room & retreat UMB-879710 Installation guide

9ft Round Market Umbrella
Assembly & Care Instructions
IMPORTANT: RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
Item Number: 4942977,4942978,4942982
Model:UMB-879710
TOLL FREE: 1-855-880-7205
8am - 5pm, Monday through Friday, Eastern Standard Time
Do Not Return To Store
FOR OUTDOOR USE ONLY
Designed in USA
Made in China
For assistance with assembly, parts, or customer service, please call:

2
Contents
Package Contents
Part Description Quantity
A Umbrella Frame with Canopy 1
B Finial 1
C Bottom Pole 1
Please lay out all parts prior to assembly to make sure all parts are present.
A
C
B
Compare carton contents with package contents list. If any part is missing or
damaged, call customer service TOLL FREE at 1-855-880-7205 for replacement parts
or further assistance.
Package Contents
Assembly and Use
Replacement Parts
Care and Maintenance
Warning and Cautions
Warranty
2
3 - 4
5
5
5
6

3
Assembly and Use
Step 1: If not attached, align finial (B) to threading on top of umbrella frame (A) and
turn clockwise (to right) to lock in to place. Do not over-tighten.
Step 2: Slide bottom pole (C) onto umbrella frame (A), while pressing snap button,
until the snap button locks into position.

4
Assembly and Use (cont’d)
Step 3: Turn Crank Handle in clockwise direction (to right) until canopy is fully
opened. Turn Crank Handle in opposite direction to close canopy and secure with
attached strap. Umbrella must not be tilted when closing.
Tilt canopy by pushing Tilt Button on pole while manually leaning top section of
umbrella pole left or right.
Step 4: Insert umbrella into a heavy umbrella base no less than 45lbs (not included).
Tighten locking nut on side of base to safely secure umbrella.

5
Replacement Parts
For replacement parts, call our customer service department at:
1-855-880-7205, 8am - 5pm EST, Monday - Friday.
Part Description Re-order Number
A
Canopy (Laurel Wreath)
Canopy (Cove Stripe)
Canopy (Dock Stripe)
B Finial FNL-38S-REC-BWN,BLK-T
CAN-9M8RBP-T-LW
CAN-9M8RBP-T-CST
CAN-9M8RBP-T-DS
C Bottom Pole
BMP-38SSN-REC-BWN,BLK-T
Care and Maintenance
• Use mild soap and warm water to clean canopy. Rinse with water and dry thoroughly. Do not
machine wash. Do not iron. Air dry the canopy thoroughly before storing for extended periods
of time. Make sure the canopy is completely open during drying process to prevent shrinkage.
• If crank becomes too hard to turn, check to see if rope has slipped off pulley. If you continue
to crank, the rope or crank handle may break. If parts have broken, call customer service, toll
free: 1-855-880-7205 8am-5pm, Monday - Friday, Eastern Standard Time.
• Placement of umbrella over or near a swimming pool will cause premature fading not covered
under our warranty.
Warning and Cautions

6
Warranty
90 DAY WARRANTY
This product is covered under a manufacturer’s 90 day warranty from date of
purchase against defects in materials and workmanship. This warranty does not
cover damage due to neglect, abuse, or weather related damage. For full warranty
disclosure, call customer service toll free at 1-855-880-7205.
NOT COVERED UNDER WARRANTY
This warranty excludes the following: acts of nature (i.e. wind, fire, or freeze);
damage caused by improper assembly, accident, disaster, misuse, abuse, negligence
and discoloration or fading of the finish as a result of exposure to the elements.
Product not intended for commercial use. This warranty gives you specific
legal rights, and you may also have other rights which vary from state to state.

customer service
TOLL FREE: 1-855-880-7205
8am - 5pm, Monday through Friday, Eastern Standard Time
Enjoy!
