Rosslare AC-015 Manual

AC-015
Single-Door Access Control
Programmer
Hardware Installation and Programming
Manual

Copyright © 2014 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to ROSSLARE
ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’
(hereafter: "ROSSLARE"). Only ROSSLARE and its customers have the right to
use the information.
No part of this manual may be re-produced or transmitted in any form or by any
means, electronic or mechanical, for any purpose, without the express written
permission of ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or
other intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN
THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS
AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND
TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION
MAY RESULT IN LEGAL PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third
party any license to these patents, trademarks, copyrights or other intellectual
property rights, except as expressly provided in any written agreement of
ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time,
without being obliged to announce such revisions or changes beforehand or
after the fact.

Table of Contents
AC-015 Hardware Installation and Programming Manual iii
Table of Contents
1. Introduction ................................................................8
1.1 Key Features ........................................................................... 9
2. Technical Specifications............................................11
2.1 Electrical Characteristics......................................................... 11
2.1.1 Main Unit .....................................................................................11
2.1.2 Outputs ........................................................................................11
2.1.3 Inputs ...........................................................................................11
2.1.4 Indicators and Annunciators .........................................................11
2.2 Environmental Characteristics ................................................ 12
2.3 Mechanical Characteristics..................................................... 12
3. Installation ................................................................13
4. Mounting the Controller...........................................14
5. Wiring ........................................................................16
6. Modes of Operation ..................................................18
6.1 Normal Mode ....................................................................... 18
6.2 Bypass Mode ........................................................................ 19
6.3 Secure Mode ........................................................................ 19
7. Changing the Modes of Operation...........................20
7.1 Changing from Normal to Secure Mode ................................. 20
7.2 Changing from Secure Mode to Normal Mode ....................... 20
7.3 Changing from Normal Mode to Bypass Mode ....................... 21
7.4 Changing from Bypass Mode to Normal Mode ....................... 21
8. Events and Event Actions .........................................22
8.1 Tamper Event........................................................................ 22

Table of Contents
iv AC-015 Hardware Installation and Programming Manual
8.2 Clearing Tamper Events......................................................... 22
9. REX Button ................................................................23
10. Programming Instructions........................................24
10.1 Entering Programming Mode................................................. 25
10.2 Exiting Programming Mode ................................................... 26
10.3 Changing Lock Strike Code 1................................................. 26
10.4 Changing Lock Strike Code 2................................................. 27
10.5 Changing the Programming Code.......................................... 27
10.6 Changing the Normal/Secure Code ........................................ 28
10.7 Changing the Normal/Bypass Code ........................................ 28
10.8 Changing the Fail Safe and Fail Secure Operations, Alarm Sound
Time, and Door Release Time................................................. 29
10.9 Enrolling Proximity Cards/Tags and Keyboard Codes into the
System ................................................................................. 30
10.10 Deleting Proximity Codes....................................................... 32
10.11 Return to Factory Default Settings.......................................... 33
10.12 Changing the Facility Code.................................................... 33
10.13 Replacing a Lost Programming Code ...................................... 34
10.14 Replacing Lost Normal/Secure Code ....................................... 35
A. Limited Warranty ......................................................36

List of Figures
AC-015 Hardware Installation and Programming Manual v
List of Figures
Figure 1: AC-015 Controller Layout.................................................................15
Figure 2: Power Wiring....................................................................................16
Figure 3: Typical Lock and Option Wiring ........................................................16
Figure 4: Reader Wiring ...................................................................................17
Figure 5: Connecting a Controller to a PC .......................................................17

List of Tables
vi AC-015 Hardware Installation and Programming Manual
List of Tables
Table 1: Programming Menu Quick Reference Guide ......................................24

Notice and Disclaimer
AC-015 Hardware Installation and Programming Manual vii
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe and
efficient installation and usage of the system and/or product, and/or software
described herein.
BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND THE
USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY
REQUIREMENTS AND OPERATING PROCEDURES.
The system must not be used for purposes other than those for which it
was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of the
purchase documents.
ROSSLARE exclusive warranty and liability is limited to the warranty and
liability statement provided in an appendix at the end of this document.
This manual describes the maximum configuration of the system with the
maximum number of functions, including future options. Therefore, not all
functions described in this manual may be available in the specific system
and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or any
responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the purpose
of illustration and reference only.
All data contained herein is subject to change without prior notice.
In no event shall manufacturer be liable for any special, direct, indirect,
incidental, consequential, exemplary or punitive damages (including,
without limitation, any and all damages from business interruption, loss of
profits or revenue, cost of capital or loss of use of any property or capital or
injury).
All graphics in this manual are for reference only, some deviation between
the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph or
graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).

Introduction
8 AC-015 Hardware Installation and Programming Manual
1. Introduction
The AC-015 Single-Door Access Control Programmer allows you to
add or delete employees from the system, change system mode status
and change system authorization codes.
The AC-015 provides a higher level of security as the programmer is
normally placed in a secure location while the reader sensor is
remotely located outside the premises to be controlled. Should the
remote sensor be attacked, entry cannot be gained as the remote
sensor only provides data to the programmer, not authorization to
release the controlled door.
The system may be connected with the optional PC monitor program
for easier management of the employee database or for online
monitoring of door access. The system is linked to a PC via RS-232
serial link. The PC receives information from the AC-015, which is
displayed and saved to a database.
Codes entries and their consequences are visible in Online mode of
the software. The Employees menu is used to describe, enter and
associate employee code numbers with employee name and details.
Programming menu is used to define door details, working days and
holiday definitions. Reports menu specifies which kind of report to
build. Options menu is used for communication setup, language
setup, operator’s password and database status. For more details
refer to the AC-015 Monitor Program Manual. The AC-015 accepts
up to 500 employees via the use of proximity cards (provided
separately) or PIN codes into the system. Each employee is issued a
unique proximity card or PIN code.
Employees designated 01 to 10 are Master Users and can operate the
system in both the Normal and Secure modes of operation.
Employees 11 to 500, when entered from the external reader sensor,
may only operate the system in both the Normal and Bypass modes of
operation.
It is very important to keep an accurate record of the slot number and
its assignment to each employee. This is to enable you to add

Introduction
AC-015 Hardware Installation and Programming Manual 9
additional employees at a later time or to delete a proximity or PIN
code if one is lost or stolen. A record form is enclosed for your
reference to assist you with your record keeping.
The AC-015 is capable of learning both PIN codes (keyboard based, 4-
digit codes) and proximity codes (received from proximity card
reader). The system can be connected to up to two reader sensors. An
external reader is to be located outside the restricted area, and it is
always required. The second reader is for internal installation. Readers
need to be a Wiegand 26-Bit interface type, and may be a proximity
card reader (for proximity codes), keyboard (for PIN type codes), or
combined PIN/proximity reader.
A PIN reader, connected to indoor reader input, can perform all the
operations usually performed from the onboard keyboard (depending
on the PIN reader model). A PIN reader connected to an external
reader input will behave similarly, but access level is different on
certain AC-015 status of operation.
1.1 Key Features
RS-232 PC Interface
Multi-language PC software
Supports up to 500 employees
Real-time system monitoring
Supports two Wiegand 26-Bit compatible readers
Three modes of operation
Normal mode
Bypass mode
Secure mode
Lock Strike Relay Output
Request-to-Exit (REX) button
Internal siren
Comes with security screw and security tool
Two status/programming Interface LEDs

Introduction
10 AC-015 Hardware Installation and Programming Manual
Built-in programming keypad
Battery charger
Built-in case tamper
Bell, Chime, and Strobe annunciator
Programmable Lock Strike release time.
Built-in Lock Strike suppressor diode.
Comes with mounting template for easier installation.
Built-in Reader power supply
Built-in Lock Strike power supply

Technical Specifications
AC-015 Hardware Installation and Programming Manual 11
2. Technical Specifications
2.1 Electrical Characteristics
2.1.1 Main Unit
Operating Voltage 16 VAC (1.5 A, 25 VA)
From a transformer
Maximum Input Current
(not including attached
devices)
Standby: 65 mA
Maximum: 120 mA
Battery Charger 12 VDC Lead Acid Battery
Up to 7 AH recommended
2.1.2 Outputs
Lock Strike Relay Output 5 A Relay
Lock Strike Power Supply 12 VDC constant voltage
1.2 A current limit
N.O. or N.C. option
Tamper Relay Output 1 A Relay N.C. Dry Contact
Reader Power Supply Voltage: 12 VDC
Max Current: 300 mA
2.1.3 Inputs
REX N.O. Dry Contact
Two Reader Inputs Wiegand 26-Bit compatible
2.1.4 Indicators and Annunciators
Visual Two tri-colored LEDs
Audio Built-in sounder (bell, chime & siren)
Piezoelectric buzzer

Technical Specifications
12 AC-015 Hardware Installation and Programming Manual
2.2 Environmental Characteristics
Operating Temperature Range -31°C to 63°C (-25°F to 145°F)
Operating Humidity Range 0 to 95% (non-condensing)
2.3 Mechanical Characteristics
Dimensions (L x W x D) 134 x 85 x 30 mm (5.3 x 3.4 x 1.2 in.)
(fits US Gang Box)
Weight 220 g (7.76 oz)

Notice and Disclaimer
AC-015 Hardware Installation and Programming Manual 13
3. Installation
The AC-015 has been designed for easy installation. Only a few steps
are required to install the controller.
In this section you will learn how to mount the controller in your
desired location. You will learn how to wire the controller to its power
source, which includes attaching the controller to a rechargeable Lead
Acid battery.
Wiring diagrams are also provided for attaching the controller to the
REX button, and external Wiegand 26-bit compatible readers. Also
covered in this section is how to wire the AC-015 to a PC.
Topics in this section:
Mounting the Controller
Power Wiring
Typical Lock and Option Wiring
Reader Wiring
Connecting a Controller to a PC

Mounting the Controller
14 AC-015 Hardware Installation and Programming Manual
4. Mounting the Controller
Before starting, select the location for mounting the AC-015
controller. The controller should be installed indoors and within the
premises to be secured. It is recommended that the controller be
installed where it cannot be seen for increased security, but still close
enough to the doors so that the controller’s annunciator (Door Bell,
Chime & Siren) can be heard. When selecting a location, take into
consideration how the controller will be attached to a PC for easier
programming and system maintenance.
To mount the controller:
If you are attaching the AC-015 to a US Gang Box, skip to
Step 2.
1. Find the mounting template label that is provided in your AC-015
packaging, and place it at the location that you wish to install the
controller. The template is designed to assist you through the
mounting procedure, showing you where you drill holes in the
wall to pass the wiring through and where the wall must be
drilled to insert the controllers mounting screws.
2. Drill a hole for cables as indicated on the wiring template. Two
hole sizes are shown to allow for the amount of cables needed,
depending on installation requirements or adding a backup
battery. Drill two screw holes for mounting the AC-015 to the
wall.
3. Remove the case screw from the controller (see Figure 1) and
remove the front case from the controller.

Mounting the Controller
AC-015 Hardware Installation and Programming Manual 15
Figure 1: AC-015 Controller Layout
4. Mount the controller to the wall using the two screws provided in
the Installation Kit or use the screws provided with your US Gang
Box when mounting to a US Gang Box.
5. Wire the controller according to the diagrams on the next few
pages.
6. Return and secure the front case using the security screw and
security tool provided in the installation kit.
You now have mechanically installed the controller.
Door LED
Mode LED
3x4 Matrix
Keypad
Bell Button
Case Screw

Wiring
16 AC-015 Hardware Installation and Programming Manual
5. Wiring
The following figures show various wiring scenarios.
Figure 2: Power Wiring
0
8
5
21
4 6
3
97
#
MODE DO OR
POWER SUPPLY
FROM
TRANSFORMER
16V AC (1.5A, 25VA)
(+)
(-)
12V DC LEAD ACID
BATTERY
UP TO 7 AH
RECOMMENDED
(+)
(-)
Figure 3: Typical Lock and Option Wiring
0
8
5
21
4 6
3
9
7
#
MODE DOOR
REX
(-)
N.O.
Common
N.C.
N.C.

Wiring
AC-015 Hardware Installation and Programming Manual 17
Figure 4: Reader Wiring
0
8
5
21
4 6
3
9
7
#
MODE DOOR
IN
READER
OUT
READER
+12V
(-)
DO
D1
+12V
(-)
DO
D1
+V
(-)
DO
D1
12V DC, Max. 300mA
12V DC, Max. 300mA
Figure 5: Connecting a Controller to a PC
0
8
5
21
4 6
3
97
#
MODE D OOR
TxD
(-)
To PC Serial Port
(COM Port)

Modes of Operation
18 AC-015 Hardware Installation and Programming Manual
6. Modes of Operation
The AC-015 has three modes of operation:
Normal Mode
Bypass Mode
Secure Mode
The three modes provide different levels of security.
6.1 Normal Mode
The Mode LED is green.
In this mode, the controller is in the normal level of security. Only
those codes that the controller recognizes activate the Lock
Strike.
The controller’s keypad is used for programming, changing
modes of operation, and activating the Lock Strike using the
employee codes.
The Lock Strike remains active according to the programmed
Release Time.
In addition, it is possible to activate the Lock Strike in the
following ways:
Pressing the REX button
Entering a valid code (from an outside reader only using a
proximity code or a PIN code)
Mode
Door
Green

Modes of Operation
AC-015 Hardware Installation and Programming Manual 19
6.2 Bypass Mode
The Mode LED is orange.
In this mode the controller is in the lowest level of security.
The Controller’s keypad is used for changing modes of operation
and activating the Lock Strike by the employee codes or by
pressing *.
The Lock Strike remains active according to the programmed
Release Time.
If the Lock Strike is defined as Normally Closed, it is always active.
If the Lock Strike is defined as Normally Open, it can be activated
in the following ways:
Pressing the REX button
Entering a valid code (from an outside reader only using a
proximity code or a PIN code)
6.3 Secure Mode
The Mode LED is red.
In this mode, the controller is in the highest level of security.
The controller’s keypad is used for changing modes of operation
and activating the Lock Strike by the employee codes.
The Lock Strike remains active according to the programmed
Release Time.
In addition, it is possible to activate the Lock Strike in the
following ways:
Pressing the REX button
Entering Master codes (from an outside reader only using a
proximity code or a PIN code)
Mode
Door
Orange
Mode
Door
Red

Changing the Modes of Operation
20 AC-015 Hardware Installation and Programming Manual
7. Changing the Modes of
Operation
7.1 Changing from Normal to Secure Mode
The default factory setting for the Normal/Secure code is 3838.
To change from Normal mode toSecure mode:
1. Enter the 4-digit Normal/Secure code.
Mode LED flashes red.
2. Press #to confirm the mode change.
The Mode LED turns red.
7.2 Changing from Secure Mode to Normal
Mode
The default factory setting for the Normal/Secure code is 3838.
To change from Secure mode to Normal mode:
1. Enter the 4-digit Normal/Secure code.
Mode LED flashes green.
2. Press #to confirm the mode change.
The Mode LED turns green.
Mode
Door
Green
Mode
Door
Red
Mode
Door
Red
Mode
Door
Red
Mode
Door
Green
Mode
Door
Green
