ROT SERVICE WIKING User manual

WIKING
width 8m, side height 4m
INSTALLATION INSTRUCTIONS
Introduction
Thanks to the new tent, you have the freedom to plan many activities. It can be used during the event, as protection against
the sun, light, storage and for many other purposes. Please follow the instructions below. This will allow you to use our tent
longer.
Important
Before using the tent, please read the assembly instructions carefully and store it for future reference.
Security
The tent has not been tested for wind and snow loads unless there is a clear indication from the manufacturer. Therefore, these
charges are not covered by the warranty. Please observe the weather forecasts in order to secure the tent or disassemble it if
necessary.

Warnings
The tents are intended for temporary use and should be dismantled in case of unfavorable weather conditions. Position the
tent at a suitable distance from water, gas and electric hoses, so as not to damage them. Please find out from local suppliers,
where all the cables run, so as not to damage them when mounting the tent.
If you use the right heaters (ask for advice from the seller), set them at a distance of not less than 1.2 meters from the tarpau-
lin. Under no circumstances should open fire or heaters with an open flame, such as heating umbrellas, garden radiators, gas
heaters, etc. be used. The person setting up the tent is responsible for its proper attachment to the ground, and thus for safety.
Regularly check the fixing of the tent to the ground to ensure the safety of the tent, avoid its damage and protect other users.
The correct attachment of the tent to the ground extends the durability of its components and the construction of the tent
as a whole.
When mounting the tent, you should wear a helmet, gloves and stable shoes. Heavy metal parts can have sharp edges, and
anti-corrosion protection means they can be slippery. During snowfall, regularly remove the snow from the tarpaulin regularly
and quickly. The same applies to heavy rainfall and tarpaulin load of other materials. Children should not play with the spare
parts of the tent. These elements should be properly protected.
Warning!
To set up a tent, please find a flat and even area. Please use only the materials provided with the tent. Please pay attention to
whether the ground is suitable for your intended purpose. The tent is also suitable for light frost. However, the tarpaulins must
have been stored for a long time at a temperature of at least 10 ° C and developed at this or higher temperature. Otherwise,
the bending locations may crack. Rubber petellas belong to consumable parts. If material is used, it must be replaced. In each
country, separate regulations apply to mobile buildings (tents) and immovable buildings. Local authorities need to find out
whether the pitching of the tent requires a permit. The size of the tent determines this in some countries. Tarpaulins should
not come into contact with any objects with sharp edges.
Before the first use
Please unpack the cartons and check on the basis of the attached loading list that all parts have been delivered.
The metal parts were covered by the manufacturer with a thin layer of grease. It may happen that there are too many parts of
the grease. In this case, remove excess grease with a cloth. We apologize for this inconvenience.
The first assembly should be reserved a little more time. The rules for pitching a tent are simple. Please help me with the dra-
wing instructions of the individual assembly steps. Screw connections of pipes with connectors should be made by hand with
an allen wrench or an automatic screwdriver set up to level 2 to avoid material wear.
Cleaning and storage
To clean the planes, please do not use aggressive cleaning agents. The best for this is water with a slight alkaline reaction.
The tent can not be folded and packed when it is damp. First, dry it thoroughly. It is not allowed to make any changes to the
structure of the metal tent, eg attach and / or weld additional loads, groove grooves and / or make other distortions. Please,
carefully handle the individual elements of the tent. When dismantling, please re-use the loading list and check completeness
to avoid problems during the next assembly.
When storing the tent in a dry place, do not put any other objects on it.
Environmental Protection
At the end of the period of use, please do not throw the tent or its elements into ordinary garbage, but subject it to the prescri-
bed recycling. If in doubt, please contact the manufacturer or an authorized representative. We are happy to help you properly
dispose of the tent, thus contributing to the protection of the environment.

12
3
5
7
9
11
13
15
4
6
8
10
12
14
16
8x12 8x20
22 szt 34 szt
8x12 8x20
22 szt 34 szt
8x12 8x20
11 szt 17 szt
8x12 8x20
2 szt 2 szt
8x12 8x20
11 szt 17 szt
8x12 8x20
22 szt 34 szt
8x12 8x20
11 szt 17 szt
8x12 8x20
22 szt 34 szt
8x12 8x20
22 szt 34 szt
8x12 8x20
117 szt 195 szt
8x12 8x20
13 szt 13 szt
8x12 8x20
20 szt 32 szt
8x12 8x20
4 szt 4 szt
8x12 8x20
4 szt 4 szt
8x12 8x20
20 szt 32 szt
8x12 8x20
4 szt 4 szt
End side pipe, 1219 mm
Leg extension, 1720 mm
Roof pipe, 1545 mm Roof pipe with a hole, 1545 mm
Lower gate leg, 1720 mm
Lower leg, 1720 mm
Roof bracket, 1820 mm
Diagonal bracket
Vertical gate bracket, 674 mm
Roof bracket, 1818 mm
Diagonal bracket
Gable arch, 1122 mm
Side arch
CONTENT
Side pipe, 1262 mm
Middle gate leg, 1720 mm Upper gate leg, 1420 mm

17
19
21
23
25
27
29
31
18
20
22
24
26
28
30
32
8x12 8x20
2 szt 2 szt
8x12 8x20
20 szt 32 szt
8x12 8x20
8 szt 16 szt
8x12 8x20
18 szt 30 szt
8x12 8x20
120 szt 120 szt
8x12 8x20
74 szt 102 szt
8x12 8x20
121 szt 169 szt
8x12 8x20
307 szt 451 szt
8x12 8x20
12 szt 12 szt
8x12 8x20
2 szt 2 szt
8x12 8x20
4 szt 4 szt
8x12 8x20
4 szt 4 szt
8x12 8x20
4 szt 4 szt
8x12 8x20
52 szt 76 szt
8x12 8x20
38 szt 56 szt
8x12 8x20
148 szt 226 szt
CONTENT
Corner foot Foot
Steel pins 8x300 mm
Screw 2.4”
Wings nuts
Fastening rubbers
Gate brackets, 1948 mm
Gate foot
Gate connector
Steel pins 6x220 mm
Screw 1.75”
Screw 4.8”
Extraction pipe
Bracing strings
Gate roof bracket, 2093 mm
Gate roof bracket, 2090 mm

33
35
37
39
34
36
38
40
8x12 8x20
20 szt 32 szt
8x12 8x20
2 szt 2 szt
8x12 8x20
26 szt 26 szt
8x12 8x20
20 szt 32 szt
8x12 8x20
4 szt 4 szt
8x12 8x20
1 szt 1 szt
8x12 8x20
26 szt 38 szt
8x12 8x20
10 szt 16 szt
CONTENT
Belt with a drawstring
Gates
Plastic cap 32 mm
Dowels for pipe clamp
Ratchet tensioner
Tarpaulin
Ground anchor
Pipe clamp for fastening

1 1
3
4 4
3
5 6
1,2 m
2
1
2
INSTALLATION INSTRUCTIONS
Find a flat surface to pitch your tent. Unpack the cartons and make sure they contain all of the items listed.
Before starting the assembly, wipe off light traces of oil from the structure pipes with a cloth. At lower temperatures we recommend
warming the tent tarpaulin to room temperature. When assembling the tent, make sure that all wing nuts are attached to the inside of
the tent.
Assemble the roof frame.
Connect one gable arch (2) with roof pipes (3) and (4). Attach side arches (1) to the ends of the roof pipes (4). Then
use the 1.75 ”screws (29) and wings nuts (32) to connect the roof supports (5 and 6) together. Secure the roof
supports to the roof pipes (3). Use 2.4 ”(30) screws and wing nuts (32) for this.
Steps described in point 1
repeat for subsequent arches
and put them on the ground
as shown
in the picture.

2a
3
11
11
11
11
11
11
11
11
11
11
11
11 11 11 11 11
10
10
10
10
10
10
38
7
18 19
11 11
22 22
22 22
11
11
11 11 11 11
10
11
11 11
31 38 32
INSTALLATION INSTRUCTIONS
Connect the additional gate roof bracket (18) and (19) to the start sections (on both sides)
and connect it in the middle with vertical reinforcement of the gate (7) with the top of the arch.
Then, connect the arches with each other using the side pipes (10) and (11). Only 10 pipes are mounted in the
front segment, all others are 11. Use 4.8 ”screws (31) and wings nuts (32) for fixing.
Apply the plastic end caps (38) to the end pipes 10 and 11. Use the string (22) to strengthen the frame.

4
1
8
8
8
8
999
9
11 11
11 11
11 11
10
10
10
12
12
13
13
INSTALLATION INSTRUCTIONS
Set up the tent from one side.
Connect the side bends (1) with the legs (8) and (9).
Use 4.5 ”screws (31) and wings nuts (32) for fixing.
Strengthen the frame with side
pipes (10) and (11).
Attach the diagonal brackets
(12) and (13) to the side legs.
Use for fastening
4.5“screws (31)
and wings nuts (32).

8
8
8
8
8
8
9
9
9
9
9
9
11
11
11
11
11
11
10
10
10
12
12 13
13
1
5
INSTALLATION INSTRUCTIONS
Anagolically to point 4, we proceed with the other side of the structure.

6
14
17
17
17
17
17
17
14
15 15
16 16
21
21
INSTALLATION INSTRUCTIONS
Gates assembly.
Assemble the gate legs (14),
(15) and (16) and connect
them to the first arch using the
gate connector (21).
Similarly, assemble the gate on the other side of the tent.
Then install the gate brackets
(17).
Remember to fix the fixing screws inside the tent so that their tips do not rub and tear the tarpaulin.

7
25 25
23 23
24 24 24 24 24 24 24 24 24
39
INSTALLATION INSTRUCTIONS
Install the gate feet (25), corner feet (23) and other feet (24),
first on one side, then on the other side of the structure. Use 4.5 ”screws (31) with nuts (32).
Setting the structure on the feet.
Use the clamping pipe clamp (39) and dowels (40) to mount the frame to the ground.
The feet are attached to the ground with an anchor (37), driven it next to the foot and
connected with a pin (27).

8
20
34
INSTALLATION INSTRUCTIONS
Install the gates (36)
using the rubbers (26).
Tighten the roof trim
using a tensioner
with ratchet (33).
Tarpaulin assembly.
Unfold the tent tarpaulin (35). Insert the fastening strip (20) into the tarpaulin sleeve on both sides from the inside
tent in the place of fastening of stupas, cut the sleeve and with a drawstring strap (34) hook the pipe from the
sleeve (the tarpaulin is stretched after the whole tent has been installed, we stretch it slightly).
Warning! when during
tilt use up the tension does not
tighten the belts too much -
after falling tilt temperature
will shrink back.
