GPS Tracking Device
Model NO.: M588L
User Manual
Version ：Rope-E17021301
1. Product Instuction.....................................................................................................................................................2
2.Characteristics……………………………………………………………………………………………………..3
3. Appearance and interface..........................................................................................................................................3
4. Specifications............................................................................................................................................................4
5.Instructions.................................................................................................................................................................5
5.1Security tips .................................................................................................................................................... 5
5.2 Led light and Interface.....................................................................................................................................5
5.3 Installation and setting.....................................................................................................................................6
6.SMS configuration………………………………………………………………………………………………...8
7. Trouble shooting......................................................................................................................................................11

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn

2
1 .Product Instruction
M588L ,a GPS tracker with strong magnetism, is applied to route-controlling, objects-tracking ,financial
security and vehicle-anti-theft and -guarding.
There are built-in terminals of GPS(Global Position System) module and GSM(Global System for Mobile
Communications) module, which send the location data to the specific cell phone by messages. The phone
will show the detailed location or a link used to locate and track by Google Earth and Google Map. Besides,
the GPS data can also be sent by GPRS to our server, with which we can check, guard and manage the
terminal on computer.

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
3
2.Characteristics
1) Synchronized tracking by SMS/GPRS(TCP);
2) Location by GPS +GSM module (LBS);
3) Timely location checking;
4)Fixed-time tracking;
5)Resend data from signal dead zone,(Built-in memory capacity:16M);
6) Mileage report;
7)Remote monitoring ;
8) Support sleep-mode(with built-in vibration sensor) ;
9) Geo-fence alarm ;
10)Low-power alarm ;
11) Over-speed alarm ;
12)Support vibration ;
13) ARM independent processor supports to upload a piece of real-time data every second;
14) Remove alarm .
3.Appearance and interface
USB PORT SIM Card

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
4
4 Specification
Item
Parameters
Work voltage
DC 4.2-5V/500-1000mA (Mini USB)
Built-in battery
Undetachable polymer battery 8000-20000mA(3.7V),optional
Size
125mm*81mm*53mm(16000-20000mA)
Weight
550g(including battery)
Working temperature
-20~55° C
Humidity
5%~95%,non-condensing
GSM module
Quad GSM 850/900/1800/1900Mhz
GPS Chip
Latest GPS U7 Chip
GPS Sensitivity
-159Db
GPS Frequency
L1,1572.42MHz
C/A Code
1.023MHz
Channel
20 channels for tracking
Position Accuracy
10m,2D RMS
Velocity Accuracy
0.1 m/s
Time Accuracy
1 us satellite time synchronization
Default Data
WGS-84
Recover
Average 0.1 s
Hot Start
Average 1 s
Warm Start
Average 38 s
Cold Start
Average 42 s
Height Limit
18,000m,60,000foot max
Velocity Limit
515m/s,1000 mile
Acceleration Limit
Less than 4g
Instant Displacement
20m/s
Touch Detector

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
5
Working Time
1data/per day in 3years in max sleep mode ;working normally for
180days
LED Light
Three LED lights display status of power, GPS and GSM
Power Consumption
Min power consumption is less than 1mA
Button
A blue button for stopping alarm
5. Instruction
5.1 safety instruction
Reading the following safety tips be careful. Incorrect use may cause danger or violate the law.
Safety startup
Don’t use our tracking product at the places of prohibiting to use of
the wireless phone or danger area.
Turn off in the hospital
Follow the rules, close the locator when close to medical equipments.
Turn off on the plane
Follow the rules of airport ,close the locator on the plane.
Turn off when fuel filling
Don’t use the locator at oil station.
Turn off at the blasting site
Follow the rules ,close the locator when working at the blasting site.
Repair methods
only can be maintained and repaired by qualified professional service
personnel
Water proof
The locator is not completely waterproof, don't put it on wet place. If
necessary, please use waterproof bag.
Far away from the
electronic storage devices
As the locator with strong magnetic, can lead to failure of magnetic
storage meduim. don’t close to the u-disk, mobile hard disk, computer
hard disk.
5.2 LED light and interface
M588L has 3 different colors LED lights
Recharge battery light status
The red light turns green
Charged
The red light always keep
on
Charging
Orange light--GPS status
Fast flashing(every 0.1s)
Initialize
Bright 0.1s,dark 2.9s
GPS signal normally
Bright 1s,dark 2s
No GPS signal
Green light-GSM status
Always keep on
Calling or dialing
Fast flashing(every 0.1s)
Initialize
Bright 0.1s ,dark 2.9s
GSM signal normally
Bright 1s,dark 2s
No GSM signal
Other interfaces
Mini USB
Used for charging, set up and upgrade firmware program, use short
USB plug wire for charging, use long for setting and upgrade .
充

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
6
5.3 Installation and Setting
Step 1: Prepare a SIM card
Please ensure that SIM card has enough money and support voice calls and short messages, confirm the lock
code of SIM card had already turnoff. If you want to use the function of receiving position via SMS when you
call, please also confirm that SIM card support caller Identification
Step 2: Charging the tracker
Please charge device at least 8 hours at the first time, the red light is always on when charging, when tracker
finish charging, red light turn off and green light turn on.
Step 3: Insert SIM card
M588L will be auto-power on after you insert SIM card, auto-power off after you take out SIM card. For the
setting of first time, we suggest to power on it at open field in order to help it located quickly.
Step 4: Set up tracker online
●Set device online by SMS Massage:
After create vehicle information on software , if the device SIM card support massage function ,please use the
SMS command to setting device online (as the form show) device is not sleep mode by the factory default ,
the interval time is 30sec .
The GPRS web based tracking platform allows real time tracking with the latest Google maps.
Service platform login website : http://211.154.139.208:8000/webgps/
Vehicle management platform website ：http://211.154.139.208:8000/vms/
After you added device successfully on the VMS platform , you can send the SMS Commands to activate
device
1. Set IP and PORT
SMS command format ：
ss,apn,user_name,user_code,ip,port,system number,password
E.g.:
ss,cmnet, , ,211.154.139.208,7000, 13862626201,123456
Notes:
If no username and password, please leave it blank,

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
7
●Setting online by software tool：
You can also using USB cable and setting software tool to setting device online by computer，software
download line : http://www.myrope.cn/m588l%20tool.exe
After connect M588L to computer, and find the COM port on device manager:
Then using the setting software to set the correct APN ,APN user name ,APN password, IP ,Port, and system
number then click write button:

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
8
6. SMS Configuration
Function
Command
Explanation of command
Reply
Reboot device
restart,password
Eg.:Restart,123456
After receiving this command, the device
will reboot after 1min
Restart OK/Restart
failed
Restore factory
password
ResetPwd
Eg：ResetPwd
The terminal will recover the default
password after you send this command.
Setting password has
been recovered to be
123456
Change
password
pwd,oldpwd,newpwd
Eg：pwd,123456,000000
Change the original password
Config OK/Config
failed
Check GPS
location
tgoogle,password
Eg：tgoogle,123456
Terminal will reply the current location, if
the status of terminal is not locate, it will
reply you the position of last location.
Google map link
When password is
error
Device will
reply :password error！
Please check！
Set up online
command
SS,APN,user_name,use
r_code,IP,PORT,ID,PAS
SWORD
Eg：
SS,CMNET,1,1,174.142.39.183,7000,138
88898788,123456
The length of APN should be in 50
characters, APN user name and password
should be not more than 30 characters.
Config OK/Config
failed
Running state
status,password
Eg：status,123456
Terminal reply: GSM signal strength,
connection and GPRS (GPRS=0 means
disconnected, GPRS=1 means connected),
GPS location satellite number of tracker,
Speed = over speed threshold , speed
threshold (no set speed threshold is 0 , if
you had already set speed threshold, it will
read the number which you had set),
S =device interval time (30s by default)
T = timing sleep mode time
Key means tracker fixed status(on = fixed
off =Shedding) VCC =vehicle voltage
Mode =sleep mode type
(0= non-sleep-mode
GSM=7
GPRS=1
GPS=7
SPEED=0
S=100
T=60
KEY=ON
VCC=3.73
MODE=0
IMEI：
356823031234501
When the password is
wrong, it will reply
as:Get status failed

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
9
1= awake by external interrupt
2= timing wake up status )
IMEI =tracker simcard IMEI number
Check
Parameter
setting
param,password
Eg：param,123456
Reply of terminal: TCP, APN, APN user
name, APN password,IP , port, system
number
TCP，CMNET，1，1，
174.142.39.183，
8880，13188888888，
When the password is
worng, it will reply
as:Get status failed
Monitoring
tap,password
Eg：tap,123456
When you set this command, terminal will
call back to the number which had set this
command, it will go into monitoring mode
after you pick up.
Config OK/ password
error!Please chck!
Set service
number
service,phone1,phone2,
phone3,password
Eg：
service,13800138001,13800138002,13800
238003,123456
When the tracker had triggered SOS after
you set service number, terminal will set
SOS message to service number
SMS format and content of SOS:Your
Vehicle Triggered emergency alarm, now
the location Of the car is
http://maps.google.com/maps?q=latitude,l
ongitude
Config OK/Config
failed
Check service
number
GetService,password
Eg：GetService,123456
If you had already set
service number, it will
content:Service,13512
345001,13512345002,
13512345003
If not set service
number yet, it will
content: Service,,,
When the password is
wrong, it will reply as:
Get status failed
Enable auto
answer call to
AUDIO-EN,password
Eg：AUDIO-EN,123456
After set success, all
the phone numbers

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
10
do voice
monitoring
can monitor tracker
until you send
audio-dis, 123456
command
Disable auto
answer call to
do voice
monitoring
AUDIO-DIS,password
Eg：AUDIO-DIS,123456
Config OK/Config
failed
Restore to
factory setting
Reset,password
Restore to factory
setting
Set GPS
location
uploading
interval time
Interval,x,password
Eg：Interval,30,123456
Interval time is 30s by
defualt setting ,
setting GPRS Time is
30s
Enable
monitoring
limited, only 3
service
numbers can
monitor track
LisLimit,ON,password
LisLimit,ON,123456
Config OK/Config
failed
Disable the
limited of
only service
number can
monitor
LisLimit,OFF,password
LisLimit,OFF,123456
Factory default status
is disable limited
Active sleep
mode
Sleep mode,x,123456
Sleep mode,0,123456
X=0 non-sleep-mode, upload data by
interval time
X=1 not detect shake in 5minutes ,device
will into sleep mode,if detect shake,it will
upload data immediately , and upload data
by interval time in moving status .at the
same time in sleep mode status can use
any SMS or calls to awake tracker
X=2 If the tracker sleeps as the time
interval set by Timing Command, then it
will upload location data as the time
interval set by Interval Command
regardless of moving or not in 5 minutes
after which the sleeping mode ends.
During the sleeping ,the tracker will not
give reaction to all commands from
plarform;and the sms commands sent by
user will be replied only after the tracker
Config OK/Config
failed

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
11
is awake.
During 5 min after waking up,the tracker
can reply to the sms commands and
operation in platform can get response too.
Geo-fence
alarm setting
geo-fence,lati,longti,rad
ius,in,out, password
Eg:
geo-fence,22.58699,113.91573,1000,1,1,
123456
Lati=[-90.000000----90.000000]
Unit= degree
Positive= N
Negative=S
Longti=[-180.000000----180.000000]
Unit= degree
Positive=E
Negative=W
Radius =[1-65536]
Unit = M radius
In= 1or 0 1 drive in alarm, 0 close
alarm
Out=1 or 0 1 drive out alarm, 0 close
alarm
Config OK/Config
failed
Timing wake
up sleep mode
interval time
setting
Timing,X,password
Eg：Timing,600,123456
This sms command only working when
send this command :
sleep mode,2,123456 to set tracker into
the sleep mode 2 status，
600= tracker will in sleep mode every 10
minutes then auto wake up for 5minutes
(5 minutes is by default can customized )
during this 5 minutes, it will upload data
by interval time, it will stop upload data
after 5 minutes,and then go on into sleep
mode for next 10 minutes .
Config OK/Config
failed

ROPE INNOVATION CO., LTD. CONFIDENTIAL NO.：ROPE-15121802
Copyright © 2017 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn
12
7. Troubleshooting
Malfunction: device can not power on
Reason:
Method:
Battery need to charge
Charge device 3 hours
Malfunction: device not reply sms massage
Reason:
Method:
Green light bright 1 second ,dark 2
seconds
Make device connect to network
GSM network busy
Waiting for massage ,GSM network may response late it is busy
or device has malfunction
Device in sleep mode
Cancel sleep mode
Password error or command error
Use correct password and massage command forma
SIM card not enough money
Change SIM card or charging
Malfunction: green light bright 1 s, dark 2 s
Reason:
Method:
Not GSM signal
Use mobile phone to detect if there is network or not ,or calling
device to check if it can communication
Not SIM card
Insert a valid SIM card
SIM card expired
Use mobile phone to check SIM card if it can send massage or
not . if SIM still cannot use ,please change SIM card
SIM card has PIN code
Use phone cancel PIN code
SIM card deformation or damage
Checking SIM card, if reinsert still cannot solve issue , then use
another SIM card
Not support roaming
If you in another area or country ,your SIM card must support
roaming function then can work
Battery used up
Charge device
Malfunction: blue light bright 1 s, dark 2s ,or receive massage start with “Last”
Reason:
Method:
The device location has a shelter
Move device to open field, building , trees will cause GPS signal
weak
GPS signal weak
Make front of device face to sky
Battery used up
Charge device
Malfunction: device cannot via GPRS communication with server
Reason:
Method:
SIM card not support GPRS function
Open GPRS function
GPRS function not activate
Activate GPRS function
IP or port error
Set correct IP and Port
GSM signal weak
Move device to good signal place
