Rosslare Mifare CP-R25 Mounting instructions

CP-R25 & AS-B01
Desktop MIFARE and fingerprint card programmer
and Software
Hardware & Software Manual
November 2009

Table of Contents
CP-R25 Hardware & Software Manual Page ii
Table of Contents
1. Introduction............................................................................... 4
1.1 The CP-R25 System .............................................................4
1.2 Desktop Convenience........................................................4
1.3 Intuitive Software System.....................................................5
1.4 Compatibility ......................................................................5
1.5 Main Features.....................................................................5
1.6 CP-R25 Desktop Programmer .............................................5
1.7 AS-B01 Software..................................................................6
2. Specifications and Requirements
............................................. 7
2.1 CP-R25 Hardware Specifications.........................................7
2.2 AS-B01 Software Requirements ...........................................8
3. Installation................................................................................. 9
3.1 Unpacking the Equipment..................................................9
3.2 CP-R25 Description.............................................................9
3.3 AS-B01 Software Installation...............................................10
3.4 CP-R25 Hardware Installation............................................13
4. AS-B01 Software Overview and LEDs
...................................16
4.1 Starting the Software .........................................................16
4.2 Software Overview ............................................................17
4.3 Indication LED’s:................................................................18
5. Programming Cards and Tags................................................20
5.1 Programming Configuration Cards...................................21
5.2 Sector Reader Configuration Cards 22
5.3 Fingerprint Swipe Reader Configuration Cards 23
5.4 Programming User Cards or Tags......................................24
5.5 Programming a Sector Read User Card 25
5.6 Programming and Enrolling Fingerprint User Card 26
6. Additional Programmer Utilities............................................29
6.1 Card Utilities ......................................................................29
6.2 Reading a Configuration Card 29
6.3 Reading an ID from a User Card 30
6.4 Programming a User Card ID 30
6.5 Changing the User Card KeyA in a specific Sector 31
6.6 Changing KeyA and Erasing All Data 32

Table of Contents
CP-R25 Hardware & Software ManualPage iii
6.7 Erasing Specific User Card Data 32
6.8 Read Serial number and Card Type 33
6.9 Fingerprint Utilities..............................................................34
6.10Enrolling Fingerprints on a Preconfigured User Card 34
6.11Verifying fingerprint enrollment on a User Card 35
7. Global Options .........................................................................36
7.1 Change Password.............................................................36
7.2 Card Overwrite..................................................................37
Appendix A. Maintenance..........................................................38
Appendix B. Field Descriptions .................................................41
Appendix C. Additional MIFARE Card Memory Map
Information ................................................................................44
Appendix D. Sample Worksheets...............................................46
Appendix E. Limited Warranty
.................................................47
Appendix F. Technical Support.................................................49

Introduction
CP-R25 Hardware & Software Manual Page 4
1. Introduction
Rosslare's CP-R25 is a desktop MIFARE and fingerprint card
programmer for MIFARE 1 and 4 K RFID proximity cards and
tags.
The CP-R25 makes managing fingerprint and MIFARE cards
easier and can help facilitate the effective deployment and
control of any facility code application, including access
control, intrusion, time and attendance applications.
1.1 The CP-R25 System
The CP-R25 is built for high-security, portability and ease of use,
enabling high quality MIFARE and fingerprint enrollment at a
low cost.
The CP-R25 programmer is controlled by computer using
Rosslare's powerful AS-B01 Programmer software package.
1.2 Desktop Convenience
The CP-R25 is small and lightweight, with a slim and attractive
design. It is built for convenience and portability, with a USB 2.0
computer interface that makes it quick to install and allows it
to run without any additional power source.
Figure 1: The CP-R25
Designed to sit safely on any desktop, the CP-R25 is sturdily
built, with large card and fingerprint trays and surface-gripping
rubber feet.

Introduction
CP-R25 Hardware & Software ManualPage 5
1.3 Intuitive Software System
The AS-B01 is a software application intended for programming
MIFARE cards, tags and fingerprints using Rosslare's CP-R25
Desktop Programmer.
The system includes a security authentication system and a
real-time operations log.
Using this tool requires basic understanding of MIFARE cards
memory architecture and access condition mechanisms.
The software does not support all MIFARE cards features
required by the systems using the CP-R25 programmed MIFARE
cards.
1.4 Compatibility
The CP-R25 Desktop Programmer and AS-B01 software are
compatible with other products, including but not limited to:
•AY-W6260 and AY-W6360 Read-Sector, smart card, read-
write access control reader family
•AY-Q6260 and AY-Q6360 Anti-vandal, read-sector, smart
card, read-write access control reader family
•AY-Bx663 (X=1,3,4) MIFARE Smart Card Fingerprint Swipe
Sensor Family
1.5 Main Features
The CP-R25 Desktop Programmer is a feature-rich MIFARE card
programmer and fingerprint enroller.
1.6 CP-R25 Desktop Programmer
•Enables the user to read, verify and program MIFARE
proximity cards
•Uses a swipe type fingerprint sensor
•Supports USB 2.0 computer connections
•Utilizes LED and buzzer sub-systems to indicate
programming, card and power supply status

Introduction
CP-R25 Hardware & Software Manual Page 6
•Runs a thorough internal diagnostic self-test every time it is
powered up
1.7 AS-B01 Software
•Programs fingerprints on Users cards
•Programs ID data on Users cards
•Produces configuration cards for Rosslare MIFARE readers
•Performs firmware updates on supported desktop
programmers
•Maintains a user log to provide feedback to the software
user
•Provides password protection
•Indicates valid connections with Desktop Programmer

Specifications and Requirements
CP-R25 Hardware & Software ManualPage 7
2. Specifications and Requirements
2.1 CP-R25 Hardware Specifications
Data Specifications
Cards MIFARE Classic 1K and 4K
RF Frequency 13.56MHz
Bit rate 106KHz
Fingerprint Reader Specifications
Sensor type Swipe type UPEK TCS4C-TCD50A
Sensor ESD Rating Sensor technology – Capacitive sensor
Electrostatic
Discharge: Up to +/- 15 kV air dischar
g
e on the sensor
surface
FAR - False Accept
Rate Actual values depends on specific user's
finger, usage condition and quality of
enrollment.
Specification – 0.0010% (1/100000)
FRR – False Reject
Rate Actual values depends on specific user's
finger, usage condition and quality of
enrollment.
Specification – 2% (1/50)
Electrical Specifications
Operating Voltage 5V DC Via USB
Input Current 75mA (standby)
160mA (maximum)
CP-R25 Physical Specifications
Dimensions
(L x W x H) 17.3x5.8x3.3 cm
6.18x2.28x1.30 inch
Weight 309g (10.89 oz)

Specifications and Requirements
CP-R25 Hardware & Software Manual Page 8
Environmental Data
Operating
Temperature 10º to 50º C
(50º to 122º F)
Operating Humidity 0 - 95% (non condensing)
2.2 AS-B01 Software Requirements
Minimum Software Requirements
Operating System Windows XP SP2
Framework Microsoft .NET 2
Processor 400MHz Pentium or equivalent
RAM Memory 512 Mbytes
Free HD space: 1 Gigabyte
Connection Port USB

Installation
CP-R25 Hardware & Software ManualPage 9
3. Installation
3.1 Unpacking the Equipment
The CP-R25 programmer is ready to use immediately "out of the
box" and includes a USB cable and documentation.
Please confirm all the items listed below are received before
beginning. If any items are missing, contact your dealer
immediately.
•One CP-R25 Programmer
•One Male A to Male B USB Cable
•One Software CD
•Instruction Manual
3.2 CP-R25 Description
The following figure illustrates the CP-R25 components:
Figure 2: CP-R25 Description

Installation
CP-R25 Hardware & Software Manual Page 10
3.3 AS-B01 Software Installation
The AS-B01 software is included on the installation CD-ROM
which is packaged with the CP-R25 hardware.
To install the AS-B01 software for the first time:
1. Insert the CD into the computer's CD drive.
2. If the Autoloader does not initiate the installation, open My
Computer, double-click on the CD drive icon and then
double-click the AS-B01 setup file.
Note:
If the Microsoft .NET 2 Framework is not installed on the
computer, it will be installed automatically before
beginning the AS-B01 installation.
The installation package extracts the installation files. After
the files are extracted the "Welcome to the CP-R25 Setup
Wizard" window is displayed.
Figure 3: AS-B01 Setup – Welcome Screen
3. Click Next to continue the installation process. The Select
Installation Folder window is displayed.

Installation
CP-R25 Hardware & Software ManualPage 11
Figure 4: AS-B01 Setup – Select Installation Folder
4. Select the folder to install the software. In the Folder field
the Rosslare default location is displayed. If another
location is required click Browse. The standard Windows
Explorer window is displayed. Navigate to and select the
required folder.
To ensure the computer has sufficient space click Disk
Cost…. The AS-B01 Setup Disk Space window is displayed.
Figure 5: ASB01 Setup – Disk Space Availability
To close the AS-B01 Setup Disk Space window click OK.
5. Select the users allowed to use the program, Everyone or
Just me. For security purposes it is suggested that Just me is
selected.

Installation
CP-R25 Hardware & Software Manual Page 12
6. Click Next to continue the installation process. The Confirm
Installation window is displayed.
Figure 6: ASB01 Setup – Confirm Installation
7. Click Next to continue the installation process. The
Installation Complete window is displayed.
Figure 7: ASB01 Setup – Installation Complete
8. Click Close to complete the installation process.

Installation
CP-R25 Hardware & Software ManualPage 13
3.4 CP-R25 Hardware Installation
The CP-R25 does not require special installation; follow the
following steps to prepare the unit for enrollment.
Note:
Before connecting the CP-R25 hardware ensure that the
ASB01 software is installed.
Connecting the CP-R25 requires two steps. First the AS-B01
software must be operating, and then the CP-R25 can be
connected.
To connect the CP-R25:
1. Click on the AS-B01 icon on the desktop, or select the
program from the Rosslare folder in the "Start" menu. The
Login dialog is displayed.
Figure 8: AS-B01 Login Dialog
2. Enter a password. The default password is "admin". The AS-
B01 software Main window is displayed. Make sure to
change the default password after the first time the
software is activated to the company approved secret
password. The Main window is displayed.

Installation
CP-R25 Hardware & Software Manual Page 14
Figure 9: AS-B01 – Main Window
At the bottom left of the Main window the CP-R25
connection indication is red with the description
Disconnected.
3. Connect the Desktop Programmer to a PC using the USB
cable.
One cable end connects to PC USB host port output and
the other end connects to the USB connector on the
Desktop Programmer.
4. Windows®automatically installs the required drivers.
5. The Desktop Programmer receives its power through the
USB. No external power supply is required.
On the AS-B01 Main window the connection indicator at
the bottom of the window changes from red to green with
the description Connected indicating the CP-R25 Desktop
Programmer is connected.

Installation
CP-R25 Hardware & Software ManualPage 15
Figure 10: AS-B01 Connectivity – Connected
The event log displays a connected message.
When the hardware and software are disconnected the
connectivity icon is Red and the event log displays a
disconnected message. The Software can only function in
demonstration mode.
If the indicator does not turn green, and the description still
indicates Disconnected after the USB cable is connected,
try disconnecting the USB cable from the Desktop
Programmer and reconnecting it.
Once the indicator is green and the description is
Connected the CP-R25 Desktop Programmer is now ready
for use.

AS-B01 Software Overview and LEDs
CP-R25 Hardware & Software Manual Page 16
4. AS-B01 Software Overview and LEDs
This section explains how to start the software and login to the
main window as well as describe the AS-B01 and CP-R25 LEDs.
4.1 Starting the Software
To start the software:
1. Click on the AS-B01 icon on the desktop, or select the
program from the Rosslare folder in the "Start" menu. The
Login dialog is displayed.
Figure 11: AS-B01 Login Dialog
2. Enter a password. The default password is "admin". The AS-
B01 software Main window is displayed.
Figure 12: AS-B01 – Main Window

AS-B01 Software Overview and LEDs
CP-R25 Hardware & Software ManualPage 17
4.2 Software Overview
Once the log-in is completed with the correct password, the
main software window is displayed.
Figure 13: AS-B01 – Main Window Layout
The AS-B01 Main window has the following functional areas:
•File menu area – used for general operations such as
setting global options on the Desktop Programmer, getting
version information and closing the software.
•Configuration Tab area – the main working area. All card
and swipe configuration parameters are entered and
displayed.
Note:
Descriptions for fields requiring parameters under all the tabs
are described in Appendix A.
•There are two programming tabs:
Sector reader – Used to configure and read sector
reader cards. This tab allows configuration of both

AS-B01 Software Overview and LEDs
CP-R25 Hardware & Software Manual Page 18
User ID/Card Serial number user cards as well as
Reader configuration cards.
Swipe reader – Used to write and read cards
containing fingerprint templates. This tab also allows
the creation of configuration cards for fingerprint
readers.
•Message log area – this event log records all activities
provides the user with real time system monitoring. The
information messages may either be operation success or
failure messages, or instruction messages for example
during fingerprints enrollment.
•Status information area – indicates connection status with
the CP-R25 Desktop Programmer hardware.
4.3 Indication LED’s:
The following table describes LED behavior on the CP-R25
Programmer (see Figure 2: CP-R25 Description).
General
Event Swipe Card
Reader LED Fingerprint Reader
LED
Buzzer Fingerprint
Directional
Indication
LED
Power
on One red LED will light for several seconds followed by all the LEDs flashing and the buzzer beeps 3 times for the duration
of 3 seconds each time
Card Programming
Event Swipe Card
Reader LED Fingerprint Reader
LED
Buzzer Fingerprint
Directional
Indication
LED
Card not
loaded Green flashing All off Off All on

AS-B01 Software Overview and LEDs
CP-R25 Hardware & Software ManualPage 19
Card Programming
Event Swipe Card
Reader LED Fingerprint Reader
LED
Buzzer Fingerprint
Directional
Indication
LED
Card
loaded On card detection
g
reen
turns on for 1
second, then off
All off On card
detection
short beep,
then off
All on
Write
card
success
Green on for 3
sec All off 3 High tone beeps All on
Write
card fail Red on for 3 seconds All off Short buzz All on
Fingerprint Scanning
Event Swipe Card
Reader LED Fingerprint Reader
LED
Buzzer Fingerprint
Directional
Indication LED
Waiting for
fingerprint Off Green flashing Off Rolling LEDs in circular mode
to indicate
finger swipe
Read
fingerprint
success
Off Green on
for 3 sec 3 High tone beeps Rolling LEDs in circular mode
to indicate
finger swipe
Read
fingerprint
fail
Off Red on for
3 sec Short buzz Turning all LEDs on, and then
according to
status, leaving
all on or going
back to
circular mode
Read finger timeout – when no finger is passed over the
scanner for 30 seconds, the CP-R25 Desktop Programmer goes
back to standby mode of swipe LEDs.
