 Auto(AE/AWB) control
• LSC (Lens Shading Compensation)
• DPC (Defective Pixel Compensation)
• Motion detection, Privacy mask, BLC/HSBLC, Defog, Sens-up(~x30),
Mirror/Flip, Freeze, Negative Image, IR Smart, Cam Title
• Built-in 2pcs High power SMD LED
• OSD MENU & Video Sub-out port for easy installation & maintenance
• Circuit protection against faulty connection in power polarity
• Zoom & Focus Adjustment on 3-Axis gimbal
• Double side Anti-scratch Hard coated bubble dome
• Quick installation with Easy Adaptor (Flat or Tilted Adaptor)
• Power: 12VDC

07
Composition
ULTRA CLEAR RESOLUTION CAMERA
Mounting Template Operating Instruction
Video Sub-out Cable
(LED type)
Mounting Screw:
3.5 x 25mm (3pcs)
Plastic Anchor:
6 x 30mm (3pcs)
Dome Camera
Easy Adaptor
(Flat type) Open & Adjust
Driver (1pc)
Easy Adaptor
(Tilted type)

(unit : mm)
ULTRA CLEAR RESOLUTION CAMERA
Dimensions
08
• Extreme care should be taken NOT to scratch the bubble dome surface while
the camera installing or adjusting.
• Care should be taken the cable is NOT to be damaged, kinked or exposed in
the hazardous area.
• Do not expose the camera directly to a strong light source such as the sun or
spot light.
CAUTION
Tilted adaptor
Ø116
Ø80
94 (with Flat adaptor)
52.5
116.3 (with Tilted adaptor)

ULTRA CLEAR RESOLUTION CAMERA
Part Names
09
Dome Cover
Lens
Bubble Shield
Bubble
Dome Base
Easy Adaptor
Flat type
OSD Control &
Video format Switch
SMD LEDs
Video Sub-out
connector
Focus & Zoom
adjustment
Light
Sensor
Power Cable
3-Axis Gimbal
Tilted Easy Adaptor

ULTRA CLEAR RESOLUTION CAMERA
Installation Instructions
10
Mounting Screw
(3.5x25mm)
Plastic Anchor
(6x30mm)
OPEN
LOCK
1. Drill three holes for mounting on the ceiling or wall.
2. Place the Easy Adaptors at the pre-drilled installation position and fix it by
using mounting screws.
3. Route the power/video cable to the connecting place.
4. Attach the dome base assembly to the Easy Adaptor.
5. Adjust the camera’s viewing angle (Pan, Tilt, Rotation)
(Then remove the caution sticker. Refer to p.14)
6. Assemble the dome cover to the dome base unit.
Open & Adjust
Driver

ULTRA CLEAR RESOLUTION CAMERA
Installation Instructions
11
Limit of pan & tilt
1) Pan limit:
Pan is limited to +/- 165°.
Do NOT force to rotate the gimbal
over the limit to prevent from the
internal damage.
2) Tilt limit:
Tilt is limited to 25° min ~ 90° max.
with reference to the ceiling when the
inclination of camera module is 0°,
that is, the image is aligned horizontally.
3) Inclination limit
(Horizontal image alignment):
Inclination limited to +/-60° max.
25º
10º
90º
Tilted Easy Adaptor
■ EXTENDED VIEWING ANGLE
15º
Zoom & focus adjustments
• Turn the Focus gear until the sharpest
focus is made.
• Adjust the zoom for the proper viewing
angle.
Use the open & adjust driver supplied.
• Be careful the IR LEDs when you control
the OSD setting with the joystick.
• Remove the sticker on the gimbal after
the OSD setting
CAUTION

Power Supply Connections
Camera can be operated with the
regulated or unregulated 12VDC but
the regulated power supply of 12VDC
is recommended.
Camera is protected from the damage
by the reverse connection of polarity.
VIDEO (BNC)
POWER ( )
ULTRA CLEAR RESOLUTION CAMERA
Installation Instructions
12
■Detach the dome camera from the easy adaptor
Push the hook on the dome base and swing the dome base to counter-
clock wise. Then detach the dome camera from the installed easy adaptor.
1
1
2
2
3
■Open the dome cover
②Hold the Dome housing with one hand and turn the open tool until Dome
Cover is sufficiently open.
①Insert wide side of Open Tool into the lock of Dome Cover.
③Once Dome Base and Dome Cover are detached, press the edge of
Dome Cover and pull it down with hands.

ULTRA CLEAR RESOLUTION CAMERA
Operating Instructions
13
OSD Control &
Video format Switch
Using OSD Control Controller
Using Video Format Switch
Setup menu can be accessed and controlled by OSD control joy stick on the
gimbal of the camera unit. Five commands are available with the joy stick.
The design of OSD could be different according to the Model.
Switching video format can be selected by Video format switch on the gimbal
of the camera unit. 4 directions are available. The default setting is THD format.
Description of the OSD control operation
1] SET Key (●) : Access to the menu or enter the setting.
To enter the main menu, press the Set Key down.
2] UP/DOWN Key (▲/▼) : Choose the desired sub-menu and to move
the cursor up or down.
3] LEFT/RIGHT Key (◄/►) : Set up the value of the selected menu. Used
to adjust the desired menu selection and to move the cursor left or right.
Description of the Multi Video format operation
1] THD (Up▲) : Moving up direction for about 3 seconds to THD format.
2] 960H (Down▼) : Moving down direction for about 3 seconds to 960H format.
3] AHD (Left◄) : Moving left direction for about 3 seconds to AHD format.
4] CHD (Right►) : Moving right direction for about 3 seconds to CHD format.

OSD menu Startup
• EXIT : Enters ‘EXIT’ menu.
• RETURN : Returns to the previous menu.
• DEFAULT : Restores to factory default.
Press the ‘OSD menu SET key’ down to access the setup menu mode.
MAIN MENU
1. LENS
2. FOCUS ASSIST
3. EXPOSURE
4. BACKLIGHT
5. WHITE BAL
6. DAY & NIGHT
7. NR
8. SPECIAL
9. ADJUST
10. EXIT
OFF
ATW
AUTO
SAVE&END
DC
ULTRA CLEAR RESOLUTION CAMERA
Operating Instructions
14
OSD menu Table
MAIN MENU SUB MENU CONFIGURATION
LENS
FOCUS ASSIST
EXPOSURE
BACKLIGHT
DC
MANUAL
DN DWELL
SHUTTER
AGC
SENS UP
BRIGHTNESS
D-WDR
DEFOG POS/SIZE, GRADATION(0~2), DEFAULT
INDOOR, OUTDOOR
MODE
IRIS SPEED
0~15
SELECT
DISPLAY
BLACK MASK
LEVEL
MODE
OFF
HSBLC
FLK, 1/60(1/50), 1/30(1/25), AUTO, x30~x2, 1/50000~1/200
1~100
OFF, AUTO (2x~30x)
ON(LEVEL:0~8), AUTO, OFF
OFF, AUTO
AREA1~4
ON, OFF
ON, OFF
0~100
ALL DAY, NIGHT(AGC LEVEL)

ULTRA CLEAR RESOLUTION CAMERA
Operating Instructions
15
WHITE BAL
DAY & NIGHT
ADJUST
EXIT
NR
SPECIAL
BACKLIGHT
ATW, AWC->SET, INDOOR, OUTDOOR, MANUAL(BLUE/RED GAIN), AWB
LEVEL, AREABLC
AUTO
EXT
B/W
COLOR
2DNR (960H)
3DNR (THD/AHD/CHD)
CAM TITLE
DEFFECT
MOTION
PRIVACY
LANGUAGE
DEFECT
RS-485*
SAVE&END, NOT SAVE, RESET
SHARPNESS
MONITOR
LSC
VIDEO OUT
COMET (960H)
OUTPUT SIZE
(THD/AHD/CHD)
D->N(AGC/CDS), D->N(DELAY), N->D(AGC/CDS), N->D(DELAY)
D->N(DELAY), N->D(DELAY)
BURST, IR SMART, IR PWN*
OFF, ON
ENG, TUR, NED, POR, RUS, POL, SPA, ITA, FRA, GER,
CHN1/CHN2
OFF, ON
LIVE DPC
WHITE DPC
BLACK DPC
CAM ID, ID DISPLAY, BAUDRATE
AUTO, OFF
LDC, CRT
OFF, ON
NTSC/PAL
1080P, 720P
OFF, ON
MIRROR, V-FLIP, ROTATE, OFF
SELECT
DISPLAY
COLOR
TRANS
AGC LEVEL(0~255), LEVEL(0~100)
SENS-UP, POS/SIZE, START, DPC VIEW, AGC
POS/SIZE, START, DPC VIEW, LEVEL
AREA1~4
COLOR, INV, MOSAIC
AREA1~4
OFF, ON(POSITION, SIZE)
0~100
Green, Red, White, Blue
0.00~1.00
0.25~1.00
VIEW TYPE, OSD VIEW, ALARM OUT,
ALARM SIG, TIME
White, User, Cyan, Green,
Yellow, Blue, Red, Black
FREEZE
MIRROR
NEG. IMAGE
SELECT
DISPLAY
SENSITIVITY
COLOR
TRANS
ALARM*
(*) : Not Available

ULTRA CLEAR RESOLUTION CAMERA
Operating Instructions
16
DC LENS MODE
1. MODE
2. IRIS SPEED
3. RETURN
OUTDOOR
RET
OSD menu Setup
1. LENS
• INDOOR: Optimized of indoor environment.
• OUTDOOR: Optimized of outdoor environment. Can set Min.SHUTTER
speed or Max.SHUTTER speed
: Selects lens mode according to installation place.
: Sets IRIS speed for INDOOR or OUTDOOR mode.
1-1. DC LENS MODE
1-2. MANUAL LENS MODE
(default: DC)
1-1-1. MODE
1-1-2. IRIS SPEED
: Horizontal wave or bar may be seen when MANUAL is selected and the camera
is working under florescent or similar lights.
Lens can be selected either DC or MANUAL lens.
Lens MUST be set to DC for the best image when DC iris lens is installed
2. FOCUS ASSIST
9
llllllllllllllllllllll
OUTDOOR MODE
1. MIN SHU.
2. MAX SHU.
3. RETURN
1/25
1/2000
RET
Usually cameras are installed in the day time and they often become OUT OF
FOCUS at night time and IN FOCUS again at next day time.
This problem can occur at any cameras regardless of types or manufacturers.
FOCUS ASSIST menu is the unique and patented feature that prevents from
the wrong focus and helps the EXACT NEEDLE focus by simulating DAY &
NIGHT conditions.
Set zoom first and adjust focus to get NEEDLE FOCUS while switching at DAY
& NIGHT.

ULTRA CLEAR RESOLUTION CAMERA
Operating Instructions
17
13
llllllllllllllllllllll
45
llllllllllllllllllllll
FOCUS ASSIST
1. DN DWELL
2. RETURN
ADJUST ZOOM & FOCUS ON LENS
FOR DAY & NIGHT WHILE SWITCHINGS
5 SEC
RET
EXPOSURE
1. SHUTTER
2. AGC
3. SENS-UP
4. BRIGHTNESS
5. D-WDR
6. DEFOG
7. RETURN
OFF
OFF
RET
FLK
- - -
13
llllllllllllllllllllll
48
llllllllllllllllllllll
EXPOSURE
1. SHUTTER
2. AGC
3. SENS-UP
4. BRIGHTNESS
5. D-WDR
6. DEFOG
7. RETURN
OFF
OFF
RET
- - -
AUTO
2-1. DN DWELL
: ICR switcher switches DAY & NIGHT at the interval of D/N DWELL to help
the EXACT NIDDLE focus at DAY and NIGHT mode.
Further simulations are performed internally during switching.
• FLK : Reduces the flicker in video when NTSC/PAL mode is used in 50Hz /
60Hz fluorescent lighting respectively.
• 1/60(1/50), 1/30(1/25), x30~x2, 1/50000 ~ 1/240: Shutter can be set to fix.
• AUTO: Optimizes the video level by controlling the iris and the shutter speed
automatically.
3. EXPOSURE
: Selects AUTO, FLK(Flickerless), or set manually.
If SHUTTER set to MANUAL or FLK modes, SENS-UP mode is inactivated.
If DC LENS MODE in the LENS option is set to OUTDOOR, SHUTTER mode
is inactivated.
3-1. SHUTTER (default: FLK)
[video format: THD/AHD/CHD] [video format: 960H]

ULTRA CLEAR RESOLUTION CAMERA
Operating Instructions
18
DEFOG
1. POS/SIZE
2. GRADATION
3. DEFAULT
4. RETURN RET
0
llllllllllllllllllllll
: Adjusts the brightness of video(1~100).
3-4. BRIGHTNESS
• AUTO: SENS-UP is enabled or disabled automatically by the scene brightness.
Higher SENS-UP can get the brighter video but the slower frame rates with more
white pixels. If set to AUTO, maximum integration limit for SENS-UP can be set
to x2, x4, x6, x8, x10, x15, x20, x25, x30 in SENS-UP menu.
• OFF: Disables SENS-UP.
: The brighter video can be obtained by increasing the exposure time in the night
with SENS-UP. SENS-UP is the maximum integrations of frame by DSS (Digital
Slow Shutter) in the low light.
3-3. SENS-UP
: AGC(0~15) amplifies the video gain for brighter video but noise and white pixel
accordingly. AGC level less than 10 disables AUTO in DAY/NIGHT.
3-2. AGC
3-5. D-WDR
※CVBS video signal:Connecting 2nd video to CVBS port disables D-WDR
function temporary. It should be considered when installer adjusts the video
with installation monitor via CVBS video signal.
: Enhance the foggy video according to status of scene. Video quality can be
less in normal environments. Setting to AUTO, it can be adjusted working
area on screen.
3-6. DEFOG (default: OFF)
: Sets the position and size
to make activated area box.
: Sets the level from 0 to 10.
3-6-1. POS/SIZE
3-6-2. GRADATION
: Restores to factory default.
3-6-3. DEFAULT
: Improves the visibility for the high bright area and the dark area by compen-
sating the video gain. Selects OFF, AUTO or ON. With D-WDR On, the level
can be set. Care should be taken to select this mode because video may
lose its quality in some environments by the over compensation.
Video noise can be increased in the dark area accordingly.

ULTRA CLEAR RESOLUTION CAMERA
Operating Instructions
19
20
llllllllllllllllllllll
HS BLC
1. SELECT
2. DISPLAY
3. BLACK MASK
4. LEVEL
5. MODE
6. DEFAULT
7. RETURN
ALL DAY
RET
AREA1
ON
ON
4. BACKLIGHT
: Cuts out the highlight area with black mask and excludes it from compensation.
4-1. HS BLC
4-2. BLC
4-1-1. SELECT : Select areas to set HSBLC function
4-2-1. LEVEL (default: MIDDLE) : Sets the BLC level.
4-2-2. AREA : Sets BLC area with position and size.
4-2-3. DEFAULT : Restores to BLC factory default.
4-1-2. DISPLAY : Displays ON/OFF the selected area and adjusts position/size.
4-1-3. BLACK MASK : Sets ON or OFF the black mask.
4-1-4. LEVEL (0~100): Sets the HS BLC level. It determines the video level
that starts cutting out. Lower setting starts the cut out at lower level.
The cut out area is masked with black color.
• ALL DAY : Enables HS BLC regardless of DAY or NIGHT mode.
• NIGHT : Enables HLC only when camera works in NIGHT mode.
Can be adjusted AGC level.
4-1-5. MODE : Sets NIGHT only or ALL DAY.
4-1-6. DEFAULT : Restores to factory default.
: Cuts out the highlight area with black mask and excludes it from compensation.
It has target areas for compensation and each area can be set LEVEL, MODE,
and DISPLAY.
: This function is used to brighten an image in the foreground with a highly
light area behind it such as sunlight, limiting the affect of silhouette.

ULTRA CLEAR RESOLUTION CAMERA
Operating Instructions
20
5-1. ATW (Auto Trace White balance)
5-2. AWB (Auto White Balance)
D&N AUTO
1. D N (AGC)
2. D N (DELAY)
3. N D (AGC)
4. N D (DELAY)
5. RETURN
5. WHITE BALANCE (default: ATW)
ATW, AWB, OUTDOOR, INDOOR, AWC->SET, and MANUAL are available for
the white balance modes.
6. DAY & NIGHT
: Automatically tracks the changes of color temperature and continuously
adjusts the white balance. The white balance range is 2,500°K~8,500°K.
: Automatically tracks the changes of color temperature and continuously
adjusts the white balance. The white balance range is 2,000°K~11,000°K.
5-4. OUTDOOR
: Optimized for outdoor sunlight applications and more easily compensates
ATW for high color temperature such as sunlight.
5-5. INDOOR
: Optimized for Indoor installation and more easily compensates ATW
for low color temperature such as incandescent lights.
5-6. AWC->SET
: WB is performed only whenever ● is pressed.
5-3. MANUAL
: White balance is fixed to the settings by Red_GAIN and Blue-GAIN.
This mode can be used only when the color temperature does not vary.
DAY/NIGHT is used to control the setting during day-time and night-time
operation. Select the mode according to the light condition and the camera
types.
3
llllllllllllllllllllll
24
llllllllllllllllllllll
3
llllllllllllllllllllll
120
llllllllllllllllllllll
RET
D&N AUTO
1. D N (CDS)
2. D N (DELAY)
3. N D (CDS)
4. N D (DELAY)
5. RETURN
3
llllllllllllllllllllll
24
llllllllllllllllllllll
3
llllllllllllllllllllll
120
llllllllllllllllllllll
RET
[None LED model] [Built-in LED model]
